Page 1: Print Server
Model DP-101 Multiprotocol Ethernet Print Server Hardware Guide Rev. 03 (October, 2000) -
Page 2: Limited Warranty
Registration Card. If a Registration Card for the product in question has not been returned to a D-Link office, then a proof of purchase (such as a copy of the dated purchase invoice) must be provided when requesting warranty service. The term "purchase" in this software warranty refers to the purchase transaction and resulting license to use such software. - Page 3 D-Link Offices for Registration and Warranty Service The product's Registration Card, provided at the back of this manual, must be sent to a D-Link office. To obtain an RMA number for warranty service as to a hardware product, or to obtain warranty service as to a software product, contact the D-Link office nearest you.
- Page 4 Wichtige Sicherheitshinweise 1. Bitte lesen Sie sich diese Hinweise sorgfältig durch. 2. Heben Sie diese Anleitung für den spätern Gebrauch auf. 3. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen. Vervenden Sie keine Flüssig- oder Aerosolreiniger. Am besten dient ein angefeuchtetes Tuch zur Reinigung. 4.
- Page 5 FCC Warning This equipment has been tested and found to comply with the limits for a Class A device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
-
Page 7: Table Of Contents
EATURES Front End ................................ 3 Rear End................................3 UNPACKING AND INSTALLATION......................5 ..........................5 NPACKING AND NSPECTING DP-101 ............................5 NSTALLING THE ..........................6 OWER UP AND LED Test Series ............................... 6 Component Test Series ............................ 6 Operational Test.............................. 7 PRODUCT SPECIFICATIONS........................ -
Page 9: About This Guide
DP-101 Print Server Hardware Guide BOUT THIS UIDE This manual describes the D-Link DP-101 Multiprotocol Ethernet Print Server, including full descriptions of its features, detailed installation procedures, and troubleshooting information. Your DP-101 package includes important software components, and additional user manuals. The software components, and procedures for installation and setup of the software, are covered in the PS Admin User’s Guide. -
Page 10: Introduction
DP-101 print servers improve network printing services in three ways: ♦ The DP-101 picks up the workload of managing print file traffic to its connected printers. This provides workload relief to your file servers, and allows the file servers' full capacity to be used for file access or other direct services to network users. -
Page 11: External Features
Printer Port The printer port, is configurable by commands in the PS Admin program, or by commands issued to the DP-101 via Telnet. See the PS Admin User’s Guide for configuration procedures. Rear End The network port, power input socket, and LED indicators are all located at the rear . -
Page 12: Led Indicators
Ethernet cabling. DC Power Input The DC power input socket uses a 7.5V power supply. The power supply included in your DP-101 package is correct for the DP-101. Substitution of other equipment may void warranty. LED Indicators The rear of the DP-101 includes three LED indicators. See "Power-up and Self-Test," Chapter 2, for LED indications upon starting up the DP-101. -
Page 13: Unpacking And Installation
DP-101 Print Server Hardware Guide NPACKING AND NSTALLATION This chapter explains how to install your DP-101 print server and connect it to the network. It also describes the automatic power-on self test. Unpacking and Inspecting Carefully remove all items from the package. Please check to be certain that you have: ♦... -
Page 14: Power-Up And Self-Test
DP-101 Print Server Hardware Guide Power-up and Self-Test Whenever the DP-101 is powered up, two kinds of testing procedures follow automatically. The first procedure is just a programmed series of LED flashes, to confirm proper operation of the three LED indicators. The second procedure comprises programmed tests of each of the DP-101's major components. -
Page 15: Operational Test
That operational test can be performed after you have completed installation of the PS Admin software, and the PS Admin procedures for configuring the DP-101. See instructions given in the PS Admin User’s Guide ("Getting Started Setting up Your Print Server" section, under the heading "Testing your Print Server"). -
Page 16: Product Specifications
DP-101 Print Server Hardware Guide RODUCT PECIFICATIONS Printer Connection Printer Port: IEEE 1284 standard bidirectional parallel interface with 36-pin connector. Bidirectional Communication: Hewlett-Packard PJL (Printer Job Language) standard for bidirectional communication. Network Connection Network Standards: IEEE 802.3 10Base-T Ethernet . -
Page 17: Port Pinouts
DP-101 Print Server Hardware Guide INOUTS The following table lists the pinouts of the DP-101's 36-pin parallel port connector (identical to the parallel port connector used on most printers.) Signal names beginning with n are active-low signals. Pin # Signal... -
Page 18: Index
