D-Link DES-5016 User Manual

D-link systems, inc fast ethernet switching system user's guide des-5016
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
DES-5016 Fast Ethernet Switching
System
User's Guide
Rev. 01 (January, 1999)
651DES32.K15

Advertisement

Table of Contents
loading

Related Manuals for D-Link DES-5016

Summary of Contents for D-Link DES-5016

  • Page 1 DES-5016 Fast Ethernet Switching System User’s Guide Rev. 01 (January, 1999) 651DES32.K15...
  • Page 2 The one-year period of warranty on complete products (or such longer period of warranty as may be offered as to your purchase) applies on condition that the product’s Registration Card is filled out and returned to a D-Link office within ninety (90) days of purchase. A list of D- Link offices is provided at the back of this manual, together with a copy of the Registration Card.
  • Page 3 D-Link Offices for Registration and Warranty Service: The product’s Registration card, provided at the back of this manual, must be sent to a D-Link office. To obtain an RMA number for warranty service as to a hardware product, or to obtain warranty service as to a software product, contact the D-Link office nearest to you.
  • Page 4 No part of this publication may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from D-Link Corporation/D-Link Systems Inc., as stipulated by the United States Copyright Act of 1976.

  • Page 5: Wichtige Sicherheitshinweise

    Wichtige Sicherheitshinweise Bitte lesen Sie sich diese Hinweise sorgfältig durch. Heben Sie diese Anleitung für den spätern Gebrauch auf. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen. Vervenden Sie keine Flüssig- oder Aerosolreiniger. Am besten dient ein angefeuchtetes Tuch zur Reinigung. Um eine Beschädigung des Gerätes zu vermeiden sollten Sie nur Zubehörteile verwenden, die vom Hersteller zugelassen sind.

  • Page 6: Table Of Contents

    Unpacking the DES-5016... 8 Installation Options ... 9 Installing Optional Modules ... 14 Power On ... 17 3... 18 Connecting the DES-5016 to the Network... 18 Cable Specifications ... 18 Copper Cable... 18 Fiber Optic Cable ... 20 Ports... 21 MDI-X Ports ...
  • Page 7 DES-5016 to DES-5016 Connection... 22 Connecting the DES-5016 to other Switches and Hubs... 22 4... 23 LEDs... 23 CPU Module ... 24 8-Port TX Module ... 26 8-Port FX Module ... 28 2-Port 100BASE-FX Module ... 29 1-Port 1000BASE-SX Module ... 31 5...
  • Page 8 Delete VLAN Menu ... 72 Trunking Port Management Menu ... 74 Create New Trunking Port... 75 Delete Trunking Port ... 77 6... 79 Troubleshooting ... 79 Appendix A... 82 DES-5016 Technical Specifications ... 82 Switch Specifications ... 82 Port Specifications... 82 Index... 87 viii...

  • Page 9: About This Guide

    Audience This user guide is intended for the networking or computer technician who is installing the DES-5016 on a network. Refer to other sources for information about networking in general. All the information you need to install, configure and troubleshoot the DES-5016 is contained in this user guide.

  • Page 10: Introduction

    3. The modules can be ordered at the time of purchase or ordered separately. The chapter is divided into the following sections. Each section briefly describes the features of the DES-5016. Most of the topics discussed will be explained in greater detail later in the manual. The topics covered are:...
  • Page 11 Eight thousand active MAC address table entries per device with self-learning and table aging. The DES-5016 supports SNMP for RFC 1213, RFC 1757, and RFC 1493. VLAN support for eight broadcast domains. Port Trunking support for bandwidth aggregation between two DES-5016 switches.

  • Page 12: Front Panel

    All ports can be used for network connections. The RS-232 port is used for Out of Band Management. All LEDs are located on the front panel of the DES-5016. Their purpose is to allow you to monitor the operation and performance of the DES-5016 at a glance.
  • Page 13 Fast Ethernet Switching System User’s Guide DES-5016TF The DES-5016TF, displayed in Figure 2, comes with eight 10/100-TX ports and eight 100BASE-FX ports. The DES-5016TF is shown with the optional 1-Port 1000BASE-SX module installed. Figure 2: DES-5016TF The DES-5016FX, displayed in, Figure 3, has 16 10/100-TX ports installed. It is shown with the optional 2-Port 100BASE-FX module installed.

