Getting Started Equipment checklist ................1-1 Getting Started ..................1-2 Chapter 2 The Grand Tour The Grand Tour for Satellite C670/C675/C670D/C675D/Satellite Pro C670/C675/C670D .................. 2-1 The Grand Tour for Satellite L770/L775/L770D/L775D/Satellite Pro L770/L775/L770D/L775D ............... 2-8 Internal Hardware Components ............2-17...
Page 3
Power conditions for Satellite C670/C675/C670D/C675D/Satellite Pro C670/C675/C670D .................. 5-1 Power conditions for Satellite L770/L775/L770D/L775D/satellite Pro L770/L775/L770D/L775D ............... 5-2 Monitoring of power condition for Satellite C670/C675/C670D/C675D/ Satellite Pro C670/C675/C670D ............5-4 Monitoring of power condition for Satellite L770/L775/L770D/L775D/ satellite Pro L770/L775/L770D/L775D ..........5-5 Battery ....................
Page 4
Devices, Inc. Windows, Microsoft and Windows logo are registered trademarks of Microsoft Corporation. Bluetooth is a trademark owned by its proprietor and used by TOSHIBA under license. HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.
Only peripherals complying with the FCC class B limits may be attached to this equipment. Operation with non-compliant peripherals or peripherals not recommended by TOSHIBA is likely to result in interference to radio and TV reception. Shielded cables must be used between the external devices and the computer’s External RGB monitor port, Universal Serial Bus (USB...
Page 6
EMC (Electromagnetic Compatibility) and safety standards. However, TOSHIBA cannot guarantee that this product still observes these EMC standards if options or cables not produced by TOSHIBA are connected or implemented. In this case the persons who have connected/implemented those options/cables have to provide assurance that the system (PC plus options/cables) still fulfils the required standards.
Page 7
Automotive Environments Aircraft Environments Any consequences resulting from the use of this product in working environments that are not approved are not the responsibility of TOSHIBA. The consequences of the use of this product in non-approved working environments may be: Interference with other devices or machines in the near surrounding area.
Page 8
For more detailed information about the collection and recycling programmes available in your country, please visit our website (http://eu.computers.toshiba-europe.com) or contact your local city office or the shop where you purchased the product. Disposal of batteries and/or accumulators...
The new European Union (EU) chemical regulation, REACH (Registration, Evaluation, Authorization and Restriction of Chemicals), entered into force on 1 June 2007. TOSHIBA will meet all REACH requirements and is committed to provide our customers with information about the chemical substances in our products according to REACH regulation.
Page 10
Blu-ray™ Combo CT31F Blu-ray™ Writer BT11F Hitachi-LG Data Storage, Inc. 22-23,KAIGAN 3-CHOME, MINATO-KU,TOKYO,108-0022 JAPAN 3. TOSHIBA Samsung Storage Technology DVD SuperMulti with Double Layer TS-L633F/L633W TOSHIBA SAMSUNG STORAGE TECHNOLOGY KOREA CORPORATION 416, MEATAN-3 DONG, YEONGTONG-GU, SUWON CITY, GYEONGGI, 443-742, KOREA 4.
Page 11
Complies with 21 CFR, Chapter 1, Subchapter J. Sony Optiarc Inc. 1-11-1 Osaki Shinagawa-ku, Tokyo, 141-0032, Japan Precautions CAUTION: This appliance contains a laser system and is classified as a “CLASS 1 LASER PRODUCT.” To use this model properly, read the instruction manual carefully and keep this manual for your future reference.
Preface Congratulations on your purchase of this computer. This powerful notebook computer provides excellent expansion capability, includes multimedia functionality, and is designed to provide years of reliable, high-performance computing. This manual tells how to set up and begin using your computer. It also provides detailed information on configuring your computer, basic operations and care, using optional devices and troubleshooting.
Page 13
Display Names of windows or icons or text generated by the computer that appear on its display screen are presented in the type face you see to the left. Messages Messages are used in this manual to bring important information to your attention.
General Precautions TOSHIBA computers are designed to optimize safety, minimize strain and withstand the rigors of portability. However, certain precautions should be observed to further reduce the risk of personal injury or damage to the computer. Be certain to read the general precautions below and to note the cautions included in the text of the manual.
Stress injury Carefully read the Instruction Manual for Safety and Comfort. It contains information on the prevention of stress injuries to your hands and wrists that can be caused by extensive keyboard use. It also includes information on work space design, posture and lighting that can help reduce physical stress.
Some of the features described in this manual may not function properly if you use an operating system that was not pre-installed by TOSHIBA. Equipment checklist Carefully unpack your computer, taking care to save the box and packaging materials for future use.
TOSHIBA Service Station TOSHIBA PC Health Monitor TOSHIBA Sleep Utility Online Manual TOSHIBA Portable Personal Computer User's Manual (This manual) * You may not have all the softwares listed above depending on the model you purchased. Getting Started All users should be sure to read the section Starting up for the first time.
DC power and reduces the voltage supplied to this computer. Always use the TOSHIBA AC adaptor that was included with your computer, or use AC adaptors specified by TOSHIBA to avoid any risk of fire or other damage to the computer. Use of an incompatible AC adaptor could cause fire or damage to the computer possibly resulting in serious injury.
