Digital Camera
User's Guide
Getting Started
Taking Pictures
Viewing and Managing Your Photos
Making Camera Settings
Using Images on Your Computer
Camera Options and Accessories
Maintenance and Troubleshooting
Specifications
Icons That Appear on the LCD Monitor
4014713-00
XXX

Advertisement

Table of Contents
loading

Related Manuals for Epson PhotoPC 2100Z

Summary of Contents for Epson PhotoPC 2100Z

  • Page 1 Digital Camera User's Guide Getting Started Taking Pictures Viewing and Managing Your Photos Making Camera Settings Using Images on Your Computer Camera Options and Accessories Maintenance and Troubleshooting Specifications Icons That Appear on the LCD Monitor 4014713-00...

  • Page 2: Online Help

    Where to Find Information This User’s Guide Provides detailed information to help you set up and use your EPSON PhotoPC 2100Z, and the optional products available from EPSON. Also contains information on troubleshooting and installing the software on the PhotoPC 2100Z Software CD-ROM included with your PhotoPC 2100Z.
  • Page 3 ® DIGITAL CAMERA User’s Guide...

  • Page 4: Important Notice

    Neither is any liability assumed for damages resulting from the use of the information contained herein. Neither SEIKO EPSON CORPORATION nor its affiliates shall be liable to the purchaser of this product or third parties for damages, losses,...
  • Page 5 This product conforms to the following Directive(s) and Norm(s): Directive 89/336/EEC: A NOTE CONCERNING RESPONSIBLE USE OF COPYRIGHTED MATERIALS Like photocopiers, digital cameras can be misused by improperly photographing copyrighted material. Unless acting on the advice of a knowledgeable attorney, be responsible and respectful by obtaining the permission of the copyright holder before photographing published material.
  • Page 6 - iv -...

  • Page 7: Table Of Contents

    Introduction PhotoPC 2100Z Features ......1 Options......... . . 3 For United Kingdom users - use of options .
  • Page 8 Taking Pictures Using the LCD monitor ....31 Setting the flash .......33 Using the optical and digital zoom features .
  • Page 9 Your Computer....... 75 Accessing the EPSON Digital Camera Software User’s Guide ..... . 75 Accessing the EPSON PhotoQuicker User’s Guide .
  • Page 10 Chapter 6 Camera Options and Accessories Using Memory Cards .......85 Inserting a memory card into your computer .
  • Page 11 Appendix A Specifications Camera ......... . . 113 Physical dimensions .
  • Page 12 When Making Camera Settings ..... . .131 Camera setting menu ......131 When setting the date and time .

  • Page 13: Photopc 2100Z Features

    Share your photos with world through e-mail and on the Internet. The PhotoPC 2100Z comes with everything you need to get started, including EPSON Photo!4 software that lets you transfer pictures from the camera to your computer’s hard disk.
  • Page 14 Built-in flash with automatic flash, red-eye reduction, and flash off options Self-timer (ten second delay) Automatic shut-off to save battery power EPSON Photo!4 software to transfer photos to your computer and manage them EPSON AutoDownloader to help you organize your downloads...

  • Page 15: Options

    The asterisk acts as a substitute for the last digit of the product number, which varies by country. The PhotoPC 2100Z comes with an 8 MB CompactFlash memory card. For details on using this option, see “Using Memory Cards” on page 85.

  • Page 16: For United Kingdom Users - Use Of Options

    For United Kingdom users - use of options EPSON (UK) LTD shall not be liable against any damage or problems arising from the use of any options or consumable products other than those designated as Original EPSON Products or EPSON Approved Products by EPSON (UK) LTD.
  • Page 17 Remove the batteries and/or disconnect the AC adapter from the camera, then unplug the AC adapter from the electrical outlet. Then contact your EPSON dealer. To prevent possible injury, do not take flash pictures in close proximity to anyone’s eyes.

  • Page 18: When Using The Strap

    If you plan to use the camera and optional equipment in Germany, observe the following: To provide adequate short-circuit protection and over- current protection for these products, the building installation must be protected by a 10 or 16 Amp circuit breaker.

  • Page 19: When Using The Batteries

    When using the batteries Note the following when using batteries. Read all relevant safety and operating instructions before using the batteries. Do not use manganese batteries (IEC R6). Do not charge primary (non-rechargeable) batteries. To avoid fire or electric shock, do not use batteries that are leaking or damaged in any way.

  • Page 20: For Users In The United Kingdom

    Do not insert batteries into wall outlets or other power sources such as car cigarette lighter sockets. Do not solder lead wires or terminals directly to a battery. If battery acid gets into your eyes or on your skin, immediately rinse the affected area thoroughly with water and seek medical treatment.

  • Page 21: For Users In The United Kingdom, Singapore, And Hong Kong

    As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows: The green and yellow wire must be connected to the terminal in the plug which is marked with the letter E or with the earth symbol (G).
  • Page 22 - 10 -...