  • Page 14: Rear Panel

    The three pronged power plug, ventilation fan and the on/off switch are located at the rear of the DES-5016 displayed in Figure 4. The switch will work with AC in the range 100- 240 VAC, 50-60 Hz. The power requirements are indicated on the rear panel of the DES- 5016.

  • Page 15: Management Methods

    DES-5016 in this mode requires a direct connection between a PC and the DES-5016. Telnet Management Telnet is done over the network. Once the DES-5016 is on the network, you can use Telnet to log in and change the configuration.

  • Page 16: Installing The Des-5016

    Installation Options Installing Optional Modules Powering on the DES-5016 Unpacking the DES-5016 Open the box and carefully unpack the DES-5016. You should have all the items on the following checklist: DES-5016 Fast Ethernet Switching System RS-232 DCE serial cable Two mounting brackets and eight screws Four rubber pads with adhesive backing One six foot (1.82 m) power cord...

  • Page 17: Installation Options

    Fast Ethernet Switching System User’s Guide Installation Options There are two options for installing the DES-5016: desktop/ shelf installation or rack installation. Follow these guidelines for desktop/ shelf installation or rack installation: The surface must support 18 lbs or 8 kg.
  • Page 18 DES-5016. Follow these steps to install the DES-5016 on a desktop or shelf: 1. Place the four rubber feet at the corners of the DES-5016. See Figure 5 and Figure 6. 2. Place the DES-5016 on the desktop/shelf. Figure 5: Install Feet on Bottom...
  • Page 19 Fast Ethernet Switching System User’s Guide Figure 6: Attach Feet Installing the DES-5016...

  • Page 20: Rack Installation

    The DES-5016 can be mounted in an EIA standard size, 19-inch rack. The dimensions of the DES-5016 are 4.4 inches (112 mm) x 10.39 inches (264 mm) x 17.32 inches (440 mm). The DES-5016 can be placed in a wiring closet along with other equipment.
  • Page 21 Fast Ethernet Switching System User’s Guide Figure 8: Insert into Rack Installing the DES-5016...

  • Page 22: Installing Optional Modules

    The process for installing all optional modules is the same. You cannot change the position of the CPU module. It must remain in the CPU slot. The DES-5016 will not work unless the CPU module is installed in the CPU slot.
  • Page 23 Fast Ethernet Switching System User’s Guide Figure 9: Remove Blank Bracket Installing the DES-5016...
  • Page 24 Fast Ethernet Switching System User’s Guide Figure 10: Insert Optional Module Installing the DES-5016...

  • Page 25: Power On

    LAN segment cables connected. The power plug is located at the rear of the DES-5016. Plug the cable into the wall socket and plug the other end into the DES-5016. There is a power on/ off switch located at the rear of the DES-5016.

  • Page 26: Connecting The Des-5016 To The Network

    Connecting the DES-5016 to another DES-5016 Connecting the DES-5016 to other switches and hubs This section deals with making cables and connecting the DES-5016 to other devices. It is extremely important that cables have the correct pin arrangement and that the proper cables be used when connecting to servers, switches, hubs, workstations and other devices.
  • Page 27 Table 1: Cable Specifications for Copper Connection Ethernet Type Cable Requirements Category 3, 4, or 5 UTP or 10BASE-T 100-TX Category 5 UTP or STP Figure 11: Cable Diagram Connecting the DES-5016 to the Network Maximum Length 328 ft (100 M) 328 ft (100 M)

  • Page 28: Fiber Optic Cable

    Multi-mode cable ISO/IEC 793-2 type B1 and ITU-T G.652 standards Cable must have SC connectors Gigabit traffic can travel the following distances using the specified cable: 62.5 um cable 720 feet (220 meters) 50 um cables 1639 (500 meters) Connecting the DES-5016 to the Network...

  • Page 29: Ports

    X ports is that you can connect a device with an MDI-II port without using a crossover cable. The steps for connecting the DES-5016 to 10 Mbps devices or 100 Mbps devices are the same. All the ports will auto negotiate the proper speed and duplex mode. The DES-5016 has two full sized modules with eight ports each and one half size optional module.

  • Page 30: Des-5016 To Des-5016 Connection

    Connecting the DES-5016 to other Switches and Hubs You can connect the DES-5016 to other switches and hubs on the network. The DES- 5016 is compatible with the DES-5024, DES-3216 and DES-3224. Port trunking can be configured on the device if more than one port is connected between a DES-5024, DES- 3216 and DES-3224.

