Page 1 EPSON ® ® PowerLite 505c/715c User’s Guide EPSON ® PowerLite ® 505c/715c Multimedia Projector...
Page 2 Illuminate buttons foot release lever on remote control foot computer port A/V jacks Stop action Power Freeze Turn projector on/off and sound A/V Mute R/C ON Turn remote control on/off E-Zoom screen Mouse pointer and Enter left mouse button...
Page 3 EPSON ® PowerLite ® 505c/715c Multimedia Projector User’ s Guide...
Page 4: Important Safety Information
SEIKO EPSON CORPORATION. The information contained herein is designed only for use with this EPSON product. EPSON is not responsible for any use of this information as applied to other products.
Page 5: Table Of Contents
Registration and Warranty ......5 Unpacking the Projector ......6 Additional Components .
Page 6 Adjusting the Image ......24 Shutting Down the Projector ......27 Using the Remote Control Turning On and Using the Remote Control .
Page 7 Fine-tuning the Projector Using the Projector’s Menu System ....70 Changing Menu Settings ..... . . 71 Adjusting the Image .
Page 8 Equipment Installing the Projector ......106 Connecting to a PC Desktop Computer ....107 Connecting to a Desktop Macintosh .
Page 9 Appendix B: Notices ......115 Important Safety Instructions ..... . 115 Remote Control Information .
Page 10: Welcome
Images are displayed at a resolution of 1024 768 pixels (PowerLite 715c) or 800 600 pixels (PowerLite 505c). Three 0.9-inch LCDs provide a 400:1 contrast ratio for incredibly vivid images and clear text. Support for component video and S-video contribute to theater-quality performance.
Page 11: Getting The Most From Your Projector
Connecting to video sources You can connect a DVD player, VCR, camcorder, laser disc player, digital camera, or any other video source to your projector. You can connect both computer and video sources at the same time and easily switch between them. See page 15 for instructions.
Page 12: Using Your Documentation
Notes contain important information about your projector. Reading This Manual Online Your PowerLite 505c/715c CD-ROM includes an electronic copy of this manual. You may find it convenient to copy it onto your laptop’s hard drive so it’s always with you—for example, when taking your presentation on the road.
Page 13: Getting More Information
See page 90 Help for details. support.epson.com Download FAQs and e-mail your questions to EPSON support. CD-ROMs Your projector comes with two CD-ROMs. The PowerLite 505c/715c CD-ROM lets you register electronically and includes the electronic copy of this book as well as a link to Presenters Online.
Page 14: Registration And Warranty
If you still need help after checking this User’s Guide and the sources listed above, you can use the EPSON PrivateLine Support service to get help fast. Call (800) 637-7661 and enter the PIN on the card in your Owner’s Kit. Or take advantage of EPSON’s automated support services 24 hours a day.
Page 15: Unpacking The Projector
(or the equivalent) when you need to send the projector to another location. If you are moving the projector by hand, use a carrying case (such as the optional cases available from EPSON). See page 8 for more information about cases. Welcome...
Page 16: Additional Components
Some older PowerBooks and Macintosh desktop models may need the Macintosh adapter set shown on page 111 (available from EPSON; see page 8). Older iMac systems may need a special adapter to provide a VGA output port; see your computer dealer.
Page 17: Optional Accessories
Optional Accessories To enhance your use of the projector, EPSON provides the following optional accessories: Product Replacement lamp and air filter Soft carrying cases: Ceiling mount Suspension adapter for ceiling mount (1-inch pipe) Suspension adapter for ceiling mount (1.5-inch pipe)
Page 18: Setting Up The Projector
Setting Up the Projector his chapter tells you how to set up the projector and connect it to a laptop computer or video source. If you need to connect the projector to a desktop or workstation computer, see Appendix A.
Page 19: Positioning The Projector
Positioning the Projector Before connecting the projector, you need to decide where to place it. The location you choose depends on the size of the room and what you are projecting. caution Don’t hold or lift the projector by the lens, or you may damage it.
Page 20 If you place the projector below the level of the screen, you’ll have to tilt it up by extending the feet as shown. Tilting the projector upward causes the image to lose its square shape, but you can correct the...
Page 21: Connecting To A Laptop Computer
Setting Up the Projector port. Computer video-out or monitor port. If you’re using a PowerBook and you can’t connect the cable, you may need to use the Macintosh desktop adapter as shown on page 111 (available from EPSON; see page 8).
Page 22: Connecting The Cable For Remote Mouse Control
