- Page 1 ATM/POS Bridge DVRXEAP01 Installation Manual...
-
Page 3: Table Of Contents
Configuring the Bridge for a Network Connection 5.1.1 Using the Bridge Detector Utility 5.1.2 Using the Direct Connection Configuring Operation via a Network 5.2.1 System Menu 5.2.2 Network Setup 5.2.3 Terminal 5.2.4 COM Port Bosch Security Systems, Inc. Installation Manual F.01U.171.816 | 1.0 | 2010.09... - Page 4 Configuring Bridge Operation via HyperTerminal 6.3.1 Network Setup 6.3.2 Communication Channels 6.3.3 Terminal Setup 6.3.4 Simulation Mode 6.3.5 Recording Language 6.3.6 Service Menu Troubleshooting Technical Data Updating Bridge Firmware F.01U.171.816 | 1.0 | 2010.09 Installation Manual Bosch Security Systems, Inc.
-
Page 5: Safety
Unplug the unit during lightning storms or when unused for long periods. Take precautions to protect the unit from power and lightning surges. Adjust only those controls specified in the operating instructions. Bosch Security Systems, Inc. Installation Manual F.01U.171.816 | 1.0 | 2010.09... - Page 6 For further information refer to: www.boschsecurity.com/standards NOTICE! Bosch has a strong commitment towards the environment. This unit has been designed to respect the environment as much as possible. F.01U.171.816 | 1.0 | 2010.09 Installation Manual Bosch Security Systems, Inc.
-
Page 7: Fcc & Ices Compliance
The user may find the following booklet, prepared by the Federal Communications Commission, helpful: How to Identify and Resolve Radio-TV Interference Problems. This booklet is available from the U.S. Government Printing Office, Washington, DC 20402, Stock No. 004-000-00345-4. Bosch Security Systems, Inc. Installation Manual F.01U.171.816 | 1.0 | 2010.09... - Page 8 Resolve Radio-TV Interference Problems (Comment identifier et résoudre les problèmes d’interférences de radio et de télévision). Cette brochure est disponible auprès du U.S. Government Printing Office, Washington, DC 20402, États-Unis, sous la référence n° 004-000-00345-4. F.01U.171.816 | 1.0 | 2010.09 Installation Manual Bosch Security Systems, Inc.
-
Page 9: Description
The ATM/POS Bridge is designed to operate with many different terminals. If you have any questions regarding the suitability of the firmware for your terminal or any other questions, contact your Bosch Security Systems, Inc. representative. Bosch Security Systems, Inc. -
Page 10: System Overview
The following illustration shows an example of how a bridge is used in a network of digital video recorders and ATM terminals. Figure 3.2 ATM terminal network ATM Terminal TCP/IP Network ATM/POS Bridge ATM Modem Recording Device F.01U.171.816 | 1.0 | 2010.09 Installation Manual Bosch Security Systems, Inc. -
Page 11: Installation
Determine a location where all incoming connections can reach the ATM/POS Bridge. Using the screws provided, attach the two mounting brackets to the sides of the bridge. Secure the brackets to a solid fixture. Bosch Security Systems, Inc. Installation Manual F.01U.171.816 | 1.0 | 2010.09... -
Page 12: Making Connections To The Bridge
Figure 4.1 ATM/POS Bridge connectors Ethernet RJ45 connector COM 3 RS-232 connector (console port) DC power input connector Activity indicator COM 4 RS485 connector COM 2 RS232 connector COM 1 RS232 connector F.01U.171.816 | 1.0 | 2010.09 Installation Manual Bosch Security Systems, Inc. - Page 13 Connect the other male connector to the printer. Connect the cable from the bridge to the open connector on the splitter cable. Refer to Section 5 Configuration, page 15 to configure the communication and terminal settings. Bosch Security Systems, Inc. Installation Manual F.01U.171.816 | 1.0 | 2010.09...