  • Page 31: Leds

    Fast Ethernet Switching System User’s Guide The LED panel of the DES-5016, is designed to allow you to manage the DES-5016 at a glance. The LEDs on the CPU Module, 8-Port 10/100-TX module and the 8-Port 10/100BASE-FX module are dealt with in the same section. The optional modules are dealt with in separate sections.

  • Page 32: Cpu Module

    The CPU module, displayed in Figure 13, is at the top of the chassis. This is the only slot it will work in. If it is not at the top of the chassis, the DES-5016 will not work. See Table 2: Power LED for an explanation of the Power LED. See Table 3: CPU Module LEDs for an explanation of the LEDs on the CPU module.
  • Page 33 DES-5016 Displays the error codes if there is a Diagnostic failure during the POST or during operation Displays the utilization of the DES-5016. Utilization LED increments left to right, higher numbers indicate greater utilization. LEDs Dark Normal if firmware is not being loaded Normal if there are no problems.

  • Page 34: 8-Port Tx Module

    Fast Ethernet Switching System User’s Guide 8-Port TX Module This section covers the LEDs on the 8-Port TX Module, displayed in Figure 14. Figure 14: 8-Port TX Module Link The Link LED indicates there is a link at the port. If a cable is plugged into the port and the Link LED is off, check the cable and connection.
  • Page 35 Fast Ethernet Switching System User’s Guide Table 4: 8-Port TX Module LEDs Lit or Flashing Orange indicates port speed is 10 Mbps Link Green indicates port speed is 100 Mbps Flashes to indicates the port is (Activity) transmitting or receiving data Lit when port is transmitting or receiving 100/10 data at full duplex...

  • Page 36: 8-Port Fx Module

    The Link/ Act LED indicates two things: link and activity. Link refers to the link between the DES-5016 and another device. The LED lights when there is a link at the port, dark when there is no link. Act refers to data passing through the port. The LED flashes Full/ Half Full/ Half refers to the duplex mode of the port.

  • Page 37: 2-Port 100Base-Fx Module

    Fast Ethernet Switching System User’s Guide 2-Port 100BASE-FX Module Figure 16: 2-Port 100BASE-FX Module The LEDs on the 2-Port 100BASE-FX module, displayed in Figure 16, are different from the LEDs on the other modules. The information given is the same but it is presented differently.
  • Page 38 Fast Ethernet Switching System User’s Guide Table 6: FX Module LED Lk (Link) Port is linked to another device (Green) Dx (Duplex mode) Port is in full duplex (Green) Tx (Transmitting) Port is transmitting data (Green) Rx (Receiving) Data is being received (Green) Col (collisions) Collisions are occurring at the port...

  • Page 39: 1-Port 1000Base-Sx Module

    Fast Ethernet Switching System User’s Guide 1-Port 1000BASE-SX Module Figure 17: 1-Port 1000BASE-SX Module The gigabit expansion module, displayed in Figure 17, is has one port. Refer to Table 7: Gigabit Module LED for an explanation the LEDs. Link The link LED lights to indicate there is a link at the port. Act means activity.

  • Page 40: Managing The Des-5016

    The interface and options are the same with Local Console and Telnet Management. The difference is the type of connection and the port that is used to manage the DES-5016. D-View is a proprietary SNMP management program. D-View is provided with the DES- 5016.

  • Page 41: Local Console Management

    DES-5016 cannot be reached by any other means. Use Local Console Management to log into the DES-5016 for the first time. You do not need to know the IP address to log into the DES-5016 using Local Console Management.

  • Page 42: Telnet

    You can manage the DES-5016 via Telnet session. However, first you must assign a unique IP address to the DES-5016. Use Local Console Management to log into the DES- 5016 for the first time so that you can assign an IP address. Once you have assigned an IP address to the DES-5016, you can use the management method of your choice.

  • Page 43: Log In

    The Log In panel, displayed in Figure 18, is the first panel you see when connecting to the DES-5016. All management methods require you to log into the DES-5016 with your user name and password before beginning a management session. For security, you should change the default User Name and Password.

  • Page 44: Help Message

    Fast Ethernet Switching System User’s Guide Help Message A one page panel, displayed in Figure 19, is available. The menu lists the keystroke and typographic conventions available on the DES-5016. Figure 19: Help Message Managing the DES-5016...