USB mouse port. 1. Locate the cable you need, depending on whether your laptop has a round PS/2 mouse port or a flat USB port. 2. Connect one end of the appropriate mouse cable to the projector’s port, as shown. Mouse/Com connecting PS/2 mouse cable 3.
Page 23: Amplifying Computer Audio
4. If necessary, configure your laptop to work with an external If you don’t need to make any other connections, you can plug in your projector and turn it on. See page 20 for instructions. Amplifying Computer Audio Your laptop probably has its own sound system; however, it may not be adequate for your presentation.
Page 24: Connecting To Video Sources
S-Video, or component video. For composite video, use the RCA AV cable included with the projector. For component video, you will need the optional EPSON component video cable (D-sub 15-pin to 3BNC, ELPKC19). For S-Video, use the S-Video cable supplied with your video device or obtain one from your electronics dealer.
Page 25: Connecting The Rca Av Cable
Connecting the RCA AV Cable Before starting, make sure the projector and your DVD player or other video source are turned off. 1. Connect the yellow plug on one end of the AV cable to the 2. Connect the other end of the cable to the video-out jack on your 3.
Page 26: Connecting S-Video
3. Connect the RCA AV cable to the left and right the projector. (Match the red and white plugs to the red and white jacks; you won’t need to use the yellow plug.) 4. Connect the plugs at the other end of the cable to the audio output jacks on your video source.
Page 27: Connecting Component Video Cables
3. Connect the RCA AV cable to the left and right 4. Connect the plugs at the other end of the AV cable to the audio 5. After you turn on the projector, use the Video menu to set the Setting Up the Projector projector’s...
Page 28: Using The Projector
Using the Projector nce you’ve set up the projector, you’re ready to turn it on, adjust the image, and give your presentation. You can use the built-in EasyMP system to project without connecting to other equipment, as described in Chapter 5. Or, you can connect the projector to a computer or video source, as described in Chapter 1 and Appendix A.
Page 29: Turning On Your Equipment
Turning On the Projector Follow these steps to plug in and turn on the projector: 1. Connect one end of the power cord to the projector’s power inlet. 2. Connect the other end to a grounded electrical outlet. 3. Use the tab on the lens ring to rotate the ring and extend the lens.
Page 30 Power Power button The power light flashes green as the projector warms up, and the projection lamp comes on in about 30 seconds. The power light stays green. You may see the EasyMP main screen or a presentation that has been saved on the memory card and set to run automatically.
Page 31: What To Do If You See A Blank Screen
If you see a message saying that it has found a plug-and-play monitor, click If you’re projecting a video, press the of the projector to switch to your video source, and press the button on your DVD player or other device. Play Make sure the cables are connected correctly, as described on page 12 (for laptops) or in Appendix A (for other systems).
Page 32 (Allow a few seconds for the projector to sync up after pressing the button.) If you’re using a PowerBook: You may need to set up your system to display on the projector screen as well as the LCD screen. Follow these steps: 1. From the Apple menu, select Monitors and Sound.
Page 33: Adjusting The Image
On most systems, the key lets you toggle between the LCD screen and the projector, or display on both at the same time. Depending on your computer’s video card, you might need to use the Display utility in the Control Panel to make sure that both the LCD screen and external monitor port are enabled.
Page 34: Focusing And Zooming Your Image
Adjusting the Height of Your Image If the image is too low, you can raise it by extending the projector’s feet. 1. Stand behind the projector. Pull up the blue foot release levers and lift the front of the projector. This unlocks the feet.
Page 35: Adjusting The Image Shape
Using the Projector If your image looks like projector off to one side of the screen, at an angle. Move it directly in front of the center of the screen, facing the screen squarely. If your image looks like button to correct the shape of the image.
Page 36: Shutting Down The Projector
When the projector has cooled, the orange light stays on and the exhaust fan shuts off. If you want to turn the projector on again, wait until the orange light stops flashing. Then press the 4.
Page 37 Using the Projector...
Page 38: Using The Remote Control
30 feet away. You can use it to turn the projector on and off, zoom in on a portion of your image, and highlight your presentation.
Page 39: Turning On And Using The Remote Control
