- Page 1 MIYN46 Wall Transmitter 970.035b | F.01U.278.521 | V2.0 | 2012.12 en User Manual US...
-
Page 3: Table Of Contents
MIYN46 Wall Transmitter | en Table of Contents Generalities Resident Alert System MIYN46 Wall Transmitter Safety Instructions Introduction 2.1.1 Principle 2.1.2 Importance of safety instructions 2.1.3 Disregarding safety rules Environmental conditions General safety instructions 2.3.1 Observation and information Special safety instructions... - Page 4 | MIYN46 Wall Transmitter Reserve Call Technical Alarm Caregiver Arrival Caregiver Departure Daily Message and Battery Low Message Error Message Operation Description of the six different states Legend of illustrations Operation with the staff presence processing activated 6.3.1 Device behavior when pressing a button Operation with the staff presence processing deactivated 6.4.1...
-
Page 5: Generalities
It is part of a Resident Alert System, and is easily expandable. In the Resident Alert System, the MIYN46 Wall Transmitter allows the resident of an independent living or assisted living facility to easily alert the care personnel if needed. The resident simply has to push the large red button. -
Page 6: Safety Instructions
Environmental conditions WARNING! The MIYN46 Wall Transmitter must not be located near a water tap or any other source of water. The electrical safety of the MIYN46 Wall Transmitter is only guaranteed if the electrical instal- lation is in accordance with the national regulations and if this installation works properly. -
Page 7: General Safety Instructions
Avoid touching conductive parts inside the MIYN46 Wall Transmitter if not absolutely nec- essary. CAUTION! Never let any liquid enter the system. In case of liquid spill inside the MIYN46 Wall Transmit- ter, act immediately as follows: Switch off the MIYN46 Wall Transmitter: take out the battery or remove the power supply. -
Page 8: Description
| Description MIYN46 Wall Transmitter Description General description 3.1.1 Top view Fig. 3.1 Top view Red emergency call button LED indicator for alarm LED indicator for presence Green acknowledgment button, to acknowledge an alarm locally. Blue assistance call button... -
Page 9: Main Functions
MIYN46 Wall Transmitter Description | en Main functions The main function of the MIYN46 Wall Transmitter is to enable easier handling of emergencies and help, directly from the resident’s room. 3.2.1 Red emergency call button Its large red button with textured surface makes it easy to identify and to press, launching an emergency call. -
Page 10: Installation
(storage or transport). NOTICE! In case of defective or missing equipment, do not try to install the MIYN46 Wall Transmitter. Contact immediately your local representative. Take the components out of the box and place the MIYN46 Wall Transmitter in front of you. -
Page 11: Installation
4.2.2 Wall installation The MIYN46 Wall Transmitter can be fixed with two to five screws on a wall. Two holes at 2.4 inches (60 mm) interval are provided for direct mounting on connection boxes. The three upper holes are used for positioning the device and cannot be reached from the installation compartment. -
Page 12: Connecting To The Power Supply
4.2.3 Connecting to the power supply The MIYN46 Wall Transmitter can be powered by a lithium battery or/and an external 12-24 VDC power supply. If the device is powered with an external power supply, the battery is not necessary, but it can be used as a backup power supply in case of power loss. -
Page 13: Replacing The Battery
Replacing the battery WARNING! – May explode if exposed to fire; – Use only original batteries intended for use with your MIYN46 Wall Transmitter. Using other type of batteries could be dangerous; – Do not expose the battery to liquids; –... -
Page 14: Configuration And Wiring
| Installation MIYN46 Wall Transmitter 4.2.8 Configuration and Wiring Solder Bridges (if soldered): B8 Call for Assistance only by Staff Presence Call for Assistance from terminals J6[4-5] B6 No Staff Presence processing B5 No Daily Message B4 Not used... -
Page 15: Inputs And Outputs
MIYN46 Wall Transmitter Installation | en Inputs and Outputs General inputs The * marks a factory setting. External trigger J4 Jack Closing contact causes a Call for Help Contact opening causes a Call for Help Power supply 12 to 24 V DC... -
