Page 1
<< NOTES >> 1. Material, printing and exterier size are refer to work tables. 2. Printing, text size and line are based on LG design film. 3. Exterier size on the drawing is cutting line. 4. Before product controlled by criteria sample.
Page 2
http//us.lge.com sitio nuestro visite información, más Para referencias. futuras para manual conserve serie nùmero modelo Guarde mantenimiento. segura, instalaciòn importante informaciòn contiene correctamente, manual favor Secadora comprar Gracias DLG8388NM DLE8377NM DLG8388WM DLE8377WM semana días día, horas Cliente) (Atención Servicio para 1-800-243-0000...
Page 3
1-800-243-0000 24 HOURS A DAY, 7 DAYS A WEEK FOR LG CUSTOMER SERVICE DLE8377WM / DLG8388WM DLE8377NM / DLG8388NM Thank you for buying a LG Dryer. Please read your manual carefully, as it provides instructions on safe Installation, Use and Maintenance.
PART4 ACCESSORIES INSTALLATION ....................................13-14 PART5. ELECTRICAL REQUIREMENTS FOR ELECTRIC DRYER.............................15-18 PART6. ELECTRICAL REQUIREMENTS FOR GAS DRYERS................................19 PART7. GAS REQUIREMENTS AND INSTRUCTIONS ..................................20 PART8. EXHAUST REQUIREMENTS AND MAINTENANCE ...............................21-22 PART9. OPERATING YOUR DRYER ......................................23-30 PART10. TROUBLESHOOTING GUIDE......................................31-33 LG DRYER LIMITED WARRANTY........................................34...
Part 1 SPECIFICATIONS Please refer to the rating label regarding detailed information. Specifications are subject to change by manufacturer. ACCESSORIES Design of pedestals are subject to change without manafaturers notice. See page 26 for how to use. See page 13 for how to use. See page 14 for how to use.
You will need the complete Model and Serial Number when requesting Warranty Service. Proof of purchase date is required. Use the space below to record the model number and serial number of your new LG dryer. Model No. Serial No.
Page 7
Part 2 IMPORTANT WARRANTY AND SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS WARNING! To help reduce any risk of electric shock, fire, or other personal injury or property damage when using your dryer, please exercise care and follow basic safety precautions, including the following: 1) Read all instructions before using the appliance.
Part 2 IMPORTANT WARRANTY AND SAFETY INSTRUCTIONS WHAT TO DO IF YOU SMELL GAS: • Do not try to light a match or cigarette, or turn WARNING! on any gas or electrical appliance. • Do not touch any electrical switches. Do not use any phone in your building.
Part 3 INITIAL STEPS FOR INSTALLING YOUR DRYER The following instructions will help guide you through the initial steps of setting up your dryer for use. Please note that every section of this manual provides important information regarding the preparation and use of your dryer, and it is important that you review this entire manual before proceeding with any installation or use.
Part 3 INITIAL STEPS FOR INSTALLING YOUR DRYER Once in position, adjust the leveling legs of the dryer until it is level from left to right and front to back. The leveling legs must remain firmly on the floor and the dryer should not rock. The maximum slope of the dryer from left to right or front to back should not exceed 2.5 cm (1 inch).
Page 11
Part 3 INITIAL STEPS FOR INSTALLING YOUR DRYER ALTERNATE EXHAUST DIRECTIONS STEP 3 Connecting the Exhaust and Venting System. WARNING! 2-1. Note Vent end will face to the outside home and improper taping and unstable installation of vent will cause undesirable drying performance. In addition to the following warnings, please refer to manual section on Exhaust Requirements and Maintenance.
Page 12
Part 3 INITIAL STEPS FOR INSTALLING YOUR DRYER STEP 4 Connection of Gas Supply STEP 5 Electrical Plug Connections (Gas dryer only). In addition to the following, Following are several warnings and instructions concerning making the electrical connection for electric please refer to manual section on Gas Requirements dryers.
