- Page 1 FU-W28J Plasmacluster is a trademark of Sharp Corporation. AIR PURIFIER OPERATION MANUAL Free standing type...
- Page 2 Please read before operating your new Air Purifier The air purifier draws in room air via its air intake, letting the air pass through an Active Carbon Filter (deodorisation filter) and a HEPA Filter (dust collection filter) inside the unit, then discharges the air from its air outlet. The air purifier unit repeats this process continuously when its internal fan is working.
-
Page 3: Table Of Contents
13m² lab using an air sampler. *4 Japan Spinners Inspecting Foundation, Japan Evaluation of deodorising effect on Thank you for purchasing the SHARP Air Puri- odour-imbued fragments of cloth fier. Please read this manual carefully for the correct usage information. Before using this product, be sure to read the section: “Important... -
Page 4: Important Safety Instructions
• Be cautious when cleaning the unit. Corrosive cleansers may damage the exterior. • Only Sharp Approved Service Centres should service this air purifier. Contact your nearest Ap- proved Service Centre for any problems, adjustments, or repairs. • This appliance is not intended for use by persons (including children) with reduced physical, sen- sory or mental capabilities, or lack of experience and knowledge, unless they have been given su- pervision or instruction concerning use of the appliance by a person responsible for their safety. -
Page 5: Cautions Concerning Operation
IMPORTANT SAFETY INSTRUCTIONS CAUTIONS CONCERNING OPERATION • Do not block the air intake and/or outlet. • Do not use the unit near or on hot objects, such as stoves or heaters or where it may come into contact with steam. •... -
Page 6: Part Names
PART NAMES MAIN UNIT DISPLAY POWER ON/OFF Button Plasmacluster ON/OFF Button Fan Speed Button Fan Speed Indicator Lights Odour Sensor Plasmacluster Ion ON/OFF Indicator Light ILLUSTRATIVE DIAGRAM Odour Sensor Main Unit HEPA Filter (blue/white) Washable Active Carbon Filter (black) Filter Support Front Panel... -
Page 7: Back
Plasmacluster Indicator Light(blue) Blue light : Plasmacluster ON Light off : Plasmacluster OFF CLEAN - SIGN Light Clean Slightly Impure Very Impure The colour changes according to the air condition. Green Orange BACK INCLUDED • Operation manual Handle Air Outlet Date Label Air Inlet Power Cord... -
Page 8: Preparation
PREPARATION Be sure to remove the power plug from the wall outlet. FILTER INSTALLATION To maintain the quality of the filters, they are installed in the main unit and packed in plastic bags. Be sure to remove the filters from the plastic bags before using the unit. Front Panel Remove the filters Remove the Front Panel. -
Page 9: Install The Filters
Install the filters Place the HEPA Filter HEPA Filter within the main unit with the tabs facing up. Do not install the filter back- wards or the unit will not operate properly. Tabs Tabs Place the Active Carbon Filter on top of the HEPA Filter. -
Page 10: Operation
OPERATION MAIN UNIT OPERATION Fan Speed Indicator Lights Plasmacluster Indicator Light Plasmacluster ON/OFF Indicator Light Power ON/OFF Button • Press to start operation (short beep) and stop operation (long beep) • Plasmacluster Indicator Light and Fan Speed Indicator Light turn on/off. •... -
Page 11: Adjustment Of Sensor Detection Sensitivity
Fan Speed Button Plasmacluster ON/OFF Button POWER ON/OFF Button Clean Slightly Impure Very Impure CLEAN - SIGN Light Green Orange The colour changes according to the air condition. ABOUT THE CLEAN-SIGN • The condition of the CLEAN-SIGN depends on the room air condition detected by the Odour Sensor when the plug is inserted into the wall outlet. -
Page 12: Care And Maintenance
CARE AND MAINTENANCE To maintain optimum performance of this air purifier, please clean the unit including the sen- sor and filters periodically. When cleaning the unit, be sure to unplug the power cord, and never handle the plug with wet hands. -
Page 13: Washable Active Carbon Filter Care
WASHABLE ACTIVE CARBON FILTER CARE WASHABLE ACTIVE CARBON FILTER CARE HAND WASH ONLY! DO NOT TUMBLE DRY! Care Cycle We recommend replacing the active carbon filter every six months. Clean the filter as offen as necessary when odour persists. Dry filter completely in a well ventilated Fill a large container with area. -
Page 14: Filter Replacement Guidelines
CARE AND MAINTENANCE FILTER REPLACEMENT GUIDELINES Depending on the usage environment, air outlet odour may become strong after several months. If dust or odour cannot be removed easily, replace the filters. (Refer to “Please read before operating your new Air Purifier”) Guide for filter replacement timing •... -
Page 15: Troubleshooting
(Refer to E-9) If you still require service, contact your SHARP approved service centre. SHARP approved service centre locations can be found in the support area of our website: Australia : http://www.sharp.net.au New Zealand : http://www.sharp.net.nz ERROR DISPLAY... -
Page 16: Specifications
SPECIFICATIONS FU-W28J Model 220-240V 50Hz Power supply SILENT Fan Speed Adjustment 3.9W(3.5W) Rated Power Speed Operation /hour Fan Speed /hour 168m /hour Recommended Room Size ~21m 2 *2 High density Plasmacluster ion applicable floor surface ~10m 2 *3 Cord Length 2.0m Dimensions 410mm(W)x158mm(D)x430mm(H) - Page 17 Memo...
