Summary of Contents for Electrolux ER 7627 BN
- Page 1 - f r e e z e r s INSTRUCTION BOOK ER 7626 B - ER 7627 BN 2222 039-24...
-
Page 2: Important Safety Information
Under no circumstances should you attempt to repair the machine yourself. Repairs carried out by inexperienced persons may cause injury or serious malfunctioning. Refer to your local Electrolux Service Force Centre and always insist on genuine spare parts. At the end of the Appliance Life ¥... -
Page 3: Table Of Contents
CONTENTS Instructions for the User Important Safety Information Description of the Appliance Operation Before use To start the Appliance Setting the temperature Use of an air circulation slider control Fresh food refrigeration Movable shelves The freezer compartment Freezing fresh food Frozen food storage Thawing Making ice cubes... -
Page 4: Description Of The Appliance
DESCRIPTION OF THE APPLIANCE A- Thermostat control for fridge and freezer compartments B- Dairy compartment C- Movable shelf D- Bottle storage shelf E- Air circulation slider control F- Wire shelves G- Glass shelf H- Salad drawers I- Compartment for freezing fresh foods J- Compartments for frozen food storage COLDES 10 -... -
Page 5: Operation
Do not cover the shelves with any protective material, such as paper, cardboard or plastic, which may obstruct the air circulation. To help you use your refrigerator correctly, here are some more useful hints: Raw meat (beef, pork, lamb & chicken or poultry): wrap in polythene bags and place on the glass shelf above the salad drawers. -
Page 6: Movable Shelves
Vent D756 Movable shelves The walls of the refrigerator have runners so that shelves can be positioned as desired. D040 The door shelves can be easily removed for cleaning. Gently ease the shelf in the directions shown. -
Page 7: The Freezer Compartment
Meat, fish and fruit should be thawed in the refrigerator compartment and small pieces of meat can even be cooked while still frozen, but you must ensure that it is thoroughly cooked through. -
Page 8: Normal Operating Sounds
Defrost water drips into the drain pan during the defrost cycle. The fan circulates cold air to cool the refrigerator and the freezer compartment and sounds like air blowing or a whirring sound. The flow of refrigerant through the freezer cooling coil makes a gurgling noise. -
Page 9: Health And Safety Guidelines
Cool cooked food as quickly as possible but do NOT place in the refrigerator until cool. (Leave food in a place as cool as possible in order that it can then be placed in the refrigerator as soon as possible). ¥... -
Page 10: Maintenance And Cleaning
MAINTENANCE AND CLEANING Before any maintenance or cleaning work is carried out, DISCONNECT the appliance from the ELECTRICITY supply. Internal cleaning Clean the inside and accessories with warm water and bicarbonate of soda (5ml to 0.5 litre of water). Rinse and dry thoroughly. NEVER USE DETERGENTS, ABRASIVE POWDERS, HIGHLY PERFUMED CLEANING PRODUCTS OR WAX... -
Page 11: Something Not Working
SOMETHING NOT WORKING Before contacting your local Service Force Centre, check the following points: Important: If you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or installation a charge will be made, even if the appliance is under guarantee. Symptom No power to the appliance The light does not come on... -
Page 12: Service And Spare Parts
The model and serial number of the appliance (found on the rating plate) The purchase date CUSTOMER CARE DEPARTMENT For general enquiries concerning your Electrolux appliance or for further information on Electrolux products, please contact our Customer Care Department by letter or telephone as follows:- Customer Care Department... -
Page 15: Guarantee Conditions
Standard guarantee conditions We, Electrolux, undertake that if within 12 months of the date of the purchase this Electrolux appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: The appliance has been correctly installed and used only on the electricity supply stated on the rating plate. -
Page 16: Technical Specification
TECHNICAL SPECIFICATIONS DIMENSIONS POWER SUPPLY VOLTAGE AND FREQUENCY TOTAL POWER ABSORBED AVERAGE DAILY UNITS ELECTRICITY * GROSS CAPACITY NET CAPACITY This figure is based on standard test results in accordance with European Standard EN 153. Actual consumption will depend on how the appliance is used and where it is located. Height Width 54.5 cm... -
Page 17: Installation
INSTALLATION Warning IF YOU ARE DISCARDING AN OLD APPLIANCE THAT HAS A LOCK OR CATCH ON THE DOOR, YOU MUST ENSURE THAT IT IS MADE UNUSABLE TO PREVENT YOUNG CHILDREN BEING TRAPPED INSIDE. Depending upon the position which you choose for your appliance, you may wish to reverse the way in which the door opens. -
Page 18: Electrical Connection
Electrical connections Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person. WARNING: THIS APPLIANCE MUST BE EARTHED. The manufacturer declines any liability should this safety measure not be observed. If the plug that is fitted to your appliance is not suitable for your socket outlet, it must be cut off and the appropriate plug fitted. -
Page 19: Door Reversal
Door reversal directions 1. Disconnect from the electricity supply. 2. Remove all loose items, including food, store food in a cool place. 3. Gently lay the fridge/freezer on its back with the top held away from the floor by 5-8 cm (2-3 inch- es) of packing. - Page 20 © Electrolux Household Appliances Limited 2001...