If they don’t, you need to change the batteries as described above. Turn off the remote control before transporting it or storing it in a projector case. This prevents the batteries from discharging if something presses against one of the buttons. Using the Remote Control battery compartment cover.
Page 40: Using The Remote Control
Using the Remote Control When using the remote control, stand within 30 feet of the projector. Point the remote control either at the front or back of the projector or at the screen (the projector’s front sensor can detect signals bounced off the screen).
Page 41: Controlling The Picture And Sound
Select video image appears. P in P source - Volume + Adjusting the Volume If you’ve connected an audio source to the projector, you can adjust the sound that’s output through the projector’s speakers. Adjust volume Select S-video source Using the Remote Control Press the button to select your computer source.
Page 42: Turning Off The Picture And Sound
Turning Off the Picture and Sound You can use the button on the remote control to turn off A/V Mute the image and sound and darken your screen. This is useful if you want to temporarily re-direct your audience’s attention without the distraction of a bright screen.
Page 43: Resizing The Image
Some computer images need to be resized to display in the projector’s Power native format—1024 Freeze A/V Mute pixels (PowerLite 505c). If only part of your computer image is R/C ON E-Zoom displayed, you can correct it with the Enter...
Page 44: Highlighting Your Presentation
3. When the window is located and sized the way you want, press button. The menu disappears, and your video plays on Enter the screen. 4. When you’re finished viewing the picture-in-picture, press the button again. The video window disappears. P in P Highlighting Your Presentation You can highlight areas on the screen using the numbered buttons on...
Page 45: Using The Pointer
Using the Pointer note You can use the pointer tool to place an arrow anywhere on your You can use the projector’s screen. Effect menu to select a different pointer. See page 75. 1. To activate the pointer tool, press button 2.
Page 46: Spotlighting Your Image
Spotlighting Your Image With the Spotlight tool, you can place a square highlight on part of the screen image. 1. To activate the spotlight tool, press button control. The screen darkens, and a box of light appears on part of the image.
Page 47: Using The Remote Control As A Wireless Mouse
With EasyMP, you can use the remote control to play back and edit presentations on the projector’s memory card. See Chapter 5 for more information. To control your computer with the remote, make sure you have...
Page 48: Creating Presentations For Your Projector
Once you install the software, you can drag and drop a PowerPoint file to convert it into a format called a scenario. Then you can download the scenario to the projector’s memory card and run it automatically or with the remote control.
Page 49: Accessing The Memory Card
Accessing the Memory Card To access the memory card, you can either transfer it to your computer or use a USB cable to access the card in the projector. Use the instructions to do one of the following: Moving the Memory Card from the Projector to...
Page 50 2. Press the button again. The memory card is released, and you can remove it from the slot in the projector. 3. Press the button to insert it in the slot. 4. Insert the card in your computer’s PCMCIA slot or card reader.
Page 51: Accessing The Memory Card Through A Usb Cable
See page 38 for more information. 2. Plug in and turn on the projector and the computer. You see the 3. Click 4. Insert the EasyMP Software CD-ROM in your drive.
Page 52: Installing Easymp
480) or better display adapter and monitor Installing the Software Locate the EasyMP Software CD-ROM that came with your projector and follow these steps to install the software. 1. Insert the EasyMP Software CD-ROM in your drive. The setup program starts automatically.
Page 53: Creating A Scenario
The drag and drop method is the easiest way to create a scenario. Use this method if you have an existing PowerPoint presentation that you want to transfer to the projector. 1. Locate the PowerPoint file you want to use in My Computer or 2.
Page 54 File menu and enter a new scenario name and folder location if you want. Once your scenario is saved, you can transfer it to the memory card, either in your computer’s PCMCIA slot or in the projector. See page 52 for instructions. scenario window from the File menu.
Page 55: Creating A New Scenario File
Drive selection box Folder window File window 2. Choose Creating Presentations for Your Projector icon on your computer’s desktop. You see the EMP SlideMaker screen: from the File menu. You see the Scenario Settings box: EMP SlideMaker Scenario window Thumbnail window...
Page 56: Building A Scenario
