Page 2
ASUSTeK COMPUTER, INC. (“ASUS”). Products and corporate names mentioned in this manual may or may not be registered trademarks or copyrights of their respective companies, and are used for identification purposes only.
Contents Notices ..............................5 Federal Communications Commission Statement ............5 Canadian Department of Communications Statement ..........6 IC Radiation Exposure Statement for Canada..............6 Declaration of Conformity (R&TTE directive 1999/5/EC) ..........6 CE Mark Warning ......................... 7 Wireless Operation Channel for Different Domains ............7 France Restricted Wireless Frequency Bands ..............
Page 4
Setting up your All-in-one PC ..............27 Connecting the wired keyboard and mouse ................27 Connecting the wireless keyboard and mouse ..............27 Powering on the system........................28 Powering off ............................28 Configuring a wireless connection .....................29 Configuring a wired connection ....................30 Using a static IP ..........................30 Using a dynamic IP (PPPoE) ....................32 Bluetooth Wireless Connection ....................35 Configuring the audio output .......................37...
Notices Federal Communications Commission Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: • This device may not cause harmful interference, and • This device must accept any interference received including interference that may cause undesired operation.
Canadian Department of Communications Statement This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications. This class B digital apparatus complies with Canadian ICES-003. IC Radiation Exposure Statement for Canada This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment.
CE Mark Warning This is a Class B product, in a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. CE marking for devices without wireless LAN/Bluetooth The shipped version of this device complies with the requirements of the EEC directives 2004/108/EC “Electromagnetic compatibility”...
France Restricted Wireless Frequency Bands Some areas of France have a restricted frequency band. The worst case maximum authorized power indoors are: • 10mW for the entire 2.4 GHz band (2400 MHz–2483.5 MHz) • 100mW for frequencies between 2446.5 MHz and 2483.5 MHz Channels 10 through 13 inclusive operate in the band 2446.6 MHz to 2483.5 MHz.
REACH Complying with the REACH (Registration, Evaluation, Authorization, and Restriction of Chemicals) regulatory framework, we publish the chemical substances in our products at ASUS REACH website at http://csr.asus.com/english/REACH.htm. TV Tuner Notices Note to CATV System Installer—Cable distribution system should be grounded (earthed) in...
ASUS follows the green design concept to design and manufacture our products, and makes sure that each stage of the product life cycle of ASUS product is in line with global environmental regulations. In addition, ASUS disclose the relevant information based on regulation requirements.
NOTE: Additional information for special situations. All illustrations and screenshots in this manual are for reference only. Actual product specifications and software screen images may vary with territories. Visit the ASUS website at www.asus.com for the latest information. All-in-one PC ET24 Series...
Safety information Your All-in-one PC ET24 Series is designed and tested to meet the latest standards of safety for information technology equipment. However, to ensure your safety, it is important that you read the following safety instructions. Setting up your system •...
Welcome Congratulations on your purchase of All-in-one PC ET24 Series. The following illustration displays the package contents of your new product. If any of the following items is damaged or missing, contact your retailer. Package contents All-in-one PC ET24 Series Keyboard (wired or wireless) Mouse (wired or wireless) AC adapter...
Getting to know your All-in-one PC Front view Refer to the following diagram to identify the components on this side of the system. All-in-one PC ET24 Series...
Page 15
Webcam The built-in webcam with the built-in digital microphone allows you to start video chats online. 3D Vision IR port (on selected models) The 3D Vision IR port transmits 3D Vision signals to the 3D glasses when you play a 3D video game or watch 3D movies.
Rear view Refer to the following diagram to identify the components on this side of the system. Power input (DC 19.5V) The supplied power adapter converts AC power to DC power for use with this jack. Power supplied through this jack supplies power to the PC. To prevent damage to the PC, always use the supplied power adapter.
