Summary of Contents for HP 9000 rp3410

  • Page 1 Generic Site Preparation Guide HP Part Number: 5991-6018_ed6 Published: July 2010 Edition: 6...
  • Page 2: Revision History

    Legal Notices © Copyright 2010 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services.
  • Page 3: Table Of Contents

    Table of Contents 1 General Site Preparation Guidelines................7 Electrical Factors.............................7 Synopsis.............................7 AC Electrical Distribution System....................7 AC Power Quality Devices......................8 UPS Recommendations........................8 Power Consumption........................8 Grounding Systems........................9 Comprehensive Discussion.......................9 Computer Room Safety........................10 Fire Protection..........................10 Fire Suppression.........................10 Lighting Requirements for Equipment Servicing..............10 Cabinet Recommendations......................10 Working Space for Product Access....................11 Power Consumption........................11 Electrical Load Requirements (Circuit Breaker Sizing)..............11...
  • Page 4 Cooling Requirements........................21 Basic Air-Conditioning Equipment Requirements..............21 Air-Conditioning System Guidelines..................22 Air-Conditioning System Types....................22 Basic Air-Distribution Systems....................22 Air-Conditioning System Installation..................23 Air-Conditioning Ducts......................23 Humidity Level..........................23 ESD Prevention..........................24 Humidity Levels Influence the Creation of Static Charges.............24 Relative Humidity...........................24 Static Protection Measures.......................24 Acoustics............................25 Facility Characteristics..........................25 Floor Loading..........................25 Floor Loading Terms........................25 Raised Floor Loading.........................26...
  • Page 5 List of Figures Raised Floor Metal Strip Ground System..................15 C20 Male Receptacle (at Power Supply)..................29 C19 Female Plug (on One End of the Power Cord)...............29 Unterminated Plug........................29 L6-20 Plug............................30 IEC 309 Plug..........................30 CEE 7-7 Plug..........................30 L6-30 Plug............................30 NEMA 5-20P Plug (left) and receptacle (right)................30 1-10 ISI 32 Plug............................31 1-11...
  • Page 6 List of Tables Maximum Contaminant Gas Levels....................21 Effect of Humidity on ESD Charge Levels..................24 Floor Loading Term Definitions....................25 Typical Raised Floor Specifications....................26 Typical Environments of Customer Installations................27 Typical Range of Product Power-Off Storage and Shipping Environments.........28 Customer and HP Information......................33 Site Inspection Checklist........................33 List of Tables...
  • Page 7: General Site Preparation Guidelines

    1 General Site Preparation Guidelines This guide contains recommendations and best practices to improve site efficiency and tolerance before installing or operating any Business Critical products. The Best Practices found in this document closely align with third party engineering, such as the ISA G1 environments.
  • Page 8: Ac Power Quality Devices

    • Electrical infrastructure is rated for maximum load. • The distance from a receptacle to power source X0 is less than 75 feet (23 m). • There are no daisy-chained receptacles or hot, neutral, or ground wires. • The system is sourced from higher distribution voltages. AC Power Quality Devices HP products have a wide range of voltage tolerances.
  • Page 9: Grounding Systems

    NOTE: Set cooling for the maximum-rated power output of the room, and develop a growth plan for the cooling infrastructure. Grounding Systems WARNING! Follow electrical code when connecting equipment AC power ground wire to the AC distribution point. Failure to properly ground the equipment or the floor can lead to shock hazard.
  • Page 10: Computer Room Safety

    Computer Room Safety WARNING! The safety of personnel must be a paramount consideration when performing the following recommendations. Failure to comply can create life-threatening scenarios. Inside the computer room, fire protection and adequate lighting when servicing equipment are important safety considerations. Federal and local safety codes govern computer installations. Fire Protection The National Fire Protection Association’s Standard for the Protection of Electronic Computer Data Processing Equipment, NFPA 75, contains information on safety monitoring equipment...
  • Page 11: Working Space For Product Access

    Working Space for Product Access The recommended working space for performing maintenance is 3 feet (0.9144 m) from vendor instructed working area. The work space must permit at least a 90-degree opening of equipment doors or hinged panels. When planning for the working-space area, consider whether access to the product will be at the front, the side, or the rear of the product.
  • Page 12: Power System Protection

    • Fluctuations occurring within the facility’s distribution system • Utility service low-voltage conditions (such as sags or brownouts) • Wide and rapid variations in input voltage levels • Wide and rapid variations in input power frequency • Electrical storms • Large inductive sources (such as motors and welders) •...
  • Page 13: Building Distribution

    Building Distribution Place building feeders and branch circuitry in rigid metallic conduits with proper connectors (to provide ground continuity). Ensure that all conduits that are exposed and subject to damage are constructed of rigid galvanized steel. Grounding Systems HP systems are tested and certified only with grounding systems in which a neutral return path and a protective earth are separate conductors without any inserted impedances.
  • Page 14: Dual Power Source Grounding