Page 19
Never place your computer or AC adaptor on a wooden surface, furniture, or any other surface that could be marred by exposure to heat since the computer base and AC adaptor's surface increase in temperature during normal use. Always place your computer or AC adaptor on a flat and hard surface that is resistant to heat damage.
Plug the power cord into a live wall outlet - the Battery and DC IN indicators or DC IN/Battery indicator on the front of the computer should glow. Opening the display The display panel can be opened to a wide range of angles for optimal viewing.
When opening or closing the display panel, place one hand on the palm rest to hold the computer in place and use the other hand to slowly open or close the display panel (Do not use excessive force when opening or closing the display panel). Turning on the power This section describes how to turn on the power - the Power indicator will then indicate the status.
When it is displayed, be sure to read the Software License Terms carefully. Turning off the power The power can be turned off in one of three modes, either Shut Down Mode, Hibernation Mode or Sleep Mode. Shut Down Mode When you turn off the power in Shut Down Mode no data will be saved and the computer will boot to the operating system's main screen the next time it is turned on.
Page 23
computer automatically, such as a timer recording function. Failure to completely shut down the computer in this way could allow the operating system to reactivate and run pre-programmed tasks or preserve unsaved data, which could interfere with aviation or other systems, possibly causing serious injury.
Click Start, point to the arrow icon ( ) and then select Sleep from the menu. Close the display panel. Please note that this feature must be enabled within the Power Options (to access it, click Start -> Control Panel -> System and Security ->...
You can return to your previous working environment immediately when you turn on the computer. Saves power by shutting down the system when the computer receives no input or hardware access for the time period set by the System Hibernate feature. Allows the use of the panel power off feature.
Page 26
An error occurs and the computer does not respond to your keyboard commands. If you need to restart the computer, there are three ways this can be achieved: Click Start, point to the arrow icon ( ) and then select Restart from the menu.
Legal Footnotes section in Appendix C. Please handle your computer carefully to avoid scratching or damaging the surface. The Grand Tour for Satellite C670/C675/C670D/ C675D/Satellite Pro C670/C675/C670D Front with the display closed The following figure shows the computer’s front with its display panel in the closed position.
Power indicator The Power indicator normally glows green when the computer is turned on. However, if you turn the computer off into Sleep Mode, this indicator will blink green - approximately two seconds on, two seconds off - both while the system is shutting down and while it remains turned off.
LAN jack This jack lets you connect to a LAN. The adaptor has built-in support for Ethernet LAN (10 megabits per second, 10BASE-T) or Fast Ethernet LAN (100 megabits per second, 100BASE-TX). Some models are equipped with a Gigabit Ethernet LAN (1000 megabits per second, 1000BASE-T).
Page 30
2.6GB and 5.2GB DVD-RAM media cannot be read from or written to. Security lock slot A security cable can be attached to this slot and then connected to a desk or other large object in order to deter theft of the computer. Please note that it is not possible to confirm the operation of all functions of all USB devices that are available.
Page 31
Underside The following figure shows the underside of the computer. You should ensure that the display is closed before the computer is turned over to avoid causing any damage. Figure 2-5 The underside of the computer 1. Battery lock 3. Memory module slot 2.
Do not block the cooling vents. Keep foreign metal objects, such as screws, staples and paper clips, out of the cooling vents. Foreign metal objects can create a short circuit, which can cause damage and fire, possibly resulting in serious injury. Carefully clean the dust on the cooling vents’...
Page 33
You can use it for video chatting or video conferences using a communication tool such as Windows Live Messenger. TOSHIBA Web Camera Application will help you to add various video effects to your video or photograph.
Legal Footnote (Wireless LAN) For more information regarding Wireless LAN, please refer to the Legal Footnotes section in Appendix C. Bluetooth antenna Some computers in this series are equipped with the bluetooth antenna. Stereo speakers The speakers emit sound generated by your software as well as audio alarms, such as low battery condition, generated by the system.
Page 35
Figure 2-7 Front of the computer with display panel closed 1. DC IN indicator 4. Hard Disk Drive/Optical Disc Drive indicator 2. Power indicator 5. Memory media slot indicator 3. Battery indicator 6. Wireless communication indicator DC IN indicator The DC IN indicator normally glows white when power is being correctly supplied from the AC power adaptor.
Page 36
Left side The following figure shows the computer’s left side. Figure 2-8 The left side of the computer 1. DC IN 19V jack 5. Universal Serial Bus (USB 2.0 or USB 3.0) port* 2. Cooling vents 6. HDMI out port* 3.
Page 37
Universal Serial Bus One Universal Serial Bus port, which complies to (USB 2.0 or 3.0) port the USB 2.0 or 3.0 standard, is provided on the left side of the computer. The port with the icon Sleep and Charge function. The USB port type may vary depending on the model you purchased.
Page 38
Microphone jack A 3.5 mm mini microphone jack enables connection of a three-conductor mini jack for monaural microphone input. The integrated sound system provides support for the computer's internal speakers and microphone, as well as allowing an external microphone and headphones to be connected via the appropriate jacks.
Page 39
Battery pack The rechargeable lithium-ion battery pack provides power to the computer when the AC adaptor is not connected. For more detailed information on the use and operation of the battery pack please refer to Chapter 5, Power and Power-Up Modes.