  • Page 23: Chapter 1 Getting Started

    Chapter 1 Getting Started This chapter helps you to set up your PhotoPC 2100Z and covers the following topics: Unpacking your PhotoPC 2100Z Getting familiar with the camera parts Installing the CompactFlash memory card Installing and replacing batteries Setting the time and date...

  • Page 24: Unpacking Your Photopc 2100Z

    Unpacking Your PhotoPC 2100Z Make sure that your camera box contains all of the items shown below. camera 8 MB CompactFlash memory card (installed in the camera) CD-ROM (quantity varies by location) alkaline batteries (4) - 12 - USB cable...

  • Page 25: Camera Parts

    Camera Parts After unpacking your PhotoPC 2100Z, take a few minutes to learn about the components shown below. Front shutter button OPEN switch timer light viewfinder front flash lens - 13 - AC adapter connector Interface connector...
  • Page 26 Back viewfinder print button LCD monitor function button Bottom connector cover indicator light button MENU button tripod mount - 14 - button button memory card cover button memory card EJECT switch battery cover...
  • Page 27 Indicator lights The camera has an indicator light beside the viewfinder. It turns on and blinks in different colors to guide you through the picture-taking process, or to indicate the status of the camera. See below for details. Light Green (On) Green (Blinking) Orange (On)

  • Page 28: Setting Up Your Camera

    A memory card is not inserted. Insufficient space in memory card to take a picture. Low battery. Error. Try to turn the camera off and back on. If the red light is still on, contact your EPSON dealer for servicing. - 16 -...
  • Page 29 1. Make sure the lens cover is closed and the indicator light next to the viewfinder is off. Caution: Never remove or insert a memory card while the camera is on. The card may be damaged and the data in the card may be lost.

  • Page 30: Installing And Replacing The Batteries

    “Using Memory Cards” on page 85. Installing and replacing the batteries Your PhotoPC 2100Z comes with four AA (IEC LR6) alkaline batteries. See the following sections for details on installing and replacing them. See “Maintaining the Batteries” on page 99, for information on cleaning, storing, and disposing of the batteries.
  • Page 31 Caution: Do not use manganese batteries (IEC R6). Always use batteries from the same package. Do not mix old and new batteries. Be sure to turn the camera off before removing the batteries. Note: Do not leave batteries in the camera for a long time without using it.
  • Page 32 1. Turn the camera upside down with the lens facing you. Slide and open the battery cover as shown below. 2. Insert four batteries into the compartment, positioning the + and - ends as shown below. Warning: Do not use different types of batteries together. Doing so could cause fire or explosion.
  • Page 33 3. Lower the battery cover shut and hold it down while you slide and lock it, as shown below. Replacing the batteries If the batteries are almost out of power, the icons appear in turn on the LCD monitor or the camera makes a sound, or both.

  • Page 34: Setting The Time And Date For The First Time

    Battery life varies depending on battery type and manufacturer. If you use rechargeable Ni-MH batteries in the PhotoPC 2100Z, make sure that all four batteries are fully charged when you replace them. If you find that your batteries run out soon after recharging them a number of times, make sure that you discharge the batteries completely before recharging them.
  • Page 35 1. Slide the OPEN switch in the direction shown below to turn the camera on. 2. The date and time appear on the LCD monitor as shown on the right. The month, day, and year are displayed with the month highlighted.
  • Page 36 6. After you are finished making the date and time settings, press the button. Note: To change the setting, or the order that the date is displayed, see “Setting the Time and Date” on page 65. You are now ready to take pictures. See the next chapter for instructions on taking pictures.

  • Page 37: Chapter 2 Taking Pictures

    Chapter 2 Taking Pictures Using the PhotoPC 2100Z to take pictures is similar to using a traditional “point and shoot” camera. This chapter explains how to take pictures with the LCD monitor and the viewfinder, and how to use the camera’s picture-taking features.

  • Page 38: Buttons Overview

    Buttons overview There are seven buttons on the back of your PhotoPC 2100Z. These buttons are for making various settings and for using the different features of the camera. In this user’s guide, the buttons are named as follows. button...

  • Page 39: Turning The Camera On And Off

    At certain times, icons and other indicators appear in the LCD monitor as shown below. For more information, see “Taking Pictures Using the LCD monitor” on page 31. icons for other information focus frame other icons Turning the camera on and off Read the following sections to turn the camera on and off.
  • Page 40 To take pictures, slide the OPEN switch in the direction shown below. The lens extends and the indicator light next to the viewfinder on the back of the camera briefly blinks green, and then stays on. A live preview image appears on the LCD monitor. To view pictures you have previously taken, press the button on the back of the camera.
  • Page 41 Note: If the following appears on the LCD monitor when you turn the camera on, see “Setting the time and date for the first time” on page 22. If the following icons appear on the LCD monitor after you press button, there are no photos saved in the camera’s memory card.
  • Page 42 Turning the camera off To turn the camera off, first slide the OPEN switch in the direction shown below, if necessary. Slide the OPEN switch in the direction of the arrow to turn the camera off. If the LCD monitor or the indicator light next to the viewfinder remains on, press the once.

