IR transmitter
1
2
IR transmitter
Sends IR signals to your heat pump, and has a range of up to 10
metres.
3
Current indicator (green)
ON:
External power supply connected.
OFF:
External power supply disconnected.
Battery indicator (green)
4
ON:
Normal battery status.
OFF:
Battery disconnected or battery on/off switch is
switched off.
Flashing:
Low battery level.
GSM indicator (red)
5
ON:
No GSM signal. Seeking GSM signal.
OFF:
GSM module has signal and working normally.
Flashing:
Error on GSM module, no SIM card.
6
IR indicator (orange)
OFF:
Normal setting
Rapid fl ashing:
Sends IR signal via IR transmitter.
Slow fl ashing:
Awaiting incoming IR programming signal to I
R receiver.
Lit for 3 seconds:
IR signal programming successful.
7
IR receiver
Discreetly placed IR receiver. Reads IR signals through unit housing,
and does NOT need to be exposed by making a hole.
Temperature sensor
8
Reads current room temperature. Do not block this hole.
GSM test button
9
Press the button to read current GSM signal strength. The GSM
indicator will fl ash from 1 to 10 times, depending on strength (1 =
low signal strength, 10 = high signal strength)
IR test button
10
Sends a test signal to your heat pump.
- HL mode: Sends the following setting: "Heat 16°C" with
automatic fan speed".
- HX mode: Sends the following setting: "Heat 18°C" with
automatic fan speed".
- PM mode:
Sends the programmed signal in the fi rst slot.
If nothing has been programmed, no signal
will be sent.
External power supply
11
Connection for 12V DC, 1A current adapter.
12
Battery on/off switch
ON:
The integrated battery will power the unit in the event
of power loss from the external power connection.
OFF:
The unit will not work without an external power
supply being connected
SIM card holder
13
Cover for the SIM card holder and battery switch.
NOTE! When installing the SIM card, the battery switch must be in
the off position, and the external power supply disconnected.
5
DESCRIPTION