Page 40
Memory module slot The memory module slot allows for the installation, replacement and removal of additional memory module. 1 GB, 2 GB or 4 GB memory modules can be installed in the computer's two memory slots for a maximum of 8 GB system memory. The actual amount of useable system memory will be less than the installed memory modules.
Figure 2-12 The front of the computer with the display panel open 1. Display screen 7. Power button 2. Web Camera* 8. Keyboard 3. Web Camera LED* 9. Touch Pad 4. Microphone* 10. Touch Pad control buttons 5. Bluetooth antenna and Wireless LAN 11.
Page 42
You can use it for video chatting or video conferences using a communication tool such as Windows Live Messenger. TOSHIBA Web Camera Application will help you to add various video effects to your video or photograph.
The processor type varies depending on model. To check which type of processor is included in your model, open the TOSHIBA PC Diagnostic Tool Utility by clicking Start -> All Programs -> TOSHIBA -> Utilities -> PC Diagnostic Tool.
Page 44
In this manual, the word "HDD" or "Hard disk drive" also refers to the SSD unless otherwise stated. SSD is a large-capacity storage media which uses Solid-State Memory in place of a magnetic disk of the hard disk. Under certain unusual conditions of prolonged non-use and/or exposure to high temperatures, the SSD may be vulnerable to data retention errors.
Due to the display panel's increased resolution, lines may appear broken in when displaying images in full-screen text mode. Graphics controller The graphics controller maximizes display performance. Legal Footnote (Graphics Processing Unit ("GPU")) For more information regarding Graphics Processing Unit ("GPU"), please refer to the Legal Footnotes section in Appendix C.
Page 46
To access this center, go to Start -> All Programs -> AMD VISION Engine Control Center -> AMD VISION Engine Control Center In this control center, ™ Select PowerPlay under Power. ™ Select the Enable PowerPlay check box, and then select the ™...
Chapter 3 Operating Basics This chapter describes the basic operations of your computer, highlights the precautions that should be taken when using it. Using the Touch Pad To use the Touch Pad, simply touch and move your fingertip across it in the direction you want the on-screen pointer to go.
In use there are five different types of keys, specifically typewriter keys, function keys, soft keys, Hot keys and Windows special keys. Keyboard indicators The following figures show the positions of the CAPS LOCK indicator and the NUM LOCK indicator which show the following conditions: When the CAPS LOCK indicator glows, the keyboard will produce capitals when any letter is typed.
The Hot Key Cards are normally hidden from view. The Cards appear when you press the FN key. To use the Hot Key Cards: Press and hold the FN key. The TOSHIBA Flash Cards appear along the top of the screen. Select the desired option The selected Card is displayed full-size with its available options below it.
To access this help, click Start -> All Programs -> TOSHIBA -> Utilities - > Flash Cards Help. Hot keys This section describes the associated functions of the hot keys. Mute Pressing FN + ESC turns the sound on and off.
Pressing FN + 4 increases the volume in increment. FN Sticky key You can use the TOSHIBA Accessibility Utility to make the FN key sticky, that is, you can press it once, release it, and then press an "F Number"...
Lay the disc, label side up, in the disc tray. Figure 3-6 Inserting a disc (Satellite L770/L775/L770D/L775D/satellite Pro L770/L775/L770D/L775D) 1. Laser lens When the disc tray is fully opened, the edge of the computer will cover the disc tray slightly. Therefore, you will need to turn the disc at an angle when you place it in the disc tray.
Writable discs This section describes the types of writable discs. Check the specifications of your drive to see the types of discs it can write. Use TOSHIBA Disc Creator and Corel Digital Studio to write compact discs. CD-R discs can be written only once. The recorded data cannot be erased or changed.
The TOSHIBA Disc Creator and Corel Digital Studio are provided as writing software with this computer. Corel Digital Studio can be used to write files in video format. TOSHIBA Disc Creator can be used to write data. You can use the DVD Super Multi drive or Blu-ray™ Combo drive to write data to either CD-R, CD-RW, DVD-R, DVD-R DL, DVD-RW, DVD+R, DVD +R DL, DVD+RW, DVD-RAM or DVD-R DL discs.
DVD+RW: MITSUBISHI KAGAKU MEDIA CO., LTD. (for 4x and 8x speed media) DVD-RAM: (DVD Super Multi drive only) DVD Specifications for DVD-RAM Disc for Version 2.0, Version 2.1 or Version 2.2 Panasonic Corporation (for 3x and 5x speed media) Hitachi Maxell, Ltd. (for 3x and 5x speed media) BD-R: Panasonic Corporation BD-R DL:...
"Disc Backup" function of TOSHIBA Disc Creator. TOSHIBA Disc Creator cannot record in packet format. You might not be able to use the "Disc Backup" function of TOSHIBA Disc Creator to back up a DVD-R, DVD-R DL, DVD-RW, DVD+R, DVD+R DL or DVD+RW disc that was made with other software on a different optical media recorder.
Click Start -> All Programs -> TOSHIBA -> CD&DVD Applications - > Disc Creator to access the TOSHIBA Disc Creator utility. Display the setting dialog box by one of the following two steps:...
