Samsung SRD-480D User Manual

4 channel hd-sdi dvr
Hide thumbs Also See for SRD-480D:

Advertisement

4 CHANNEL HD-SDI DVR
User Manual
SRD-480D

Advertisement

Table of Contents
loading

Summary of Contents for Samsung SRD-480D

  • Page 1 4 CHANNEL HD-SDI DVR User Manual SRD-480D...
  • Page 2: User Manual

    Disclaimer Samsung Techwin makes the best to verify the integrity and correctness of the contents in this document, but no formal guarantee shall be provided. Use of this document and the subsequent results shall be entirely on the user's own responsibility. Samsung Techwin reserves the right to change the contents of this document without prior notice.
  • Page 3: Overview

    overview IMPORTANT SAFETY INSTRUCTIONS Read these operating instructions carefully before using the unit. Follow all the safety instructions listed below. Keep these operating instructions handy for future reference. Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water.
  • Page 4: Before Start

    • SAMSUNG retains the copyright on this manual. • This manual cannot be copied without SAMSUNG's prior written approval. • We are not liable for any or all losses to the product incurred by your use of non-standard product or violation of instructions mentioned in this manual.
  • Page 5: Table Of Contents

    CONTENTS OVERVIEW Important Safety Instructions Before Start Contents Key Features Part Names and Functions (Front) Part Names and Functions (Rear) Remote Control Checking the installation environment INSTALLATION Rack Installation HDD Addition CONNECTING WITH OTHER DEVICE Wiring diagram for external devices Connecting the camera, monitor and audio Connecting to an external storage device Using the I/O ports...
  • Page 6 overview SEARCH & PLAY Play Mode Search Mode Copy Overview of Web Viewer WEB VIEWER Connecting to the web viewer Using the Live Viewer Using the Search Viewer Setup Viewer SMARTVIEWER System Setup Device Setup Event Setup Record Product Specification APPENDIX Product Overview Troubleshooting...
  • Page 7: Key Features

    KEY FEATURES This DVR is a digital recorder that enables you to save a 4CH high-definition (HD) digital video to the internal HDD and play it for an intended purpose. You can use the mouse or front buttons to configure your settings and make a desired instruction. This model is a standalone digital video recorder with high performance and proven stability that is used for security purposes in banks, apartments and public offices.
  • Page 8 overview Search/Play It provides various functions to facilitate your search and playback. • Playback by the time, date or channel • User-friendly search interface using the mouse • Forward/backward navigation of frozen video • Play by the event list (sensor, video loss, motion detection, text) •...
  • Page 9: Standards Approvals

    COPY EVENT PLAY NETWORK MULTI MENU PAUSE MENU COPY AUTO SEARCH PLAY ENTER DIGITAL VIDEO RECORDER SRD-480D DVD RECORDER COPY STOP ZOOM FUNC SEARCH LOAD PRESET AUX ON Network Viewer S/W, Remte Control Power Cable User Manual CD SATA Cable...
  • Page 10: Part Names And Functions (Front)

    COPY EVENT PLAY NETWORK MULTI MENU PAUSE AUTO SEARCH PLAY ENTER DIGITAL VIDEO RECORDER SRD-480D DVD RECORDER COPY STOP ZOOM FUNC Part Names Functions Copy DVD-Multi Drive Used to copy recording data in DVD/CD media. Channel Indicator Show the video input status and event operation status.
  • Page 11 Part Names Functions Start or stop manual recording. MULTI Switch the split mode in Live or play mode. MENU Access the main menu. AUTO Activate or deactivate the user sequence. SEARCH Access the search mode. Start or end the PTZ operations. COPY Access the copy mode.
  • Page 12: Part Names And Functions (Rear)

    overview PART NAMES AND FUNCTIONS (REAR) AC 100-240~IN COM 1 COM 2 COM 3 COM 4 COM2 / COM3 ALARM IN ALARM OUT Termination RS485 AUDIO IN Exter nal l/O CH 1 CH 2 HD-SDI CH 1 CH 2 CH 3 CH 4 CH 3 CH 4...
  • Page 13: Remote Control

