  • Page 1 LCD Monitor LCD Farbmonitor Moniteur LCD Monitor LCD Monitor LCD LL-T1520 LL-T1620 OPERATION MANUAL BEDIENUNGSANLEITUNG MODE D’EMPLOI MANUALE D’USO MANUAL DE FUNCIONAMIENTO...

  • Page 2: Table Of Contents

    Table of Contents Notice for Users in the USA ............. 4 TCO '95/ '99 .

  • Page 3: Notice For Users In The Usa

    Sharp Plaza, Mahwah, New Jersey 07430 TEL :1-800-BE-SHARP * As an ENERGY STAR Partner, SHARP has determined that this product meets the ENERGY STAR guidelines for energy efficiency. This product utilizes tin-lead solder, and fluorescent lamp containing a small amount of mercury.

  • Page 4: Tco '95/ '99

    LL-T1520-B LL-T1520-H LL-T1620-B LL-T1620-H Congratulations! You have just purchased a TCO’95 or TCO’99 approved and labelled product! Your choice has provided you with a product developed for professional use. Your purchase has also contributed to reducing the burden on the environment and also to the further development of environmentally adapted electronics products.
  • Page 5 TCO Development SE-114 94 Stockholm, Sweden Fax: +46 8 782 92 07 Email (Internet): development@tco.se Current information regarding TCO’99 approved and labelled products may also be obtained via the Internet, using the address: http://www.tco-info.com/ Environmental requirements Flame retardants Flame retardants are present in printed circuit boards, cables, wires, casings and housings. Their purpose is to prevent, or at least to delay the spread of fire.

  • Page 6: Notice For Users In Europe

    Notice for Users in Europe This equipment complies with the requirements of Directives 89/336/EEC and 73/23/EEC as amended by 93/68/EEC. Dieses Gerät entspricht den Anforderungen der EG-Richtlinien 89/336/EWG und 73/23/EWG mit Änderung 93/68/EWG. Ce matériel répond aux exigences contenues dans les directives 89/336/CEE et 73/23/CEE modifiées par la directive 93/68/CEE.

  • Page 7: Notice For Users In The Uk

    "WARNING :THIS APPARATUS MUST BE EARTHED" Notice for Users in Australia Service Inquiries Please contact your dealer for service if required or contact Sharp Corporation of Australia on 1 300 13 50 22 for referral to your nearest Sharp authorized Service Center.

  • Page 8: Tips And Safety Precautions

    - Sharp Corporation holds authorship rights to the recognized under law. Utility Disk program. Do not reproduce it without - This monitor and its accessories may be permission.

  • Page 9: Product Description

    Product description 1. INPUT button ....To switch between the signal’s input terminals. (Analogue RGB input terminal ↔ DVI-I input terminal) 2. MENU button ....This button is used to pop-up, select and close the OSD (On Screen Display) Menu.
  • Page 10 DVI standard output terminal (DVI-D24 pin or DVI-I29 pin) for digital connection. (Note that the display may not appear correctly, depending on the connected computer.) LL-T1520: Computers capable of XGA output LL-T1620: Computers capable of SXGA output - Separately sold cables are necessary for connection.

  • Page 11: Connecting The Monitor And Turning The Monitor On And Off

    (Note that the display may not appear correctly, depending on the connected computer.) LL-T1520: Computers capable of XGA output - If the cover is hard to refit, do not force it. LL-T1620: Computers capable of SXGA output Check whether cables are trapped.

  • Page 12: Connection Of Headphones (Commercially Available)

    Connecting the monitor and turning the monitor on and off When connecting to an analog RGB output terminal: Connect the accessory audio cable - Use an analog signal cable (model name: NL- When the accessory audio cable is connected to C02E).

  • Page 13: Connecting The Monitor To A Power Source

    Connecting the monitor and turning the monitor on and off 3.Turn on the computer. Connecting the monitor to a power source Turn on the computer power Press power button supply. Power terminal When a signal is input from the computer, the power LED lights up green, and the screen is displayed (After power is turned on, it may take a little time until the screen is displayed.)

  • Page 14: Turning The Power Off

    Connecting the monitor and turning the monitor on and off Turning the power off 1. Turn the computer off. 2. Press the monitor's POWER button. The Power LED will disappear. Turn the compu- Press power button ter off If the monitor will not be used for a long time, turn off the main power switch of the monitor, and remove the power plug from the outlet.

  • Page 15: Adjusting The Screen Display And Speaker Volume

    Adjusting the screen display and speaker volume For analog signal Adjustment lock function 1. First perform an automatic adjustment. (p. 18) 2. Perform manual adjustment where necessary. By disabling the control buttons (i.e. setting the (p. 19) lock) any attempted changes to adjusted values For digital signal will be voided.

  • Page 16: Adjusting The Speaker Volume

    Adjusting the screen display and speaker volume Adjusting the speaker volume Carry out the commands without the On Screen Display (OSD) Menu displayed. If the OSD Menu is displayed, press the MENU button (several times may be required) and begin when the OSD Menu has disappeared.

  • Page 17: Adjusting The Screen Display (When Using An Analog Signal)

    Adjusting the screen display (When using an analog signal) How to Adjust Automatic screen adjustment 1. Press the MENU button. Options in the ADJUSTMENT Menu can be The ADJUSTMENT Menu will be displayed. adjusted automatically (CLOCK, PHASE, H-POS V- ADJUSTMENT POS).

