Handling Precautions

G Do not disassemble this lens.
Please refer to your authorized dealer for any maintenance and inspections requiring an open
cabinet.
G Except for the lens fastener catch tab, touching any other internal part could cause
personal injury or machine malfunction.
G Do not touch any glass or protruding part of the lens. This may cause personal injury
and reduced performance of the projector.
G When maintaining the projector the following points should be noted.
• When cleaning the lens be sure to use a commercial air blower or lens cleaning paper (used
in cleaning glasses and cameras).
• The surface of the lens is very delicate. Do not allow hard objects to bump or rub against it.
Caution
G Be sure not to attach this lens to the projector when storing or carrying the projector. This
may cause damage to them.

Supplied Accessories

• 1 lens cover stick
• 2 lens caps (for the front and the back)
Projector and Lens Dimensions

Specifications

Product type
Model
Type of lens
Picture size (diagonal)
Focal length
F no.
Throw ratio
Weight
Dimensions
• 1 lock release strap
• Installation Manual (this manual)
329 - 334 (12 61 / " - 13 5 /
64 32
Tele-zoom lens for LCD projector
AN-C27MZ
Zoom lens
40'' to 300''
53.8 to 82.9 mm (2
2.0 to 2.8
1:2.7 to 4.3
Approx. 710g (1.57 lbs)
ø80 × 164 mm (6
Unit : mm (inch)
")
1 / '' to 3 1 /
8 4
29 / '')
64
'')
-4