    REMOTE CONTROL STATUS Show the system configuration information Not used ZOOM Digital zooming Not used FUNC FUNC Access the function menu Select a remote control ID MULTI DISP Change the split mode STATUS Access the selection screen of channel and split mode MULTI DISP AUTO...
  • Page 14: Installation

    Life (Unit: HOURS) [Figure 1] The followings are the recommendations when Samsung DVR is installed on a rack. 1. Please ensure that the rack inside is not sealed. 2. Please ensure the air is circulated through the inlet/outlet as shown in the picture.
  • Page 15: Rack Installation

    RACK INSTALLATION Install the Bracket-Rack as shown in the figure, and then fasten the screws on both sides (2 screws on each side).  Fix the screws not to be loosened by vibrations. HDD ADDITION You can install additional HDDs. Make sure to unplug the power cord from the wall outlet to prevent possible electric shock, injury or product damage.
  • Page 16 installation Installing the HDD 1. Loosen the bracket screws on the man unit. 2. Pull out the main unit slightly backward to remove the bracket. 3. Insert and mount the HDD bracket and tighten the left and right HDD screws. 16_ installation...
  • Page 17 4. Insert the bracket where the HDD is fixed in the main unit. 5. Tighten the bracket screws to fix the HDD-installed bracket to the main unit. 6. Connect both SATA cable and power cable. For HDD position, the bottom right is IntA; the bottom left is IntB;...
  • Page 18: Connecting With Other Device

    Note that the HDMI monitor and VGA monitor cannot used simultaneously for video output.  However, some of Samsung or LG manufactured monitors can be used simultaneously for video output if either monitor supports both resolutions of 1080p and 1920x1080p RB.
  • Page 19: Connecting To An External Storage Device

    The DVR introduces eSATA as an interface with the external storage device, which provides one eSATA port on the rear panel. By taking advantage of the internal HDD and eSATA port, you can install up to 12TB storage device.  The eSATA port supports only Samsung Techwin-manufactured external HDD (SVS-5R). English _19...
  • Page 20: Using The I/O Ports

    connecting with other device Connecting to an eSATA device If using a SVS-5R external HDD, you can use one rear port of the DVR. However, the DVR does not supply a separate power source so you should use an external power source for operating the HDD. ...
  • Page 21: Specifications

    Inserting/Removing the wire If you want to insert or remove the wire in or from the terminal block, push the lever as shown. Alarm Connection and Setting Specifications The alarm input signal shall meet the following specifications and operating conditions. No.
  • Page 22 connecting with other device Relay Connection and Setting Specifications The alarm output signal shall meet the following specifications and operating conditions. No. of output circuits 4 relay outputs Specification Output type Dry Contact Connection system Connected to the terminal block with the coating peeled off 30V 1A Rated Power 125V 0.5A...
  • Page 23 Connection and setting of the serial communication port Connecting the serial communication port for Pan/Tilt/Zoom You can control the PTZ device via the COM port if it is compliant with the DVR. For the compatibility, refer to "Compatible PTZ devices and keyboards". (page 24) The figure below provides an example of connecting the PTZ-featuring camera to the RS-485 (COM2/COM3) communication port.
  • Page 24: Network Connection

    Samsung Techwin  If you want to select a protocol for the keyboard, make sure that you choose <SVR/SRD-480D>. NETWORK CONNECTION Connect to a remote PC via the Internet/Intranet. Then, you can control the DVR and make monitoring using the PC as if you were in the scene.
  • Page 25 Network connection via the router AC 10 0- 24 0~ IN xDSL or Cable modem Broadband Router Network xDSL or Cable modem DDNS Server (Data Center) External Remote Network connection via xDSL Change the type to <xDSL> before moving to the xDSL menu. First of all, change the port for the Ethernet line.
  • Page 26 connecting with other device Connection using DDNS Change the interval to more than 1 minute and enter the DDNS server IP and the user ID that you registered. • To prevent damage to the DVR, you must connect the Ethernet cable before applying power. •...
  • Page 27: Live

    live GETTING STARTED Starting the system 1. Connect the power cable to the rear Power port of the DVR. 2. Every indicator blinks once. The booting process will take a minute with the booting logo on the screen. 3. The Live screen appears. [54.44%] 01/01/2012 01:10:25 [ OOOO ]...
  • Page 28 live Live function menu Besides the front button or the remote control button, you can right-click any area on the Live screen to display the Function menu bar. Select a desired item in the Function menu bar. 01/01/2012 01:10:25 [54.44%] [ OOOO ] ID = All Cam 1...
  • Page 29: Using The Live Menu

