- Page 1 RJP-110S Remote Jack Pack Installation & Setup Guide Warranty © Copyright 2007, LG Electronics U.S.A., Inc.
- Page 2 • Consult the dealer or an experienced radio/TV technician for help. CAUTION: Do not attempt to modify this product in any way (except as noted herein) without written authoriza- tion from LG Electronics U.S.A., Inc. Unauthorized modification could void the user’s authority to oper- ate this product. COMPLIANCE: The responsible party for this product’s compliance is:...
-
Page 3: Table Of Contents
Table of Contents Safety Warnings ..........2 Table of Contents . -
Page 4: Product Overview
Product Overview The Remote Jack Pack (RJP) contains circuitry to determine the pres- ence of a signal at each input jack. (Note: Audio In, Audio In L-R and Video In inputs detect the pres- ence of the inserted plug, regardless if a signal is present or not.) When a source is detected, its priority is compared to the priority of other sources which may be present. - Page 5 Introduction Conveniently installed right in the room where guests will stay, the LG Remote Jack Pack, (RJP) multi-media interface is available to end-users to connect audio, video and computer devices to hear and view on the in-room TV display panel.
-
Page 6: Installation On Desk/Cabinet Top
Installation on Desk/Cabinet Top In-Room TV RJP-110S Cable Leads to TV Desktop As shown above, install on a desk or cabinet in a convenient location for the end-user to have access to the RJP interface and so RJP cable bundle connections can be made to the dis- play panel. -
Page 7: Installer Connections
Installer Connections CAUTION: Be sure TV power is turned off before attempting to connect the RJP-110S remote jack pack to the TV display panel. AC Power Cord Connect to a standard 120V 60Hz power outlet. RJP-110S Audio/Video Cables Connect to Left-Right Audio/composite Video input jacks on TV display panel. -
Page 8: Connections To Tv Display Panel
Connections to TV Display Panel After completing connections between the RJP, the TV display panel and other resources (if available), be sure the installer menu items have been updated to enable the RJP. Installer Menu item 040 Auto Camport needs to be set to 000 and 093 RJP Available needs to be set to 001. -
Page 9: Rjp-110F Remote Jack Pack Hole Drilling Template
RJP-110S Remote Jack Pack Hole Drilling Template Detach the hole drilling template from the manual by bending up the staples ends in the center of the manual and removing this sheet. Bend the staples down again to secure the manual pages. - Page 10 RJP-110S Remote Jack Pack Hole Drilling Template for Cabinet or Desk Top Surfaces Template Size Before drilling the holes, measure the template to be sure the holes are the sizes stated. Some printers will change the size of the page because of their default setup. The print size selected should be 100% or same size and not ‘fit to page’...
- Page 11 Drill Hole Template...
- Page 12 RJP-110S Remote Jack Pack Desk Top Hole Drilling / Mounting Instructions Hole Drilling Tools Required - Drill Bit 1/4” - Drill RJP-110S - Phillips-Head #2 Screw Driver - Center Punch - Masking Tape 3/8" Max. Thread Depth - Lightweight Hammer Parts List •...
-
Page 13: Accessory Cable: Dvi To Hdmi Adapter Cable / Strain Relief
Accessory Cable: DVI to HDMI Adapter Cable / Strain Relief Special Connections Note: Optional DVI to HDMI Adapter Cable For TVs equipped with Male HDMI, this adapter cable Connector will be required to connect the RJP for digital Female video/audio. Connector RS-232C .. -
Page 14: End-User Multi-Media Connections
End-User Multi-Media Interface Connections The end-user simply plugs a device such as a laptop computer with the appropriate cables into the RJP connection panel. The Remote Jack Pack senses the new source connection and switches the TV to the newly-connected source. The device’s sound and image are then presented on the in-room TV display panel. - Page 15 End-User Connectable External Source Devices Examples of devices a guest/end-user can connect are shown to the right. There are two AC power outlets avail- able on the jack pack for added con- venience. The End-User Can Connect: • PC Laptop/Notebook Computers •...
-
Page 16: Specifications
Specifications Application Makes available to the hotel’s guests, a multi-media interface to the in-room TV display panel and in-room audio source (if available). Input jacks are provided for external portable devices such as DVD/CD Players, Laptop Computers, Camcorders, etc. Dimensions Height 3.68 Inches ( 9.3 cm) -
Page 17: Troubleshooting
• Make sure all connectors and connections are tight and secure on user device, RJP-110S and TV. • Check to assure user device, RJP-110S and TV are all powered up and working properly and that the TV Installer menu items are set correctly. -
Page 18: Troubleshooting Flow Charts
Troubleshooting Flow Charts No Audio (or No Video (or not desired not desired Power Audio) Video) Remove AC Has Circuit Power Remove AC Has Circuit Restore Breaker load, press Failure? Breaker load, press Power Tripped RESET Tripped RESET Connect Connect Is Audio Is power cord Connect... -
Page 19: Quick Setup Reference Guide
(See TV installation guide for com- ment system.) with installing and setting up an RJP plete instructions on new TV • RJP-110S Series Tent Card. System. installations. The master TV setup (Or comparable equivalent from 1. Install RJP on cabinet. -
Page 20: Warranty
LG RJP-110S Warranty Remote Jack Pack Welcome to the LG family! We believe that you will be pleased with your new LG product. Please read this warranty carefully, it is a “LIMITED WARRANTY” as defined under Federal Law. This warranty gives you specific legal rights, and you may also have other rights that vary from state-to-state within the U.S.A.