Insert a Labelflash disc in optical disc drive. Set PRINTING SIDE for underside. Click Start -> All Programs -> Corel Digital Studio for TOSHIBA -> Corel Digital Studio for TOSHIBA -> Create. Click Create Disc Label. How to make a DVD-Video or a Blu-ray Disc™ Movie Simplified steps for making a DVD-Video or a Blu-ray Disc™...
If you use an over-used rewritable disc, the full formatting might be locked. Please use a brand new disc. TOSHIBA VIDEO PLAYER Please be aware of the following limitations when you use the TOSHIBA VIDEO PLAYER: Notes on use This software can only be used on Windows 7.
Page 62
TOSHIBA VIDEO PLAYER. Do not lock the computer using the Windows logo ( ) + L keys or the FN + F1 keys when running the TOSHIBA VIDEO PLAYER. The TOSHIBA VIDEO PLAYER does not have a parental control function.
Page 63
Media Player, please use TOSHIBA VIDEO PLAYER or Media Center to play DVD. Display Devices & Audio TOSHIBA VIDEO PLAYER will only run when "Colors" is set to "True Color (32 bit)". Click Start -> Control Panel -> Appearance and Personalization -> Display -> Adjust resolution, click "Advanced settings", select "Monitor"...
Page 64
2D home video and other 2D contents you created, in 3D according to your personal preferences. The “TOSHIBA VIDEO PLAYER” is set by default in the 2D format. By pressing the 2Dto3D conversion function button, you decide to activate the 2Dto3D conversion function and therefore decide to watch your 2D content in 3D.
Page 65
When an DVD-Video disc is set in the DVD drive (for models with DVD Super Multi drive), if the application selection screen appears, select Play DVD movie, (using TOSHIBA VIDEO PLAYER) to launch the TOSHIBA VIDEO PLAYER. Select Start -> All Programs -> TOSHIBA VIDEO PLAYER ->...
Please be aware of the following limitations when you use WinDVD BD for TOSHIBA: Notes on use WinDVD BD for TOSHIBA is for Blu-ray Disc™ playback only. DVD playback is not supported. Please use TOSHIBA VIDEO PLAYER for DVD playback.
Page 67
HD viewing. 3D playback feature (Only some models) WinDVD BD for TOSHIBA supports the playback of Blu-ray 3D™ discs on external 3D display/TV using HDMI 1.4. Before playback Blu-ray 3D™ discs, configure the 3D Playback.
WinDVD BD for TOSHIBA does not support 2Dto3D conversion function. Please use “TOSHIBA VIDEO PLAYER” for 3D playback of DVD or 3D video file. The 3D effect differs among individuals. Depending on the lighting condition of your room, you may experience some flickerings when you have the 3D glasses on.
Only some models are equipped with both Wireless LAN and Bluetooth functions. Do not use the Wireless LAN (Wi-Fi) or Bluetooth functionalities near a microwave oven or in areas subject to radio interference or magnetic fields. Interference from a microwave oven or other source can disrupt Wi-Fi or Bluetooth operation.
TOSHIBA is not liable for the loss of data due to eavesdropping or illegal access through the wireless LAN and the damage thereof. Card Specifications...
Authentication prevents access to critical data and makes it impossible to falsify the origin of a message. Encryption prevents eavesdropping and maintains link privacy. Bluetooth Stack for Windows by TOSHIBA Please note that this software is specifically designed for the following operating systems:...
This Bluetooth Stack is based on the Bluetooth Version 1.1/1.2/2.0+EDR/ 2.1+EDR/3.0/3.0+HS specification, depending on the model you purchased. However, TOSHIBA cannot confirm the compatibility between any computing products and/or other electronic devices that use Bluetooth, other than TOSHIBA notebook computers.
LAN cable types The computer must be configured properly before connecting to a LAN. Logging onto a LAN using the computer’s default settings could cause a malfunction in LAN operation. Check with your LAN administrator regarding set-up procedures. If you are using Gigabit Ethernet LAN (1000 megabits per second, 1000BASE-T), be sure to connect with a CAT5e cable or higher.
External monitor HDMI Other Security lock Optional TOSHIBA accessories Memory media slot The computer is equipped with a memory media slot that can accommodate some kinds of memory media with various memory capacities so that you can easily transfer data from devices, such as digital cameras and Personal Digital Assistants.
Secure Digital (SD) Card microSD card adaptor and microSD card Memory Stick MultiMediaCard (MMC) Memory media This section provides the important safety precautions in order to handle your memory media. Points to note about the memory media card SD/SDHC/SDXC memory cards comply with SDMI (Secure Digital Music Initiative), which is a technology adopted to prevent unlawful copy or playback of digital music.
Formatting an memory media card Memory media cards are sold already formatted in conformity to specific standards. If you reformat an memory card, be sure to reformat it with a device such as digital camera or digital audio player that uses the memory cards, not with the format command provided within Windows.
Set the write-protect switch to the lock position, if you do not want to record data. Inserting a memory media The following instructions apply to all types of supported media devices. To insert a memory media, follow the steps as detailed below: Turn the memory media so that the contacts (metal areas) are face down.
When installing or removing a memory module, you must ensure that you do not touch any other internal areas of the computer. Use only memory modules approved by TOSHIBA. Do not try to install or remove a memory module under the following conditions.
