Chapter 3
accompanying power cord to the PDU and attach the C20 end of the same cord to
the IEC 320 receptacle in the rear of the UPS.
Alternate 230/240 VAC Power Configuration
When the 230/240 VAC PDU is to be used without a UPS in the rack, the PDU is
shipped with a localized power cord.
NOTE Only localized power cords rated 16A will allow the full 16A
rating of the PDU to be used.
For use with 230/240 VAC power mains, direct connection to a junction box is
usually necessary. In this case, an unterminated power cord is supplied. Be sure to
obey all local electrical code requirements when connecting to the site electrical
power supply.
Table 3-3. 230/240 VAC PDU Power and Current
1
Component
200/240 VAC E7671A or E7672A
PDU
HP NetServer D8515A, 533 MHz, 128 MB
D8520A, 600 MHz, 128 MB
LC 2000r
D8525A, 667 MHz, 128 MB
HP NetServer Rack Storage/12 is D5989A
Mass Storage Rack Storage/12FC is D5991A
Unit
HP Console
Switch
Note 1 More ratings are listed in Table 2-9. For a full list of power ratings, see the rack
configuration utilities (for instance, Rack Assistant) on the HP Web Site.
Note 2 Indicated current ratings are for use in selecting PDU and UPS components and
may not reflect actual measured amounts.
Description of the Recommended 230/240 VAC Configuration
Figure shows a UPS connected to the power mains through an attached power
3-5
cord (appropriate cords are supplied for each country). The UPS has eight IEC
320 receptacles for use with the rack jumper cords. The E7671A PDU connects to
the UPS via a detachable line cord, which connects to the PDU via a C-19 plug.
This cord connects to the UPS with a C-20 plug. The 200/240 VAC PDU has two
Procedure for Connecting and Routing Cables to the LC 2000r
Model Power
(VA)
N/A
514
518
J1497B
Power Current
2
(W)
(A)
N/A max 16
504 2.3
507 2.3
42 29 0.2
43