1. Use the Drive selection box and Folder window to locate files that you want to include in your scenario. PowerPoint, JPG, and BMP files appear as icons in the File window, as shown to the right. folder, but you can Creating Presentations for Your Projector...
Page 57 Each slide appears in a numbered “cell” in the Scenario window as you drop it. The cell background color varies according to the type of file in the cell. Creating Presentations for Your Projector window. icon. PowerPoint opens briefly in the background, and the PowerPoint slides appear in the Thumbnail window.
Page 58: Setting Up Transitions
3. Click . The Cell Settings box appears: Cell Properties Click to change slides manually Click to change slides automatically key while you Ctrl from the Edit Select All Cell menu Creating Presentations for Your Projector Click to add transition effects...
Page 59: Adding Computer Access Or Video
The cell is initially set to PC (computer access). This means that your scenario will access a computer connected to the projector at the point where the cell occurs. However, you can change the source to video, as described in the following step.
Page 60 File menu. Save Once your scenario is saved, follow the instructions in the next section to transfer it to the memory card. from the Cell Properties On mouse click. Save Creating Presentations for Your Projector...
Page 61: Transferring Your Presentation To The Projector
After the scenario has been transferred to the card, you see the following message about your scenario’s Autorun setting: The Autorun setting means that the scenario will start playing whenever the projector is turned on (with the memory card in the projector). Transfer Scenario...
Page 62 Creating Presentations for Your Projector note If you want to change the autorun setting for the built-in demo (or any other scenario), you can open the...
Page 63 6. Do one of the following: Once your scenario is saved on the card in the projector, follow the instructions in Chapter 5 to present it. Creating Presentations for Your Projector If the memory card is inserted in the projector, you can begin your presentation as described in Chapter 5.
Page 64: Presenting Without A Computer
See Chapter 4 for instructions. Once the scenario is saved on the memory card in the projector, you can run it automatically or with the remote control. You can also rearrange your slides and show images captured from videos or other sources.
Page 65: Presenting Your Scenario
Presenting Your Scenario If your scenario is set to autorun, it will start when the projector’s lamp comes on after you press the the default settings, each slide will display for 30 seconds. However, you can also display each slide manually, as described on page 57.
Page 66: Displaying Each Slide Manually
Two types of icons appear on the screen: EasyMP creates a folder for each scenario on the card. Scenarios always have the .SIT file name extension. 3. Use the button on the remote control to highlight your Enter scenario file (SCN002.SIT, for example). 4.
Page 67: Editing Your Scenario
Editing Your Scenario You can modify your scenario using EasyMP on the projector. Some of the things you can do include: Rearranging and Hiding Slides You use the Edit Scenario function to rearrange your presentation or hide individual slides. 1. Press the 2.
Page 68 4. Use the button to highlight Enter to select it. Enter You see thumbnail images of the slides in your scenario: To move a slide: Use the button to highlight the slide you want to move. Enter Then press . A white line (or “I-beam”) appears to the left of Enter the slide.
Page 69 Select to hide a slide 5. Do one of the following: Presenting Without a Computer The red non-display icon appears on your slide: If you change your mind and want to display the slide, repeat the process to remove the non-display icon. To save your changes, press highlight the icon.
Page 70: Changing The Continuous Play Setting
Changing the Continuous Play Setting You can set a scenario to repeat continuously or to play through only once. 1. Press the button on the remote control to display the EasyMP EasyMP main screen. 2. Use the button on the remote control to highlight your Enter scenario file.
Page 71: Previewing Slides
Previewing Slides For each folder on the memory card, you can display thumbnails and preview the slides in the folder. 1. Press the 2. Use the 3. Press 4. To preview all the files, use the Presenting Without a Computer button on the remote control to display the EasyMP EasyMP main screen.
Page 72: Changing Display Timing And Other Settings
5. Press to access the menu icons. 6. Use the button to highlight Enter display the first slide in the folder. 7. Press to change to the next slide. Continue pressing Enter to display each slide in sequence. Press if you want to display the previous slide. 8.
Page 73 5. Use the 6. When you’re finished changing settings, press 7. Do one of the following: Presenting Without a Computer button to select the following settings. After you Enter make your choice for each option, press change. Continuous Play Determine whether to repeat the display of slides or images in the folder.
Page 74: Capturing Images
Capturing Images EasyMP lets you capture any image displayed on the projector and save it on the memory card. You can capture images from video or computer sources. Once you have captured an image or a series of images, you can play them back through EasyMP.
Page 75: Previewing Captured Images
1. Press the 2. Use the 3. Press Presenting Without a Computer CAP_001.JPG in the Memory Card,” press the exit the projector menus. CAPTURE button on the remote control to display the EasyMP EasyMP main screen. button on the remote control to highlight the Enter folder.
Page 76 You see icons for the images in the folder: 4. To preview an image, use the press to display it. To return to the folder display, press Enter Esc. 5. To return to the EasyMP main screen, use the highlight the folder icon.
Page 77 Presenting Without a Computer...
Page 78: Fine-Tuning The Projector
Fine-tuning the Projector ou can use the projector’s on-screen menus to adjust the image, sound, and other features. You can also create your own startup screen, customize the highlighting tools, and find out how long your lamp has been in use. This chapter covers the following information:...
Page 79: Using The Projector's Menu System
Using the Projector’s Menu System The eight projector menus let you adjust and customize the projector features from the remote control: Fine-tuning the Projector The Video menu controls the look and quality of the projected image. It lets you adjust the image position and fine-tune settings such as Brightness, Sharpness, and Contrast.
Page 80: Changing Menu Settings
Comp EasyMP S-Video Video Auto Resize P in P - Volume + note If you want to go back to the default settings on any menu, select , press Reset Enter select , and then press Enter Fine-tuning the Projector...
Page 81: Adjusting The Image
Sharpness About Gamma Dynamic Normal Reset All Video Signal Select [Auto Reset Execute :Select :Enter Video menu for composite video or S-Video Fine-tuning the Projector Video Audio Effect Setting Capture Advanced Natural About YCbCr YPbPr ) Reset All :Select :Enter...
Page 82: Repositioning The Image
Sync (computer images only) Corrects fuzziness or screen flicker by synchronizing the projector with the tracking signal sent from the computer. Brightness Lightens or darkens the overall image. Contrast Adjusts the difference between light and dark areas.
Page 83: Adjusting The Sound
You can use the Audio menu to adjust the sound volume or treble/bass balance. 1. Press the 2. Use the Fine-tuning the Projector Color (composite video or S-Video only) Adjusts the depth or intensity of the image. Tint (video only) Adjusts the balance of green to magenta in the image.
Page 84: Customizing The Highlighting Tools
Effect menu to customize these tools and set the cursor speed for highlighting. The option lets you return all the highlighting Reset tools to their default settings. 1. Press the button. You see the main menu. Menu 2. Use the button to highlight Enter Execute Menu Effect Fine-tuning the Projector...
Page 85 3. Press 4. Use the 5. Use the 6. When you’re finished customizing the highlighting tools, press Fine-tuning the Projector You see the Effect menu: Video 1 Cursor/Stamp Audio 2 Box Effect 3 Spotlight Setting 4 Bar Capture Cursor Speed...
Page 86: Creating Your Own Startup Screen
Creating Your Own Startup Screen You can transfer any image on your computer to the projector, and then use it as the screen displayed when the projector is not receiving a signal. You can also set it to be displayed when you press the button, or as a startup screen.
Page 87: Setting Up When The Image Displays
Setting menu. Enter button to highlight Enter button to select Enter Logo screen displayed when the projector is not receiving a signal. button to move down to Enter button to select Enter Logo screen displayed when you press the...
Page 88: Customizing Projector Features
To test your setting, press the A/V Mute Press it again to turn off the image. Customizing Projector Features You can use the Setting menu to disable the projector’s sleep mode, adjust the image shape, and customize several other features. 1. Press the button.
Page 89: Setting Advanced Features
5. When you’re finished, press Setting Advanced Features You can use the Advanced menu to configure the projector for rear projection or ceiling mounting, and adjust several other features. 1. Press the 2. Use the 3. Press Fine-tuning the Projector...
Page 90: Viewing Lamp Usage And Other Information
4. Use the button to set the following options: Enter Language Select from nine languages to be used for the projector menus. Startup Screen Turn on to display the image or logo you have captured whenever the projector starts. See page 77 for more information.