Page 13
Part 3 INITIAL STEPS FOR INSTALLING YOUR DRYER STEP 6 Preparation of the Dryer. STEP 8 Dryer Airflow. Prior to the first use of this appliance, use all- Effective dryer operation requires appropriate dryer purpose cleaning products or a solution of detergent airflow.
Page 14
Part 3 INITIAL STEPS FOR INSTALLING YOUR DRYER 4) Electric dryers may be vented to the outside STEP 9 Additional Instructions using the back, left, right, or bottom panel. for Installation of Your 5) Gas dryers may be vented to the outside using the Dryer in a Manufactured back, left, or bottom panel.
Part 4 ACCESSORIES INSTALLATION Stacking Kit Installation Instructions WARNING! Stacking kit Note If there are some foreign objects on the surface of top plate, it becomes difficult to apply double- sided tape on.
Page 16
Part 4 ACCESSORIES INSTALLATION Pedestal Installation Instructions...
Part 5 ELECTRICAL REQUIREMENTS FOR ELECTRIC DRYERS Following are additional instructions regarding electrical connections and requirements for electric dryers. Important Warning: To help prevent fire, electric shock, serious injury or death, the wiring and grounding must conform to the latest edition of the National Electrical Code, ANSI/NFPA 70 and all applicable local regulations.
Page 18
Part 5 ELECTRICAL REQUIREMENTS FOR ELECTRIC DRYERS Review the following options to determine the appropriate electrical connection for your home: 4-wire connection : Direct wire 4-wire receptacle (NEMA type14-30R) Important : Grounding through the neutral conductor is prohibited for (1) new branch-circuit installations, (2) mobile homes, and (3) recreational vehicles, and Use the instructions in this section if your home has (4) areas where local codes prohibit grounding through...
Page 19
Part 5 ELECTRICAL REQUIREMENTS FOR ELECTRIC DRYERS 3-wire connection : Direct wire Option 1: 4-wire connection with a Power supply cord. Important : Grounding through the neutral conductor is prohibited for (1) new branch-circuit installations, • lf your local codes or ordinances do not allow the (2) mobile homes, and (3) recreational vehicles, and use of a 3 wire connection, or you are installing (4) areas where local codes prohibit grounding through...
Part 5 ELECTRICAL REQUIREMENTS FOR ELECTRIC DRYERS Option 3: Optional 3-wire Option 2: 3-Wire Connection with connection. a Power Supply Cord • If your local codes or ordinances do not allow the lf your local codes or ordinances permit the connection of a frame-grounding conductor to the connection of a frame-grounding conductor to the neutral wire, use the instructions under this...
Part 6 ELECTRICAL REQUIREMENTS FOR GAS DRYERS 120 Volt, 60 Hertz, with 3-Prong Grounding Plug Following are additional instructions regarding electrical connections and requirements for gas dryers. Important Warning: To help prevent fire, electric shock, serious injury or death, the wiring and grounding must conform to the latest edition of the National Electrical Code, ANSI/NFPA 70, or the Canadian Electrical Code, CSA C22.1, and all applicable local regulations.
Part 7 GAS REQUIREMENTS AND INSTRUCTIONS Following are important instructions and information concerning the requirements for the gas supply and service for gas dryers. Important Warning: The gas supply and service for a gas dryer must comply with all local codes and ordinances.
Page 23
Part 8 EXHAUST REQUIREMENTS AND MAINTENANCE Following are important instructions and information concerning the exhaust requirements for your dryer. Important Warning: To reduce the risk of fire, combustion, or accumulation of combustible gases, DO NOT exhaust dryer air into an enclosed and unventilated area, such as an attic, wall, ceiling, crawl space, chimney, gas vent, or concealed space of a building.
Part 8 EXHAUST REQUIREMENTS AND MAINTENANCE Exhaust and Dryer Maintenance Cleaning the Lint Screen 1. Clean the lint filter either before drying each load WARNING! or after drying each load. Always make sure the lint filter is clean before starting a new load, because a clogged lint filter may increase drying times.
