Philips C2 Series Specification

C2125L2RT6
24.0"
(61.0 cm)
12.0"
(30.5 cm)
15.6"
(38.7 cm)
4.4"
(11.3 cm)
6.0"
(15.2 cm)
Recessed Emergency Lighting
Features
Illumination: Illumination
is provided by up to four
adjustable lamp heads. Choose
from round or rectangular
thermoplastic heads with
Par 36 sealed beam tungsten
or halogen, or wedge base
tungsten or halogen lamps.
Lamp heads are factory
installed. The suggested head
is Lightolier's "R" series wedge
base tungsten round lamp
head.
Housing: Faceplate
constructed of 18 gauge steel
with a white epoxy powder
coat finish; backbox 20 gauge
steel. Up to four lamp heads
can be mounted on the unit
faceplate. Lamp head choices
include round or rectangular
white thermoplastic to match
housing. Designed for easy,
drop-in installation into
suspended ceilings. Additional
wire supports may be required
by local codes and are supplied
by others.
C2 Series
Operating Temperature
Range: Standard Location
65°F (19°C) to 85°F (30°C)
Electronics: 120/277 VAC
dual voltage input with surge-
protected, solid-state charging
circuitry provides for a reliable
charging system. Charging
system is complete with
low voltage disconnect, AC
lockout, brownout protection,
AC indicator lamp and test
switch.
Electrical Specifications:
0.150 A, 18 W max. (120 VAC)
0.065 A, 18 W max. (277 VAC)
Job Information Type:
Job Name:
Cat. No.:
Notes:
Page 1 of 2
Code Compliance
UL 924 listed. NFPA 101,
NEC, BOCA, OSHA and IBC
illumination standards. Chicago
Approved City Plan No. 1879E.
Warranty
Three year full electronics
warranty. One year full plus
four year prorated lead calcium
battery warranty. Five year full
plus five year prorated nickel
cadmium battery warranty.
