Contents Contents Introduction ........3 Playback Operation ....17 About this manual........3 Basic operation.......... 17 Supplied accessories ........3 Selecting a track/chapter ........17 Region codes ..........3 Searching backward/forward ......17 Playable disc formats ........4 Repeat/Shuffle functions ......17 Cleaning discs..........
Page 4
Contents Setup Menu ........25 Language Codes ......41 Menu overview ........... 25 Setup menu operation ....... 27 Troubleshooting......42 General setup menu ........28 Locking/Unlocking the disc for viewing...28 Glossary........46 Recording CD tracks onto your USB device ..28 Programming disc tracks Specifications......
Introduction Introduction About this manual Region codes Thank you for purchasing this unit. This This unit is designed to support the region owner’s manual explains the basic operation management system. Check the regional code of this unit. number on the DVD disc package. If the •...
Introduction Playable disc formats Notes • CD-R/RW, DVD-R/RW/R DL, and DVD+R/RW/ This unit is designed for use with discs having R DL cannot be played unless finalized. the logos shown below. Do not attempt to load • Progressive JPEG, copyright-protected WMA any other type of disc into this unit.
Introduction Patent information Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories. Manufactured under license under U.S. Patent No’s : 5,451,942 and other U.S. and worldwide patents issued and pending. DTS and DTS Digital Out are registered trademarks and the DTS logos and Symbol are trademarks of DTS, Inc.
Functional Overview Functional Overview Front panel STANDBY/ON Front panel display Turns on this unit or sets it to the standby mode Shows the current status of this unit. (see page 13). In the standby mode, this unit Remote control sensor consumes a small amount of power in order to Receives infrared signals from the remote receive infrared signals from the remote control.
Connect the REMOTE CONTROL (IN) jack of this unit to the remote control output jack of ) jacks your Yamaha AV receiver (see page 12). Connect to the component input jacks of your Connect the REMOTE CONTROL (OUT) jack AV receiver (see page 10).
Functional Overview Remote control Stops playback (see page 17). Opens the disc tray.* Numeric buttons (0-9) Selects numbered items in the currently displayed menu. SUBTITLE Selects the subtitle language (see pages 20 and 22). ZOOM Enlarges or shrinks the video image (see pages 18 and 22).
Connections Connections General notes on connections Notes • You need to set [DIGITAL OUTPUT] to [ALL] Be sure to turn off this unit and unplug the (see “DIGITAL OUTPUT” on page 32). power cable before you make or change • If the audio format of the digital output does not connections.
Connections commercially available component video Video connections cable. Observe the color of each jack when you make connections. Make video connections to your receiver and If your receiver does not have component TV so that you can use one TV for several output jacks, you can achieve a better video different video sources (LD, VCR, etc.) by image by connecting the component output...
Connections HDMI connection Notes • You need to set [HDMI AUDIO] (see page 32) and [HDMI VIDEO] (see page 36) properly. HDMI jack • You need to make appropriate audio connections HDMI (High-Definition Multimedia if the connected component does not output audio Interface) provides high quality digital audio signals (see “Audio connections”...
Connections Remote control jacks Other connections This unit has remote control input/output jacks. If your AV receiver is a Yamaha product USB port and has the capability to transmit SCENE This unit has a USB port and can access MP3, control signals, you can use the SCENE ®...
Getting Started Getting Started Using the remote control Step 1: Inserting batteries into Use the remote control within 6 m the remote control (approximately 20 ft) of this unit and point it toward the remote control sensor. Within 6 m (approximately 20 ft) Open the battery compartment.
Getting Started Step 3: Setting a TV type/display Select this if the connected TV is a PAL and language system TV. It will change the video signals of NTSC discs and output them in PAL format. You can customize this unit using the setup NTSC menu displayed on the TV screen.
Getting Started Setting an aspect ratio for your TV Setting the OSD Language You can set the aspect ratio of this unit to You can select your own preferred language match your TV. If the aspect ratio of your TV for the setup menu.