Page 17
LAN port The eight-pin RJ-45 LAN port supports a standard Ethernet cable for connection to a local network. HDMI In Port (on selected models) HDMI (High-Definition Multimedia Interface) is an uncompressed all-digital audio/ video interface between any audio/video source, such as a set-top box, DVD player. Display (Monitor) Input (on selected models) The 15-pin D-sub monitor port supports a standard VGA-compatible device such as a monitor or projector to allow viewing on a larger external display.
Side views Refer to the following diagrams to identify the components on both sides of the system. Memory card reader Normally an external memory card reader must be purchased separately in order to read memory cards. This All-in-one PC has a built-in memory card reader that supports SD cards used in devices like digital cameras, MP3 players, mobile phones, and PDAs.
Page 19
Up Button Press to display the volume or brightness menu directly. Or use it to scroll up when navigating other menus. The button definition varies with models. Menu Button Press to display the main menu. The menu options vary with models. Down Button Press to display the source or volume menu directly.
Using the touch screen All-in-one PC brings digital life to your fingertips. With a few touches, you can make All-in-one PC work at your command. Your touch functions like a mouse device: • Touch = left-click on the mouse • Touch and hold = right-click on the mouse The touch-enabled screen is available on selected models.
Click Change touch input settings. Click the Touch tab on the top and click You will see a virtual mouse on the screen the box before Show the touch pointer when you touch the screen. when I’m interacting with items on the screen.
Using the keyboard Your All-in-one PC comes with a wired or wireless keyboard that facilitates your control of the system. The following keyboard illustration is for reference only. Actual product specifications may vary with territories. All-in-one PC ET24 Series...
Function keys The following table defines the colored function keys on the keyboard. To access the colored commands, hold the Function key while pressing a key with a colored command. The actual colored function keys and supported commands may vary with models. Fn + F1: Places the system in suspend mode.
Positioning your All-in-one PC Placing on the desktop Place your All-in-one PC on a flat surface such as a table or desk, pull the stand open, and tilt pull the stand open, and tilt the display panel to an angle of between 12 and 25 degrees from an upright position. When you tilt the display panel to the angle of 12 degree, a click sound indicates that the display panel is at the proper angle.
Mounting to the wall To mount your All-in-one PC to the wall, purchase the optional wall mount pad adapter, wall mount pad and a wall mount kit. Install the wall mount pad according to the following instructions. The following instructions are for reference only. The actual installation procedures may vary depending on your purchased wall mount kit.
Page 26
Secure the wall mount pad to the pad adapter with the four screws noting the correct orientation. Hook your All-in-one PC to the wall mount kit securely. The wall mount kit in this illustration is for reference only. Fasten the wall mount kit to the wall following the instructions described in the installation manual that came with your wall mount kit package.
Setting up your All-in-one PC Connecting the wired keyboard and mouse Connect the keyboard to the USB port on the rear panel ( ). You may also connect the ou may also connect the connect the keyboard to the USB port on the left side if the keyboard cable is not long enough.Then, .
Powering on the system Connect the supplied AC adapter to the DC IN jack on the rear panel ( ) and then press the Power switch on the right ( ) to turn on the system. WARNING! DO NOT connect the AC power cord to an AC outlet prior to connecting the DC plug to the system.
Configuring a wireless connection Click the wireless network icon with an orange star in the Windows® Notification area. Select the wireless access point you want to connect to from the list and click Connect to build the connection. If you cannot find the desired access point, click the Refresh icon on the upper right corner to refresh and search in the...
Configuring a wired connection Using a static IP Click the network icon with a yellow warning triangle in the Windows® Notification area and select Open Network and Sharing Center. Ensure that you have connected the LAN cable to the All-in-one PC. Click Change adapter settings in the left pane.
Page 31
Click Internet Protocol Version 4(TCP/ IPv4) and click Properties. Select Use the following IP address. Enter your IP address, Subnet mask, and Default gateway. If needed, enter the Preferred DNS server address. After entering all the related values, click OK to finish the configuration. All-in-one PC ET24 Series...