    Dual Power Source Grounding The use of dual power might create an electrical potential that can be hazardous to personnel and might cause performance issues for the equipment. When using dual power sources, measure voltage potentials with a high impedance digital multi-meter (DMM). Dual power sources might originate from two different transformers or two different UPS devices.
  • Page 15: Equipment Grounding Implementation Details

    Figure 1-1 Raised Floor Metal Strip Ground System Equipment Grounding Implementation Details Connect all HP equipment cabinets to the site ground grid as follows: Check that the braid contact connection points are free of paint or other insulating material and treated with a contact enhancement compound (similar to Burndy Penetrox). Check that the braid contact on each end of the ground strap consists of a terminal and connection hardware (a 1/4-inch (6.0-mm) bolt, nuts, and washers).
  • Page 16: Acclimatization

    NOTE: In domestic installations, install approved receptacles before the HP equipment arrives. See the appropriate installation guide for installation procedures. Acclimatization IMPORTANT: After removal of shipping material, HP recommends allowing the thermal mass of the product to equalize to the temperature and humidity of the installation facility. A minimum of 10°C (50°F) to one hour of temperature difference between the shipping/receiving facility and installation facility is required.
  • Page 17: Airflow

    HP equipment will operate in a broad environment within a Controlled Computer room. Temperature can range from 18–27 °C (64.40–80.60 °F) and humidity can range between 20%–80% relative humidity (rh). Use a Best Practice to gain the highest reliability by ensuring the temperature is 20–25 °C (68–77 °F) and humidity range of 40%–50% rh.
  • Page 18: Equipment Orientation

    Also be aware that the racking cabinets are integral to the proper environmental support for mounted equipment. See the following additional items: • Cabinet blanking panels must be used in non-populated U-space levels to prevent unpredictable air mixing. This can lead to No Trouble Found (NTF) diagnosis. •...
  • Page 19: Computer Room Preparation

    • Computer room preparation • Airflow • Cooling requirements • Humidity level • ESD prevention • Acoustics Computer Room Preparation Consider the following guidelines to prepare a computer room for a product: • Locate the computer room away from the exterior walls of the building to avoid the heat gain from windows and exterior wall surfaces.
  • Page 20: Dust And Pollution Control

    Dust and Pollution Control Computer equipment can be adversely affected by dust and microscopic particles in the site environment. Specifically, disk drives, tape drives, and some other mechanical devices can have bearing failures resulting from airborne abrasive particles. Dust might also blanket electronic components such as printed circuit boards, causing premature failure due to excess heat or humidity buildup on the boards.
  • Page 21: Metallic Particulate Contamination

    http://www.isa.org/ for more information. If the environment does not meet G1 levels, third party experts in remediation should be engaged to help bring the site into compliance. This work will include verifying contaminant levels and sources, as well as determining the most effective remediation techniques. Those may include filtration and abatement of the environment by qualified professionals to remove the contaminants.
  • Page 22: Air-Conditioning System Guidelines

    • Humidification • Reheating • Air distribution • System controls When calculating cooling requirements, include the heat generated by lighting and personnel. For example, a person dissipates about 450 Btus per hour while performing a typical computer room task. At altitudes above 10,000 feet (3,048 m), the lower air density reduces the cooling capability of air-conditioning systems.
  • Page 23: Air-Conditioning System Installation

    Under-floor air distribution system—Downflow air-conditioning equipment located on the raised floor of the computer room uses the cavity beneath the raised floor as plenum for the supply air. Return air from an under-floor air-distribution system can be ducted return air (DRA) above the ceiling.
  • Page 24: Esd Prevention

    resistance between connections, leading to equipment failures. High humidity can also have an adverse affect on some magnetic tapes and paper media. CAUTION: Low humidity contributes to undesirably high levels of electrostatic charges. This increases the electrostatic discharge (ESD) voltage potential. ESD can cause component damage during servicing operations.
  • Page 25: Acoustics

    • Maintain recommended humidity level and airflow rates in the computer room. • Install conductive flooring (use conductive adhesive when laying tiles). • Use conductive wax (if waxed floors are necessary). • Ensure that all equipment and flooring are properly grounded and are at the same ground potential.
  • Page 26: Raised Floor Loading

    NOTE: Have a floor system consultant for the appropriate flooring environment verify any floor system under consideration for a product installation. Raised Floor Loading Raised floor loading is a function of the manufacturer’s load specification and the positioning of the equipment relative to the raised floor grid. While HP cannot assume responsibility for determining the suitability of a particular raised floor system, it does provide the following guidelines: •...
  • Page 27: Windows

    Windows Do not house computers in a room with windows. Sunlight entering a computer room can cause problems. Magnetic tape storage media is damaged if exposed to direct sunlight. Also, the heat generated by sunlight places an additional load on the cooling system. Space Requirements This section contains information about space requirements for the product.
  • Page 28: Storage And Powered Off

