TECHNICAL & SERVICE MANUAL
CS-KE30NKU + CU-KE30NKU
CS-KE36NKU + CU-KE36NKU
DC INVERTER SPLIT SYSTEM AIR CONDITIONER
Indoor Model No.
CS-KE30NKU
CS-KE36NKU
CS-KE30NKU
CS-KE36NKU
IMPORTANT
These air conditioners employ new
refrigerant R410A.
Pay special attention when
servicing the unit.
Product Code No.
1 852 360 88
1 852 360 89
Indoor Unit
Outdoor Model No.
Product Code No.
CU-KE30NKU
1 852 360 82
CU-KE36NKU
1 852 360 83
Outdoor Unit
CU-KE30NKU
CU-KE36NKU
SM
700876
REFERENCE NO.