Use a point size 1 Phillips screwdriver to remove and fasten the screw - the use of an incorrect screwdriver can damage the screw heads. Installing a memory module To install a memory module, follow the steps as detailed below: Shut down the computer - make sure the Power indicator is off (refer to the Turning off the power...
Page 80
Align the notch of the memory module with that of the memory slot and gently insert the module into the slot at about a 30 degree angle before holding it down until the latches on either side snap into place. Figure 3-12 Seating the memory module (Satellite L770/L775/L770D/L775D/ satellite Pro L770/L775/L770D/L775D) 1.
Seat the memory module cover in place and secure it with the screw. Take care to ensure that the memory module cover is firmly closed. Figure 3-13 Seating the memory module cover (Satellite L770/L775/L770D/ L775D/satellite Pro L770/L775/L770D/L775D) 1. Screw 2. Memory module cover Install the battery pack - refer to Replacing the battery pack section in...
Grasp the module by its edges and remove it from the computer. If you use the computer for a long time, the memory modules and the circuits locating close to the memory modules will become hot. In this case, let them cool to room temperature before you replace them. Or you will get burnt if you touch any of them.
Figure 3-15 Connecting the monitor cable to the External RGB monitor port (Satellite L770/L775/L770D/L775D/satellite Pro L770/L775/L770D/L775D) 1. External RGB monitor port 2. Monitor cable There are no fastening screws for an external monitor cable on this computer's External RGB monitor port. However, external monitor cables which have connectors with fastening screws can still be used.
As the port operation of all HDMI (High-Definition Multimedia Interface) monitors have not been confirmed, some HDMI monitors may not function properly. Connecting the HDMI out port Plug one end of the HDMI cable into the HDMI in port of the HDMI device.
When you change the display output device by hot key like FN + F5, the playback device may not switch automatically. In this case, in order to set the playback device to the same device as the display output device, please adjust the playback device manually by the following steps: a.
Page 86
Display mode at List All Modes HD Format 720 by 576, True Color (32bit), 50Herts 576p 720 by 480, True Color (32bit), 60Herts 480p The above display mode is a typical HDMI display mode. The selectable display modes will vary for different HDMI monitors. HDMI 1.4 3D Video Only some models are supported with NVDIA HDMI 1.4 3D Video feature.
12. Select the "I have read and understand the Health and Safety Information" check box. 13. Click the Next button. 14. Click the Finish button. HDMI 1.4 3D Video feature is only supported at two resolutions: 1920x1080 24Hz and 1280x720 60Hz. The resolution can be reconfigured by the following procedure: Click Start ->...
You are able to add a number of options and accessories in order to make your computer even more powerful and convenient to use. For reference, the following list details some of the items that are available from your reseller or TOSHIBA dealer: Memory Kit A 1 GB, 2 GB or 4GB memory module (DDR3-1066/1333) can easily be installed in the computer.
Audio Enhancements In order to apply the sound effects for your current speaker, follow the steps below. Right click on the speaker icon on the Taskbar, and select Playback Devices from the sub menu. Select Speakers, and click Properties. On the Enhancements tab select the sound effects you would like, and click Apply.
from your computers. The Dolby Advanced Audio feature is supported by some models. Dolby Advanced Audio includes: High-Frequency Enhancer: Analyzes and restores high frequencies lost during encoding. Works on any speaker for a higher level of audio than was previously possible. Audio Optimization: Corrects common audio problems caused by laptop limitations for a better entertainment experience.
Clean the plastics of the computer using a slightly water dampened cloth. You can clean the display screen by spraying a small amount of glass cleaner onto a soft, clean cloth and then wiping the screen gently with the cloth. Never spray cleaner directly onto the computer or let liquid run into any part of it.
Page 92
If the processor's temperature reaches an unacceptably high level with either setting, the computer automatically shuts down to prevent any damage. In this instance all unsaved data in memory will be lost. User's Manual 3-46...
The TOSHIBA Password utility allows you to set Utility a password in order to restrict access to the computer. TOSHIBA Flash Cards The TOSHIBA Flash Cards provide a quick way to modify selected system functions. Hot key function HW Setup...
Page 94
To access this utility, click Start -> All Programs -> TOSHIBA -> Utilities -> TOSHIBA Assist . TOSHIBA ConfigFree TOSHIBA ConfigFree is a suite of utilities that improve the ease and control of communication devices and network connections, help in the...
Page 95
Alert Utility the Disk Drive operating status and execute the system backup. To access the utility, click Start -> All Programs -> TOSHIBA -> Utilities -> HDD SSD Alert. TOSHIBA Service Sta- This application allows your computer to tion automatically search for TOSHIBA software...
Page 96
TOSHIBA Sleep Utility This utility is able to either enable or disable the Sleep and Charge function. It shows the positions of USB ports that support the USB Sleep and Charge function and displays the battery's remaining capacity. To access this utility, click Start -> All Programs ->...
Resolution+ Plug-in for Windows Media Player Help. Special features The following features are either unique to TOSHIBA computers or are advanced features which make the computer more convenient to use. Access each function using the following procedures. *1 To access the Power Options, click Start -> Control Panel -> System and Security ->...
Page 98
HDD automatic power This feature automatically cuts off power to the hard disk drive when it is not accessed for a specified time, with power being restored when the hard disk drive is next accessed. This can be specified in the Power Options. System automatic This feature automatically shuts down the system Sleep/Hibernation...