Part 9 OPERATING YOUR DRYER Following are instructions for starting and using your new dryer. Please refer to specific sections of this manual for more detailed information. Important Warning: To reduce the risk of fire, electric shock, or injury to person, read this entire manual, including the Important Safety Instructions, before operating this dryer.
Page 26
Part 9 OPERATING YOUR DRYER Cycle Selection Cycle Selection • By dialing the knob, select the desired cycle based on laundry types and conditions. 1. Sensor Dry Cycles Sensor Dry Cycles allow you to match the cycle to the load you are drying. Each cycle dries certain fabrics at the recommended temperature.
Page 27
Part 9 OPERATING YOUR DRYER Estimated Time Remaining 2. Manual Dry Cycles Use Manual Cycles to select a specific amount of MANUAL DRY drying time and a drying temperature. When a 0:26 EST. TIME REMAINING Manual Cycle is selected, the ESTIMATED TIME DRYING REMAINING display shows the actual time HIGH...
Part 9 OPERATING YOUR DRYER Option Buttons To use the RACK DRY 1. CUSTOM PROGRAM. Select SELECT A CYCLE AND OTHER DESIRED OPTIONS, NEXT SAVE BY PRESSING AND HOLDING THE CUSTOM BUTTON FOR 3 SECONDS. Set up your favorite combination of settings and save them here for one-touch recall.
Page 29
Part 9 OPERATING YOUR DRYER 3. Wrinkle Care 6. Setting a Language Language change is available at Check Filter after Select Power On HELPS TO AVOID WRINKLES FROM FORMING ON YOUR LAUNDRY. When you Press and hold DAMP DRY BEEP for 3 seconds, DAMP DRY BEEP can be used to switch trilingual.
Page 30
Part 9 OPERATING YOUR DRYER 1 1 0 0 Time Dry Temp. Control HIGH 60(MIN) MID HIGH 50(MIN) MEDIUM 40(MIN) 30(MIN) ULTRA LOW 20(MIN) NORMAL HIGH HIGH 40(MIN) Use Time Dry Option to change Drying Time Use Temp. Control Option to select temperatures for on your own.
Part 9 OPERATING YOUR DRYER Starting your dryer 1 1 1 1 Dryness Level control 1. Before use • Clean lint screen before or after each cycle. • Place laundry into dryer and shut door. See Loading. VERY DRY MORE DRY •...
Page 32
Part 9 OPERATING YOUR DRYER 5. Pausing or restarting To pause the dryer at 4. To use a manual dry cycle any time • Select a Manual Dry Cycle. Open the door or press START/PAUSE once. • Press MORE TIME or LESS TIME until the desired drying time is displayed.
Part 10 TROUBLESHOOTING GUIDE 1.Problem:My Dryer Won ’t Start Question What to Do • Is the dryer plugged in? Confirm that the dryer’s plug is securely and completely pushed into the laundry room’s power outlet • Is the fuse blown, or is the circuit Check your home’s or laundry room’s fuse box/circuit breaker box and replace the breaker tripped? fuse or reset the circuit breaker.
Page 34
Part 10 TROUBLESHOOTING GUIDE 5.Problem:There is Lint on my Clothes Question What to Do • Is your lint filter full? Please refer to the manual section on cleaning the lint filter, and please confirm that the lint filter is clean. It is important that the lint filter is clean before each new load of laundry.
Page 35
Part 10 TROUBLESHOOTING GUIDE 8.Problem:It takes too long for my clothes to dry Question What to Do • Did you properly sort your loads of Separate heavy weight items from light weight items when creating loads. laundry? • Are you drying large loads of heavy Heavy fabrics take longer to dry because they tend to retain more moisture.
LG DRYER LIMITED WARRANTY – USA 1-800-243-0000 1-800-243-0000...
Page 37
PARTE 7. REQUERIMIENTOS E INSTRUCCIONES SOBRE EL GAS ...............................20 PARTE 8. REQUERIMIENTOS Y MANTENIMIENTO SOBRE EL ESCAPE ..........................21-22 PARTE 9. USANDO SU SECADORA ......................................23-30 PARTE 10. GUÍA PARA LA SOLUCIÓN DE PROBLEMAS................................31-33 GARANTÍA LIMITADA DE LA SECADORA LG ....................................34...
