Disassembly Procedure
Please follow the information provided in this section to perform the complete
disassembly procedure of the notebook. Be sure to use proper tools
described before.
A
SUS A6Jc/Jm Notebook consists of various modules. This chapter describes the
procedures for the complete notebook disassembly. In addition, in between procedures,
the detailed disassembly procedure of individual modules will be provided for your
service needs.
The disassembly procedure consists of the following steps:
• Battery Module
• Memory Module
• Wireless LAN Module
• HDD Module
• ODD Module
• Keyboard
• LCD Module
• Top Case Module
• Main Board Module
• Modem Module
• CPU/Heat Sink Module
2 – 1
Disassembly Procedure
2
Chapter
