Page 1
Use and Care Guide ® LiquidPropaneGasGrill Kenmore Model No. 415.30812800 This Grill is For Outdoor Use Only • Read this manual before cooking grill. Failure to follow manufacturer's instructions could result in fire or explosion which could cause property damage, personal injury or death.
Page 2
CALIFORNIA PROPOSITION65 if you smell gas: 1. Combustion by-products producedwhen using this product contain chemicals known to the State of 1. Shut off gas to the appliance. California to cause cancer, birth defects, and other reproductive harm. 2. Extinguish any open flame. 2.
Page 3
Congratulations on making a smart purchase. Your new of normal use, accident or improper maintenance. Kenmore®product is designed and manufactured for years of dependable operation. But like all products, it may require repair from time to time. That's when having a Repair Protection All warranty coverage is void if this grill is ever used for Agreement can save you money and aggravation.
Page 4
LP Tank The LP tank used with your grill must meet the following requirements: Use LP tanks only with these required measurements: 12" (30.5cm) (diameter) x 18" (45.7 cm) (tall) with 20 lb. (9 kg.) capacity maximum. LP tanks must be constructed and marked in accordance with * NEVER store a spare LP tank under or near grill or in specifications for LP tank of the U.S.
Page 5
LP Tank Exchange Connecting Regulator To The LP Tank , Many retailers that sell grills offer you the option of replacing 1. LP tank must be properly secured onto grill. (Refer to assembly section.) your empty LP tank through an exchange service. Use only those reputable exchange companies that inspect, precision fill, 2.
Page 6
Leak Testing Valves, Hose and Regulator 1. Turn all grill controlknobs to OFF. Be sure regulator is tightly connected to LP tank. Completely open LP tank valve by turning OPD hand wheel counterclockwise. If you hear a rushing sound, turn gas off immediately.
Page 7
Safety Tips ,A. Before opening LP tank valve, check the coupling nut for tightness. For Safe Use Of Your Grill And To Avoid Serious A When grill is not in use, turn offall control knobs and LP tank injury: valve. •...
Page 8
Before Your First Cookout Main Burner ignitor Lighting A Do not lean over grill while lighting. , Light burners, check to make sure they are lit, close the lid and 1. Open lid during lighting. warm up grill on HIGH for 15 minutes. This curing of paint and 2.
Page 9
, Plastic parts: Wash with warm soapy water and wipe dry. Cleaning the Burner Assembly ,A. Do not use citrisol, abrasive cleaners, degreasers or a Follow these instructions to clean and/or replace parts of burner concentrated grill cleaner on plastic parts. Damage to and assembly or if you have trouble igniting grill.
Page 10
Storing Your Grill Indirect Cooking Poultry and large cuts of meat cook slowly to perfection on the • Clean cooking grates. grill by indirect heat. The heat from selected burners circulates • Store in dry location. gently throughout the grill, cooking meat or poultry without the •...
Page 13
Placelegsas shown(A). Left leg assemblyhas largeaxle holeson endsof legs. Hooktank exclusionwire intorightand left leg Tank Exclusion Wire assemblies(B). TankExclusionWire MatchHolder RightLegAssembly Left Le_ 466311208.13...
Page 14
Bottom Shelf to Legs Placebottomshelfend with cut out hole for LP cylinderbetweenlegswith axleholes.Attachto rightand left leg assemblies with (4) 1/4-20x1-1/2"screws and 1/4-20flange nuts, Tightensecurely. 1/4-20FlangeNuts Qty:4 1/4-20xl-1/2"Screws Qty:4 BottomShelf 14 °466311208...
Page 15
Wheels and Leg Extenders to Cart Turnassemblyupsidedown. Insertaxlerod throughwheel,wheelspacer,legs,wheelspacerand otherwheel.Attachwith (1) 8mmflat washer and hitchpin. Hammerleg extendersinto rightlegs. HitchPin WheelSpacer Qty:l Qty: 2 8mm Flat Washer Qty:l Leg Extenders Wheel Axle Rod "Cone" side of wheelagainst leg 466311208o15...
Page 16
Front Panels Standcart upright. Attachlowerfront panelto lowerhalfof cart with (4) #8x318"self-tapscrews. Slideslot in upperpanelontotank exclusionwire andattachto upper halfof cart with (4) #8x3/8" self-tap screws. !" #8x3/8" self-tapscrews Qty:8 LowerFrontPanel UpperFrontPanel 16. 466311208...
