Replacing the Printhead
Important
3
Pull the Printhead Fixer Lever forward all the way
to open it completely.
4
Pull up the Printhead Fixer Cover to open it com-
pletely.
36
• Do not touch the Linear Scale (a) or Carriage
Shaft (b). Touching these parts may damage
them.
•
Never touch the metal contacts of the Carriage. This may damage the printer.
