SPECiFiCaTioNS
Model Number EH-TW5910
Projection System rGb liquid crystal shutter projection system
Projection Method Front / rear / Ceiling mount
Pixel Number 2,073,600 dots (1920 x 1080) x 3
LCD
Native resolution 1080p
Size 0.61 - inch wide panel with Mla (D9, C2Fine, 12 bit)
light output / Colour light output (Colour brightness) 2,100lm / 2,100lm
Screen Size (Projected Distance) 30 to 300 inches [0.87 to 8.9m] (Zoom: Wide)
30 to 300 inches [1.42 to 14.5m] (Zoom: Tele)
Contrast 20,000:1
3D Format Frame Packing 1080p 24, 720p 50/60
Side by Side 1080p 50/60, 1080i 50/60, 720p 50/60
Top and bottom 1080p 24, 720p 50/60
WirelessHD N / a
Projection lens Type optical Zoom (Manual) / Focus (Manual)
F-number 1.51-1.99
Focal Length 18.2mm - 29.2mm
Throw ratio 1.32 - 2.15:1
Zoom ratio 1-1.6
lens Cover lens cap (Without string)
Lamp Type 230W uhE (E-Torl)
Fan Noise Power Consumption: ECo 24db (Colour mode: Cinema)
Supported Video Signals 480i / 576i / 480p / 576p / 720p / 1080i / 1080p
NTSC x 1 / NTSC4.43 x 1 / Pal x 1 / M-Pal x 1 / N-Pal x 1 / Pal60 x 1 / SECaM x 1
Digital input hDMi x 2
Video input Component x 1, Composite rCa (Yellow) x 1, audio l/r pair rCa (red/White) x 1
uSb PC-free Slideshow uSb type a x 1
analog rGb input D-sub 15pin x 1
Control i/o rS-232C
internal Speaker Sound output Stereo:10W x 2
Colour Mode auto, Dynamic, living room, Natural, Cinema, 3D Dynamic, 3D Cinema
adjustment Functions auto iris Controlled automatically adjusting to video source
(user selectable high Speed / Normal / off on oSD)
aspect Mode auto / Normal / Full / Zoom / Wide
Keystone Correction Vertical: -30 to +30 degrees (auto)
horizontal: -30 to +30 degrees (Slide)
operating Temperature 5° C to 35° C (41°F to 95°F)
Power Supply Voltage 100 - 240 V aC + / - 10%, 50/60 hz
Exhaust Direction Front
intake Direction Front
Excluding Feet (W x h x D) 420 x 137 x 365mm
Dimension
Maximum Dimension (W x h x D) 420 x 139 x 365mm
Weight approx. 13.23lbs./ 6.0kg
Super-resolution 5 Steps (2D Mode only)
2D - 3D Conversion 3 steps
Supplied accessories Power Cable (3m), remote Control, battery, user's Manual Set, hDMi Cable Clamp x 2,
WirelesshD Transmitter Set (Eh-TW6100W only)
Full hD 3D rF active shutter glasses x 1 (Eh-TW6100 & Eh-TW6100W only)
other Functions brightness Control, Epson Super White, Customized Gamma adjustment,
Six-axis Colour adjustment, advanced Sharpness adjustment,
Tilt angle (0 to 10.0 degrees), Memory (1-10)
oPTioNal aCCESSoriES
EH-TW6100 EH-TW6100W Spare lamp
air Filter 1 sheet
Ceiling Mount
Ceiling Pipe 668 - 918mm, White
2,300lm / 2,300lm 2,300lm / 2,300lm
918 - 1168mm, White
rF 3D Glasses
40,000:1 40,000:1
uSb Charging adaptor
N / a Supported
iNTErFaCES
1
Speaker
2
Power inlet
3
remote control light receiver
4
rS-232C port
5
PC input port
6
Component input port
7
audio (l-r) input port
8
Video input port
9
uSb port
10
Cable holder
11
hDMi1 input port
12
hDMi2 input port
approx 13.67lbs. /
6.2kg
The WiHD™ logo is licensed for use by WirelessHD, LLC.
For further information please contact your local Epson office or visit www.epson-europe.com
Not all products are available in all countries. Please check with your local Epson representative for details.
For more information please contact:
Telephone: 0871 222 6702 (uK)+
01 436 7742 (republic of ireland)
E-mail: enquiries@epson.co.uk
Chat: etalk.epson-europe.com
Fax: 0871 222 6740
+ Calls cost 10p per minute plus network extras.
Trademarks and registered trademarks are the property of Seiko Epson Corporation or their respective owners.
Product information is subject to change without prior notice.
ElPlP68
ElPaF38 ELPGS03
ElPMb22
ElPMb30
ElPFP13
ElPFP14
ELPAC01
ElPGS03
ElPaC01
Web: www.epson.co.uk
www.epson.ie
EPSON EH-TW5910, EH-TW6100 AND EH-TW6100W
BRIGHT 3D HD HOME
ENTERTAINMENT
