Thank you for purchasing this Panasonic Product.
Before operating this product, please read the instructions carefully, and save this manual
J
for future use.
Before using your projector, be sure to read "Read this first!" (See pages 2 to 6).
J
Operating Instructions
DLP
Projector
™
Model No.
Functional Manual
Commercial Use
P T-LX300E
PT-LX270E
ENGLISH
TQBJ0609
Advertisement
Table of Contents
Related Manuals for Panasonic PT-LX300E
Summary of Contents for Panasonic PT-LX300E
-
Page 1: Operating Instructions
P T-LX300E Model No. PT-LX270E Thank you for purchasing this Panasonic Product. Before operating this product, please read the instructions carefully, and save this manual for future use. Before using your projector, be sure to read “Read this first!” (See pages 2 to 6). -
Page 2: Read This First
Read this first! WARNING: THIS APPARATUS MUST BE EARTHED. WARNING: To prevent damage which may result in fire or shock hazard, do not expose this appliance to rain or moisture. The sound pressure level at the operator position is equal or less than 70 dB (A) according to ISO 7779. WARNING: Remove the plug from the mains socket when this unit is not in use for a prolonged period of time. - Page 3 Read this first! WARNING: POWER „ The wall outlet or the circuit breaker shall be installed near the equipment and shall be easily accessible when problems occur. If the following problems occur, cut off the power supply immediately. Continued use of the projector in these conditions will result in fire or electric shock. If foreign objects or water get inside the projector, cut off the power supply.
- Page 4 If liquid enters inside of the projector, consult your dealer. Particular attention must be paid to children. Use the ceiling mount bracket specified by Panasonic. Defects in the ceiling mount bracket will result in falling accidents. Attach the supplied safety cable to the ceiling mount bracket to prevent the projector from falling down.
- Page 5 Read this first! The battery can cause personal injury if swallowed. If swallowed, seek medical advice immediately. If the battery fluid leaks, do not touch it with bare hands, and take the following measures if necessary. Battery fluid on your skin or clothing could result in skin inflammation or injury. Rinse with clean water and seek medical advice immediately.
-
Page 6: Remote Control Battery
Read this first! If the lamp has broken, ventilate the room immediately. Do not touch or bring your face close to the broken pieces. Failure to observe this will cause the user to absorb the gas which was released when the lamp broke and which contains nearly the same amount of mercury as fluorescent lamps, and the broken pieces will cause injury. - Page 7 - Quiet 29 dB design does not Æ page 22) interrupt meetings or classes. (Lamp power mode: ECO) (* 3 000 lm is for PT-LX300E. 2 700 lm is for PT-LX270E.) 3. Connect the power cord. Æ page 24) Eco Friendly Performance...
-
Page 8: Table Of Contents
Contents Be sure to read “Read this first!”. ( pages 2 to 6) Basic operation by using remote Important Information control........... 28 Read this first! ........... 2 Switching the input signal ..........28 <LAMP> button ............28 Contents ............. 8 <INFO.>... - Page 9 Contents Audio ............39 Mute ................39 Volume ................. 39 In Standby Mode (Audio) ..........39 Options ............. 40 Auto Source ..............40 Input ................40 Auto Power Off (Min) ............ 40 Lamp Settings .............. 40 High Altitude ..............41 Information ..............