-
Page 14: Com Connector Detail
Note: The console cable has pin 9 connected to pin 5 (GND). When pin 9 of COM 3 (console) is at GND level on power-up, the bridge enters firmware download mode. F.01U.171.816 | 1.0 | 2010.09 Installation Manual Bosch Security Systems, Inc. -
Page 15: Configuration
Connect the RJ45 connector of the bridge via a straight Ethernet CAT5 network cable to a network switch or hub that supports 10BaseT. Bosch Security Systems, Inc. Installation Manual F.01U.171.816 | 1.0 | 2010.09... -
Page 16: Using The Direct Connection
Connect the bridge directly to a PC using an RJ45 cross- over Ethernet CAT5 network cable. Reboot the PC after you connect to the bridge with the cross-over Ethernet cable. F.01U.171.816 | 1.0 | 2010.09 Installation Manual Bosch Security Systems, Inc. - Page 17 IP Address, Subnet Mask, and Gateway in the appropriate input boxes. Note: The MAC Address cannot be changed. Click the Save button to accept the network settings and to apply these settings to the bridge. Bosch Security Systems, Inc. Installation Manual F.01U.171.816 | 1.0 | 2010.09...
-
Page 18: Configuring Operation Via A Network
Refer to the following sections for details about each configuration page. Click Save on each page to accept the changes. 5.2.1 System Menu The System Menu contains settings for bridge operation. F.01U.171.816 | 1.0 | 2010.09 Installation Manual Bosch Security Systems, Inc. -
Page 19: Network Setup
CAUTION! Changing a parameter on the Network Setup page may interrupt the operation of the ATM/POS Bridge. Contact your network administrator before making any changes. Bosch Security Systems, Inc. Installation Manual F.01U.171.816 | 1.0 | 2010.09... - Page 20 NOTICE! It is recommended to disable this feature once the network settings are configured. – MAC Address: Displays the MAC Address for the bridge. This value cannot be changed. F.01U.171.816 | 1.0 | 2010.09 Installation Manual Bosch Security Systems, Inc.
-
Page 21: Terminal
Capture: The bridge receives all characters from an ATM/POS terminal one character at a time; then transmits an individual character to a recording device. The bridge does not perform character conversion. Bosch Security Systems, Inc. Installation Manual F.01U.171.816 | 1.0 | 2010.09... - Page 22 ATM/POS terminal) on the network. – Specific IP Address: Type the IP Address of a specific terminal to instruct the bridge to accept transactions only from that ATM/POS terminal on this Comm Channel. F.01U.171.816 | 1.0 | 2010.09 Installation Manual Bosch Security Systems, Inc.
-
Page 23: Com Port
Communication Parameters: Select the appropriate settings to match the communication parameters for the terminal connected to this port: – Baudrate – Databits – Parity – Stopbits – Flow Control Bosch Security Systems, Inc. Installation Manual F.01U.171.816 | 1.0 | 2010.09... -
Page 24: Configuration Using Hyperterminal
Type a name for the new HyperTerminal session and select an icon for the session, then click OK. Select the appropriate COM port number on the PC that is connected to the bridge, then click OK. F.01U.171.816 | 1.0 | 2010.09 Installation Manual Bosch Security Systems, Inc. - Page 25 Click OK to accept the COM properties and to start the HyperTerminal session. Refer to Section 6.3 Configuring Bridge Operation via HyperTerminal, page 26 for details about configuring the bridge operation via HyperTerminal. Bosch Security Systems, Inc. Installation Manual F.01U.171.816 | 1.0 | 2010.09...
-
Page 26: Configuring Bridge Operation Via Hyperterminal
CAUTION! Changing a parameter on the Network Setup page may interrupt the operation of the ATM/POS Bridge. Contact your network administrator before making any changes. F.01U.171.816 | 1.0 | 2010.09 Installation Manual Bosch Security Systems, Inc. - Page 27 NOTICE! It is recommended to disable this feature once the network settings are configured. – MAC Address: Displays the MAC Address for the bridge. This value cannot be changed. Bosch Security Systems, Inc. Installation Manual F.01U.171.816 | 1.0 | 2010.09...