    The maximum elevation for all operating environmental classes is 3,050 m (10,007 ft). Dry bulb temperature is the regular ambient temperature. Derate maximum dry bulb temperature 1 ºC/300 m (34 ºF/984 ft) above 900 m (2,953 ft). Must be noncondensing environment. Controlled computer room environment is comparable to ASHRAE Class 1 and IEC 60721 Class 3K1.
  • Page 29: Power Plug Configuration

    • Equipment cable routing • Doors Power Plug Configuration Several power cables are designed for use with HP products. The region the product ships to will determine which power cable ships with the product. Figure 1-2 Figure 1-11 (page 31) provide an overview of the power plug configurations available.
  • Page 30: L6-20 Plug

    Figure 1-5 L6-20 Plug Figure 1-6 IEC 309 Plug Figure 1-7 CEE 7-7 Plug Figure 1-8 L6-30 Plug Figure 1-9 NEMA 5-20P Plug (left) and receptacle (right) General Site Preparation Guidelines...
  • Page 31: Conversion Factors And Formulas

    Figure 1-10 ISI 32 Plug Figure 1-1 1 GB 1002 Plug Power Cable The power cable length and configuration varies based on the region the product ships to. Figure 1-12 (page 31) provides an example of one power cable configuration used to supply power to the product.
  • Page 32: Example Of An Installation Schedule

    Conversion Factors • Refrigeration — 1 watt = 0.86 kcal/hour — 1 watt = 3.412 Btu/hour — 1 watt = 2.843 × 10-4 tons — 1 ton = 200 Btu/minute — 1 ton = 12,000 Btu/hour — 1 ton = 3,517.2 watts •...
  • Page 33: Sample Site Inspection Checklist

    — A signed copy of the site inspection and delivery survey is mailed to HP. — Site inspection and predelivery coordination meeting is arranged with an HP representative to review the inspection checklist and to arrange an installation schedule. • Seven days before installation —...
  • Page 34 Table 1-8 Site Inspection Checklist (continued) Check either Yes or No. If No, include comment number or date. Comment or Date Is the raised floor adequate for equipment loading? Are channels or cutouts available for cable routing? Is a network line available? Is a telephone line available? Are customer-supplied peripheral cables and LAN cables available and of the proper type?
  • Page 35: Delivery Survey

    Table 1-8 Site Inspection Checklist (continued) Check either Yes or No. If No, include comment number or date. Comment or Date Are air-conditioning filters installed and clean? Storage Number Area or Condition Are cabinets available for tape and disc media? Is shelving available for documentation? Training Number...
  • Page 36: Delivery Survey (Part 1)

    Figure 1-13 Delivery Survey (Part 1) DELIVERY CHECKLIST DOCK DELIVERY Is dock large enough for a semitrailer? Circle the location of the dock and give street name if di erent than address. North West East South STREET DELIVERY Circle the location of access door and list street name if di erent than address. North East West...
  • Page 37: Delivery Survey (Part 2)

    Figure 1-14 Delivery Survey (Part 2) ELEVATOR Fill in the following information if an elevator is required to move equipment. Capacity (lb or kg) Depth Height Width Height Depth Width STAIRS Please list number of ights and stairway dimensions. Number of ights Number of ights Width Width...
  • Page 39: Support And Other Resources

    2 Support and other resources Contacting HP Before you contact HP Be sure to have the following information available before you call contact HP: • Technical support registration number (if applicable) • Product serial number • Product model name and number •...
  • Page 41: Glossary

    Glossary apparent power A value of power for AC circuits that is calculated as the product of root mean square (RMS) current times RMS voltage, without taking the power factor into account. ASHRAE Industry-standard term for air filtration efficiency set forth by the American Society of Heating, Standard 52-76 Refrigerating, and Air-Conditioning Engineers, Inc.
  • Page 42 maximum input The operating current of the product equal to the maximum load divided by the minimum current input voltage. NEBS Network Equipment Building Standards. A set of safety guidelines. All electronic equipment has the potential to interfere with other electronic equipment. Interference can be caused by electromagnetic radiation, the grounding system, the electrical power connection, excessive heat or blocking the natural airflow, and connecting wires or cables.
  • Page 43 watt A unit of electricity consumption representing the product of amperage and voltage. When the power requirement of a product is listed in watts, you can convert to amperes (A) by dividing the wattage by the voltage. (For example, 1,200 W divided by 120 V equals 10 A.)
  • Page 45: Index

    Index air-distribution systems, 22 computer room considerations, 19 acoustics, 25 cooling requirements, 21 air-conditioning dust and pollution control, 20 ducts, 23 electrostatic discharge requirements, 21 prevention, 24 system recommendations, 22 humidity level, 24 air-distribution system static protection measures, 24 room space return air, 22 equipment airflow, 17 grounding, 15...
  • Page 46 raised floor ground system, illustrated, 15 loading, 26 specifications, 26 relative humidity, 24 row orientation, 19 site inspection checklist, 33 sources of electrical disturbances, 11 space requirements, 27 delivery space requirements, 27 system installation guidelines, 15 data communications cables, 16 wiring connections, 16 technical requirements based on customer, 27 telephone use, 18...