  • Page 43: Taking Pictures Using The Lcd Monitor

    To turn the camera back on when the lens is retracted, either button or slide the OPEN switch to open the lens press the cover. Otherwise, slide the OPEN switch to close the lens cover, then slide it again to open the lens cover and turn the camera back on.
  • Page 44 Make sure that you are not blocking the areas around the lens, flash, and timer light with your finger, the strap, clothing, or other objects. 2. Hold the shutter button halfway down to lock the auto focus. The focus is locked when the indicator light next to the viewfinder stops blinking and the focus...

  • Page 45: Setting The Flash

    Note: For more information on specifying the number of prints, see “Making Print Settings” on page 58. After you are finished taking pictures, you can view the pictures you took, delete them, and make print settings. See Chapter 3, “Viewing and Managing Your Photos”. Setting the flash You can choose between three flash settings: Flash Auto, Flash Off, and Red-eye Reduction.
  • Page 46 2. Press the function button repeatedly under the flash setting icon to select the appropriate icon. See the table below for function descriptions. Flash Auto Flash Off Red-eye Reduction 3. Once you are finished setting the flash, take a picture. The flash fires whenever more lighting is needed.

  • Page 47: Using The Optical And Digital Zoom Features

    Using the optical and digital zoom features You can capture a smaller portion of your subject at a higher magnification using the zoom feature. When taking pictures with the LCD monitor, you can use the digital zoom in addition to the optical zoom to seamlessly magnify the image by as much as five times.

  • Page 48: Using The Self Timer

    Note: You cannot use the digital zoom feature when taking pictures using the viewfinder. Photos taken using the digital zoom feature take more time to be processed. Using the self timer You can take a picture of yourself easily by using the self timer.
  • Page 49 4. Press the button. The the LCD monitor. Note: To cancel this setting, press the back to the right. 5. Press the shutter button to start the self timer. The camera beeps and icons appear on the LCD monitor to indicate the countdown, and the red timer light on the front of the camera starts blinking.

  • Page 50: Taking Close-Ups Using The Macro Setting

    Taking close-ups using the macro setting Use the macro feature for taking close-ups. This setting allows you to take pictures of subjects 30 to 50 centimeters away from the camera. 1. Turn on the camera by sliding the OPEN switch to open the lens cover.

  • Page 51: Taking Pictures Against A Bright Background

    Note: You cannot use the macro feature when taking pictures using the view finder. Taking pictures against a bright background If the background is excessively bright, use the backlight setting to avoid making the subject of the photo appear too dark. Follow the steps below. 1.

  • Page 52: Taking High-Resolution Photos Using The Hypict Feature

    See “Taking Pictures Using the Viewfinder” on page 47. Taking high-resolution photos using the HyPict feature By default, your PhotoPC 2100Z takes pictures that are fit for printing with a resolution of 1800 1200 pixels You can also take pictures that have a higher resolution of 2160 1440 pixels.
  • Page 53 1. Turn on the camera by sliding the OPEN switch to open the lens cover. Note: For more information on turning on the camera, see “Turning the camera on and off” on page 27. 2. Press the button. The tool box opens, other icons appear above it, and a red frame appears around the tool box.

  • Page 54: Taking Pictures To Share Over The Internet

    See “Taking Pictures Using the Viewfinder” on page 47. Taking pictures to share over the Internet By default, your PhotoPC 2100Z takes pictures that are fit for printing with a resolution of 1800 1200 pixels You can also take pictures that have a smaller resolution of 720 480 pixels, which are ideal for sharing over the Internet via e-mail.
  • Page 55 2. Press the button. The box opens, other icons appear above it, and a red frame appears around the tool box. 3. Press the button repeatedly until the red frame appears around the bag. 4. Press the button. The icons appear. 5.

  • Page 56: Taking Pictures In Low-Light Conditions

    Taking pictures in low-light conditions Follow the steps below for best results in low-light conditions, such as when taking pictures of a nightscape or under insufficient room light. More time is required to take a picture with this setting. 1. Turn on the camera by sliding the OPEN switch to open the lens cover.
  • Page 57 6. Press the button. The the LCD monitor. Note: To cancel this setting, press the back to the right. 7. Once you are finished making the setting, take a picture. Note: If you want to take a picture of a person or persons in a nightscape, set the flash function to the images of your subject and the background.

  • Page 58: Using The White Balance Feature

    Using the white balance feature The EPSON PhotoPC 2100Z adjusts the balance of colors automatically. If you want to make the colors in your photos appear more realistic, use the white balance setting as follows. For example, turn the white balance setting on when taking...