  • Page 45: Panel Conventions

    [168.8.254.1] Each changeable value is enclosed in square brackets. EXIT Uppercase letters indicate a COMMAND item. Blinking Text Warning Message. After you are finished viewing the help panel, press Enter to return to the main menu. Managing the DES-5016...

  • Page 46: Console Program

    Fast Ethernet Switching System User’s Guide Console Program The Console Program, shown in Figure 20, is the main menu of the DES-5016. Figure 20: Console Program System Configuration The System Configuration menu gives you general information about the DES-5016 and allows you to assign a LAN IP Address, Subnet Mask, LAN Default Gateway and contact information on the system administrator.

  • Page 47: Spanning Tree Configuration

    The Trunking Port Management menu allows you to create, delete and modify Trunking Ports quickly and easily. Follow these steps to select a menu: 1. Use the tab key or the up and down arrow keys to select an option. 2. Press Enter. Managing the DES-5016...

  • Page 48: System Configuration Menu

    The System Information menu displays the Hardware revision, MAC address, LAN IP address and other information on the DES-5016. System Reset The System Reset menu allows you to reset the DES-5016 through software rather than powering off. Factory Reset to Default Config Values The Factory Reset to Default Config Values menu allows you to reload factory default configurations.

  • Page 49: System Information Menu

    Fast Ethernet Switching System User’s Guide Software Update The Software Update menu is used to update the software on the DES-5016. This feature is only supported through Local Console Management. Follow these steps to select a menu: 1. Highlight the menu option.

  • Page 50: Mac Address

    Brief manufacturer description of the DES-5016. This value cannot be changed. System Name Specifies the full name of the DES-5016. This value can be changed, allowing you to assign a unique name to the DES-5016. You can enter up to 44 characters.

  • Page 51: System Reset

    Figure 23: System Reset Some configurations will require you to reset the DES-5016 in order for them to take effect. Screen prompts will tell you to reset the DES-5016 as needed. Follow these steps to reset the DES-5016: 1.

  • Page 52: Factory Reset

    Fast Ethernet Switching System User’s Guide Factory Reset The Factory Reset panel, displayed in Figure 24, is used to reset the DES-5016 and restore all factory default values. Using this panel erases all configurations and customization. Figure 24: Factory Reset Follow these steps to restore factory default configurations: 1.
  • Page 53 Fast Ethernet Switching System User’s Guide Figure 25: Factory Reset Confirmation Follow these steps to exit the panel without restoring factory default parameters: 1. Select No or Exit. 2. Press Enter. Managing the DES-5016...

  • Page 54: System Rate Control

    Through. Figure 26: System Rate Control The DES-5016 can be set for Store and Forward or Cut-Through. This is a global setting that affects all the ports except the RS-232 port. Store and Forward means that when the DES-5016 receives an incoming packet it “stores”...
  • Page 55 1500 byte packets are delayed by 1200 microseconds in a Store and Forward device versus 60 microseconds in a Cut-Through device. Store and Forward requires more memory because the DES-5016 must store the packet before sending it out. Advantages of Cut-Through Cut-Through is faster because the packet is sent as soon as the first 128 bytes are received.

  • Page 56: Software Update Menu

    1. Load the new software to the hard drive of the PC you will be downloading from. Never attempt to load software from the floppy drive. 2. Connect the DES-5016 and the PC with the software on it with the RS-232 cable provided. Use the settings given at the beginning of this chapter. Never attempt to load firmware through Telnet.
  • Page 57 Fast Ethernet Switching System User’s Guide Figure 28: Transfer Firmware Figure 29: Send File Managing the DES-5016...
  • Page 58 Fast Ethernet Switching System User’s Guide Figure 30: Xmodem When the transfer is complete you will see the panel in Figure 31. The DES-5016 will reset itself automatically and you will have to log in again. Figure 31: EEPROM Managing the DES-5016...

  • Page 59: User Account Management

    The User Account Change menu, displayed in Figure 32, allows you to add users, delete users, and modify user rights. Figure 32: User Account Change Follow these steps to select a menu option: 1. Select an option. 2. Press Enter. Managing the DES-5016...