-
Page 10: Precautions For Use
Precautions for Use Cautions when transporting When transporting the projector, hold it securely by its bottom and avoid excessive vibration and impacts. Doing so may damage the internal parts and result in malfunctions. Do not transport the projector with the adjustable feet extended. Doing so may damage the adjustable feet. Cautions when installing Do not set up the projector outdoors. -
Page 11: Security
Security instruction Make your password as difficult to guess as possible. Change your password periodically. Panasonic or its affiliate company never inquires a password directly to a customer. Do not tell your password in case you receive such an inquiry. Disposal When disposing of the product, ask your local authority or dealer about the correct methods of disposal. -
Page 12: Cautions On Use
To assure continued compliance, follow the attached installation instructions, which include using the provided power cord and shielded interface cables when connecting to computer or peripheral device. Importer's name and address within the European Union Panasonic Marketing Europe GmbH Panasonic Testing Center Winsbergring 15, 22525 Hamburg, Germany... -
Page 13: Accessories
Precautions for Use Accessories Make sure the following accessories are provided with your projector. Numbers in the brackets ( ) show the number of accessories. Wireless remote control VGA cable (x1) Lithium coin cell Battery CD-ROM (x1) unit (x1) (H4200200G105) CR2025 (x1) (H368UB01G001) (H458UB01G001) -
Page 14: About Your Projector
About Your Projector Remote control (13) <VIDEO> button Switches to Video source. (14) <KEYSTONE +> button Adjusts the image to compensate for distortion (11) caused by tilting the projector. (15) <IMAGE> button (12) Selects the color mode among Dynamic, PC, (13) Movie, Game and User. -
Page 15: Projector Body
About Your Projector Projector body 12 9 12 9 12 8 12 4 12 7 12 5 12 6 (1) Control panel and indicators ( Æ page 16) (10) Security slot Attaches the commercial shackle lock, (2) Zoom lever manufactured by Kensington, to protect your (3) Air intake port projector. -
Page 16: Control Panel And Indicators
About Your Projector Control Panel and Indicators (6) ▲▼◄► buttons (1) <ON(G) / STANDBY(R)> indicator Uses to operate menu. Indicates the projector’s status. (7) Unavailable button (2) < v / b > button (8) <TEMP> indicator Turns the projector on/off. Indicates the status of the internal temperature or (3) <INPUT>... -
Page 17: Connecting Terminals
About Your Projector Connecting terminals Note (1) <HDMI IN> Input When the <HDMI IN> terminal is connected to a computer Connects to HDMI input signals. via a HDMI-DVI conversion cable, it can only input video (2) <COMPUTER IN> signal and the analog audio signal can not be input. Connects to COMPUTER IN input signal. -
Page 18: Using Remote Control
Using Remote control Using Remote control Installing and Removing battery Press the guide and pull Install new battery into Put the battery base out the battery base. the compartment. back. Remove the old Lithium coin cell battery and install new one (CR2025). Ensure that the side with a “+”... -
Page 19: Setting Up
Setting up Setting up Projection method You can use the projector with any of the following 4 projection methods to set the desired method in the projector. Setting on a desk/floor and Mounting on the ceiling and projecting forward projecting forward Menu setting* Menu setting* Ceiling Mount Front... -
Page 20: Screen Size And Throw Distance
Setting up Screen size and throw distance Place the projector referring to the diagram on the right and the figures of throwing distance. You can adjust the display size. Attention Before installing, please read “Precautions for Use”. ( Æ pages 10 to 13) Do not use the projector and the high-powered laser equipment in the same room. -
Page 21: Adjusting The Projector's Height
Setting up Calculation formulas for projection distance Any other projection distance can be obtained according to the screen dimensions (m) using the following calculations. The calculation result is with the "m" unit. (The calculated distance below may contain a certain error.) If the screen dimensions are written as "SD", For 4:3 aspect ratio For 16:9 aspect ratio... -
