Sony SLV-678HF - Video Cassette Recorder Dimensions

SLV-688/678HF
1/4 inch =1 inch Scale 4:1
1/4 1 7/8
3/4"
7/8"
AC
CONTROL S IN
CABLE MOUSE
IN
NOTE:
WHERE THERE ARE CLOSE TOLERANCES
OR APPLICATIONS WHICH REQUIRE A GREAT DEGREE OF PRECISION
RECOMMEND THAT THE PRODUCT ITSELF
MEASUREMENTS. SONY WILL NOT BE RESPONSIBLE FOR
IN THE DESIGN OR MANUFACTURE OF ENCLOSURES .
Sony Electronics Inc • Consumer Integrated Systems • Park Ridge, New Jersey 07656
Features and specifications subject to change without notice. • Non-metric weights and measurements are approximate.
MODEL:
DESCRIPTION:
DESCRIPTION:
DIMENSIONS
DIMENSIONS
(WHD):
(WHD):
14" X 4 1/8" X 11
WEIGHT:
WEIGHT:
8 lbs. 2 oz.

FRONT VIEW

14"
HI-FI Stereo
VHS
R
9 3/4"
SIDE VIEW
11"
8 5/8"
BACK VIEW
L Audio R VIDEO
LINE
IN
LINE
OUT
INVOLVED IN CABINET BUILDING
BE USED TO MAKE THE ACTUAL
VHS HI-FI VCR
POWER
REQUIREMENTS:
POWER
CONSUMPTION:
4 1/8"
1 7/8" 1/4"
3/4"
RF UNIT
3
IN
4
OU
VHF/UHF
WE
INACCURACIES
120V
60H
25
Watts
