Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
FEB27S7FCC
38254783F60S3
Series
27" single
Color
stainless
Market
North America
Wiring Diagram
318046237
Owner's Guide
318205119
Installation Instructions 318201514
Service Data Sheet
318047413
Timer Guide
318200189
Publication No.
5995492310
07/06/06
(EN/SERVICE/ECL)
377
SINGLE ELECTRIC
WALL OVEN
Model No.
FEB27S7F
©
Copyright
2007 Electrolux Home Products, Inc.
All rights reserved.
Advertisement
Related Manuals for Frigidaire FEB27S7FCC
Summary of Contents for Frigidaire FEB27S7FCC
-
Page 1: Wall Oven
Product No. FEB27S7FCC 38254783F60S3 Series 27" single Color stainless Market North America Wiring Diagram 318046237 Owner's Guide 318205119 Installation Instructions 318201514 Service Data Sheet 318047413 Timer Guide 318200189 SINGLE ELECTRIC FEB27S7FC.tif CPLEB27S9DCA.eps BFEB27S7FCA.eps DFEB27S7FCB.eps WALL OVEN 318046237.eps Electrolux Major Appliances Model No. -
Page 2: Control Panel
Publication No: 5995492310 FEB27S7FCC CONTROL PANEL 06/07... - Page 3 FEB27S7FCC Publication No: 5995492310 CONTROL PANEL POS. NO PART NO. DESCRIPTION 318257301 Shield, oven top 318260101 Cover, box 318271530 Control Panel Assembly, steel/glass, stainless/black, w/touch pad 20 # 316418521 Clock/Timer, electronic, ES350W2 316021107 Screw, hex head, 8-32, silver 5303211311 Screw, 8 x 0.500 06/07 # Functional Parts * Non-Illustrated Parts...
- Page 4 Publication No: 5995492310 FEB27S7FCC BODY 06/07...
- Page 5 FEB27S7FCC Publication No: 5995492310 BODY POS. NO PART NO. DESCRIPTION 318259212 Back, main 318258910 Shield, insulation, upper 318345209 Rack, oven, (3) 5303317977 Pan, broilerOPTIONAL ACCESS0RY 5303317976 Insert, broiler panOPTIONAL ACCESS0RY 316445501 Switch, oven light, door frame 318224000 Receptacle, oven light 318268099 Insulation, oven light 5303013071...
- Page 6 Publication No: 5995492310 FEB27S7FCC BODY 06/07...
- Page 7 FEB27S7FCC Publication No: 5995492310 BODY POS. NO PART NO. DESCRIPTION 318003000 Plate, shield 318123910 Deflector 318172904 Support, wire 318014111 Spacer 318014700 Spacer, oven shield, (4) 219# 318003614 Thermostat, safety 219A 318003613 Thermostat, safety, 1.375" mtg, 105/120 316136500 Washer, flat 318257711 Trim, oven, black, front 318249401 Tube, protector...
- Page 8 Publication No: 5995492310 FEB27S7FCC DOOR DFEB27S7FCB 06/07...
- Page 9 FEB27S7FCC Publication No: 5995492310 DOOR POS. NO PART NO. DESCRIPTION 318260401 Trim, oven door, side, (2) 318262101 Cover, rear door, black, (2) 318260510 Baffle, door 318372000 Insulation, door, (2) 318372001 Insulation, door, 20.5 x 2.375, (2) 318212200 Glass, oven door, heat barrier 318259615 Liner, upper door 5303325980...
-
Page 10: Wiring Diagram
Publication No: 5995492310 FEB27S7FCC WIRING DIAGRAM 06/07...