Getting Started To select a language not in the list Setting the audio, subtitle, and disc Select [OTHERS] in [AUDIO], menu languages (DVD-Video only) [SUBTITLE], or [DISC MENU], and then You can select your own preferred language press ENTER. for the audio, subtitle, and disc menu. This unit automatically switches to the selected Use the numeric buttons (0-9) to enter language whenever you load a disc.
Playback Operation Playback Operation Selecting a track/chapter Notes 2 2 / 33 or use the numeric Press • If the prohibited icon ( ) appears on the TV screen when a button is pressed, the function for buttons (0-9) to select a track/chapter that button is not available on the current disc or number.
Playback Operation VCD/SVCD/CD To select a playback feature or item RPT ONE (repeat track) Use 2 / 3/5/a or the numeric RPT ALL (repeat all) buttons (0-9), and then press ENTER to SHUFFLE (shuffle) start playback. RPT SHF (shuffle repeat) RPT OFF (repeat off) To access or exit from the menu ®...
Playback Operation Press 5/a to scroll the information, and Load one of the last ten discs. then press ENTER to access the selected “LOADING” appears on the TV item. screen. Press 3 / 8 while “LOADING” is Use the numeric buttons (0-9) to input the number/time or press 5/a to make a displayed on the TV screen.
Playback Operation For Audio and Subtitle: Selecting an audio language/ Press 5/a to highlight your selection, and format and subtitle language then press ENTER. To select an audio language/format For Angle: Press AUDIO repeatedly to select an audio Select an angle using the numeric language and/or format.
Playback Operation Selecting a folder and track/file Playing data discs ® (MP3/WMA/WMV/JPEG/DivX Press 5/a to select a folder, and then press ENTER to open the folder. Load a data disc. Press 5/a to select a track/file. • The disc reading time may exceed 30 Press ENTER.
Playback Operation Use 2 / 3/5/a to highlight one of the During MP3 music playback, select a thumbnails, and then press ENTER to start JPEG picture file from the TV screen, and playback. then press ENTER. The picture files are played back one after another until the end of the folder.
Playback Operation To select a subtitle language Notes During playback, press SUBTITLE to • Some devices may not work properly. switch or turn on/off the subtitle language • If “Device not supported” appears on the TV recorded on the contents. screen when you connect the USB device, follow the procedure below.
Page 26
After exiting from the USB mode, disconnect the USB device from this unit. Notes • Yamaha and suppliers accepts no liability for the loss of data saved on the USB devices connected to this unit. As a precaution, it is recommended that the files are made backup copies.
Setup Menu Setup Menu Menu overview The bold items/parameters listed below are the default settings. The menu items, setting items, and default settings may change depending on the models. Setup page Menu item Setting Item/Submenu Setting item/Parameter Page GENERAL DISC LOCK LOCK, UNLOCK SETUP PAGE MP3 RECORD...
Page 28
Setup Menu Setup page Menu item Setting Item/Submenu Setting item/Parameter Page PREFERENCE AUDIO ENGLISH (Europe, U.S.A., Canada, PAGE Central and South America, Australia, and Asia models), RUSSIAN (Russia model), KOREAN (Korea model), etc. SUBTITLE OFF (Europe, U.S.A., Canada, Central and South America, Australia, and Asia models), RUSSIAN (Russia model), KOREAN (Korea model), etc.
Setup Menu Press 5/a to highlight the desired menu Setup menu operation item. Menu items and setting items appear. Setup is carried out on the TV, enabling you to customize this unit to suit your own particular requirements. Follow the procedures below to VIDEO SETUP PAGE start the setup menu operations.
Unauthorized use of copyrighted recordings can be copyright infringement. GENERAL SETUP PAGE • Yamaha and suppliers accepts no liability for the DISC LOCK loss of data saved on the USB devices connected MP3 RECORD to this unit. As a precaution, it is recommended...
Page 31
Setup Menu In “MP3 RECORD”, press 5/a to • The tracks may be displayed on more highlight [SPEED], and then press ENTER than one page in “TRACK”. In this case, press 5/a to select repeatedly to select the desired setting. and then press ENTER to scroll MP3 RECORD through pages.