    USING THE LIVE MENU Select a split mode Press the [MULTI] button on the remote control or select the display menu in the Function menu window to display the screen mode menu where you can select a desired screen mode. Single Screen Press each channel button in Live mode, or place the cursor on a desired channel and just left click it.
  • Page 30: Digital Zoom

    live Digital Zoom 1. In single full screen mode, press [FUNC] and select <E> button and [+] button. Then, press [ENTER] or left-click it to enlarge the screen. 2. If selecting the <E> button, the center of the screen will be enlarged by default. In the enlarged screen, you can move the enlarged screen by 48 levels horizontally, and by 27 steps vertically.
  • Page 31: Event Monitoring

    Pan/Tilt Used to control the pan and tilt operations in real-time monitoring mode. 1. Select "Pan/Tilt" in PTZ mode. 2. Use the [◄►] buttons on the front panel or click a left or right area on the screen to control the pan operation;...
  • Page 32: Menu Setup

    menu setup menu setup QUICK SETUP The Quick Setup menu is a collection of only key functions of the DVR for you to access with ease. MENU - ENTER - ▼ - ▼ - ENTER Record Mode It sets recording method. ...
  • Page 33: Display Setup

    DISPLAY SETUP Display settings You can specify the title for each channel available and also specify the use of the channels. MENU - ► - ENTER - ENTER • Channel Number : Select a channel that you want to apply your settings to. •...
  • Page 34: Record Setup

    menu setup Monitor settings If you want to display a video on the monitor, you must configure the related settings first. MENU - ► - ENTER - ► - ENTER • Sequence : Change the auto sequence settings to your preference. You can specify up to 16 sequence modes, and the dwell time shall be specified between 1 and 60 seconds.
  • Page 35 • Event Duration : Specify the pre- and post-event recording time.  Your setting for <Pre Event Duration> and <Post Event Duration> apply to the entire channels. • Overwrite : Specify the use of overwrite if the HDD's space is full. •...
  • Page 36 menu setup To delete an existing schedule Select an index and press <Delete>. If you press <Delete> without selecting an index, the previous index will be deleted at first. Then, deletion will progress in the descending order from the largest number of index. To change an existing schedule Select an index and change the date, program and time manually.
  • Page 37 To configure the audio settings • Audio Channel : Select a channel for audio setting. • Auto Recording : Specify the saving of the existing audio settings. If you set it to <Off>, only the live video will output the audio signal; if setting it to <On>, the recording video as well will output the audio signal. •...
  • Page 38: Event Setup

    menu setup • Input Res : Display the input resolution. • Rec. Res : Display the recording resolution. • F(FPS) : FPS stands for frames per second. You can specify FPS between 0 and 30fps. The maximum frame rate can differ depending on your setting. When mixed with 720p and 1080p setups, 1 frame of 1080p is estimated as 2 frames of 720p.
  • Page 39 Event Action Setting Specify the operation according to the incoming event. MENU - ► - ► - ► - ENTER - ENTER - ▼ - ▼ - ▼ - ▼ - ▼ - ENTER • Action Duration : This is used for relay and buzzer settings. This will keep the operation as long as the specified time.
  • Page 40 menu setup • Including Picture : If you set it to <On>, the email to send if an event occurs will include the event image at the event occurrence time. If you set it <Off>, the email will be sent if an event occurs but with no image attached. •...
  • Page 41 Normal event setting You can specify the motion detection area, sensor and text. MENU - ► - ► - ► - ENTER - ► - ENTER Motion Detection Setting The Motion Detection item will be used to detect every single channel and notice the user of a motion if it occurs.
  • Page 42 menu setup To specify a motion area 1. Select a motion detection channel. Only if you select a single channel, you can specify the motion detection area. 2. Move to <Area> and select <Select Area>. 3. Select <Custom Area>. 4. When the custom area setup window appears, use the direction buttons to move to a desired area and press [ENTER].
  • Page 43: Network