Page 91: Restoring The Default Settings
3. When you’re finished, press Restoring the Default Settings The Reset All option lets you return all the projector settings to their default values. Select display the confirmation screen. Select...
Page 92: Maintaining And Transporting The Projector
You also need to periodically clean the air filter on top of the Before you clean any part projector. A clogged air filter can block ventilation needed to cool the of the projector, turn it projector and keep it from overheating.
Page 93: Cleaning The Lens
Cleaning the Lens Clean the lens whenever you notice dirt or dust on the surface. Cleaning the Projector Case Before you clean the case, first turn off the projector and unplug the power cord. Maintaining and Transporting the Projector Use a canister of compressed air to remove dust.
Page 94: Cleaning And Replacing The Air Filter
2. Stand the projector on end to keep dust and dirt from falling inside. 3. To clean the filter, EPSON recommends using a small vacuum cleaner designed for computers and other office equipment. If you don’t have one, gently clean the filter using a very soft brush (such as an artist’s camel-hair brush).
Page 95: Replacing The Lamp
You can check to see how many hours the lamp has been used. See page 81. Contact your dealer or call EPSON at (800) 873-7766 in the United States and Canada for a replacement lamp. Request part number ELPLP14 Maintaining and Transporting the Projector off.
Page 96 Follow these steps to replace the lamp: 1. Turn off the projector, then unplug the power cord. 2. Allow the projector to cool down for at least an hour (if it has been on). 3. Turn the projector upside-down to access the lamp compartment.
Page 97: Transporting The Projector
When transporting the projector for business use, first put it in a carrying case (such as an optional EPSON case), then pack it in a firm box, using cushioning around the case. When you are hand-carrying the projector, be sure to store it in a carrying case (such as an optional EPSON case).
Page 98: Solving Problems
Solving Problems his chapter helps you solve problems with your projector, and tells you how to contact technical support for problems you can’t solve yourself. This chapter explains the following: Using the projector’s on-screen help system What to do when the projector’s status lights flash...
Page 99: Using On-Screen Help
Return need to back up. If the solution is to adjust one of the settings, press the side of the ) button on the projector (or use the Select Keystone button on the remote control) to adjust it.
Page 100: What To Do When The Lights Flash
The lights on top of the projector indicate the projector’s status and let you know when a problem occurs. If the projector is not working correctly, first turn it off and unplug it. Then plug the power cord back in and turn on the projector. If this does not solve the problem, check the status lights on top of the projector and try the solutions recommended below.
Page 101 The air filter may be clogged. Clean or replace it as described on page 85. If the projector continues to overheat after you clean the air filter, the problem may be caused by damage to the cooling fan or internal circuits. Contact EPSON for help.
Page 102 If it continues to overheat, you may need to change the air filter. See page 85 for instructions. There is a problem with the cooling fan or temperature sensor. Turn off the projector and unplug it. Contact EPSON for help. Solving Problems...
Page 103: Solving Problems With The Image Or Sound
Solving Problems Check that the power light is green, not flashing, and the lens cap is off. The projector may be in sleep mode. If the power light is orange, press the button to turn the projector on. Power If the power was switched off and then on again, the projector may still be cooling down.
Page 104 Make sure your computer’s resolution doesn’t exceed UXGA (1600 1200, for the PowerLite 715c) or SXGA (1280 1024, for the PowerLite 505c), and the frequency is supported by the projector (see page 124). If necessary, change your computer’s resolution setting as described on page 96.
Page 105 Make sure your computer’s resolution setting is correct. Ideally, it should be 1024 768 to match the projector’s native resolution (800 600 on the PowerLite 505c). If this option isn’t available, select one of the other compatible video formats listed on page 124.
Page 106 Make sure the lens is fully extended. Adjust the focus using the focus ring. Make sure the lens is not fogged by condensation. You may need to wait before using the projector after moving it from a cold environment. Adjust the setting on the Video menu (see page 73).
Page 107 Press the button on the remote control. This resets Auto the projector’s tracking and sync settings. If further adjustment is needed, you can fine-tune the settings manually using the Video menu as described Sync on page 73.