  • Page 60: Create New User

    Super Users have administrative rights on the DES-5016. They can add and delete users, change the configuration of the DES-5016 and perform all management functions. General Users have read only access to the DES-5016. They can look at the panels but they cannot make any changes to existing settings or configurations.
  • Page 61 1. Enter the User Name. 2. Enter the Password. 3. Reenter the password in the Confirm Password field. 4. Toggle the space bar to set the access level of the new user. 5. Select Save and press Enter. Managing the DES-5016...

  • Page 62: Delete Users

    Delete Users The Delete Users panel, displayed in Figure 34, allows you to delete users from the DES- 5016. As a safety precaution, the DES-5016 will not allow the user who is currently logged in to delete themselves by accident.
  • Page 63 1. Select the Access Level of the user you want to delete. 2. Move the cursor to the Delete column and use the space bar to toggle the option from No to Yes. 3. Press Enter. 4. Select Save and press Enter. Managing the DES-5016...

  • Page 64: Change Password

    1. Enter the user’s name in the User Name field. 2. Enter the user’s old password in the Old Password field. 3. Enter the new password in the New Password field. 4. Reenter the new password in the Confirm Password field. Managing the DES-5016...
  • Page 65 Fast Ethernet Switching System User’s Guide 5. Select Save and press Enter to save your changes. Managing the DES-5016...

  • Page 66: Switch Port Configuration

    Fast Ethernet Switching System User’s Guide Switch Port Configuration The Switch Port Configuration panels are used to configure individual ports on the DES- 5016. The only difference between the panels is the port number that they deal with. The options and settings are the same for each. Select the group of ports that you want to configure and then go to the appropriate panel.

  • Page 67: Switch Port Configuration Menu

    Fast Ethernet Switching System User’s Guide Switch Port Configuration Menu The Switch Port Configuration menu, displayed in Figure 31, enables you to change the configurations of individual ports. Figure 36: Switch Port Configuration State All ports have two states: enabled or disabled. Enabled ports transmit and receive data packets.

  • Page 68: Port State

    2. Enter a new value between zero and 255. 3. Select Save and press Enter. Follow these steps to enable or disable flow control: 1. Toggle the space bar to change the setting, select Save and press Enter to save changes. Managing the DES-5016...

  • Page 69: Spanning Tree Configuration

    (using multiple switches or bridges) in your network. These backup paths are idle until the DES-5016 determines that a problem has developed in the primary path. If the primary path breaks down STA will activate the backup path. STA is very complicated and you should understand it well before changing the default settings.

  • Page 70: Spanning Tree Algorithm

    Root Bridge. Forward Delay Time This is the time any port on the DES-5016 spends in the listening state while moving from the listening state to the forwarding state. It can be set from 4 to 30 seconds. Use the following formula when setting the Hello Time and the Forward Delay Time: 2 x (Forward Delay minus 1 second) >...

  • Page 71: Root Bridge

    Root Bridge the best switch on the network to ensure the best network performance and reliability. Root Bridge Specifies the MAC address of the Root Bridge. The DES-5016 may or may not be the root bridge. The DES-5016 is the default root bridge. Root Port Specifies the preferred path to the Root Bridge.

  • Page 72: Snmp Management Configuration

    DES-5016 is running. For example, the number and type of ports on the DES-5016 is a read-only constant. The number and type of ports is fixed. Statistics, such as the number of errors that have occurred, are read-only variables.

  • Page 73: Snmp Management Configuration Menu

    DES-5016 for SNMP management. Figure 38: SNMP Management Configuration menu SNMP Manager Setting The fields under this setting are used to configure the DES-5016 for SNMP Management. You must configure these fields in order to manage the DES-5016 through SNMP. SNMP Community String The SNMP Community String field allows you to name the SNMP Communities.

  • Page 74: Snmp Trap Manager Setting

    A cold start is different from a factory reset. Authentication Failure Signifies that an addressee (or manager/ user) on the DES-5016 is not a valid user of the DES-5016 and may have entered an incorrect community name.
  • Page 75 1. Enter the IP Address of the Trap Manager. 2. Enter the name of the SNMP Community String. 3. Select Status and toggle the space bar to select Valid or Invalid. 4. Select Save and press Enter. Managing the DES-5016...

  • Page 76: Vlan Port Management

    LAN segment. VLANs can be used to subdivide the network. The DES-5016 supports port based VLAN. Port based VLAN means that the VLAN is grouped by port. If a VLAN is created using three ports, then those ports become a separate broadcast domain.