    NETWORK Network setting via Ethernet This is a menu where you can configure the network settings for connecting to the network via the Ethernet. MENU - ► - ► - ► - ► - ENTER - ENTER • Type : Set the type of network line (connected to the DVR) to <Ethernet>. This is suitable if the DVR is connected to the DVR-dedicated line, cable modem or LAN.
  • Page 44: Ddns Setting

    menu setup Network Setup via xDSL If the DVR is connected to xDSL line that uses PPPoE, change the type to xDSL and provide the user ID and password. Use the user ID and password that were assigned when you registered with xDSL service. MENU - ►...
  • Page 45 To use the DDNS feature, subscribe to the DDNS server and register the DVR. Log in to the DDNS server and click Register Device to provide the domain information that you entered. To register with Samsung DDNS 1. Register yourself at iPOLiS homepage (www.samsungipolis.
  • Page 46: Ntp Setting

    menu setup NTP Setting NTP (Network Time Protocol) is used to synchronize the time between network devices. It consists of the server providing the standard time in the network and the client that is connected to the server for receiving the sync time.
  • Page 47 • Remote Control ID : Provide the ID of the remote control in sync with the DVR. You can specify up to 16 remote control IDs. Each remote control can control up to 16 DVRs.  For registering the remote control ID, refer to "Changing the Remote Control ID". (page 13) •...
  • Page 48: System Setup

    menu setup SYSTEM SETUP System Setting You can configure the system-related settings and upgrade the software. MENU - ► - ► - ► - ► - ► - ENTER - ENTER • Language : The OSD menu is provided in multiple languages. Select a preferred language. •...
  • Page 49 To update the software The USB updatable files is formatted in "*.dat". 1. Download the USB updatable files to the USB device before connecting to the DVR. 2. Select the Software Update item in the system menu, and press [ENTER]. 3.
  • Page 50 menu setup  For the overlapped time when DST expires, play data with the DST time and then, play data after the DST time.  For more information about NTP, refer to "NTP" in the network setup.  However, if NTP is set to <On>, you cannot specify the time. •...
  • Page 51: Security Setting

    If you change HDD to No - Enabled : With this set to <Yes>, if you press [ENTER] or turn the mouse wheel, you will see a notice as below: "NOTICE: Disk will be removed." - If selecting <YES>, you will see a message of "Recording disk removed." and this option will switch to <No>.
  • Page 52: Exit

    menu setup 1. Select Change P/W. 2. When a new password dialog appears, provide a new password.  You can enter a max of 12-digit password. 3. Press the <Change> button. 4. If you are prompted to confirm the change, click <YES>. EXIT Exit You can return to the Live screen with saving or without saving the settings in other menus.
  • Page 53: Search & Play

    search & play PLAY MODE Play in default mode (4-split screen) • In Live mode, press the [►] button or click <L> in the Function menu bar. • If you press the Play or Change Speed button, the video will be played in the default speed of x1. •...
  • Page 54: Search Mode

    search & play SEARCH MODE In this mode, you can search for a specific time or log for playing a desired video. Search mode includes time, calendar, event and thumbnail. To enter the search mode, press [SEARCH] on the front panel or remote control, or click <G> in the Function menu bar. ...
  • Page 55: Event Search

