Bosch D202A Series Technical Specifications

Intrusion Alarm Systems | D202A Series Vertical LED Keypads
D202A Series Vertical LED Keypads
www.boschsecurity.com
The D202A Series Keypads have displays that are
strategically placed, easy to read, and bright enough to
be visible from a distance. A pull-up reference card
and labeled keypad provide the user with a quick
reference to features and displays. Most users can
operate the keypad with confidence after only a few
minutes of instruction, eliminating the need for
extensive training sessions.
Functions
Individual Color-coded Lights
The keypads have the following lights to indicate
system status:
• Red light indicating the system is On
• Yellow light indicating the system is On with No Delay
• Red lights indicate each of the eight sensor loops
• Green light indicating the system is "All On"
• Green light indicating the system is "Part On"
• Green light indicating overall system operation is okay
Hinged Door Covers Keys and User Instructions
The hinged door covers the keys when they are not in
use and prevents command entry if someone
accidentally bumps into the keypad. The inside of the
door holds a custom user instruction card.
Step Outside excursion feature provides easy to use
u
bypass and restoral of entry points
Exit Only function allows users to exit when the
u
system is On with No Delay without turning the
system Off
Individual color-coded lights show system status at
u
a glance
Hinged door covers keys and user instructions
u
Coded Sounder
The sounder uses coded tones to provide alarm,
trouble, watch, entry and exit delay, error, and other
annunciation. Some tones can be enabled, disabled,
and otherwise altered by programming.
Three Programmable Emergency Keys
Along with the eleven action keys, there are three
programmable keys that can be programmed for
specific functions, such as Emergency, Fire, or Panic.
Single key operation controls many of the basic
functions. All of the keys illuminate during entry delay
and when a key is pressed. Custom labeling is
provided for all the keys except the "CLEAR" key.
Certifications and approvals
Keypad Approval
D202A and UL365, Police Station Connected Burglar Alarm Units
D202AW and Systems
UL609, Local Burglar Alarm Units and Systems
UL985, Household Fire Warning System Units
UL1023, Household Burglar-alarm System Units
UL1076, Proprietary Burglar Alarm Units and
Systems
UL1610, Central Station Burglar-alarm Units CSFM
NFPA 72 Household