-
Page 28: Communication Channels
Communication Parameters: Select the appropriate settings to match the communication parameters for the terminal connected to this port: – Baudrate – Databits – Parity – Stopbits – Flow Control F.01U.171.816 | 1.0 | 2010.09 Installation Manual Bosch Security Systems, Inc. -
Page 29: Terminal Setup
Capture: The bridge receives all characters from an ATM/POS terminal one character at a time; then transmits an individual character to a recording device. The bridge does not perform character conversion. Bosch Security Systems, Inc. Installation Manual F.01U.171.816 | 1.0 | 2010.09... - Page 30 ATM/POS terminal) on the network. – Specific IP Address: Type the IP Address of a specific terminal to instruct the bridge to accept transactions only from that ATM/POS terminal on this Comm Channel. F.01U.171.816 | 1.0 | 2010.09 Installation Manual Bosch Security Systems, Inc.
-
Page 31: Simulation Mode
This setting is set to Off for normal operation. 6.3.5 Recording Language Select the language that is set on the digital recorder to ensure that characters display correctly. Bosch Security Systems, Inc. Installation Manual F.01U.171.816 | 1.0 | 2010.09... -
Page 32: Service Menu
Reset Bridge: Reboots the bridge by cycling the power. – Diagnostics: Select this option to perform the EEPROM diagnostic test. – Version Info: Displays the firmware release level for the bridge. F.01U.171.816 | 1.0 | 2010.09 Installation Manual Bosch Security Systems, Inc. -
Page 33: Troubleshooting
Refer to Section 5.2.1 System Menu, page 18. Check that the ATM/POS license is enabled in the recorder, if necessary. Bosch Security Systems, Inc. Installation Manual F.01U.171.816 | 1.0 | 2010.09... -
Page 34: Technical Data
Environmental Temperature Operating: 0°C to +45°C (+32°F to +113°F) Storage: -25°C to +70°C (-13°F to +158°F) Relative Operating: < 80% non-condensing Humidity Storage: < 90% non-condensing Electromagnetic Compatibility F.01U.171.816 | 1.0 | 2010.09 Installation Manual Bosch Security Systems, Inc. - Page 35 USA: FCC Part 15, Class B Requirements EU: EMC directive 89/336/EEC Immunity: EN50130-4 Emission: EN55022 Class B Harmonics: EN61000-3-2 Voltage Fluctuations: EN61000-3-3 Safety USA: UL60950 EU: EN60950 Canada: CAN/CSA - C22.2 - 60950-00 Bosch Security Systems, Inc. Installation Manual F.01U.171.816 | 1.0 | 2010.09...
-
Page 36: A Updating Bridge Firmware
Follow the steps below to update the firmware on the ATM/ POS Bridge. Download the Zip file for the ATM/POS Bridge firmware from the Bosch Security Systems Web site (www.boschsecurity.com). Unzip the firmware update file into a folder on the PC that you will use to update the bridge. - Page 37 PC via a low- end USB to Serial adapter, the firmware download attempt may take several attempts before it succeeds. Bosch recommends the SIIG USB to Serial serial adapter, a higher-end adapter.
- Page 38 By default, the wizard searches for the file in the same directory that contains the downloadwizard.exe file. To navigate to a different folder, click the ... button to select another directory. Then, click OK to return to the wizard. F.01U.171.816 | 1.0 | 2010.09 Installation Manual Bosch Security Systems, Inc.
- Page 39 Click Unselect All Devices to clear the check boxes for all device profiles. 11. Click Next to view a summary of the download settings and to start the update process. Bosch Security Systems, Inc. Installation Manual F.01U.171.816 | 1.0 | 2010.09...
- Page 40 16. Reconnect a serial cable from a terminal to COM Port 3, if required. NOTICE! Ensure that the console cable is disconnected from the bridge before reconnecting the power. 17. Reconnect the power cable to the bridge. F.01U.171.816 | 1.0 | 2010.09 Installation Manual Bosch Security Systems, Inc.
- Page 41 Use the following values for the communication settings: – Baud Rate: 19200 – Data: 8 bits – Parity: None – Stop: 1 bit Continue through the wizard screens to start the upload process. Bosch Security Systems, Inc. Installation Manual F.01U.171.816 | 1.0 | 2010.09...
- Page 42 | ATM/POS Bridge F.01U.171.816 | 1.0 | 2010.09 Installation Manual Bosch Security Systems, Inc.
- Page 44 Bosch Security Systems, Inc. www.boschsecurity.com © Bosch Security Systems, Inc., 2010...