Page 17
GrillHeadto Cart Standcart upright. This step requirestwo peopleto lift and positiongrill headontocart. Carefullylowerthegrill headontothe cart.Makesure the regulatorhoseis hangingoutsidethe cart.Attachwith (4) 1/4-20x1/2"screws, 7ramlock washers and 7ramflat washers, 7mm lock washers 7mmflat washers 1/4-20x1/2" s crews Qty:4 Qty:4 Qty:4 Grill Head 466311208.17...
Page 18
Right Side Shelf Hooksidewallof shelfoversupportbracketson sideof firebox(A). Insert(2) 7ramfiber washers and 1/4-20x1/2"screws throughinsidefront d firebox and (2) throughoutside backof fireboxfor eachsideas shown(B). Attachshelfwith (4) 1/4-20flange nuts (C), RightSide Shelf 1/4-20xl/2"screws 7mm FiberWasher 1/4-20FlangeNut Qty:4 Qty:4 Qty:4 FasciaRight Side Shelf Attachfasciaand sideshelf tofireboxwith (1)#8x3/8" self- tap screw.
Page 19
Sideburner Shelf and Left Fascia Hooksidewall of sideburnershelf oversupportbracketson side of firebox(A). Insert(2) 7ramfiber washers and 1/4-20x1/2"screws throughinsidefront of fireboxand (2) throughoutsidebackof fireboxfor eachsideas shown(B), Attachsideburner s helf with (4) 1/4-20flange nuts (C), Attachfasciato fireboxwith (1) #8x3/8" self-tap screw (D). Tightenup sideburnersideshelf tofirebox with another(1) #8x3/8"self-tap screw betweenmountingbracketandfascia (D).
Page 20
Sideburner Bezel, Sideburner, Sideburner Knob and ignitorWire. Positionvalve behindfasciaand line up holes. Insert(1) of the #8-32x3/8" stainlesssteelscrews,do notfully tighten. Slip bezelunderscrewinsertedand positionas shown(A). Line up otherhole and insertscrew#8-32x3/8" throughbezeland intovalve. Tightenbothsecurely. Placesideburnerintoshelf. Makesurevalve is insidesidebumertube.Attachsideburnerwith (2) #8-32x3/8" screwsto the drip pan as shown(B).
Page 22
Heat Diffusers Placeheatdiffusersover burnersby insertingtabs intoslots in front offirebox.Opposite endsof heatdiffusersrest on pinsin back offirebox. Cooking Grate Placecookinggratesontograterests. CookingGrate Swing Away Insertendsof SwingAway pivotwire intoholesin sides of grill lid. Insertendsof SwingAway legwire into holesin sides of firebox.NOTE:Pivotand leg wires,runningside- to-side,shouldbe underwires runningfront-to-back.If PivotWire pivotand leg wires are on top, SwingAway is installed upside-down.
Page 23
GreaseCup Clip and GreaseCup Hanggreasecupclipfrom bottomoffirebox and placegreasecupinto greasecup clip. GreaseCu GreaseCu CAUTION Failureto installgrease cup clip and cup will cause hot greaseto drip from bottom of grill with risk of fire or property damage. LP Tank LP tank is sold separately. Use only with an OPD(over-fill protection device) equipped LP tank. Fill and leak check before attaching to grill and regulator.
Page 24
Troubleshooting EMERGENCIES: if a gas leak cannot be stopped, or a fire occurs due to gas leakage, call the fire department. Gasleakingfrom , Damaged hose. , Turnoff gas at LP tank. If hoseis cut or cracked,replace cracked/cut/burned valve/hose/regulator. See LP TankLeakTestand Connecting hose.
Page 25
Troubleshooting (continued) , Push-button sticksat bottom.. Burner(s) w ill not light , Replaceignitor. usingignitor. , Sparkingbetweenignitorand electrode. , Inspectwireinsulationand properconnection.Replacewires if insulationis broken. Burner(s) w ill not , See "GAS ISSUES:"on previouspage. matchlight. , Impropermethodof match-lighting. , See"Match-Lighting" s ectionof Useand Care. Suddendrop in gas , Outof gas.
Page 26
Troubleshooting - Electronic ignition SECTIONI Nosparksappearat , Batterynot installed . Checkbatteryorientation. . Installbattery(makesure that"+" and "-" any electrodeswhen properly. connectors are orientedcorrectly,with "+" end up ignitionbuttonis and "-" end down.) pushed;no noisecan be heardfrom spark . Deadbattery. . Has batterybeen used .