  • Page 59: Taking Pictures Using The Viewfinder

    3. Press the button repeatedly until the red frame appears around the tool bag. 4. Press the button. The icons appear. 5. Press the button repeatedly until the red frame appears around the icon. 6. Press the button. The the LCD monitor. Note: To cancel this setting, press the back to the right.
  • Page 60 2. Press the MENU button twice to turn the LCD monitor off. 3. Wait until the indicator light beside the viewfinder comes 4. Look straight through the viewfinder and center your subject in the focus frame. Note: Hold the camera steadily with both hands and keep it still for a few moments after you press the shutter button.

  • Page 61: Setting The Flash

    After you take the picture, the LCD monitor comes on momentarily, displaying the picture you just took, and appears on the bottom left of the LCD monitor. At this time, you can specify the number of prints by pressing the print button.
  • Page 62 2. Press the function button repeatedly under the flash setting icon to select the appropriate icon. See the table below for function descriptions. Flash Auto Flash Off Red-eye Reduction 3. Once you are finished setting the flash, press the MENU button twice to turn the LCD monitor off.

  • Page 63: Using The Optical Zoom Feature

    Using the optical zoom feature You can capture a smaller portion of your subject at a higher magnification using the zoom feature. 1. Turn on the camera by sliding the OPEN switch to open the lens cover. Note: For more information on turning on the camera, see “Turning the camera on and off”...

  • Page 64: Making Other Settings

    Making other settings When taking pictures using the viewfinder, you can use many of the same features that are available when taking pictures using the LCD monitor. To use these features, you must first make settings using the LCD monitor. Once you have made the desired settings, press the MENU button twice to turn off the LCD monitor, and then take pictures using the viewfinder.

  • Page 65: Chapter 3 Viewing And Managing Your Photos

    Chapter 3 Viewing and Managing Your Photos This chapter explains how to view photos on your camera’s LCD monitor. It also includes explanations for deleting photos, and for making print settings. Viewing Your Photos on the LCD Monitor See the following sections to view photos on your camera’s memory card, follow the steps below.

  • Page 66: Displaying Nine Photos At Once

    If the lens on your camera is extended, you can take a picture afterwards. If it is not extended, the camera is off. Displaying nine photos at once The PhotoPC 2100Z’s monitor can display nine photos at once. To view nine photos at once, follow the steps below. 1. Press the button to display your photos.

  • Page 67: Magnifying Photos

    3. Press the button. After the indicator light blinks green, the LCD shows nine photos. Note: To cancel this setting, press the 4. To select the next photo, press T on the the previous photo, press W. 5. To exit the multi-display, press the If you make other settings, you can switch back to viewing one photo at a time.

  • Page 68: Deleting Photos

    4. Press the button. 5. The icon appears at the top of the LCD monitor. This icon indicates that the center part of the photo is magnified now. 6. To change the magnified area, press T (to the right) or W (to the left) on the to go up or the 7.

  • Page 69: Deleting All Of The Photos

    3. Press the function button under the icons appear in turn. 4. Press the button to delete the selected photo. Note: To cancel this setting, press the function button under the icon. Deleting all of the photos To delete all of the photos stored on the memory card in your camera at once, follow these steps.

  • Page 70: Making Print Settings

    EPSON Photo!4 or a different EPSON camera. Making Print Settings You can use your PhotoPC 2100Z to make settings that determine how your photos are printed. After you select which photos you want to print, you can make the following...
  • Page 71 To make these settings, see the following sections. Note: To print the photos on your memory card, see the online EPSON Digital Camera Software User’s Guide. - 59 -...

  • Page 72: Selecting Photos And Specifying The Number Of Prints

    Selecting photos and specifying the number of prints You can use the select a photo to be printed, and to specify the number of prints. Follow the steps below. 1. Press the button to display your photos. See “Displaying your photos” on page 53. The last photo you took appears on the LCD monitor.

  • Page 73: Making The Print Brightness Setting

    3. Press the print button once to specify one print for that photo. Press the button again to increase the number of prints. You can specify up to nine prints per photo. The number of prints appears with an icon in the top left corner of the LCD monitor.

  • Page 74: Resetting The Number Of Prints To Zero

    The brightness of the image on the LCD monitor changes when you change the brightness setting. This approximates the effect the setting will have when printed by a printer that supports the PRINT Image Matching system. 1. Press the button. The last photo you took appears on the LCD monitor.

  • Page 75: The Icon

    Note: To specify the number of prints for a selected photo, see “Selecting photos and specifying the number of prints” on page 60. Specifying zero prints for individual photos Follow the steps below to specify zero prints for one photo at a time.
  • Page 76 Specifying zero prints for all photos Follow the steps below to specify zero prints for all photos in the memory card at once. 1. Press the button. The last photo you took appears on the LCD monitor. 2. Press the button repeatedly until the red frame appears around the...