USB port when your computer is in Sleep Mode, Hibernation Mode or in the shutdown state. This function is worked by the TOSHIBA Sleep Utility. TOSHIBA PC Health The TOSHIBA PC Health Monitor application...
The TOSHIBA Sleep Utility is only supported by Satellite L770/L775/ L770D/L775D/satellite Pro L770/L775/L770D/L775D models. Sleep and Charge Your computer can supply USB bus power (DC5V) to the USB port even when the power of the computer is turned OFF. "Power OFF" includes Sleep Mode, Hibernation Mode or shutdown state.
USB ports. Do not allow USB ports to come into contact with metal products, for example when carrying the computer in your bag. Starting the TOSHIBA Sleep Utility To start the utility, click Start -> All Programs -> TOSHIBA -> Utilities -> Sleep Utility. Enabling Sleep and Charge This utility can be used to enable and disable the Sleep and Charge function.
TOSHIBA does not guarantee that the face recognition utility will accurately screen out unauthorized users at all times. TOSHIBA is not liable for any failure or damage that might arise out of the use of the face recognition software or utility.
To register the data needed when you log in, follow the steps as described below: To launch this utility, click Start -> All Programs -> TOSHIBA -> Utilities -> Face Recognition. The Registration screen is displayed for a logged-in user whose face has not been registered.
To delete the Face Recognition Data, follow the steps as described below: To launch this utility, click Start -> All Programs -> TOSHIBA -> Utilities -> Face Recognition. The Management screen is displayed. Select a user which is displayed in the Management screen.
Windows password. User Password To start the utility, point to or click the following items: Start -> All Programs -> TOSHIBA -> Utilities -> TOSHIBA Assist -> SECURE -> User password Registered Click to register a password of up to 10 characters. After a password is set, you will be prompted to enter it when you start the computer.
This section explains how to use the TOSHIBA HW Setup program to configure your computer, and provides information on settings for various functions. Accessing HW Setup To run the HW Setup program, click Start -> All Programs -> TOSHIBA -> Utilities -> HWSETUP. User's Manual 4-14...
HW Setup window The HW Setup window contains a number of tabs (General, Password, Display, Boot Setting, Keyboard, LAN, SATA and USB) to allow specific functions of the computer to be configured. In addition there are also three buttons: OK, Cancel and Apply. Accepts your changes and closes the HW Setup window.
If character strings match, the password is registered. Click OK. If they do not match, the following message appears. You must repeat from step 1. Entry Error!!! To delete a user password: Select Not Registered to display the following prompt: Enter Password: Enter the currently registered password.
Page 109
To change the boot drive, follow the steps below. Hold down F12 and boot the computer. when the TOSHIBA Leading Innovation >>> screen appears, release the F12 key. Use the up and down cursor keys to select the boot device you want and press ENTER.
Page 110
this option will only work with the internal keyboard and only when the computer is in Sleep Mode. Enabled Enables the Wake-up on Keyboard function. Disabled Disables the Wake-up on Keyboard function. (Default) Wake-up on LAN This feature lets the computer's power be turned on from shutdown when it receives a wake-up packet (Magic packet) from the LAN.
10MB or less per year. This information is used to identify and provide a notification of system conditions which may effect the performance of your TOSHIBA computer. It may also be used to help diagnose problems should the computer require service by TOSHIBA or TOSHIBA's authorized service providers.
Once enabled, you may disable the TOSHIBA PC Health Monitor at any time by uninstalling the software via Uninstall a program in the Control Panel. Doing so will automatically delete all collected information from the HDD.
Restoring the pre-installed software from your created Recovery Media Restoring the pre-installed software from the Recovery hard disk drive System Recovery Options The System Recovery Options feature is installed on the hard disk when shipped from the factory. The System Recovery Options menu includes tools to repair startup problems, run diagnostics or restore the system.
Page 114
Set the computer on a level surface and avoid places subjected to vibrations such as airplanes, trains, or cars. Do not use on an unstable surface such as a stand. A recovery image of the software on your computer is stored on the hard disk drive, and can be copied to either DVD or USB Flash Memory by using the following steps: Select either blank DVD or USB Flash Memory.
Page 115
Recovery Media. However, if you have already created a "Recovery Media", you can use it to restore the recovery partition. If you have not created "Recovery Media", please contact TOSHIBA support for assistance. Restoring the pre-installed software from the...
Page 116
When the sound mute feature has been activated by pressing the FN + ESC key, be sure to disable this to allow sounds to be heard before starting the restore process. Please refer to The Keyboard in Chapter 3, Operating Basics, for further details.
Power conditions for Satellite C670/C675/ C670D/C675D/Satellite Pro C670/C675/C670D The computer's operating capability and battery charge status are affected...
Power on Power off (no operation) Remaining • Operates adaptor battery • LED: off capacity is connected above low battery trigger point Remaining • Operates battery • LED: blink amber capacity is below low battery trigger point Remaining Computer shuts down battery capacity is exhausted...
Page 119
Power on Power off (no operation) AC adaptor Battery fully • Operates • No charge connected charged • No charge • LED: • LED: Battery white Battery white DC IN white DC IN white Battery partially • Operates • Quick charge charged or no •...