  • Page 18: Manual Screen Adjustment

    Adjusting the screen display (When using an analog signal) CLOCK Manual screen adjustment The figure below demonstrates how to adjust so Adjustments can be made using On Screen that vertical flicker noise is not emitted. ( Display (OSD) Menu provided. buttons) On Screen Display for adjustment If you are using Windows, open the Adjustment...
  • Page 19 Adjusting the screen display (When using an analog signal) GAIN CONTROL Menu COLOR CONTROL Menu GAIN CONTROL COLOR CONTROL MANUAL AUTO COLOR MODE sRGB VIVID WHITE BALANCE BLACK LEVEL SATURATION CONTRAST INPUT-1 ANALOG INPUT-1 ANALOG 1024 x 768 V : 60Hz H : 48.4kHz 1024 x 768 V : 60Hz...
  • Page 20 Adjusting the screen display (When using an analog signal) COOL ... Color tone bluer than standard MODE SELECT Menu • ..Color tone slightly bluer than standard MODE SELECT STD ..Color tone standard setting OSD H-POSITION • ..Color tone slightly redder than standard OSD V-POSITION SCALING WARM ..

  • Page 21: Adjusting The Screen Display (When Using A Digital Signal)

    Adjusting the screen display (When using a digital signal) Adjustments can be made using On Screen COLOR CONTROL Menu Display (OSD) Menu provided. COLOR CONTROL COLOR MODE sRGB VIVID On Screen Display for adjustment WHITE BALANCE If you are using Windows, open the Adjustment SATURATION Pattern on the accompanying Utility Disk.
  • Page 22 Adjusting the screen display (When using a digital signal) COOL ... Color tone bluer than standard MODE SELECT Menu • ..Color tone slightly bluer than standard MODE SELECT STD ..Color tone standard setting OSD H-POSITION • ..Color tone slightly redder than standard OSD V-POSITION SCALING WARM ..

  • Page 23: Monitor Care And Repair

    Use a soft dry cloth to lightly wipe away dirt and inquire at the shop where you purchased the dust from the surface of the LCD panel. (A soft monitor or your nearest Sharp authorized cloth such as gauze or that used for lens cleaning Service Center. (Never attempt this is suitable.)

  • Page 24: Specifications

    ; ° - ° ° 5 f ° ° 5 Dimensions (Units: mm) LL-T1620 LL-T1520 Analog signal cable: Approx. 2.0m Audio cable: Approx. 2.0m Digital signal cable, NL-C01E (purchased separately): Approx. 2.0m Analog signal cable, NL-C02E (purchased separately): Approx. 2.0m...
  • Page 25 71.7kHz 67.2Hz 117.01MHz - Recommended resolution for LL-T1520 is 1024 x 768. - Recommended resolution for LL-T1620 is 1280 x 1024. - All are compliant only with non-interlaced. - The monitor can be connected to the following computers that have a DVI standard output terminal (DVI-D24 pin or DVI-I29 pin) for digital connection.
  • Page 26 DPMS: Display Power Management Signalling DMPM: Digital Monitor Power Management Power Power DMPM mode Screen DPMS mode Screen H-sync V-sync consumption consumption LL-T1520: 36W LL-T1520: 36W Display on Display on LL-T1620: 42W LL-T1620: 42W LL-T1520: 3W STANDBY Display off LL-T1520: 3W LL-T1620: 3W SUSPEND...

  • Page 27: Installing Set-Up Information And The Icc Profile (For Windows)

    Installing set-up information and the ICC profile (For Windows) Depending on the computer or OS, it may be For Windows98 necessary to use the computer to operate the Installing monitor set-up information into Win- installation of monitor set-up information etc. If so, dows98, and setting the monitor's ICC profile as a follow the steps below to install the monitor set-up predetermined value.
  • Page 28 Installing set-up information and the ICC profile (For Windows) For Windows2000 For WindowsMe Installing monitor set-up information into Win- Installing monitor set-up information into dows2000, and setting the monitor's ICC profile as WindowsMe, and setting the monitor's ICC profile a predetermined value. as a predetermined value.
  • Page 29 Installing set-up information and the ICC profile (For Windows) For WindowsXP Installing the ICC profile Installing the monitor’s ICC profile. (If the set-up Installing monitor set-up information into information has already been installed, so too has WindowsXP, and setting the monitor's ICC profile the profile, and there is no need to install it.) as a predetermined value.

  • Page 30: Information About The Colorsync Profile (For Macos)

    Information about the ColorSync profile (For MacOS) About the ColorSync profile ColorSync is the Apple Corporation's color management system and is a function that enables color resolution to be realized when used with a compatible application. A ColorSync profile describes the color characteristics of the LCD monitor.

  • Page 31: Instructions For Attaching A Vesa Compliant Arm

    Instructions for attaching a VESA compliant arm An arm or stand based on the VESA standard Notes: (commercially available) can be attached to the - The stand is specially made for use with this monitor. monitor. Once having removed the stand, never Procurement of the arm or stand is at the custom- attempt to attach it to another device.
  • Page 32 SHARP CORPORATION © 2002 SHARP CORPORATION DSC2 TINSM1035MPZZ (2)