Setup Menu Repeat steps 3-4 to input another track/ Note chapter number. You cannot edit the files on your USB device To remove a track connected to this unit by using this unit (for example, deleting or renaming the files). Use 2 / 3/5/a to select the track you want to remove.
• Select [ANALOG OUTPUT] in registration code “AUDIO SETUP PAGE”. ® Yamaha provides you with a DivX STEREO (Video On Demand) registration code that Select this to change channel output to stereo, allows you to rent and purchase videos using which only delivers sound from the two front ®...
Setup Menu 96KHz Setting the digital output Select this to play back discs recorded at the The [DIGITAL AUDIO] options are: sampling rate of 96 kHz. If the 96 kHz disc is [DIGITAL OUTPUT] and [LPCM OUTPUT]. copy protected, the digital output is automatically converted to the sampling rate of In “AUDIO SETUP PAGE”, press 5/a to 48 kHz.
Setup Menu TV type This unit can output the following audio signals This menu contains the options for selecting using HDMI: 32/44.1/48 kHz, 2ch linear PCM the color system that matches your TV. For signals and bitstream signals (Dolby Digital and details, see “Setting a color system for your DTS).
Setup Menu When the aspect ratio of your TV is 16:9 Notes on activating progressive scan: • Ensure that your TV is equipped with (widescreen): progressive scan. Playback Setting TV display • Connect using a component video cable. disc • When making HDMI connections, you cannot select [PROGRESSIVE].
Setup Menu The “PERSONAL PICTURE SETUP” Turning the black level on/off menu appears. When [TV TYPE] is set to [NTSC] (see page 14), this menu is effective for improving the visibility of the black color in the dark area PERSONAL PICTURE SETUP on the screen.
Setup Menu SUPERWIDE Note Select to display a 4:3 image on the 16:9 screen with non-linear stretching (center position of This function is only available for NTSC video screen is stretched less than the sides). format and composite video / S-video output. 4:3 PILLAR BOX Switching YUV/RGB Select to display a 4:3 image on the 16:9 screen...
Setup Menu Preference setup menu Notes • For the settings other than [AUTO], images may Press 7 twice to stop playback (if necessary) not be displayed properly if a resolution output before pressing SET UP. setting is not supported by the HDMI component you are using.
Setup Menu In “PREFERENCE PAGE”, press 5/a to ORIGINAL LIST highlight [PARENTAL], and then press 3. Select this to play the originally recorded titles on the disc. PLAY LIST Select this to play the edited version of the PREFERENCE PAGE disc.
Setup Menu GROUP1: Selecting the PBC (playback Albanian (sq), Basque (eu), Catalan (ca), control) function Danish (da), Dutch (nl), English (en), You can set playback control (PBC) to on or Faroese (fo), Finnish (fi), French (fr), off. This function is available only on Video German (de), Icelandic (is), Irish (ga), CD 2.0 with the playback control (PBC) Italian (it), Norwegian (no),...
Setup Menu Enter the new six-digit password. Changing the password Enter the new six-digit password again to The same password is used for both parental confirm the password. control and disc lock. Enter your six-digit password when prompted on the screen. The Press ENTER to confirm your new default password is 000 000.
Language Codes Language Codes These codes can be used to select other languages. This does not affect the options in “AUDIO”, “SUBTITLE”, or “DISC MENU”. Abkhazian 6566 Gaelic 7168 Macedonian 7775 Sardinian 8367 Afar 6565 Gallegan 7176 Malagasy 7771 Scottish Gaelic 7168 Afrikaans 6570...
Refer to the chart below when this unit does not function properly. If the problem you are experiencing is not listed below or if the instruction below does not help, set this unit to the standby mode, disconnect the power cable, and contact the nearest authorized Yamaha dealer or service center.
Page 45
Troubleshooting Problem Solution No picture is displayed when Follow the steps below to turn off the progressive scan. you do not use progressive 1. Press OPEN/CLOSE ( ) on the front panel or press and hold scan connections (using the on the remote control to open the disc tray.