Page 108 Make sure the audio cable is securely connected to both the projector and your computer’s headphone jack or audio out jack. See page 14 (for laptops) or Appendix A (for other systems).
Page 109: Solving Problems With The Remote Control
Solving Problems Make sure the remote control is turned on. Make sure you are within 30 feet of the projector, and within range of the projector’s front or back sensor (approximately 30° to left or right and 15° above or below).
Page 110: Solving Easymp Problems
When scenario files are transferred, they are converted to the .SIT format. You can only edit scenarios before they are transferred (in the .SIC format). You can’t access the memory card in the projector through the USB cable. To use the USB connection, your system must have a “clean”...
Page 111: Easymp Error Messages
EasyMP Error Messages Error discovered in the EasyMP system or No memory card Insert the memory card all the way into the projector’s card slot. See page 54 for instructions. No displayable file Only the following file types can be displayed from the memory card with EasyMP: Scenario files (.SIT), JPEG files (.JPG), and Bitmap...
Page 112: Where To Get Help
Electronic support and automated telephone services Service Access World Wide Web From the Internet, you can reach EPSON’s product support page at http://support.epson.com. After selecting your product, you can access troubleshooting information, download product documentation, and receive technical advice through e-mail.
Page 113 Before you call, please have the following information ready: You can purchase screens, carrying cases, or other accessories from EPSON at (800) 873-7766 or by visiting www.epson.com (U.S. sales only). In Canada, please call (800) 873-7766 for dealer referral Solving Problems...
Page 114: Appendix A: Connecting To Additional Equipment
Appendix A: Connecting to Additional Equipment his appendix explains how to connect the projector to a desktop computer or Macintosh, or a high-end workstation. The following information is covered: Installing the projector Connecting to a PC desktop computer Connecting to a desktop Macintosh...
Page 115: Installing The Projector
Keystone system (see page 79). If you place the projector’s lens so it’s level with the top of the screen, the image will be square and you won’t have to adjust it. If you place the lens lower than the top of the screen, you’ll have to tilt the projector upward if you want to fill the whole screen with the image.
Page 116: Connecting To A Pc Desktop Computer
Before you start, make sure the projector and speakers or PA system are turned off. 1. Connect the cable’s 3.5-mm stereo miniplug to the projector’s jack. Audio Out 2. Connect the RCA plugs to the speaker or PA system. Insert the cable’s red plug into the...
Page 117: Connecting The Computer Cable
Connecting the Computer Cable 1. Disconnect the monitor cable from the video port on the back of 2. Connect one end of the computer cable to the projector’s 3. Connect the other end of the computer cable to the computer’s 4.
Page 118: Connecting The Mouse Cable
PS/2 mouse port or a flat USB port. 1. Connect one end of the appropriate mouse cable to the projector’s port or the USB port, as shown.
Page 119: Connecting The Audio Cable
Connecting the Audio Cable If your presentation includes sound and you want to use the projector’s built-in speakers, you can use a computer audio cable. The required cable (3.5-mm stereo miniplug cable) is available from computer or electronics dealers. 1. Connect one end of the audio cable to the 2.
Page 120: Connecting To A Desktop Macintosh
Macintosh monitor. Follow the steps in each section for the cables you need to connect. Before beginning, turn off the projector and computer if they are on. Connecting the Computer Cable Follow these steps to connect the computer cable. You may not need to use the adapter as shown.
Page 121: Connecting The Mouse Cable
If the Macintosh has a USB port, you can use the USB mouse cable that came with the projector. If it has a round mouse port, you’ll need a Macintosh ADB mouse cable. See your projector dealer for help in obtaining the correct cable.
Page 122: Connecting The Audio Cable
Connecting to a High-End Workstation Your PowerLite projector is capable of remapping input resolutions up to 1600 1200 pixels (1280 1024 pixels on the PowerLite 505c). Since 1280 1024 pixels is the default resolution for most leading workstations, your projector is ideal for displaying workstation video output.
Page 123 Appendix A: Connecting to Additional Equipment...
Page 124: Appendix B: Notices
Do not use the projector near water or sources of heat. Use attachments only as recommended. Use the type of power source indicated on the projector. If you are not sure of the power available, consult your dealer or power company.
