Bosch MIC400 Quick Start Manual

MIC400 Quick Start Guide
CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK,
DISCONNECT POWER SUPPLY BEFORE OPENING THE POWER
SUPPLY UNIT.
POWER DISCONNECT: POWER SUPPLY UNITS HAVE POWER
SUPPLIED WHENEVER THE POWER CORD IS INSERTED INTO THE
POWER SOURCE
WARNING: INSTALLATION SHOULD BE CARRIED OUT BY QUALIFIED
PERSONNEL ONLY IN ACCORDANCE WITH THE APPLICABLE LOCAL
CODES.
BOSCH SECURITY SYSTEM ACCEPTS NO LIABILITY FOR ANY
DAMAGES OR LOSSES CAUSED DUE TO INCORRECT OR IMPROPER
INSTALLATION.
Unit Mechanical mounting
The upright unit can be mounted either way up with the camera ball up or down. The get the picture the correct
way up for installation with camera ball down rotate the camera tilt axis over by 180 degrees.
Please refer to the MIC400 Manual for further details of configuring Image Flip and reversing the controls for IR
unit and inverted units.
The MIC400, if canted is designed only to be mounted ball up, the tilt limits for the canted unit prevent it from
working properly if mounted ball down, the MIC412 and MIC440 cannot be canted.
WARNING: DUE CAUTION SHOULD BE EXERCISED WHEN
INSTALLING THE MIC400 RANGE OF CAMERAS, COMMON SENSE
PRECAUTIONS SUCH AS FITTING A SAFETY CHAIN SHOULD BE
FOLLOWED.
SPECIAL CARE SHOULD BE TAKEN WITH STAINLESS STEEL, MIC412
or MIC440 MODELS DUE TO THEIR EXTRA WEIGHT.
Bosch Security Systems Issue 1
