Subject:
Equity and Apex Series Compatibility with the System OmniBridge
Controller and BridgeFiler External Floppy Drives
Date:
04/11/90
Page:
1 of 3
The purpose of this bulletin is to provide the results of compatibility testing
conducted by the Computer Product Support Center with the Sysgen
OmniBridge controller and Bridge - Filer external floppy disk drives.
Equity I
Equity II
Equity III
Equity I +
Equity le
Product Support Bulletin
Comments
The Equity I was found compatible with the OmniBridge
controller. It was able to support one or two external
disk drives (daisychained) together. The external drives
could be used as high density (1.2M and 1.44M) or
normal (360K and 720K) disk drives.
The Equity II was found to be totally incompatible with
the OmniBridge controller.
The Equity III was found compatible with the OmniBridge
controller. It was able to support one or two external
disk drives (daisychained) together. The external drives
could be used as high density (1.2M and 1.44M) or
normal (360K and 720K) disk drives.
The Equity I + was found compatible with the
OmniBridge controller.
two external disk drives (daisychained) together. The
external drives could be used as high density (1.2M and
1.44M) or normal (360K and 720K) disk drives.
The Equity le was found compatible with the OmniBridge
controller. It was able to support only one external
floppy drive, unlike the other models tested. The drive
could be used as a high density (1.2Mb and 1.44Mb) or
normal (360K and 720K) disk drive.
PSB No:
Originator:
It was able to support one or
S-0088B
KAS 60

Advertisement

loading

Related Manuals for Epson Apex 200

Summary of Contents for Epson Apex 200

  • Page 1 Product Support Bulletin Subject: Equity and Apex Series Compatibility with the System OmniBridge Controller and BridgeFiler External Floppy Drives PSB No: S-0088B Date: 04/11/90 Originator: KAS 60 Page: 1 of 3 The purpose of this bulletin is to provide the results of compatibility testing conducted by the Computer Product Support Center with the Sysgen OmniBridge controller and Bridge - Filer external floppy disk drives.
  • Page 2 (1.2M and 1.44M) or normal (360K and 720K) disk drives. APEX The Epson APEX was found compatible with the OmniBridge controller. It was able to support one or two external disk drives (daisychained) together. The external drives could be used as high density (1.2M and...
  • Page 3 (1.2M and 1.44M) or normal (360K and 720K) disk drives. APEX 200 The Epson APEX 200 was found compatible with the OmniBridge controller. It was able to support one or two external disk drives (daisychained) together. The external drives could be used as high density (1.2M and...
  • Page 4 Does the APEX 200 have a serial interface port? Yes, an IBM PC/AT- compatible (9 - pin connector) serial port is standard with the APEX 200 and can be used to connect a serial device such as a modem, serial mouse or a serial printer.
  • Page 5 A. The Apex 200\20 uses a 5.25”, half - height, 20 MB, Seagate ST- 225, MFM hard disk with an average disk access time of 65ms. The Apex 200\40 uses a 5.25”, half - height, 40 MB, CDC 94205 - 51 MFM, hard disk with an average disk access time of 28ms.
  • Page 6 PSB No: S-0098 Page: 3 of 8 Q. What kind of floppy disk drive does the APEX 200 have and what kind of floppy diskettes should I use? A. The APEX 200 - series computers use a half - height, 5 1/4”, 1.2MB floppy disk drive.
  • Page 7 Make sure the system requirements on the software package match your computer configuration and video adapter type. Software is available through Epson Accessories, Inc. at 1 - 800 - 873- 7766, or at your local software store. Q. Is the APEX 200 compatible with MS-OS/2? A.
  • Page 8 Q. How many option cards can be installed in the APEX 200? A. The APEX 200 has six l/O expansion slots (3 8 - bit and 3 16 - bit). The video adapter board and the SPF2 board occupy two 8 - bit slots and the hard.
  • Page 9 Q. What kind of joystick can I use with the APEX 200 and where do you connect it? A. There are many IBM PC-compatible joysticks available and some have different types of connectors.
  • Page 10 Q. What are the CPU wait states for the APEX 200? A. The default wait state for the APEX 200 I/O bus is 1, adjustable to 4, 3, or 2 by setting jumpers J2 and J3 on the ANDRO board according to the User’s Guide.
  • Page 11 * Will run at 8MHz, not at 12MHz CPU speed. Q. Will it support Unix and/or Xenix? Which versions? A. The APEX 200 has been tested with the Santa Cruz Operations Xenix Rel. 2.1 and IBM Xenix Vers. 1. Q. What terminal emulation boards are compatible with the APEX 200? A.
  • Page 12 EPSON Product Support Bulletin Subject: Proper Method for Running Benchmark and Diagnostics Programs Date: 06/04/93 PSB No: S-0158 Originator: MWT Page(s): 1 of 1 This bulletin describes the proper method for running any benchmark or diagnostics programs. This applies to any computer system.