Page 46
Troubleshooting Problem Solution Buttons do not work To completely reset this unit, unplug the AC cord from the AC outlet for 5-10 seconds, plug the AC cord to the AC outlet again, and then turn on this unit. This unit does not respond to Some operations may not be permitted by the disc.
Page 47
Troubleshooting Problem Solution This unit stops recording CD If “Max files reached” appears on the TV screen, delete any files you do tracks onto your USB device not need or create a new folder and then move some files to the created folder so that the number of files on a root directory in your USB device is reduced.
Glossary Glossary ® Analog DivX Ultra ® Sound that has not been converted into numerical DivX Ultra Certified products provide enhanced values. Analog sound varies, while digital sound has playback of advanced media features supported by the ® specific numerical values. These jacks send audio DivX Media Format.
Page 49
Glossary Interactive menu Region code Interactive video menus offer unprecedented A system for allowing discs to be played back only in convenience and control so you can quickly navigate the region designated beforehand. This unit will only between various scenes or bonus features, and select play discs that have compatible region codes.
Specifications Specifications PLAYABLE DISC FORMATS TV STANDARD • DVD-Video • Number of lines ......PAL: 625, NTSC: 525 • DVD-R, DVD-RW, DVD-R DL • Vertical frequency....PAL: 50 Hz, NTSC: 60 Hz • DVD+R, DVD+RW, DVD+R DL • Playback.......Multi-standard (PAL/NTSC) • Video CD, SVCD CONNECTIONS •...
Page 51
定值高的电压是危险的并可能导致火灾,损坏 本机或造成人体伤害。Yamaha 将不对由于在本 机上使用非规定电压而造成的任何损害负责。 13 请勿尝试修改或修理本机。当需要任何维修时 AVOID DIRECT EXPOSURE TO THE BEAM DANGER: INVISIBLE LASER RADIATION WHEN OPEN 请联系专业 Yamaha 维修人员。不能以任何理由 DO NOT STARE INTO BEAM CAUTION: 打开机壳。 INVISIBLE LASER RADIATION WHEN OPEN 14 当准备长时间 (例如休假)不使用本机时,请 将 AC 电源线从墙上插座断开。 15 对通常的操作错误,在断定本机出故障之前,...
将本机的 REMOTE CONTROL (IN) 插孔连接到 您的 Yamaha AV 接收机的遥控输出插孔 VIDEO OUT - S VIDEO 插孔 (请参阅第 12 页) 。将本机的 REMOTE 连接到您的 AV 接收机的 S- 视频输入插孔 CONTROL (OUT) 插孔连接到您的 Yamaha 装置 ( 请参阅第 10 页 )。 的遥控输入插孔。 VIDEO OUT - VIDEO 插孔 HDMI 插孔...
USB 装置 AV 接收机 • 关于 SCENE 功能的详情,请参考您的 Yamaha AV 接收机附带的说明书。 注 • 您可以将具有 SCENE 功能的 Yamaha 装置 (比如 DVD 播放机和 CD 播放机)连接到本机 本机也许不能识别某些 USB 装置。 的 REMOTE CONTROL (OUT) 插孔。 有关 USB 的详情,请参阅第 23 页上的 “使用 USB 装置” 。...
开始 设置电视机的宽高比 设置 OSD 语言 您可以设置本机的宽高比以匹配您的电视 您可以为设置菜单选择自己喜欢的语言。 机。当您的电视机的宽高比为 16:9 则没有 一旦选择,该设置保持不便。 必要改变此设置。有关详情,请参阅第 33 页上的 “设置电视机显示” 。 GENERAL SETUP PAGE DISC LOCK ENGLISH MP3 RECORD DANSK VIDEO SETUP PAGE PROGRAM DEUTSCH TV TYPE DISPLAY DIM ESPAÑOL TV DISPLAY 4:3 PAN SCAN OSD LANGUAGE FRANÇAIS PROGRESSIVE...