Using a dynamic IP (PPPoE) Repeat steps 1–4 in the previous section. Select Obtain an IP address automatically and click OK. (Continue the following steps if using PPPoE) Return to the Network and Sharing Center and then click Set up a new connection or network.
Page 33
Select Broadband (PPPoE) and click Next. Enter your User name and, Password, and Connection name. Click Connect. Click Close to finish the configuration. All-in-one PC ET24 Series...
Page 34
Click the network icon in the notification area and click the connection you just created. Enter your user name and password. Click Connect to connect to the Internet. All-in-one PC ET24 Series...
Bluetooth Wireless Connection Your All-in-one PC features Bluetooth v3.0 technology and actual transferring speed varies with the connected devices. Alll-in-one PCs with Bluetooth technology eliminates the need for cables for connecting Bluetooth-enabled devices. Examples of Bluetooth-enabled devices may be Notebook PCs, Desktop PCs, mobile phones, and PDAs.
Page 36
Select a Bluetooth-enabled device from the list and click Next. Enter the Bluetooth security code into your device and start pairing. The paired relationship is successfully built. Click Close to finish the setting. All-in-one PC ET24 Series...
Configuring the audio output All-in-one PC supports different types of audio configurations. Set up the system using stereo speakers. Speaker configurations Set up the system with the following speaker configurations: Name Speaker system 2-channel (stereo) Left speaker and right speaker. Audio jack Headphones/2-channel Audio Out...
Configuring audio output settings After connecting a speaker system to your All-in-one PC, follow the steps below to configure the speaker settings: Right-click the speaker icon in the Windows® notification area and click Sounds. Select a playback device and Do the advanced configurations, such as click Properties to configure the adjusting the speaker level and output settings.
Overclocking your All-in-one PC Click the S.H.E. button on the speedometer on the desktop. The pointer will move from High to Super as shown. Click the S.H.E. button again to undo the overclocking configuration. All-in-one PC ET24 Series...
Using 3D Vision Glasses Charging your 3D Vision glasses Connect the Type A plug of the provided USB cable to the All-in-one PC and the Type B plug to the 3D vision glasses frame to charge the 3D vision glasses before first use and whenever the power is depleted.
(For External 3D Vision-Ready LCD displays and notebooks with built-in 3D Vision LCDs) Do you notice flicker in your peripheral vision when looking through the glasses? If you are seeing excessive flicker in your peripheral vision, this screen allows you to change the refresh rate of your display.
Adjusting the Refresh rate The best Refresh rate for 3D Vision effect may differ by territories, follow the instructions below to manually adjust the Refresh rate. Refer to the FAQ at http://www.nvidia.com/content/3dvision/docs/3DVISION_TipsTricks_ Dec08_Screen.pdf for the best Refresh rate in your region. Right-click on the desktop and select NVIDIA Control Panel.
Unscrew and remove the metal plate memory door. cover. Removing or installing the memory based on your needs as instructed bellow. installing memory removing memory Visit the ASUS support site at http://support.asus.com for the latest memory QVL. All-in-one PC ET24 Series...
Recovering your system Using the hidden partition The recovery partition includes an image of the operating system, drivers, and utilities installed on your system at the factory. The recovery partition provides a comprehensive recovery solution that quickly restores your system’s software to its original working state, provided that your hard disk drive is in good working order.
Based on the different situations in the previous step, data on the selected USB storage device or on the selected partition will be cleared. Click Backup to start backup. You will lose all your data on the selected USB storage device or on the selected partition. Ensure to back up your important data beforehand.
Canada only. Manufacturer ASUSTek COMPUTER INC. Address, City No. 150, LI-TE RD., PEITOU, TAIPEI 112, TAIWAN R.O.C Country TAIWAN Authorized Representative in Europe ASUS COMPUTER GmbH Address, City HARKORT STR. 21-23, 40880 RATINGEN Country GERMANY All-in-one PC ET24 Series...