Page 22: Connections
Connections Before connecting to the projector Read carefully the instruction manual for the device to be connected. Turn off the power switch of the devices before connecting cables. If any connection cable is not supplied with the device, or if no optional cable is available for connection of the device, prepare a necessary system connection cable to suit the device. -
Page 23: Connecting Example: Computers
Connections Connecting example: Computers Control Computer Computer Monitor Audio equipment Computer Connecting example: AV equipment Blu-ray disk DVD player Audio equipment player (with built-in TBC) ENGLISH -... -
Page 24: Basic Operation
Basic Operation Powering ON/OFF Powering ON/OFF Connecting the power cord Use the supplied power cord to prevent removal of the power cord and make sure that it is fully inserted into the projector. For detailed power cord handling, refer to “Read this first!” ( pages 2 to 6). -
Page 25: On(G)/Standby(R) Indicator
Powering ON/OFF ON(G)/STANDBY(R) indicator The ON(G)/STANDBY(R) indicator informs you the status of the power. Confirm the status of the <ON(G)/STANDBY(R)> indicator before operating the projector. <ON(G)/STANDBY(R)> indicator Indicator status Status No illumination or blinking The power plug is not connected to the outlet. The power is switched off. -
Page 26: Powering On The Projector
Powering ON/OFF Powering On the Projector Connect the power plug to the power outlet. Enter Standby status when the <ON(G)/STANDBY(R)> indicator is lighting / blinking in red. Press the < v / b > button on the control panel or the remote control. When the <ON(G)/STANDBY(R)>... -
Page 27: Projecting
Projecting Projecting Check the connections of the peripheral devices and connection of the power cord ( page 24) and switch on the Æ power ( page 26) to start the projector. Select the image and adjust the state of the image. Æ... -
Page 28: Basic Operation By Using Remote
Basic operation by using remote control Basic operation by using remote control <INFO.> button Press this button to display the [Information] menu. Button Press the <INFO.> button on the remote control. Note Æ For details, see “Information”. ( page 41) <FREEZE>... -
Page 29: Image> Button
Basic operation by using remote control <IMAGE> button <MUTE> button Press this button to display the [Picture mode] menu Press this button to temporarily turn off the sound. and to change the settings of the image. Button Button Press the <MUTE> button on the remote Press the <IMAGE>... -
Page 30: Settings
Settings On-screen Display Menus On-screen Display Menus How to operate menu Operation steps Press <MENU> button on the remote control or on the control panel. Main Menu displays. Use ▲▼ to select any item in the Main Menu. The selected item is highlighted in orange. Press ►. -
Page 31: Menu Tree
On-screen Display Menus Menu Tree Main Menu Sub Menu 2nd Sub Menu Default Value Range Color Mode Dynamic / PC / Movie / Game / User Wall color White / Light Yellow / Light Blue / White Pink / Dark Green Brightness 0 ~ 100 Contrast... - Page 32 On-screen Display Menus Main Menu Sub Menu 2nd Sub Menu Default Value Range Auto Source On / Off Input HDMI, Computer, Video Auto Power Off (Min) 0~120 Lamp Hours Used (Normal) Lamp Hours Used (ECO) Lamp Life Off/On Reminder Lamp Normal / AUTO / ECO Normal Lamp Settings...
-
Page 33: Picture
Picture Picture Wall color Select [Picture] from the Main Menu (see “How to operate menu” on page 30) and then select Select an appropriate color for wall projection. the item from the Sub Menu. Press ▲▼ to select [Wall color]. Press ►... -
Page 34: Sharpness
Picture Sharpness Gamma You can adjust the sharpness of the projected image. Adjust the gamma table when the dark areas or bright areas of the image is not clear. Press ▲▼ to select [Sharpness]. Press ▲▼ to select [Gamma]. Press ► to display the adjustment dialog box. -
Page 35: Position
Position Position Note Select [Position] from the Main Menu (see “How If an aspect ratio which is different from the aspect ratio to operate menu” on page 30) and then select for the input signals is selected, the pictures will appear the item from the Sub Menu. -