Monitoring of power condition for Satellite C670/C675/C670D/C675D/Satellite Pro C670/ C675/C670D As shown in the below table, the DC IN/Battery and Power indicators on the system indicator panel alert you to the computer’s operating capability and battery charge status. DC IN/Battery indicator Check the DC IN/Battery indicator to determine the status of the battery pack and power with the AC adaptor connected.
No light Under any other conditions, the indicator does not light. Monitoring of power condition for Satellite L770/ L775/L770D/L775D/satellite Pro L770/L775/ L770D/L775D As shown in the below table, the Battery, DC IN and Power indicators on the system indicator alert you to the computer’s operating capability and battery charge status.
**** RTC Power Failure **** Check system. Then press [F2] key. You can change the Real Time Clock settings by turning on the computer while pressing the F2 key and then release F2 key when the TOSHIBA Leading Innovation >>> screen appears. Please refer to Chapter 6 Troubleshooting for further information.
TOSHIBA as replacements. The computer's RTC battery is a lithium battery and should be replaced only by your dealer or by a TOSHIBA service representative. The battery can explode if not properly replaced, used, handled or disposed. Dispose of the battery as required by local ordinances or regulations.
- the DC IN/Battery or Battery indicator will glow amber while the battery is being charged. Use only the computer connected to an AC power source or optional TOSHIBA Battery charger to charge the battery pack. Never attempt to charge the battery pack with any other charger. Time Refer to User Information Guide about Charging time.
Via the Battery Status in the Windows Mobility Center window You should wait at least 16 seconds after turning on the computer before trying to monitor the remaining operating time. This is because the computer needs this time to check the battery's remaining capacity and then calculate the remaining operating time, based on this together with the current power consumption.
Extending battery life To maximize the life of your battery packs: At least once a month, disconnect the computer from a power source and operate it on battery power until the battery pack fully discharges. Before doing so, follow the steps as detailed below. 1.
Do not remove the battery pack while the computer is in Sleep Mode. Data is stored in RAM, so if the computer loses power it could be lost. In Hibernation Mode, data will be lost if you remove the battery pack or disconnect the AC adaptor before the save is completed.
Power-up modes The computer has three different power-up modes as follows: Shut Down Mode: The computer will shut down without saving data - in view of this you must always save your work before you turn the computer off. Hibernation Mode: Data in memory will be saved to the hard disk drive.
In reality many problems can be solved simply, but a few may require help from TOSHIBA Support - if you find you need to consult others, be prepared to describe the problem in as much detail as possible.
Always try to make detailed notes of your observations and keep them in a permanent error log - this will help you to describe your problems to TOSHIBA Support. In addition, if a problem recurs, the log you have made will help to identify the problem faster.
Before using a peripheral device or application software that is not an authorized TOSHIBA part or product, make sure the device or software can be used with your computer. Use of incompatible devices may cause injury or may damage your computer.
If the AC adaptor still does not power the computer, you should contact TOSHIBA Support. Battery If you suspect a problem with the battery, you should check the status of the DC IN indicator as well as the Battery indicator, or DC IN/Battery indicator.
Page 133
However, if you do not believe the battery is at the end of its operating life, you should speak to TOSHIBA Support. (For Satellite C670/C675/C670D/C675D/Satellite...
RTC Power Turn on the computer. Failure. Check Press the F2 key when the TOSHIBA system. Then Leading Innovation >>> screen appears - press [F2] key. the BIOS setup application will load. Set the date in the System Date field.
- if so remove it and try to start the drive computer again. If this has no effect, check the Boot Priority setting within the TOSHIBA HW Setup utility - please refer to the Boot Setting section in Chapter 4, Utilities &...
If you are still unable to resolve the problem, contact TOSHIBA Support. Pointing device If you are using a USB mouse, you should also refer to both the mouse section in this chapter, and the documentation supplied with your mouse.
Adjust the touch Sensitivity. Touch pad is either To access it, click Start -> Control Panel -> too sensitive or not Hardware and Sound -> Mouse. sensitive enough. If you are still unable to resolve the problem, contact TOSHIBA Support. User's Manual...
If you are still unable to resolve the problem, contact TOSHIBA Support. USB device In addition to the information in this section, please also refer to the documentation supplied with your USB device.
Page 139
Sleep and Charge function may be disabled. Sleep and Charge Select the "Enable Sleep and Charge" check box function. in the TOSHIBA Sleep utility to enable this function. When there is a current overflow of the external device connected to the compatible port, USB bus power (DC5V) supply may be stopped for safety reasons.
Page 140
Problem Procedure The battery depletes If Sleep and Charge function is enabled, the quickly even when I computer's battery will discharge during turned OFF the hibernation or when the computer is turned off. power of the Connect the AC adaptor to the computer or disable computer.
Page 141
Basics for further information. Volume cannot be adjusted during Windows start up or shut down. If you are still unable to resolve the problem, contact TOSHIBA Support. External monitor Please also refer to Chapter 3, Operating Basics, and to the documentation supplied with your monitor for further information.
Page 142
Display error occurs Check that the cable connecting the external monitor to the computer is firmly attached. If you are still unable to resolve the problem, contact TOSHIBA Support. Problem Procedure Cannot access LAN Check for a firm cable connection between the LAN jack and the LAN hub.