Parte 1 ESPECIFICACIONES Favor de consultar la etiqueta de medición referente a la información detallada Las especificaciones son sujetas a cambio por el fabricante. ACCESORIOS Vea la página 26 para su uso Vea la página 13 para su uso Vea la página 14 para su uso...
Necesitará el número de modeloo y de serie completo al solicitar la garantía de servicio. Es necesaria la prueba de la compra (ticket o recibo). Utilice el siguiente espacio para anotar el número de modelo y de serie de su nueva secadora LG. Modelo No.
Page 40
Parte 2 GARANTÍA E INSTRUCCIONES DE SEGURIDAD IMPORTANTES INSTRUCCIONES DE SEGURIDAD IMPORTANTES ADVERTENCIA! Para ayudar a reducir el riesgo de choque eléctrico, incendio, o lesión personal o daño a la propiedad cuando use su secadora, por favor sea precavido y siga las precauciones de seguridad básicas, incluyendo las siguientes: 1) Lea todas las instrucciones antes de usar el artefacto.
Page 41
Parte 2 GARANTÍA E INSTRUCCIONES DE SEGURIDAD IMPORTANTES QUE HACER EN CASO DE OLER GAS: • No intente encender un fósforo, o cigarrillo, o ADVERTENCIA! encender ningún artefacto de gas o eléctrico. • No toque ningún interruptor eléctrico. No use ningún teléfono en su casa o edificio.
Parte 3 PASOS INICIALES PARA LA INSTALACIÓN DE SU SECADORA Las siguientes instrucciones le servirán de guía a través de los pasos iniciales para la preparación de su secadora para el uso. Por favor note que cada sección de este manual proporciona información importante sobre la preparación y uso de su secadora, y es muy importante que lea este manual completamente antes de proceder con cualquiera instalación o con su uso.
Page 43
Parte 3 PASOS INICIALES PARA LA INSTALACIÓN DE SU SECADORA Una vez en posición ajuste las patas niveladoras de la secadora hasta que esté nivelada de izquierda a derecha y del frente hacia atrás. Las patas niveladoras deben permanecer firmes en el piso y la secadora no debe mecerse.
Page 44
Parte 3 PASOS INICIALES PARA LA INSTALACIÓN DE SU SECADORA DIRECCIONES ALTERNAS PARA EL ESCAPE PASO 3 Conexión del Sistema de Escape y Ventilación ADVERTENCIA! 2-1. Nota El extremo de la ventilación mirará hacia el lado externo y el mal roscado o una instalación inestable de la ventilación provocarán niveles de secado no deseados.
Page 45
Parte 3 PASOS INICIALES PARA LA INSTALACIÓN DE SU SECADORA PASO 4 Conexión del Suministro PASO 5 Electrical Plug Connections Conecciòn Elèctrica de Gas A continuación encontrará advertencias e instrucciones (Secadora a Gas solamente). Además de lo siguiente, por concernientes a la confección de la conexión eléctrica favor refiérase a la sección del manual sobre para secadoras eléctricas.
Page 46
Parte 3 PASOS INICIALES PARA LA INSTALACIÓN DE SU SECADORA PASO 8 Flujo de Aire PASO 6 Preparación de la Secadora La efectiva operación de la secadora requiere de un flujo de aire adecuado. El flujo de aire adecuado Antes de usar por primera ves esta secadora, utilice puede ser medido evaluando la presión estática.
Page 47
Parte 3 PASOS INICIALES PARA LA INSTALACIÓN DE SU SECADORA 4) Las secadoras eléctricas pueden ser ventiladas PASO 9 Instrucciones Adicionales hacia el exterior usando el panel trasero, para la Instalación de su izquierdo, derecho o inferior Secadora en una Casa 5) Las secadoras a gas pueden ser ventiladas hacia Prefabricada o Móvil.