Page 36: Position
Position V Position Press the ▼◄ on the remote control Shift the projected image position vertically. or the ◄ on the control panel to Press ▲▼ to select [V Position]. adjust the bottom of Press ► to display the adjustment the keystone. -
Page 37: Setting
Setting Do not display Closed Caption. Select [Setting] from the Main Menu (see “How to operate menu” on page 30) and then select Displays the CC1 data. the item from the Sub Menu. Displays the CC2 data. Displays the CC3 data. Displays the CC4 data. -
Page 38: Remote Id
ID on the Æ projector. ( page 18) Startup Logo Set this function to display the Panasonic logo when the projector is turning on. Press ▲▼ to select [Startup Logo]. Press ► to display the setting dialog box. -
Page 39: Audio
Audio In Standby Mode (Audio) Select [Audio] from the Main Menu (see “How to operate menu” on page 30) and then select This function is used to switch the output audio signal the item from the Sub Menu. from the <VARIABLE AUDIO OUT> terminal On/Off at standby mode. -
Page 40: Options
Options Options The input with a check mark will be able to be Select [Options] from the Main Menu (see “How searched when [Auto Source] is set to [On]. to operate menu” on page 30) and then select To remove the check mark, choose the desired the item from the Sub Menu. -
Page 41: High Altitude
Options Lamp Power Mode Information Selects desired lamp power mode under different situations. Displays the input signal source and setting state information of the projector. Press ▲▼ to select [Lamp Power Mode]. Press ▲▼ to select [Information]. Press ► to display the setting dialog box. Press ►... -
Page 42: Maintenance
Maintenance About indicator status About indicator status If an indicator turns on If a problem should occur inside the projector, the <TEMP> and/or <LAMP> indicators will inform you. Manage the indicated problems as follow. Attention Before you take a remedial measure, follow the procedure of switching the power off indicated in “Powering off the projector”. -
Page 43: Maintenance/Replacement
Maintenance/replacement Before cleaning/replacing the unit When you perform maintenance or replacement of the parts, make sure to turn off the power and disconnect Æ the power plug from the wall outlet. ( pages 24, 26) Æ Be sure to observe the procedure “Powering off the projector” ( page 26) when performing power supply operation. -
Page 44: Replacing The Unit
The lamp replace time, it is necessary to carry the following calculation. Confirm the lamp used time in the [LAMP settings] Æ page 40). For PT-LX300E, Lamp use time = [Lamp used time (Normal)] + [Lamp used time (ECO)] × 0.75 For PT-LX270E, Lamp use time = [Lamp used time (Normal)] + [Lamp used time (ECO)] × 0.833 The usage period of 4 500 hours / 5 000 hours is a rough estimate and is not guaranteed. -
Page 45: Replacing The Lamp Unit
Maintenance/replacement Replacing the Lamp unit Attention When the projector is mounted on a ceiling, do not work with your face close to the projector. Attach the lamp unit and the lamp cover securely. When you experience difficulty in installing the lamp, remove it and try again. If you use force to install the lamp, the connector may be damaged. -
Page 46: Troubleshooting
Troubleshooting Troubleshooting Please check following points. For details, see the corresponding pages. Reference Problem Cause page The power cord may not be connected. — No electric supply is at the wall outlet. — Power does not turn The circuit breakers have tripped. —... - Page 47 1. First, follow the steps above to adjust resolution of the computer. 2. Press the appropriate keys listed below for your notebook manufacturer to send signal out from notebook to projector. Partial, scrolling Panasonic [Fn]+[F3] SAMSUNG [Fn]+[F4] or incorrectly Gateway [Fn]+[F4] Acer ...
- Page 48 Troubleshooting Reference Problem Cause page Lamp Warning Message: The lamp has reached its end of life, please replace it as soon as possible. Fan Locked Warning Message: Messages displays This shows the fan has stopped during projection and the power will be shut off soon.