  • Page 77: Chapter 4 Making Camera Settings

    Chapter 4 Making Camera Settings You can change the time and date settings, and specify the order in which date is displayed. See the following sections. Setting the Time and Date If the memory for the time and date are deleted, or if you want to change them, you can set them as follows.
  • Page 78 The LCD monitor appears as shown on the right. 3. Press the button. The date and time appear on the LCD monitor as shown on the right. The month, day, and year are displayed with the month highlighted. Note: To go back, press the button again.

  • Page 79: Changing The Display Order

    Note: The flash setting may change while making the above settings. To change the flash setting back, see “Setting the flash” on page 33. Changing the display order You can change the order that the year, month, and day are displayed on the camera’s LCD monitor. Follow the steps below.
  • Page 80 4. Press the button to change the order that the date is displayed. The order at the top of the LCD monitor changes as well as the selected icon. You can choose between the following orders. Note: The flash setting may change while making the above settings. To change the flash setting back, see “Setting the flash”...

  • Page 81: Setting The Beep

    Setting the Beep You can choose from three types of beep settings. Make the settings as follows and see the table for descriptions. 1. Slide the OPEN switch to turn the camera on. 2. While pressing the The LCD monitor appears as shown on the right.
  • Page 82 Silent Note: To go back to the previous screen on the LCD monitor, press the function button. 5. After you finish making the setting, press the then press the function button. Note: The flash setting may change while making the above settings. To change the flash setting back, see “Setting the flash”...

  • Page 83: Chapter 5 Using Images On Your Computer

    Connecting and disconnecting the camera to your computer Note: For information on using the EPSON camera software, see the online EPSON Digital Camera Software User’s Guide. For information on printing photos with EPSON PhotoQuicker, see the online EPSON PhotoQuicker User’s Guide.

  • Page 84: For Windows

    For Windows The system requirements for using the PhotoPC 2100Z with Windows are as follows: USB port (TYPE A receptacle) At least 48 MB RAM (64 MB when using EPSON PhotoQuicker) Hard disk drive with at least 50 MB of free space...

  • Page 85: Included Software

    Note: The included software cannot be used with the Multiple Users function of Mac OS 9. Included Software The EPSON Camera Software CD-ROM that comes with your PhotoPC 2100Z digital camera contains the following EPSON software. PhotoPC 2100Z USB driver Driver necessary to connect your camera to your computer (except for Windows 2000 and Mac OS 9).

  • Page 86: Installing The Software

    Software necessary for viewing the included EPSON Digital Camera Software User’s Guide. Installing the Software To install the necessary software, see the online EPSON Digital Camera Software User’s Guide. For instructions on viewing this manual, see “Accessing the EPSON Digital Camera Software User’s Guide”...

  • Page 87: Viewing The Software User's Guides On Your Computer

    2. The EPSON Installation Program dialog box appears. Select View PDF Manual, then click Note: If the EPSON Installation Program dialog box does not appear, double-click the My Computer icon. Click the CD-ROM icon, then select Open from the File menu. Then double-click Setup.exe.
  • Page 88 2100Z Camera Software CD into the CD-ROM drive. In the EPSON folder that appears on your computer’s desktop, double-click the English icon. Note: If the EPSON folder does not appear on your desktop, double- click the EPSON icon on your desktop. 2. Double-click the Manual folder. Note:...

  • Page 89: Accessing The Epson Photoquicker User's Guide

    Accessing the EPSON PhotoQuicker User’s Guide The online EPSON PhotoQuicker User’s Guide is installed automatically when you install the EPSON PhotoQuicker software. Follow the steps below to view the manual. For Windows Click Start, point to Programs, then to EPSON PhotoQuicker, and then click EPSON PhotoQuicker3.X...

  • Page 90: Connecting The Camera To Your Computer

    Connecting the camera to your computer You can connect your PhotoPC 2100Z to a computer using the USB cable. Before connecting your camera, make sure that the USB driver is installed in your computer (except for Windows 2000 and Mac OS 9). For installation instructions, see the online EPSON Digital Camera Software User’s Guide.
  • Page 91 To connect the camera, follow the steps below. 1. Turn on your computer. 2. Plug the cable connector into the USB port on your computer or the port on the USB hub connected directly to your computer. USB port on computer Caution: Be sure to use the USB cable that comes with your camera...
  • Page 92 3. Open the connector cover on the side of the camera and insert the other end of the USB cable into the interface connector as shown below. Make sure that the shape of the cable connector corresponds to the shape of the interface connector.
  • Page 93 Close all applications, then install the USB driver (except for Windows 2000 and Mac OS9) following the instructions in the online EPSON Digital Camera Software User’s Guide. When you connect the camera, the indicator light next to the viewfinder blinks orange while the connection is being established.