    If you click a hour-based time line, you will see the recording details by the minute. Select a specific minute in the time line and press [ENTER]. • Year : Select a year for your search. You can use the mouse wheel to change the year. •...
  • Page 56: Copy

    search & play Thumbnail Use the [▲▼] button or the mouse wheel to select a specific time at which interval you will search. The search result will be listed in thumbnails. Select a thumbnail. The DVR will play the recording data at the specific time and date.
  • Page 57 • Type : Select CD/DVD. Use the front [▲▼] buttons or mouse wheel to select CD/DVD. Press and hold [ENTER], and use the [▲▼] button or mouse wheel to change the setting. • Channel : You can select some or the entire channels from 4 channels. Select a channel position and press [ENTER].
  • Page 58 search & play • Select Disk : Select a medium to use for the copying. Move to a desired disk and press [ENTER] or simply click it. • Start : Start copying. Press [ENTER] or just click it. • FAT32 Format : Format the USB memory or eSATA HDD if not formatted in FAT32 before proceeding. Press [ENTER] or simply click it to start formatting.
  • Page 59 Controlling the MiniPlayer Item Description REW Step Move backward by one step Play reversely at x1 speed Pause Stop playing temporarily Play Play at x1 speed FWD Step Move forward by one step Image Save Save the image Image Print Print out the image File Open Open a selected file...
  • Page 60 search & play This enables you to copy some of the selected channel in the USB memory.  The USB type of HDD is not supported. • Type : Select AVI. Select this using the [▲▼] button or the mouse wheel. •...
  • Page 61: Web Viewer

    web viewer OVERVIEW OF WEB VIEWER What is the Web Viewer? Mobile Viewer is management software that enables you to connect to DVR (Digital Video Recorder) remotely and control the video playback and PTZ operations (if configured) in real time. Key Features •...
  • Page 62: Connecting To The Web Viewer

    web viewer CONNECTING TO THE WEB VIEWER 1. Open the web browser and enter the IP address and port number (that are specified in the DVR) in the address bar. The address is in such a format of "http://192.168.1.200 :4000." If you change the default port number (4000), enter the new port number in the port input box.
  • Page 63: Using The Live Viewer

    USING THE LIVE VIEWER Provide the user ID and password in the login page. If the information is authenticated, you will move to the monitoring page. In the monitoring page, you can view the camera video in real time and control the PTZ camera, relays, listening to audio and microphone, which are connected according to your permission level.
  • Page 64 web viewer Item Description SENSOR IN Display the sensor input channel. SENSOR OUT Display the sensor output channel. Specify the use of the microphone. Display the event log. Display Pane Display the video from the camera that is connected to the DVR. OSD Information Place the cursor on the channel screen and right-click any area to display the context menu where you can select to display or hide the information on the OSD screen.
  • Page 65: Split Mode

    Split Mode Click a desired numeric icon to switch the split mode. 1-split Mode 4-split Mode • Click < >. The "1-split mode" will display the video from the camera connected to the DVR.  <Show in Original Size> appears in case of full screen mode, and selecting it displays the stream in its original resolution on the screen.
  • Page 66: Sensor Input

    web viewer Connected DVR Display the IP address and operation status of the connected DVR.  Connection failure message No response : Displayed if the DVR makes no response Connection not allowed : If the number of concurrent users exceeds the limit ...
  • Page 67: Event Information

    Microphone You can turn on or off the microphone. It is defaulted to OFF. If you click the button, it will turn blue, indicating that it is ready for use. The audio signal incoming to the microphone will output to the audio output port of the DVR. Event Information Display the real-time information of an event that occurred in the bottom of the monitoring screen.
  • Page 68: Camera Setup

    web viewer To save the video The video image can be saved in two formats of jpg and bmp, which is, namely, a video clip of the current monitoring screen that is saved in 1 frame. 1. If you want to save the video, select a channel to save the video from and right-click it. 2.
  • Page 69: Using The Search Viewer

    USING THE SEARCH VIEWER With the search viewer, you can play the recording video. However, you must have the admin account or have the 'HDD' permission granted to your account. Search Viewer at a Glance To move to the search viewer, click <SEARCH> on the top right corner of the viewer screen. Item Description Connection...
  • Page 70 web viewer Capture You can capture the current video in .bmp format. 1. Select a channel to capture. 2. Click <CAPTURE>. The "Save Image" dialog appears. 3. Enter a memo or provide the channel name, date and event information. 4. Click <OK> and specify the saving path. Print You can print out the current video image using the printer connected to the PC.
  • Page 71 To move to the search time and date The date containing recording data will be active in black. You can select a date containing recording data and play the video. 1. Using the calendar, select a date for your search. 2.
  • Page 72: Smartviewer

