Philips Lytecaster 2008 Specification

Page 1 of 2
5 1/2"
2008/2002P1 Series
Standard Incandescent
5 3/8"
2008/2003R
0
NON-IC
Remodeler Ring
2008/2000IC
Insulated Ceiling
5 1/2"
2008/2000AIC
Insulated Ceiling
AirSeal
®
Complete Fixture consists of Reflector Trim & Frame-In Kit. Select each separately.
Reflector Trim Frame-In Kit — See Individual Frame-In Kit Specification Sheets
2008* Brushed Gold
Frame-In Kit Install Type
2010* Brushed Clear
2002P1
2012* Specular Gold
2003R
2013* Specular Clear
2013CD*
Clear Diffuse
2000P1
2013BK*
Specular Blk
2013WH Matte White
2000IC
2000AIC
*Add "NM" to SKU for Natural Metal Flange ** 60W A19 with 2003R
Features
1. Reflector: Hydroformed aluminum, .040" thick (18 ga.); white or Natural
Metal trim flange.
2. Cone: Aluminum cone painted anodized finish.
3. Frame-In Kit: (2002P1 standard frame shown) Other frame shown on the
right. See Frame-In Kit specification sheet for more detail.
Options & Accessories
Lytegems: See 1300 Series Specification Sheets.
Retaining Clips: 1955 - For Installing in Existing Ceiling
Labels
UL (Suitable for Damp Locations), I.B.E.W
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2011 Philips Group • I0911
Lytecaster Recessed Downlighting
Line Voltage
Lamping Height Frame-In Kit Installation Type
Standard Non-IC 40W A19** 5 1/2"
Std. Non-IC Rem. 75W R20, PAR16 5 3/8"
50W PAR20
Standard Non-IC 40W A19** 5 1/4"
75W R20, PAR16
50W PAR20
IC 50W R20, PAR20 5 9/32" 2004ICV/N
AirSeal IC 45W PAR16 5 9/32" 2000LVNT Low Voltage Remote Transformer
®
3 3/4" Aperture Cone Reflector Trim
7 1/4"
2008/2004ICV/N
0
5 3/8"
5 3/8"
2008/2000LVR
Remodeler Low Voltage
5 3/8"
Low Voltage
2000LV Standard Non-IC
2000LVR Remodeler Non-IC
2000LVE1 Electronic Low Voltage Non-IC 120V
2000LVE2 Electronic Low Voltage Non-IC 277V
2000LVRE1
Electronic Low Voltage Remodeler 120V
Lytening AirSeal IC
®
2000AICV Lytening AirSeal IC
®
Job Information
Job Name:
Cat. No.:
Lamp(s):
Notes:
2008
AirSeal Insulated Ceiling
®
2008/2000LV
Standard Low Voltage
2008/2000LVNT
Remote Transformer
Lamping Height
5 3/8"
5 3/8"
5 3/8"
20W-50W MR16 5 3/8"
5 3/8"
5 3/8"
7 1/4"
20W-42W MR16 5 3/8"
20W-35W MR16 5 9/32"
Type:
