Asus A7V8X-MX SE Troubleshooting Manual

Motherboard diy troubleshooting guide
Hide thumbs Also See for A7V8X-MX SE:

Advertisement

Quick Links

®
A7V8X-MX SE

Advertisement

loading

Summary of Contents for Asus A7V8X-MX SE

  • Page 1 ® A7V8X-MX SE...
  • Page 2 T1493 © 2003...
  • Page 5 • • • • • • • • • • • •...
  • Page 6 A7V8X-MX SE-TAYZ 10839 11036 11XX11XX11...
  • Page 8 viii...
  • Page 11 ®...
  • Page 15 24.5cm (9.6in) Socket 462 CPU_FAN COM1 VGA1 A7V8X-MX SE CHA_FAN1 SPDIF CLRTC CHASSIS USBPWR56 USB56 FP_AUDIO AUX1 GAME PANEL SB_PWR...
  • Page 17 SB_PWR ® A7V8X-MX SE Standby Powered A7V8X-MX SE Onboard LED Power...
  • Page 18 CPU NOTCH TO INNER CORNER LOCK LEVER ® CPU NOTCH A7V8X-MX SE AMD™ CPU A7V8X-MX SE Socket 462 1-10...
  • Page 19 ® A7V8X-MX SE A7V8X-MX SE 184-Pin DDR DIMM Sockets 1-11...
  • Page 20 1-12...
  • Page 21 ® A7V8X-MX SE Keyed for 1.5v A7V8X-MX SE Accelerated Graphics Port (AGP) 1-13...
  • Page 22 1 2 3 4 5 1.Frequency Selection 2.Frequency Selection ® 3.Frequency Selection A7V8X-MX SE 4.Frequency Selection 5.Frequency Selection A7V8X-MX SE DIP Switches 1 2 3 4 5 1 2 3 4 5 1 2 3 4 5 100MHz 166.67MHz 133.33MHz 66.67MHz 66.67MHz...
  • Page 23 USBPWR12 USBPWR34 +5VSB (Default) USBPWR56 ® A7V8X-MX SE +5VSB (Default) A7V8X-MX SE USB Device Wake Up 1-15...
  • Page 24 CLRTC ® A7V8X-MX SE Clear CMOS Normal A7V8X-MX SE Clear RTC RAM (Default) 1-16...
  • Page 25 ® A7V8X-MX SE PIN 1 A7V8X-MX SE IDE Connectors FP_AUDIO ® A7V8X-MX SE A7V8X-MX SE Front Panel Audio Connector 1-17...
  • Page 26 SPDIF ® A7V8X-MX SE A7V8X-MX SE Digital Audio Connector ATXPWR +12.0VDC +5.0VDC +5VSB +5.0VDC PWR_OK -5.0VDC +5.0VDC +5.0VDC PS_ON# ® A7V8X-MX SE +3.3VDC -12.0VDC +3.3VDC +3.3VDC A7V8X-MX SE ATX Power Connector 1-18...
  • Page 27 ® A7V8X-MX SE USB56 A7V8X-MX SE USB 2.0 Header ® A7V8X-MX SE GAME A7V8X-MX SE Game Connector 1-19...
  • Page 28 CPU_FAN ® CHA_FAN A7V8X-MX SE +12V Rotation A7V8X-MX SE 12-Volt Fan Connectors CHASSIS ® A7V8X-MX SE A7V8X-MX SE Chassis Alarm Lead (Default) 1-20...
  • Page 29 FLOPPY ® PIN 1 A7V8X-MX SE A7V8X-MX SE Floppy Disk Drive Connector AUX(White) CD(Black) ® A7V8X-MX SE A7V8X-MX SE Internal Audio Connectors 1-21...
  • Page 30 Speaker Connector Power LED Reset SW ® IDELED ATX Power A7V8X-MX SE SMI Lead Switch* Requires an ATX power supply. A7V8X-MX SE System Panel Connectors • • • • • • 1-22...
  • Page 36 <F1> <Esc> (keypad arrow) (keypad arrows) <PgDn> or - (minus key) <PgUp> or + (plus key) <Enter> <F10>...
  • Page 37 Date (mm:dd:yy) Time (hh:mm:ss) Drive A Drive B IDE Primary Master IDE Primary Slave IDE Secondary Master IDE Secondary Slave...
  • Page 38 Drive A [1.44M, 3.5 in.] Change the day, month, Drive B [None] year and century. IDE Primary Master [ST321122A] IDE Primary Slave [ASUS CDS520/] IDE Secondary Master [None] IDE Secondary Slave [None] Case open Warning [Enabled] Set Supervisor Password Clear...
  • Page 40 IDE Primary Master IDE HDD Auto-Detection [Press Enter] To auto-detect the HDD’s size, head...on IDE Primary Master [Auto] this channel. Access Mode [Auto] Capacity 40020 MB Cylinder 19158 Head Sector Transfer Mode UDMA 2 2-10...
  • Page 41 IDE Secondary Master IDE HDD Auto-Detection [Press Enter] To auto-detect the IDE Primary Master [Manual] HDD’s size, head...on Access Mode [CHS] this channel. Capacity 40020 MB Cylinder [19158] Head Sector 255] Transfer Mode UDMA 2 2-11...