TOSHIBA Support. TOSHIBA support If you require any additional help using your computer or if you are having problems operating the computer, you may need to contact TOSHIBA for additional technical assistance. Before you call Some problems you experience may be related to software or the operating system so it is important that you investigate other sources of assistance first.
Page 144
- they are your best resource for current information and support. TOSHIBA technical support If you are still unable to solve the problem and suspect that it is hardware related, visit TOSHIBA technical support website http://www.toshiba.co.jp/ worldwide/. User's Manual 6-16...
Appendix A Specifications This appendix summarizes the computer’s technical specifications. Physical Dimensions Size 413.6(w) x 270 (d) x 28/37.9 (h) millimeters (not including parts that extend beyond the main body). Environmental Requirements Conditions Ambient temperature Relative humidity Operating 5°C (41°F) to 35°C 20% to 80% (95°F) (noncondensing)
External RGB monitor port pin assignment Signal Name Description Red Video Signal Green Video Signal Blue Video Signal Reserved Reserved Ground Ground Ground Ground Power Supply Ground Reserved Reserved Data Signal HSYNC Horizontal Sync Signal VSYNC Vertical Sync Signal Data Clock Signal I/O (I): Input to computer I/O (O): Output from computer User's Manual...
Appendix B AC Power Cord and Connectors The power cord’s AC input plug must be compatible with the various international AC power outlets and the cord must meet the standards for the country/region in which it is used. All cords must meet the following specifications: Wire size: Minimum 0.75 mm...
Page 148
For the United States and Canada, two pin plug configuration must be a 2-15P (250V) or 1-15P (125V) and three pin plug configuration must be 6-15P (250V) or 5-15P (125V) as designated in the U.S. National Electrical code handbook and the Canadian Electrical Code Part II. The following illustrations show the plug shapes for the U.S.A.
Appendix C Legal Footnotes This chapter states the Legal Footnotes information applicable to TOSHIBA computers. Non-applicable Icons Certain computer chassis are designed to accommodate all possible configurations for an entire product series. Therefore, please be aware that your selected model may not have all the features and specifications corresponding to all of the icons or switches shown on the computer chassis.
Read additional restrictions in your product documentation. Contact TOSHIBA technical service and support, refer to Troubleshooting section in Chapter 6 Troubleshooting for more information. 64-Bit Computing 64-bit processors are designed to take advantage of 32 and 64 bit computing.
Page 151
TOSHIBA at the time of publication. Recharge time varies depending on usage. Battery may not charge while computer is consuming full power. After going through many charge and discharge cycles, the battery will lose its ability to perform at maximum capacity and will need to be replaced.
Copy Protection Applicable copy protection standards included in certain media may prevent or limit recording or viewing of the media. User's Manual...
The “Wi-Fi CERTIFIED™” logo is a certification mark of the Wi-Fi Alliance ® Bluetooth wireless technology Interoperability Bluetooth™ Cards from TOSHIBA are designed to be interoperable with any product with Bluetooth wireless technology that is based on Frequency Hopping Spread Spectrum (FHSS) radio technology, and is compliant to: Bluetooth Specification Ver.
Please visit http://www.pc.support.global.toshiba.com, if you have any questions about using Wireless LAN or Bluetooth Card from TOSHIBA. In Europe visit http://www.toshiba-europe.com/computers/tnt/bluetooth.htm Your Bluetooth product is not compatible with devices using Bluetooth Version 1.0B specifications Wireless Devices and your health Wireless products, like other radio devices, emit radio frequency electromagnetic energy.
Page 155
Italy: For private use, a general authorization is required if WAS/ RLAN’s are used outside own premises. For public use, a general authorization is required. Luxembourg: Implemented General authorization required for network and service supply. Norway: Implemented This subsection does not apply for the geographical area within a radius of 20 km from the centre of Ny-Alesund.
Page 156
Restrictions for Use of 5470-5725MHz Frequencies in Europe Italy: For private use, a general authorization is required if WAS/ RLAN’s are used outside own premises. Luxembourg: Implemented General authorization required for network and service supply Russian Limited e.i.r.p 100mW. Permitted to use Federation: only for indoor applications, closed industrial and warehouse areas,...
Page 157
designed to provide reasonable protection against harmful interference in a residential installation. Refer to the FCC information section for the detailed information. Caution: Exposure to Radio Frequency Radiation The radiated output power of the Wireless device is far below the FCC radio frequency exposure limits.
If this equipment causes RF interference to other radio stations, promptly change the frequency being used, change the location of use, or turn off the source of emissions. Contact an authorized TOSHIBA service provider if you have problems with interference caused by this product to Other Radio Stations.
: This equipment uses a frequency bandwidth from 2,400 MHz to 2,483.5 MHz. It is impossible to avoid the band of mobile object identification systems. 4. About the JEITA 5GHz Wireless LAN supports W52/W53/W56 Channel. Device Authorization This device obtains the Technical Regulation Conformity Certification and it belongs to the device class of radio equipment of low-power data communication system radio station stipulated in the Telecommunications Business Law of Japan.
Page 160
Do not use this equipment in the countries/regions which are not listed in the table below. Available channel of Peer-to-peer connection by ad-hoc mode is Ch1- Ch11. Connection with an access point by the Infrastructure mode is Ch1- Ch13. As of Jan. 2011 Albania Australia Austria...
Page 161