-
Page 49: Appendices
Appendices Appendix Appendix Serial terminal The serial connector which is on the connector panel of the projector conforms to the RS-232C interface specification, so that the projector can be controlled by a personal computer which is connected to this connector. Connection Connecting terminals on projector... -
Page 50: Basic Format
Appendix Basic format Transmission from the computer begins with STX, then the command, parameter, and ETX are sent in this order. Add parameters according to the details of control. Colon (1 byte) Start 3 command Parameter (1 byte) characters (undefined length) (1 byte) (3 bytes) When sending commands without parameters, a colon (:) is not necessary. -
Page 51: Control Commands
Appendix Control commands When controlling the projector from a computer, the following commands are available: [Projector control command] Command Control contents Remarks Power [ON] Power [OFF] (Parameter) VID = Video INPUT selection RG = Computer HD1 = HDMI Turning off the projection and sound temporarily. AV mute function Sending the command switches [ON]/[OFF]. -
Page 52: Other Terminals
Appendix Other terminals Pin assignments and signal names of <COMPUTER IN> terminal Pin No. Signal names Outside view G/G SYNC/Y + 5 V DDC data HD/SYNC : Not assigned DDC clock : GND terminals Pin assignments and signal names of <MONITOR OUT> terminal Pin No. -
Page 53: List Of Compatible Signals
Appendix List of compatible signals The following table specifies the types of signals compatible with the projectors. Format : V = VIDEO, R = RGB, Y = YP , H = HDMI Scanning Plug and play * Display Dot clock frequency Mode resolution *... - Page 54 Appendix Scanning Plug and play * Display Dot clock frequency Mode resolution * frequency Format (dots) (MHz) H (kHz) V (Hz) COMPUTER HDMI 63.98 60.0 108.00 SXGA 1 280 x 1 024 79.98 75.0 135.00 91.15 85.0 157.50 1366x768 1 366 x 768 47.72 59.8 84.75...
-
Page 55: Specifications
Specifications Specifications Model No. PT- LX300E PT-LX270E Power supply AC 100 V -240 V 50/60Hz 100 V -240 V 2.7 A -1.0A, 218 W 100 V -240 V 2.4 A -0.9A, 218 W Standby power consumption Power consumption 0.5 W When [VGA Out (Standby)]/[In Standby Mode (Audio)] are all set to [Off]. 1.2 W When one or more among [VGA Out (Standby)]/[In Standby Mode (Audio)] is/are set to [On]. - Page 56 Specifications Model No. PT-LX300E PT-LX270E 1 set, high-density D-Sub 15p (female) [RGB signal] 0.7 V [p-p] 75 Ω (When G-SYNC: 1.0 V [p-p] 75 Ω) HD/SYNC TTL high impedance, automatic positive/negative polarity compatible COMPUTER IN VD TTL high impedance, automatic positive/negative polarity compatible...
-
Page 57: Dimensions
Specifications Dimensions <Unit : mm (inch)> 118.7(4.67") 167.7 (6.60") 10.5 (0.41") 63.0 (2.48") 125.5 (4.94") Lens Center 55.0 (2.17") 110.0 (4.33") 286.3 (11.27") 88.2 (3.47") Lens Center 3.7° Max. 100.6 (3.96") 42.4 (1.67") 44.3 (1.74") Actual dimension may differ by product. ... -
Page 58: Ceiling Mount Bracket Safeguards
Ceiling mount bracket safeguards Ceiling mount bracket safeguards Installation work of the ceiling mount bracket should only be carried by a qualified technician. Even if it is during guaranteed period, the manufacturer is not responsible for any hazard or damage caused by using a ceiling mount bracket which is not purchased from an authorized distributors, or environmental conditions. -
Page 59: Index
Index About Your Projector.......14 ON(G)/STANDBY(R) indicator ..25 Accessories ........13 Optional accessories ......13 Adjusting the Projector's Height ..21 Other terminals .......52 Adjusting the zoom and focus ..21 Aspect Ratio ........35 Parts for ceiling mount (Optional) ...19 Auto Power Off (Min) ......40 Phase ..........35 Powering Off the Projector .....26 Before cleaning/replacing the unit ..43... - Page 60 Note for the battery symbol (bottom two symbol examples): This symbol might be used in combination with a chemical symbol. In this case it complies with the requirement set by the Directive for the chemical involved. Panasonic Corporation Web Site : http://panasonic.net/avc/projector/ © Panasonic Corporation 2013 M0613HY0 -ST...