Parte 4 INSTALACIÒN DE ACCESORIOS Instrucciones de Instalaciòn para montar el Kit ADVERTENCIA! Kit para Apilar Nota Si hay objetos extraños en la superficie de la placa superior, será difícil aplicar dobles burletes.
Page 49
Parte 4 INSTALACIÒN DE ACCESORIOS Instalacion de la secadora (Cinta de tipo doble-cara) B. Desinstalación de una secadora a gas:...
Parte 5 REQUERIMIENTOS ELÉCTRICOS PARA SECADORAS ELÉCTRICAS Las siguientes son instrucciones adicionales sobre las conexiones y requerimientos eléctricos para las secadoras eléctricas. Advertencia Importante: Para ayudar a prevenir incendios, choque eléctrico, lesiones serias o muerte, el cableado y la conexión a tierra deben estar de acuerdo con la edición más reciente del código Eléctrico Nacional, ANSI/NFPA 70 y todas las regulaciones locales aplicables.
Page 51
Parte 5 REQUERIMIENTOS ELÉCTRICOS PARA SECADORAS ELÉCTRICAS Revise las siguientes opciones para determinar la conexión eléctrica adecuada para su casa: Conexiòn de 4-cables: Cableado directo Tomacorriente de 4-alambres (Tipo NEMA 14-30R). Importante : Contacto por conductor neutro esta prohibido por(1) nuevas instalciones de branch- circuito (2) las casas de Utilice las instrucciones en esta sección si su casa mobiles (3) vehiculo recreacional y (4) areas donde los codigos tiene un tomacorriente de 4-alambres (Tipo NEMA...
Page 52
Parte 5 REQUERIMIENTOS ELÉCTRICOS PARA SECADORAS ELÉCTRICAS Conexiòn de 3-cables: Cable Directo Opción 1 Conexión de 4-alambres con un Cordón de Alimentación. Importante : Contacto por conductor neutro esta prohibido por(1) nuevas instalciones de branch- circuito (2) • Si los códigos y ordenanzas locales no permiten el las casas de mobiles (3) vehiculo recreacional y (4) areas uso de una conexión de 3 alambres, o está...
Page 53
Parte 5 REQUERIMIENTOS ELÉCTRICOS PARA SECADORAS ELÉCTRICAS Opción 2 Conexión de 3-alambres con Opción 3 Conexión Opcional de un Cordón de Alimentación. 3-alambres. • Si los códigos y ordenanzas locales no permiten la Si los códigos y ordenanzas locales permiten la conexión de un conductor estructura-tierra a un conexión de un conductor estructura-tierra al cable neutral, utilice las instrucciones bajo esta...
Parte 6 REQUERIMIENTOS ELÉCTRICOS PARA SECADORAS A GAS 120 Voltios, 60 Hertz, con Enchufe de 3-Clavijas con Conexión a Tierra Las siguientes son instrucciones adicionales sobre las conexiones y requerimientos eléctricos para las secadoras a gas Advertencia Importante: Para ayudar a prevenir incendios, choque eléctrico, lesiones serias o muerte, el cableado y la conexión a tierra deben estar de acuerdo con la edición más reciente del código Eléctrico Nacional, ANSI/NFPA 70, o el Código Eléctrico Canadiense, CSA C22.1, y todas la regulaciones locales aplicables.
Parte 7 REQUERIMIENTOS E INSTRUCCIONES SOBRE EL GAS Las siguientes son instrucciones e información importante concernientes a los requerimientos para el suministro y servicio del gas para las secadoras a gas. Advertencia Importante: El suministro y servicio del gas para las secadoras a gas debe cumplir con los códigos y ordenanzas locales.
Page 56
Parte 8 REQUERIMIENTOS Y MANTENIMIENTO SOBRE EL ESCAPE Las siguientes son instrucciones e información importante concernientes a los requerimientos del escape para su secadora. Advertencia Importante: Para reducir el riesgo de incendio, combustión, o acumulación de gases combustibles, NO dirija el escape de la secadora hacia un área cerrada y no ventilada, como un ático, pared, techo, sótano, chimenea, salidas de gas, o espacio oculto de un edificio.
