Page 2
WARNING ikvA,/,1 ;__,ll_,[€,,ll To reduce the risk of electric shock, To reduce the risk not remove cover (or back). No user IRISKO F ELECTRIC SHOCKI DONOTOPEN I serviceable parts inside. Refer servicing of fire or shock to qualified service personnel. hazard, do not expose...
Page 3
STEP 1 Unpack the TV and remote control. IMPORTANT INFORMATION Caution: If you choose to use a stand with your TV, take precautions that the stand or other furniture the TV is placed on is properly located and of adequate size and strength to prevent the TV from...
Page 4
STEP 3: Plug in the TV. Plug the end of the power cord into the wall outlet, matching the wide blade of the plug with the wide slot in the outlet. Be sure to insert the plug completely. STEP 4 Put batteries in the remote.
Page 5
WHAT IS POINT SELE•CT? CHAN The point and select method has two steps. Point to a menu item using the MOVE arrows the remote. (The CHAN/VOL buttons on the remote.) Select a menu item by pressing MENU. Selecting an item tells the TV's menu system to go...
Page 6
Point to your preferred language by pressing the up and down arrows until the language is highlighted in green. Press MENU to select the language. A screen appears asking if you would like the TV to search for all channels. Setu Complete the Setup...
TV Main Menu The Main menu is your gateway to controlling theTV. It lets you adjust TV's audio, picture quality, screen, time functions and channel settings. MAIN MENU To select any other menu item: Press MENU to bring up the TV's Main menu.
The Picture Quality Menu The Picture Quality menu contains the controls that adjust the TV's picture. Picture Qualit There are five slider controls for adjusting the way the picture looks. Use the left and right arrow buttons to adjust the controls. Contrast Adjusts the difference...
Page 9
Screen Closed-Caption Display Displays a choice list that lets you choose the way closed captioning information is shown on the screen. Use the MENU button to toggle between the choices. No captioning information displayed. On Captioning information shown always, when available.
Page 10
The Channel Menu The Channel menu contains all the commands used to control your channels, including custom-building your channel list and setting parental controls. Channel Signal Type Displays a choice list that lets you select the current antenna type. Antenna Choose this if you are currently...
Chan # Use the up and down arrows to scroll up and down through channel scan list. You can enter the channel number directly using number buttons. Chan Labels Use the up and down arrows to enter a four-character label for each channel.
Page 12
Sleep Timer Displays a control panel that lets you select the amount of time you want to give the TV before it shuts itself off. Use the up and down arrows to increase or decrease the sleep timer by 15 minute increments.
Page 13
There are several indicators that come up when you change channels or press the DISPLAY button. This display is called the Channel Marker. The Channel Marker shown below is just an example of what your screen look like. 08:59 Displays the current time.
Page 15
MUTE Turns off the TV's sound. Press again to restore the sound. PREV CH Returns you to the previous channel. VOL - or VOL + Decreases or increases the TV's volume. Also used as left and right arrows. CHAN ^ or CHAN v Scans up or down through...
Page 16
FRONT PANEL < Decreases the volume. When in the > p0wE. MENU tHAN < menu system, VOL < is used to point left to items and adjust menu controls. • Increases the volume. When in the menu system, VOL > is used to point right items and adjust...
Page 17
'7,',, • Program providers have the option of sending information through airwaves along their programs. If this information is available, the TV can display it up when press DISPLAY on the remote. To display the on-screen program details: Press DISPLAY once to bring up the channel marker.
Page 18
in the cabinet to help assure adequate ventilation. To clean the TV screen, use a diluted soap and water mixture and a soft cloth. Do not use furniture polish on the TV cabinet or screen. While cleaning do not allow liquid to run down...
Page 19
Troubles sometimes are caused by simple "faults" that you can correct without the help of a service technician. If you experience any difficulty with your TV, check a few basic remedies before calling your service technician. TV WILL NOT TURN ON OR CONTROLS DON'T WORK...
Page 20
SCHEDULE DOES TURN OFF THE TV AT THE SET TIME Check schedule on/off function (it must be set to On). Check to make sure clock is set to the correct time. BLANK SCREEN BLACK APPEARS SCREEN • Try another channel. •...