  • Page 94: Disconnecting The Camera From Your Computer

    Disconnecting the camera from your computer After you are finished using the camera with the computer, be sure to disconnect the camera correctly. Follow the steps in the appropriate section below. Caution: Be sure to follow these steps when disconnecting the camera. Doing otherwise may damage the camera or memory card, and could cause your computer to function incorrectly.
  • Page 95 2. Click the Stop button. The Stop a Hardware device dialog box appears. 3. Select USB Mass Storage Device, then click the OK button. 4. A confirmation message appears. Click OK. Note: If the Problem Ejecting USB Mass Storage Device window appears, click the OK button and restart the operation from step 1.
  • Page 96 - 84 -...

  • Page 97: Chapter 6 Camera Options And Accessories

    Chapter 6 Camera Options and Accessories This chapter describes how to use the optional equipment that is available from EPSON to expand the memory and flexibility of your PhotoPC 2100Z. The following topics are included in this chapter. Using CompactFlash memory card...

  • Page 98: Inserting A Memory Card Into Your Computer

    Note: A memory card must be installed in your PhotoPC 2100Z before you can take pictures. One has been installed in the camera prior to shipment. To install a memory card, see “Installing and removing a memory card” on page 16.
  • Page 99 To insert the memory card in your computer, follow these steps. 1. If necessary, remove the memory card from the camera. See “Installing and removing a memory card” on page 16. 2. Insert the memory card all the way into the adapter (sold separately), as shown on the right.

  • Page 100: Copying Files Directly From The Memory Card

    Macintosh documentation for more information. You can also access the files on your memory card using the included EPSON Photo!4 software. For instructions, see the online EPSON Digital Camera Software User’s Guide. 1. Connect the camera to your computer, or insert the memory card into the PC Card slot in your computer or other device.

  • Page 101: Formatting Memory Cards

    Note: The PhotoPC 2100Z saves image files in the automatically generated number from 100 to 999. Photos that you have taken are automatically named in the order in which they were saved to the memory card. For example, EPSN0012 is the name of the twelfth photo that was saved.

  • Page 102: Lcd Monitor

    To format a memory card, follow the steps below. Caution: When you format a memory card, all the data on the card is deleted, including any photos that ware locked using EPSON Photo!4 or a different EPSON camera. 1. Slide the OPEN switch to turn the camera on.

  • Page 103: Using Rechargeable Batteries

    “Setting the flash” on page 33. Using Rechargeable Batteries You can use Ni-MH rechargeable batteries (Model EU-24) with your PhotoPC 2100Z, instead of the included four AA (IEC LR6) alkaline batteries. The rechargeable batteries help you save time and money that you might otherwise spend buying replacement alkaline batteries.
  • Page 104 Batteries that are charged in a hot environment wear out more quickly. Do not leave batteries in the camera or charger for a long time without using them. See “Storing the batteries” on page 100 for storage instructions. Rechargeable batteries wear out with repeated use; as their charging capacity decreases, your camera’s operating time decreases.

  • Page 105: Using The Ac Adapter

    Using the AC Adapter The AC adapter (B867 PhotoPC 2100Z to a standard electrical outlet. This is especially useful when you are previewing pictures, transferring pictures, or making print settings. The adapter powers the camera, but does not charge the batteries. In some locations the AC adapter comes with a separate AC power cable.
  • Page 106 To avoid losing any images or settings, make sure that the camera is finished processing and is turned off before you connect or disconnect the AC adapter. Then follow the steps below. 1. If your AC adapter has a separate AC power cable, push the cable connector firmly into the AC inlet.
  • Page 107 Caution: Place the camera and the AC adapter near an electrical outlet where the plug can be easily unplugged. Note for French-speaking users: Placez l'appareil photographique et ses options près d'une prise de courant où la prise peut être débranchée facilement.
  • Page 108 - 96 -...

  • Page 109: Chapter 7 Maintenance And Troubleshooting

    Chapter 7 Maintenance and Troubleshooting The PhotoPC 2100Z is easy to take care of, and most problems can be solved quickly and easily. This chapter helps you to maintain your camera and contains information on the following topics. Handling, cleaning, and storing the camera...

  • Page 110: Handling The Camera

    Handling the camera Keep the following points in mind when handling the camera. To avoid damaging the optics of the camera, do not expose the lens to direct sunlight for extended periods of time. Avoid sudden temperature changes, which can cause moisture to form on the camera and optional equipment.

  • Page 111: Storing The Camera

    Storing the camera If you are not planning to use the camera for a long period of time, remove the batteries and store them at a low temperature in a dry location. This prevents damage to the camera from battery leaks or corrosion. Do not store the camera in the following locations.

  • Page 112: Storing The Batteries

    To prevent this kind of power loss, keep the contact points ( ) on the batteries and inside the battery cover clean. When necessary, wipe them with a soft, dry cloth. If you are using a battery charger, clean the terminals of the battery charger with a soft, dry cloth before use to ensure that your batteries charge fully.