Parte 8 REQUERIMIENTOS Y MANTENIMIENTO SOBRE EL ESCAPE Mantenimiento del Escape y la Secadora Limpieza de la Malla de Pelusa 1. Limpie el filtro de pelusa antes o después de haber ADVERTENCIA! secado cada carga. Siempre asegúrese que el filtro de pelusa esté...
Page 58
Parte 9 USANDO SU SECADORA Las siguientes son las instrucciones para encender y utilizar su nueva secadora. Por favor refiérase a las secciones especificas de este manual para información más detallada. Advertencia Importante: Para reducir el riesgo de incendio, choque eléctrico, o lesiones personales lea este manual completamente, incluyendo las Instrucciones de Seguridad Importantes, antes de operar esta secadora.
Page 59
Parte 9 USANDO SU SECADORA 2 2 2 2 Selección del ciclo • Marcando con la perilla, seleccione el ciclo deseado basándose en los tipos de colada y las condiciones existentes. 1. Ciclo de Sensor Dry[sensor de secado] Seleccione el ciclo de secado que concuerde con el tipo de carga que desea secar. (Vea la tabla de Características Preestablecidas de los Ciclos Sensor Dry[sensor de secado] y Manual.
Page 60
Parte 9 USANDO SU SECADORA Tiempo rest. estimado 2. Ciclos Manuales Use los Ciclos Manuales para seleccionar una cantidad especifica de tiempo de secado y una temperatura de secado. Cuando un Ciclo Manual es seleccionado, la pantalla del estimated time remaining(Tiempo Restante Estimado) muestra el tiempo actual restante en su ciclo.
Page 61
Parte 9 USANDO SU SECADORA Botones OPCIÓN PARA USAR LA PARRILLA DE SECADO 1. PROGRAMA PERSONALIZADO Selecciona Programación personalizada para ajustar su 1. Abra la puerta combinación favorita de distintos ajustes y Sostenga la parrilla de guardarlos aquí para rellamarlos con un simple toque secado con ambas manos de un botón.
Page 62
Parte 9 USANDO SU SECADORA 6. Seleccionando el lenguaje 3. Cuidado arrugas El lenguaje puede cambiar ya que está disponible al Selecciona cambiar el filtro despues de encender . Cuando presiona y retiene el botón de alarma por humedad en el secado por 3 segundos, dicho botón puede ser utilizado para cambiar el lenguaje.
Parte 9 USANDO SU SECADORA 1 1 0 0 Control temp Control tiempo secado Use la opción de control del tiempo para seleccionar Opción seca del tiempo del uso para cambiar tiempo las temperaturas par alos ciclos manuales. Pulse de secado en sus el propios usted puede seleccionar TEMP CONTROL hasta que se ilumine el ajuste de el tiempo deseado de la operación manualmente temperatura.
Page 64
Parte 9 USANDO SU SECADORA Arranque de seu secadora 1 1 1 1 Nivel secado 1. Antes de usar • Limpie la pantalla de hilos antes y después de cada ciclo. • Coloque la colada en la secadora y cierre la puerta. Consulte el apartado de carga.
Page 65
Parte 9 USANDO SU SECADORA 5. Pausar o reiniciar. Para pausar la secadora en 4. Para usar un ciclo de manual por sensor • Seleccione un ciclo de secado manual. cualquier momento • Pulse MORE TIME o LESS TIME hasta que el Abra la puerta o pulse START/PAUSE una vez.
Parte 10 GUÍA PARA LA SOLUCIÓN DE PROBLEMAS 4. Problema: Mi Secadora muestra "Error" Pregunta Qué Hacer Se muestra cuando el Thermistor no esta conectada. En este caso, el thermistor debe ser reemplazadoy llamar al centro de servicio. Se muestra cuando el thermistor es muy corto. En este caso, el thermistator debe ser reemplazado y llamar al centro de servicio.
Page 67
Parte 10 GUÍA PARA LA SOLUCIÓN DE PROBLEMAS...
Page 68
Parte 10 GUÍA PARA LA SOLUCIÓN DE PROBLEMAS...