    SmartViewer SmartViewer SETUP VIEWER Open the Smart Viewer and click [ ] button in the top right corner. Open the Smart Viewer and move to <Device Menu Setup> where you can configure the DVR settings remotely. Using the Setup Viewer This will display the DVR menu items.
  • Page 73 Import & Export • Save : You can save the configuration information of the selected DVR as a file. • Load : You can use a recorded file to configure the same settings for other DVR. This is useful if you want to apply the same settings to multiple DVRs. However, this is possible only for those DVRs with the same software version and model type.
  • Page 74 SmartViewer If it's the same device, the configuration file will be saved immediately. Provide the admin password and click <OK>. The configuration file will be imported. When done, you will see the "Completed" message and the <Finish> button will be active. •...
  • Page 75 • Custom DST contains two options : "Day of Week" and "Day of Month". In "Day of Week", specify the month, week, day of the week and time for the start and end times of DST. • "Day of Month" requires you to specify the month, day and hour for the start and end times of DST.
  • Page 76 SmartViewer User Account The DVR accounts are classified in two: user and admin. The admin account can access all features of the DVR without restriction. You can add up to 10 users, each of whom can use or access the DVR only within the permissions granted. •...
  • Page 77 It is recommended to set it to one minute in a network environment with very frequently changing IPs. (Off/1min/1hr/ 3hr/6hr/12hr/24hr) • Server : The DDNS server run by Samsung Techwin is "www. samsungipolis.com". • DDNS ID : Provide the IP that is registered with the DDNS server.
  • Page 78: Network Stream

    SmartViewer  Add dynamic IPs in the following cases: - If the Ethernet uses the DHCP protocol - If using xDSL (However, this is not applicable if using a static IP) Option • Port : You must change the port number if the DVR fails to connect due to such as fire wall.
  • Page 79: Device Setup

    DEVICE SETUP Camera Video Channel Setting You can specify the basic information, brightness, and contrast for each channel. The tap number (CH1, CH2, CH3, CH4) indicates the channel number of each video. Channel Information • Activity : Specify the use of the channel. - Channel Name : Provide the channel name.
  • Page 80: Ptz Setting

    SmartViewer The tab number indicates the channel number. According to this number, the PTZ device will be connected to a specific channel. PTZ Setting You can change the PTZ settings only after you had set to enable PTZ in the COM port page. •...
  • Page 81: Event Setup

    Audio The audio signal can be paired with any channel available. • Sync Audio Channel : Sets to which channel the audio input will be linked. If linked channel 1 audio to the video channel 4, the audio input of channel 1 is produced when the channel 4 is selected.
  • Page 82: Event Action

    SmartViewer Preset You can specify the preset for motion, sensor or text event. You can set the preset for each channel. Event Action In this page, specify the operation according to the incoming event. The DVR provides 4 relays, buzzer, e-mail and FTP transfer by default. And you can operate the DVR in sync with events such as sensor input or motion detection.
  • Page 83 Post Time 4 relays are supported that can be activated manually or if a normal or system event occurs. Select an event source and specify the duration. To activate the relay manually, press the relay button that will be active if you access the Smart Viewer or Web Viewer. •...
  • Page 84 SmartViewer • Enable : Check this option if you want to use the FTP transfer. Otherwise, deselect it. • Server URL : Enter the address for a FTP server to which you will upload event images when an event occurs. •...
  • Page 85: Record