Page 125 Do not place the projector where the cord can be walked on. This may result in fraying or damage to the plug. Unplug the projector from the wall outlet before cleaning. Use a damp cloth for cleaning. Do not use liquid or aerosol cleaners.
Page 126: Remote Control Information
(14 to 140 °F) or in direct sunlight for long periods of time. Doing so may cause damage to the case. Do not use the projector with the lens cap in place. The heat generated by the lens may damage the cap.
Page 127: Declaration Of Conformity
Trade Name: Type of Product: LCD Projector Model: Appendix B: Notices EPSON AMERICA, INC. 3840 Kilroy Airport Way MS: 6-43 Long Beach, CA 90806-2469 (562) 290-5254 EPSON...
Page 128: Fcc Compliance Statement
FCC Compliance Statement For United States Users This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Page 129 Appendix B: Notices...
Page 130: Appendix C: Technical Specifications
Poly-silicon Thin Film Transistor (TFT) Diagonal: 0.9 inches (22.9 mm) F=2.0 to 2.2, f=35 to 42 mm 715c: 1024 768 pixels (native format) 505c: 800 600 pixels (native format) 24 bit, 16.7 million colors 715c: 1200 lumens (ANSI) 505c: 1100 lumens (ANSI)
Page 131: Projection Lamp
Projection Lamp Type Power consumption Lamp life Part number Remote Control Range Batteries Mouse Compatibility Supports PS/2, USB, ADB Dimensions Height Width Depth Weight Electrical Rated frequency Power supply Power consumption Appendix C: Technical Specifications UHE (Ultra High Efficiency) 150 W About 1000 hours ELPLP14 32.8 feet (10 meters)
Page 132: Environmental
Environmental Temperature Operating: 41 to 95 °F (5 to 35 °C) Storage: 14 to 140 °F (–10 to 60 °C) Humidity Operating: 20 to 80% RH, non-condensing Storage: 10 to 90% RH, non-condensing Safety United States FCC Part 15B Class B UL1950 Rev.
Page 133: Compatible Video Formats
To project images output from a computer, the computer’s video card must be set at a refresh rate (vertical frequency) that’s compatible with the projector; see the following table for compatible formats. As noted below, some images are automatically resized to display in one of the projector’s “native”...
Page 134 HDTV1125P HDTV1125P NTSC SECAM The image is resized so that it displays using one of the projector’s native formats (PowerLite 505c only). The image is resized so that it displays using one of the projector’s native formats. Not supported on the PowerLite 505c.
Page 135: Computer Video Port Pin Assignments
Computer Video Port Pin Assignments The Computer port is a female video RGB, 15-pin micro-D-style connector. Here are its pin assignments: Pin no. Appendix C: Technical Specifications Computer port Red video Green video Blue video Monitor (ID bit 2) Red video GND Green video GND Blue video GND +5 V...
Page 136: Index
CD-ROMs, 4 Ceiling mount, 8, 81, 106 Cell menu, 49 to 50 Cleaning air filter, 85 to 86 lens, 84 projector case, 84 Color adjusting, 74, 81 problems, 98 Comp button, 32, 99 CompactFlash memory cards, 41 Component video cable, 7, 8, 15...
Page 137 Desktop computer, connecting to, 107 to 113 Digital camera, connecting to, 15 to 18 Display order setting, 63 to 64 Display/Hide icon, 59 Distance from projector to screen, 10, 121 Drawing on the screen, 35 to 37 DVD player, connecting to, 15 to 18 EasyMP...
Page 138 121 Light button (on remote control), 30 Lights, status, 91 to 94 Lines, drawing on screen, 37 Logo, saving on projector, 77 to 79 Macintosh, connecting to, 111 to 113 Manuals, 3 to 5 Memory card accessing, 40 to 42, 52 to 54...
Page 139 Picture-in-picture video source, selecting, 79 Pin assignments, connector, 126 Pointer tool customizing, 76 using, 36 Positioning image, 25, 73 Positioning the projector, 10 to 11, 106 Power button, 21 consumption, 122 saving, 27, 80 status light, 91, 93 supply, 122...
Page 140 Continuous Play, 61 creating, 44 to 51 default location, 47 dragging and dropping PowerPoint files, 44 to 45 editing on the projector, 58 to 64 exiting, 57 presenting on the projector, 56 to 57 previewing slides, 62 to 63 problems, 101...
Page 141 89 to 99 remote control problems, 100 Turning off picture (using A/V Mute), 33 Turning off projector, 27 Turning on projector, 20 to 22 Unpacking projector, 6 to 7 installing driver, 42 problems, 100, 101 using cable to access memory card, 42...

This manual is also suitable for:

Powerlite 715c Emp505 - emp 505 svga lcd projector Emp-505 Emp-715 Elp-505 Elp-715

Epson PowerLite 505c User Manual

1 Setting up the Projector

2 Using the Projector

3 Using the Remote Control

4 Creating Presentations for Your Projector

5 Presenting Without a Computer

7 Maintaining and Transporting the Projector

8 Solving Problems

Appendix A: Connecting to Additional Equipment

Appendix B: Notices

Appendix C: Technical Specifications

Quick Links

Related Manuals for Epson PowerLite 505c

Summary of Contents for Epson PowerLite 505c

This manual is also suitable for:

Table of Contents
