Haier GDZ5-1 Parts Manual

Haier dryer parts manual
Hide thumbs Also See for GDZ5-1:
1
2
3
4
5

Advertisement

Quick Links

Download this manual See also: Service Manual, User Manual
Parts Manual
Dryer
Model:
GDZ5-1

Advertisement

loading

Related Manuals for Haier GDZ5-1

Summary of Contents for Haier GDZ5-1

  • Page 1 Parts Manual Dryer Model: GDZ5-1...
  • Page 2 GDZ5-1Exploded view...
  • Page 3 62 63...

  • Page 4: Spare Part Number

    Front Load Electric Dryer Model:GDZ5-1 NO.INEXP SPARE PART LOED NAME OF PART Q'ty Model NUMBER VIEW 00213500013900 iron top panel GDZ5-1 00213500008400 rear protective panel GDZ5-1 00214500005500 sealing bar for the rear panel GDZ5-1 00213500008500 reflector GDZ5-1 00213500013400 bearing support...
  • Page 5 00213500007700 right-side panel GDZ5-1 00214000041700 hinge for porthole GDZ5-1 00214000041700 hinge board for porthole GDZ5-1 00214800591100 inner frame of porthole GDZ5-1 00214000028304 lock for porthole GDZ5-1 00221120012000 shaft for the lock of the porthole GDZ5-1 00221122324008 spring GDZ5-1 00214800591000 handle...