  • Page 42 CPU Type AMD Athlon(tm) CPU Speed 1050MHz/280MHz CPU Cache RAM 256K Current FSB Frequency 133MHz Current DRAM Frequency 166MHz DRAM Clock SPD] External Cache [Enabled] PS/2 Mouse Function Control [Enabled] USB Legacy Mode Support [Auto] Chip Configuration I/O Device Configuration PCI ConfigurationFrequency Voltage Control 2-12...
  • Page 43 Chip Configuration AGP & P2P Bridge Control DRAM Clock/Drive Control CPU & PCI Bus Control VIA OnChip IDE Device VGA Share Memory Size [32MB] tWTR [2T] 2-13...
  • Page 44 AGP & P2P Bridge Control AGP Aperture Size [128MB] AGP Mode [4X] AGP Driving Control [Auto] AGP Driving Value AGP Fast Write [Disabled] AGP Master 1 WS Write [Disabled] AGP Master 1 WS Read [Disabled] AGP 3.0 Calibration Cycle [Enabled] 2-14...
  • Page 45 DRAM Clock/Drive Control DRAM Timing [Auto by SPD] DRAM CAS Latency [2.5] Bank Interleave [Disabled] Pre-charge to Active (Trp) [5T] Active to Precharge (Tras) [7T] Active to CMD (Trcd) [5T] DRAM Burst Lenght DRAM Command Rate [2T Command] Write Recovery Time [3T] 2-15...
  • Page 46 CPU & PCI Bus Control PCI1 Master 0 WS Write [Enabled] PCI2 Master 0 WS Write [Enabled] PCI1 Post Write [Enabled] PCI2 Post Write [Enabled] Vlink 8X Support [Enabled] PCI Delay Transaction [Enabled] 2-16...
  • Page 47 VIA OnChip IDE Devices IDE DMA Transfer Access [Enabled] OnChip Pri IDE Controller [Enabled] OnChip Sec IDE Controller [Enabled] Primary Master PIO [Auto] Primary Slave PIO [Auto] Secondary Master PIO [Auto] Secondary Slave [Auto] Primary Master [Auto] Primary Slave [Auto] Secondary Master [Auto] Secondary Slave...
  • Page 48 I/O Device Configuration Onboard FDC Controller [Enabled] Onboard Serial Port 1 [3F8/IRQ4] Onboard Parallel Port [378/IRQ7] Parallel Port Mode [SPP] ECP Mode USE DMA EPP Mode Select [EPP1.7] VIA-3058 AC97 Audio [Auto] Onboard LAN [Auto] Onboard LAN Boot ROM [Disabled] Game Port Address [201] MIDI Port Address...
  • Page 49 2-19...
  • Page 50 PCI Configuration Resources controlled by [Auto (ESCD)] IRQ Resources PCI/CGA Palette Snoop [Disabled] Assign IRQ for VGA [Enabled] Assign IRQ for USB [Enabled] 2-20...
  • Page 51 IRQ Resources IRQ 3 assigned to [PCI Device] IRQ 4 assigned to [PCI Device] Select [PCI Device] to IRQ 5 assigned to [PCI Device] assign the IRQ to a IRQ 7 assigned to [PCI Device] PCI/PnP device. Select IRQ 9 assigned to [PCI Device] [Reserved] to allocate...
  • Page 52 ACPI Suspend Type [S1 & S3] Power Management Option [User Define] HDD Power Down [Disabled] Video-off Option [Suspend -> Off] AC Loss Auto Restart [Previous State] Video Off Method [V/H Sync+Blank] C.O.P. Control [85 degree] PWR Button < 4 Sec [Instant-off] Power Up Control Hardware Monitor...
  • Page 53 IRQ/Event Activity Detect Power Up On PCI Devices [Disabled] PS2KB Wakeup Select [Hot Key] PS2KB Wakeup from S3/S4/S5 [Disabled] PS2MS Wakeup from S3/S4/S5 [Disabled] USB Resume from S3 [Disabled] Modem Ring Resume [Disabled] RTC Alarm Resume [Disabled] Date (of Month) Resume Time 0 : 0 : 0 2-23...
  • Page 54 2-24...
  • Page 55 Hardware Monitor Shutdown Temperature [Disabled] System Temperature 34 C/ 93 F CPU Temperature 47 C/116 F Chassis Fan 0RPM CPU Fan 5443RPM Vcore 1.79V +3.3V 3.37V 4.94V +12V 11.36V 2-25...
  • Page 56 First Boot Device [HDD-0] Second Boot Device [CDROM] Third Boot Device [Floppy] Select your boot Fourth Boot Device [Disabled] device priority. Plug and Play OS [Yes] Reset Configuration Data [Disabled] Quick Power On Self Test [Disabled] Boot Up Floppy Seek [Disabled] Boot Up NumLock Status [On]...
  • Page 57 Save & Exit Setup Exit Without Saving Load Optimized Defaults Save data to CMOS. Discard Changes Save Changes 2-27...
