Ventilating Fan
READ AND SAVE THESE INSTRUCTIONS.
R
Please read these instructions carefully before attempting to install,
operate or service the Panasonic Ventilating Fan. Failure to comply
with instructions could result in personal injury and/or property
damage. Please retain this booklet for future reference.
Table of Contents
Supplied Accessories
Description
Dimensions
Specifications
Unpacking
General Safety Information
Wiring Diagram
I
( Joist Mounting- ) I
Installation
II
Installation
( Joist Mounting- )
III
I
Installation
( -Joist Mounting )
IV
Installation
( Between Joist Mounting )
V
Installation
( Wooden Header )
VI
Installation
( In Existing Construction )
V I
I
( Wall Installation- ) I
Installation
I V II
Installation
( Wall Installation- )
IX
Installation
( Wall Installation-
Maintenance
Practical Guide to Installation
Product Service
II
II
III
)
FV-05VS1
FV-08VS1
2
2
3
4
4
4-5
5
6-8
8-9
10
10-11
12
12
13
14
14-15
16
16
16
Advertisement
Related Manuals for Panasonic FV-08VS1
Summary of Contents for Panasonic FV-08VS1
- Page 1 READ AND SAVE THESE INSTRUCTIONS. Please read these instructions carefully before attempting to install, operate or service the Panasonic Ventilating Fan. Failure to comply with instructions could result in personal injury and/or property damage. Please retain this booklet for future reference.
- Page 2 Suspension bracket III These Panasonic ceiling mount ventilation fans use a sirocco fan driven by a capacitor motor. The motor is designed to have an extended service life with reduced energy consumption. It also incorporates a thermal-cutoff for safety. The grille covering the main body is a spring-loaded, quick-release type. A damper...
- Page 3 Unit: inches mm FV-05VS1 FV-08VS1 1 25 2 3/8 60 1 1/2 38 1/2 13 3 1/8 78 3 6/8 95 13 330 10 1/4 261 3 3/4 (94) Part name Part name Grille Bracket cover Adaptor Junction box cover Fan body Junction box Damper...
- Page 4 Duct Air deliver Noise Power consumption Speed Weight diameter (cfm) Model No. Air direction (sone) (rpm) Ib.( (inches) at 0.1'' WG. 4.8 (10.7) FV-05VS1 Exhaust 4.8 (10.7) FV-08VS1 Specifications are based on HVI standard. Unpack and carefully remove unit from carton. Refer to the Supplied Accessories list to verify that all parts are present.
- Page 5 (Cooking area) Do not install above or inside this area CAUTION: 1. For general ventilating use only. Do not use to exhaust hazardous or explosive materials and vapors. 2. Not for use in cooking area. (Fig. B) 3. This product must be properly grounded. Floor Cooking equipment...
- Page 6 1. Before installation, secure the fan body to adaptor by using thumb screw. (Fig.1) Thumb screw IMPORTANT : Remove the tape from damper and adaptor Fan body before installation. As shown below: Adaptor Damper Fig.1 Remove tape 2. Insert the supension bracket into the fan body and adaptor.
- Page 7 3. Install the suspension bracket and the flange of fan body to joists by using long screws (M4X30) according to Fig. 3. Fan body Joist Fig. 3-1 4 Long screws (M4X30) A = 10 1/4~12 inches Joist 2 Long screws (M4X30) Fan body Fig.
- Page 8 8. Finish ceiling work. Ceiling hole should be aligned with the edge of the flange. (Fig. 6) Ceiling Fig. 6 inches (mm) 9. Insert mounting springs into slots as shown and Mounting spring Slot mount grille to fan body. (Fig. 7) Ceiling Fig.
- Page 9 5. Insert the fan body into joists. (Fig. 9) Circular duct Joist IMPORTANT: Conduit Make sure that adaptor claws are properly inserted into body slots. Junction box cover 6. Secure the fan body to adaptor by using thumb screw and plug connector to receptacle. (Fig. 10) 7.
- Page 10 4 kinds of -joist inches (mm) Suspension 9/16 ( 14.3 bracket III 11/16 (17.5) Screw (M4X10) 31/32 (24.6) 1 17/32 38.9 Fig. 13 Suspension bracket The suspension bracket can comply with different kinds of -joist. 1. Before installation, Secure the fan body to adaptor by using thumb screw.
- Page 11 3. Insert the fan body between joists. Make sure the fan body is level and square Joists (perpendicular) with the joists. (Fig. 16) CAUTION: Ensure that distance B is no more than 1/2 inch (13 mm). Adaptor Fan body Junction box Suspension bracket 13 1/4~15 1/2 ( 336~394 ) 16 1/2~18 3/4 ( 419~480 )
- Page 12 1. Before installation, secure the fan body to adaptor by Joist Header using thumb screw. (Fig. 1 of page 6) Joist 2. Install header between joists by using nails or screws. ( 2 7 Adaptor 3. Install the ventilating fan and secure it by using long Fan body screws (M4X30).
- Page 13 IMPORTANT: When the product is installed on the wall, the adaptor shall be faced upward. (Fig. 21) Prohibition Prohibition Prohibition Fig. 21 1. Disconnect plug connector from receptacle and remove adaptor from fan body before starting installation. (Fig. 22) 2. Insert the suspension bracket into the adaptor. (refer to step 2 of installation of page 8).
- Page 14 1. Before installation, Secure the fan body to adaptor by using thumb screw. (Fig.1 of page 6) 2. Insert the suspension bracket into bracket cover of adaptor side and the back of the fan body (refer to Fig.15-1 of page 10). 3.
- Page 15 4. Secure the suspension bracket to the wall stud using long screws (M4X30). Secure the fan body and spacer to stud using long screws (M4X30). (Fig. 29) 2 Long screws (M4X30) Suspension 5. Complete the duct work and wiring (refer to steps 5 to 7 bracket I of the installation on page 7).
- Page 16 AUTHORIZED INDEPENDENT SERVICE CENTERS is maintained to support your product's warranty. (In the U.S.A.,call 1-866-292-7292 to Customer call center.) PANASONIC CONSUMER ELECTRONICS COMPANY One Panasonic Way, 1H-3 Secaucus, NJ 07094 PANASONIC CANADA INC. 5770 Ambler Drive, Mississauga, ON L4W 2T3...
