HP StorageWorks
Disk Array XP operating system
configuration guide: Windows
2000/2003
XP12000
XP10000
XP1024
XP128
This guide describes the requirements and procedures for connecting and configuring the XP family
of disk arrays to work with a Windows 2000/2003 system running the Windows 2000/2003
operating system.
Part number: A5951-96193
Fourth edition: November, 2005