    RECORD Record Schedule & Event Schedule & Event allows you to make recording according to a specific schedule and event. Specify the date or time, and select a program before specifying the schedule. You can select A through I. The event recording can be triggered by the 'sensor', by the 'motion detection', by the 'text' and by the 'digital input'.
  • Page 86: Appendix

    appendix appendix PRODUCT SPECIFICATION Item Details Inputs 4CH (HD-SDI SMPTE292M) Video Resolution 720p 30fps / 720p 60fps / 1080p 30fps Frame rate 120fps Live Resolution 1920x1080p Multi Screen display 1/4/SEQUENCE Performance Embedded Linux Compression H.264 Record Rate 1280x720p : 120fps 1920x1080p : 60fps Mode Manual &...
  • Page 87 Item Details Dual codec (CIF120fps/2CIF120fps/4CIF120fps) Transmission speed Single codec (720p, 1080p) Bandwidth Up to (15)Mbps,15M~256kbps Bandwidth control Selectable Network Stream 720p, 1080p (Record Encoding), 4CIF/2CIF/CIF (Dual codec) Selectable Remote users 10 users (two users for searching are included) Protocol support TCP/IP/DHCP/HTTP, PPPoE/DDNS(iPOLiS only)/NTP/SMTP/TLS Monitoring NET-i Viewer, Smart viewer, Webviewer...
  • Page 88 USB 2.0, Front 2 ports Connections e-SATA 1 External SATA ports Application Supoort Mouse, Remote Controller, Samsung System Keyboard (SPC-6000) PTZ Protocol support SAMSUNG-E / SAMSUNG-T / PELCO-D / PELCO-P General Input Voltage /Current 100 to 240 VAC ±10%; 50/60 Hz, Autoranging...
  • Page 89: Product Overview

    PRODUCT OVERVIEW unit : mm (inches) 412 (16.22) 445 (17.51) 88 (3.46) English _89...
  • Page 90: Troubleshooting

    appendix TROUBLESHOOTING Symptom Countermeasures • Check if the power supply system is properly connected. The system does not turn on and the indicator on the • Check the system for the input voltage from the power source. front panel does not work at all. •...
  • Page 91 Symptom Countermeasures • Menu No response is made even if I press the [PTZ] button on Network Remote Device Check if the current protocols and the Live screen. other settings in the PTZ device are properly configured according to the PTZ camera.
  • Page 92 appendix Symptom Countermeasures • Make sure the channel to be recorded is fed with video from the camera. Recording does not work. • Check the recording mode settings. • Check whether the HDD is available for recording. • If set to Continuous or Event Recording, check whether the recording schedule includes the current time.
  • Page 93: Open Source License Report On The Product

    The software included in this product contains copyrighted software that is licensed under the GPL/LGPL. You may obtain the complete Corresponding Source code from us for a period of three years after our last shipment of this product by sending email to <help.cctv@samsung.com>.
  • Page 94 Thus, it is not the intent of this section to claim rights or contest your 8. If the distribution and/or use of the Program is restricted in certain rights to work written entirely by you; rather, the intent is to exercise the countries either by patents or by copyrighted interfaces, the original right to control the distribution of derivative or collective works based on copyright holder who places the Program under this License may add an...
  • Page 95: Terms And Conditions

    Gnomovision version 69, Copyright (C) year name of author make it effectively proprietary. To prevent this, the GPL assures that patents cannot be used to render the program non-free. Gnomovision comes with ABSOLUTELY NO WARRANTY; for details The precise terms and conditions for copying, distribution and type `show w’.
  • Page 96 terms of this License in conveying all material for which you do not d) Convey the object code by offering access from a designated place control copyright. Those thus making or running the covered works for (gratis or for a charge), and offer equivalent access to the you must do so exclusively on your behalf, under your direction and Corresponding Source in the same way through the same place at no control, on terms that prohibit them from making any copies of your...
  • Page 97 d) Limiting the use for publicity purposes of names of licensors or include claims that would be infringed only as a consequence of further authors of the material; or modification of the contributor version. For purposes of this definition, “control” includes the right to grant patent sublicenses in a manner e) Declining to grant rights under trademark law for use of some trade consistent with the requirements of this License.
  • Page 98 choose that version for the Program. GNU GPL, see <http://www.gnu.org/licenses/>. Later license versions may give you additional or different permissions. The GNU General Public License does not permit incorporating your However, no additional obligations are imposed on any author or program into proprietary programs.
  • Page 99 a de-facto standard. To achieve this, non-free programs must be allowed same sections as part of a whole which is a work based on the Library, to use the library. A more frequent case is that a free library does the the distribution of the whole must be on the terms of this License, whose same job as widely used non-free libraries.