  • Page 113: Disposing Of Batteries

    Warning: Do not store batteries together with metal objects, which could short-circuit the batteries. Avoid storing batteries in extremely hot or humid locations. Store batteries out of reach of children. Always remove the batteries from the camera and charger before storing. Batteries left in your camera and charger for a long time could leak and cause damage.

  • Page 114: Problems And Solutions

    To transfer photos, see the EPSON Digital Camera Software User’s Guide. To delete photos, see “Deleting Photos” on page 56, or “Formatting memory cards” on page 89.
  • Page 115 These icons appear in turn when a memory card is not installed in your camera. No buttons will function. Turn off the camera, then insert a memory card. For instructions on installing a memory card, see “Installing and removing a memory card” on page 16. These icons appear in turn when your camera requires time to process data.
  • Page 116 Note: To delete pictures using the LCD monitor, see “Deleting Photos” on page 56. To transfer pictures to your computer before deleting them, see the online EPSON Digital Camera Software User’s Guide. icons appear in - 104 -...
  • Page 117 The camera may be connected to your computer. When it is connected, you can use only the information, see “Connecting and Disconnecting the Camera” on page 77. The camera takes too long to take a picture. You may be pressing the shutter button all the way down at once.
  • Page 118 Nothing appears on the LCD monitor. Make sure that the batteries are installed correctly. See “Installing the batteries” on page 19. Also, make sure that you are using appropriate batteries and that they are charged. See “Replacing the batteries” on page 21. The camera may have shut off automatically after standby mode to save power.
  • Page 119 LCD monitor, or transfer the pictures to your computer and then delete them. Note: The PhotoPC 2100Z saves image files in the automatically generated number from 100 to 999. The folder name begins with a three digit number, from 100 to 999.

  • Page 120: Picture Problems

    Picture problems If you are not satisfied with the photos that you get from your PhotoPC 2100Z, you may need to adjust some of the camera’s settings, or you may need to brush up on your photography techniques. Try the suggestions listed below.
  • Page 121 If your photos look better on the computer screen or LCD monitor than when you print them out, you may need to upgrade your printer. EPSON color ink jet printers provide excellent image quality. Your picture is blurry or out of focus.
  • Page 122 When you use the built-in flash, make sure that you are within the effective flash range of 50 to 320 centimeters for a wide-angle shot, and 50 to 230 centimeters for a telephoto shot. When using the macro feature, you can position the camera 30 to 50 centimeters away from the subject.
  • Page 123 The color in your photos does not look right. When you take pictures under certain artificial lighting conditions, the colors may be slightly distorted. You can use image-editing software to adjust the color. When you want to get more realistically colored images (for example, reddish images at dusk), set the white balance.
  • Page 124 - 112 -...

  • Page 125: Appendix A Specifications

    Appendix A Specifications Camera Model G871A Physical dimensions Width Height Depth Weight Temperature Humidity (non-condensing) 130 mm (The width including the strap protrusion is 146 mm) 73 mm 46.7 mm 265 g (without batteries, memory card, and strap) Operating: 5 to 35°C Non-operating: -20 to 60°C Operating: 30 to 80% Non-operating: 10 to 80%...

  • Page 126: Product Type

    Product type Type Zoom LCD monitor Memory card Digital still AF camera with LCD monitor 1/2.6 inch color area CCD (2.18 megapixels – effective picture element) Optical 2 zoom Digital 2.5 zoom 1.6-inch D-TFD color LCD monitor (approximately 55 K pixels) CompactFlash memory card - 114 -...

  • Page 127: Recorded Image

    Recorded image Data types Image quality modes (image size) Alternative formats JPEG image following Exif Ver.2.1 and recorded based on The Design rule for camera file system (16 million colors, 24 bit) Note: Exif is a standard format for audio/image files.

  • Page 128: Optical

    Optical Lens Focal length (AF area) Focus Sensitivity Aperture Shutter Exposure control White balance Viewfinder Self timer f = 5.6 - 11.2 mm (equivalent to a 35 - 70 mm lens on a 35 mm camera) F3.3 (5.6 mm) - F4.5 (11.2 mm) 0.5 m to infinity 0.3 to 0.5 m (macro mode) Auto focus...

  • Page 129: Functional

    Flash Flash modes Built-in flash range Range Functional Photo processing time in seconds (approximate) Image quality mode e-mail Print Hypict Built-in automatic luminance control flash Automatic, flash off, red-eye reduction 0.5 to 3.2 m (Wide) 0.5 to 2.3 m (Tele) Photo Photo processing processing...

  • Page 130: Interface

    DC 7.0 V When using the optional AC adapter (model EU-40) Battery life When using the four included alkaline batteries and taken under conditions determined by EPSON. Taking photos using the LCD monitor Taking photos using the View Finder Viewing photos Max.
  • Page 131 Power consumption Charging temperature Dimensions Weight AC 100 - 240 V, 50 - 60 Hz DC 1.2 V 490 mA 4 EPSON Ni-MH Batteries (Model EU-24) Max. 240 min. 5 to 35°C 76 115 28 mm Approx. 130 g - 119 -...

