Rear Panel Connections

Phone
Connections
Connect to
your phones
using
standard
phone
cabling.
All Ethernet Ports (WAN
and LAN) are auto
MDI/MDIX, meaning you
can use either a
straight-through or a
crossover Ethernet
cable.
Auto MDI/MDIX
LAN Ports
Connect the
Ethernet cable
from computers
on your LAN to
these ports.
WAN Port
cable from
modem to
Factory Reset
Button
Pressing this
button will
restore the router
to its factory
default settings.
Power
Adapter
Connect
the Connect
Ethernet your 12V
1.25A
your power
ADSL adapter
here.
this port.
5
