UseandCare& Installation Guide
Operating Instructions, Tips
Canning.............................................................3
Controls.............................................................3
Cooking Tips ....................................................3
Blower ...............................................................4
Grease Filter .....................................................4
GE Appliances
Downdraft Vent System
.........................2
.................................4
More questions ?...call
.....................................5-11
Ductwork Table...............................................8
Plan Ductwork.................................................8
Plan Wiring.......................................................9
Install Ductwork ...........................................10
Install Wiring .................................................10
Consumer Services
Warranty ........................................Back Cover
Models: JVB34
JVB65
JVB35
JVB93
JVB64
JVB96
Advertisement
Table of Contents
Related Manuals for GE JVB34
Summary of Contents for GE JVB34
-
Page 1: Table Of Contents
Care and Cleaning Blower ...4 Grease Filter ...4 GE Appliances Downdraft Vent System Problem Solver ...2 More questions ?…call GE Answer Center® 800.626.2000 Installation Ductwork Table...8 Plan Ductwork...8 Plan Wiring...9 Install Ductwork ...10 Install Wiring ...10 Consumer Services Warranty ...Back Cover Models: JVB34 ...4... -
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Read and save these instructions. WARNING—TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: A. Use this unit only in the manner intended by the manufacturer. If you have questions, contact the manufacturer. -
Page 3: Canning
Reverse the steps in the Install the Downdraft section to remove the downdraft from the cabinet. Service parts are available from your local GE distributor or from a GE Service and Parts Center. Turn the downdraft blower OFF by pressing the activating switch again. -
Page 4: Care And Cleaning
5. Reconnect the power supply. USE THIS PROBLEM SOLVER PROBLEM FAN DOES NOT WORK If you need more help…call toll free: GE Answer Center ® 800.626.2000 consumer information service CARE AND CLEANING NOTE: The filters are different sizes. Be sure to replace them with the longer filter on the left. -
Page 5: Installation Instructions
This downdraft blower system is designed to be used to exhaust smoke and odors when cooking with all GE electric and sealed burner gas cooktops (not approved for standard burner gas cooktops). It can be mounted in either an island or peninsula location. - Page 6 JP345 29-3/8 20-1/2 JP347 JP392 20-3/4 JP393 JGP330 JGP331 JGP334 *Required to maintain UL or AGA approvals. JVB34, JVB35, JVB93 B&C (Figure 1) (Figure 3*) (Figure 2) Min. Setback— Depth Front Edge Min. Req’d. Cktop + Cntrtop to Front Inside Cabinet D.D.
- Page 7 36 COOKTOPS/DOWNDRAFT UNITS Figure 1 Overall Cooktop Dimensions Figure 2 Overall Cutout Dimensions NOTE: AGAINST-THE-WALL INSTALLATIONS ARE LIMITED DUE TO DIMENSION REQUIREMENTS. REFER TO DETAILS BELOW. PLANNING INSTALLATION (Note: 26 deep cabinets required) (Figure 1) (Figure 1) (Figure 1) Cooktop Cooktop Overall Overall...
-
Page 8: Ductwork Table
*Equivalent lengths of duct pieces are based on actual tests conducted by 7 ft. GE Evaluation Engineering and reflect requirements for good venting performance with a downdraft rated at 500 CFM. ( ___ in. offset) x (14 Ft. per inch) = ___ Ft. -
Page 9: Plan Wiring
Plan the Wiring 1. The downdraft blower system draws 4 AMPS and requires a 120 VAC, 60 Hz circuit. 2. The unit has a 2 ft. long power cord with a 3-pronged plug. Plan to provide a grounded outlet in a location which will allow the unit’s power cord to reach. -
Page 10: Install Ductwork
INSTALLATION INSTRUCTIONS Install the Downdraft Mounting screws Leveling bracket– flange facing out Leveling bracket– flange facing in 1. Set the downdraft into the opening. Extend the leveling brackets to the floor of the cabinet so the downdraft sits straight. (NOTE: Leveling brackets can be removed and re-attached in other positions. - Page 11 Install the Cooktop 1. Align the cooktop with the downdraft and fasten cooktop in place. NOTE: Accurate alignment of cooktop and downdraft is necessary to ensure that there is not interference when air vent is raised and lowered. There should be a gap of 1/32 –1/16 between the back of the cooktop and the front of the downdraft cover.
-
Page 12: Ge Answer Center® 800.626.2000
To know what your legal rights are in your state, consult your local or state consumer affairs office or your state’s Attorney General. If further help is needed concerning this warranty, write: Manager—Consumer Affairs, GE Appliances, Louisville, KY 40225 Part No. 164D3333P139 Pub No.