  • Page 132: Pcmcia Adapter

    Optional Battery Model EU-24 Type name Type Size Ratings Temperature Humidity Weight PCMCIA Adapter Interface Card slot type Physical Dimensions: Width Height Depth Cylindrical sealed Nickel-Metal Hydride rechargeable battery SBA HR6 IEC HR15/51 AA / IEC LR6 compatible DC 1.2 V Charging: 5 to 35°C Storage: -20 to 30°C 45 to 85% RH...

  • Page 133: Optional Ac Adapter

    Optional AC Adapter Model EU-40 Input Output Power consumption Physical Dimensions: Width Height Depth Weight AC 100 - 240 V, 50 - 60 Hz DC 7.0 V, 2.0 A Max. 0.4 A, 19 W 43 mm 31 mm 104 mm Approx.
  • Page 134 - 122 -...

  • Page 135: Appendix B Icons That Appear On The Lcd Monitor

    Appendix B Icons That Appear on the LCD Monitor A variety of icons appear on the LCD monitor at different times to help you use your camera, and to inform you of the camera’s status. See the following sections for information on the icons that appear when you take pictures and make settings, and when the camera needs help.

  • Page 136: With The Tool Box Open

    With the tool box open The remaining number of pictures you can take. Shows the current flash setting. See “Setting the flash” on page 33. Shows the approximate amount of remaining battery power. For using the self timer. See page For using the macro feature to take close-ups.

  • Page 137: With The Bag Open

    With the bag open The remaining number of pictures you can take. Shows the current flash setting. See “Setting the flash” on page 33. When using the zoom feature Appears when the zoom feature is being used. Shows the current optical zoom level.

  • Page 138: When Specifying The Amount Of Prints After Taking A Picture

    When specifying the amount of prints after taking a picture Number of prints specified for the currently displayed photo. See page 60. Appears after you take a picture. See page 31. When Viewing Photos When you turn the camera on to view photos with the LCD monitor, a tool box monitor.

  • Page 139: With The Tool Box Open

    With the tool box open The number of the currently selected photo. To select a different photo, see page 53. (blue) For deleting the currently selected photo. See page 56. Shows the approximate amount of remaining battery power. For making the print brightness setting.

  • Page 140: When Magnifying A Photo

    When magnifying a photo Shows which part of the photo is displayed. See page 55. To move to the upper part of the magnified photo. See page 55. To move to the lower part of the magnified photo. See page 55. (Use the button to scroll right and left) When there are no photos in the memory card...

  • Page 141: When Specifying The Amount Of Prints

    When specifying the amount of prints Number of prints specified for the currently selected photo. The number of the currently selected photo. Total number of prints to be made. Shows the approximate amount of remaining battery power. Tool box from which other icons emerge.

  • Page 142: When Selecting Zero Prints

    When selecting zero prints Number of prints specified for the currently selected photo. This blue icon is for deleting the currently displayed photo. See page 56. The number of the currently selected photo. Shows the approximate amount of remaining battery power. For specifying zero prints of the displayed photo.

  • Page 143: When Making Camera Settings

    When Making Camera Settings See the following sections for brief explanations of the icons that appear on the LCD monitor when you make date and time settings and beep settings, and when you format the memory card. Camera setting menu To go back to the preview screen.

  • Page 144: When Setting The Date And Time

    When setting the date and time For increasing the value of selected item. See page 65. For decreasing the value of selected item. See page 65. (Use the When formatting the memory card To go back to the previous screen. See page 65. button to scroll right and left) Indicates that you are about to format the memory card.

  • Page 145: Status And Error Icons

    Status and Error Icons See the following sections for brief explanations of icons that appear on the LCD monitor to tell you the camera’s status or to alert you to a problem. Informs you that the automatic shut-off feature has been triggered. See page 102. Alerts you that the memory card cannot store any more photos.
  • Page 146 - 134 -...

  • Page 147: Glossary

    Glossary application A software program that helps you carry out a particular task, such as word processing, image editing, or financial planning. Short for binary digit. The smallest unit of data in computer processing. A bit can represent two values: on and off, or 1 and 0. browser (Web browser) An application which allows users to view HTML documents.
  • Page 148 exposure The amount of light the camera captures when a photo is taken. image Data representing a two-dimensional scene. A digital image is composed of pixels arranged in a rectangular array with a certain height and width. Each pixel may consist of one or more bits of information, representing the brightness of the image at that point.
  • Page 149 PRINT Image Matching A new standard that allows digital cameras to record special information about the photos it takes and relay that information seamlessly to a printer compatible with this standard. This information can be used by printers that support the PRINT Image Matching system for enhanced printing results.