Page 16: General Configuration
The Assistance Call is possible only if the Care Personnel has signaled his/her presence. MIYN46 Wall Transmitters that feature the output relays are delivered with the Staff Pres- ence Processing activated (B6 open). Models that do not feature the output relays are deliv- ered with the Staff Presence Processing disabled (B6 soldered). -
Page 17: Use
MIYN46 Wall Transmitter Use | en Every time a MIYN46 Wall Transmitter is used by pressing a button or activating a wired input, the device sends a radio signal and the lamps indicates its actual state. Optionally, two relays allow the transmission of status to a remote display such as the signal lamps placed on top of the door. -
Page 18: Call Acknowledgement (Staff Presence)
| Use MIYN46 Wall Transmitter Call Acknowledgement (Staff Presence) The call acknowledgement is triggered by pushing the Acknowledgement button (green). The call acknowledgement stops immediately all repetitions of the calls. Optionally, a call acknowledgement triggers the Staff Presence signal: –... -
Page 19: Caregiver Departure
MIYN46 Wall Transmitter Use | en Insertion of the coded key is signaled by green flashes on the signal lamp and by activating the Staff Presence relay. Caregiver Departure The Caregiver Departure message is triggered when the Caregiver removes the coded key from the housing, when leaving the room. -
Page 20: Operation
| Operation MIYN46 Wall Transmitter Operation Description of the six different states During operation, the MIYN46 Wall Transmitter can be set to one of six following states: State Description Stand-by No call is being processed. Alarm without staff presence The resident has triggered a Call for Help but the Care Personnel has not yet responded. -
Page 21: Legend Of Illustrations
Call for Assistance staff presence ** ** If the function Assistance only in case of Staff Presence is activated and the MIYN46 Wall Transmitter is not in Staff presence state, the Call for Assistance causes a state Alarm without Staff Presence and a Call for Help radio message. - Page 22 Call for Assistance staff presence ** **If the function Assistance only in case of Staff Presence is activated and the MIYN46 Wall Transmitter is not in Staff presence state, the Call for Assistance causes a state Alarm without Staff Presence and a Call for Help radio message.
- Page 23 MIYN46 Wall Transmitter Operation | en State before action: Assistance with staff presence Signal lamp Radio Message Action State Relay contact Assistance with staff (none) presence Assistance with staff Call for Help presence Call for Assistance (unchanged) Call Alarm with staff...
-
Page 24: Operation With The Staff Presence Processing Deactivated
| Operation MIYN46 Wall Transmitter Operation with the staff presence processing deactivated 6.4.1 Device behavior upon pressing a button State before action: Stand-by Signal lamp Radio Message Action State Relay contact (none) Stand-by Alarm without staff Call for Help... -
Page 25: Storage
If the MIYN46 Wall Transmitter must be temporarily stored, it may not be necessary to wrap it completely. However, if you wish to store the MIYN46 Wall Transmitter for a longer time, for instance in a storage room or any similar location, it is recommended to use original packing material. -
Page 26: Disposal
The nearest disposal locations are established in accordance with the currently applicable laws. Ask the local authorities. Returning to the manufacturer If there is no practical disposal place, the MIYN46 Wall Transmitter may be returned to your local representative. Materials The MIYN46 Wall Transmitter must be returned to an authorized point of recycling. -
Page 27: Appendix
MIYN46 Wall Transmitter Appendix | en Appendix Electrical specifications External power supply 12-24 VDC & consumption Transmission: < 40 mA Idle mode: < 10 mA Battery power supply 3V lithium battery CR2450 & consumption Transmission: < 30 mA Idle mode: < 10 µA Battery life Approx. - Page 28 Robert Bosch Healthcare Systems, Inc. 2400 Geng Road, Suite 200 Palo Alto, CA 94303 U.S.A. Phone: 650-690-9100 Toll Free: 1-888-947-8957 Fax: 650-798-3770 www.bosch-telehealth.com...