  • Page 77: Vlan Port Management Menu

    Fast Ethernet Switching System User’s Guide VLAN Port Management Menu The VLAN Port Management menu, displayed in Figure 39, enables you to create, delete and modify VLANs on the DES-5016. Figure 39: VLAN Port Management menu Follow these steps to create, delete and modify VLAN: 1.

  • Page 78: Create New Vlan

    Is the name of the VLAN you are creating. All VLANs must have a unique name. Port # Is the number of the port. The numbers on the panel match the ports on the DES-5016. Some ports are combined. For example, ports 5 and 9 are shown as “Port 5/9”. Ports that are grouped together must be part of the same VLAN.
  • Page 79 1. Enter the name of the VLAN you are creating. 2. Select the ports you want to include in the VLAN and toggle the space bar to change the status from Available to Selected. 3. Select Save and press Enter. Managing the DES-5016...

  • Page 80: Delete Vlan Menu

    2. Toggle the space bar to Yes to delete the VLAN. 3. Select Save and press Enter. 4. A screen prompt will warn you that you must reset the DES-5016 in order for the change to take effect. Managing the DES-5016...

  • Page 81: Modify Vlan Menu

    Toggle the space bar to change the current setting. Available means the port is available for inclusion in the VLAN. Selected means the port has been selected as part of a VLAN. 5. Select Save and press Enter to implement your changes. Managing the DES-5016...

  • Page 82: Trunking Port Management Menu

    The Trunking Port Management panels, displayed in Figure 43, are used to create, delete and modify trunk ports. Figure 43: Trunking Port Management menu Follow these steps to create, delete and modify trunk ports: 1. Select the appropriate option. 2. Press Enter. Managing the DES-5016...

  • Page 83: Create New Trunking Port

    Port # Is the number of the port. The numbers on the panel match the ports on the DES-5016. Some ports are not available for trunking. For example, port 5 has a status of N/A. Ports that are shown as N/A are not available for inclusion in any trunking groups.
  • Page 84 1. Enter the name of the TrunkGroup. 2. Select the ports you want to include in the TrunkGroup and toggle the space bar to change the status from Available to Selected. 3. Select Save and press Enter. Managing the DES-5016...

  • Page 85: Delete Trunking Port

    1. Select the Trunking Group you want to delete in the Delete column. 2. Toggle the space bar to Yes to delete the Trunking Group. 3. Select Save and press Enter. Modify Trunking Port The Modify Trunking Port panel, displayed in Figure 46, enables you to Modify Trunking Ports. Managing the DES-5016...

  • Page 86: Trunking Port Name

    Trunking Group. Selected means the port has been selected as part of a Trunking Group. N/A indicates ports that are not available for inclusion in any trunking group. 5. Select Save and press Enter to implement your changes. Managing the DES-5016...

  • Page 87: Troubleshooting

    This troubleshooting section is intended to help you solve the most common problems on the DES-5016. The Diagnostic LED displays a code if there is a problem on the DES-5016. If an error cannot be resolved by implementing the solutions in this section, contact D-Link Technical Support.
  • Page 88 Log in to the DES-5016 using Local Console Management, see Chapter 5, Managing the DES-5016, for instructions. Power the DES-5016 off and then power it on again. Use the monitor to check the error messages. Return the DES-5016 to D- Link for service if the problem persists.
  • Page 89 Fast Ethernet Switching System User’s Guide Table 9: Diagnostic LED Troubleshooting...

  • Page 90: Appendix A

    Fast Ethernet Switching System User’s Guide DES-5016 Technical Specifications Switch Specifications Complies with IEEE 802.3 CSMA/CD 10/100-TX, 100BASE-FX and 1000BASE-SX Complies with IEEE 802.1d Spanning Tree Switched IEEE 802.3 MAC layer frame size: 64-1518 NWAY Auto-negotiation for each 10/100-TX network port providing auto-...
  • Page 91 Fast Ethernet Switching System User’s Guide Full or Half Duplex for all 10/100-TX ports 100BASE-FX ports operate at full or half duplex requires 1300 nm mulitmode fiber optic cable, ISO/IEC 793-2 type B-1 and ITU-T G.652 with SC connectors One 1000BASE-SX port, operates at full duplex and requires 850 nm multimode fiber optic cables with SC connectors.
  • Page 92 Fast Ethernet Switching System User’s Guide General Standards: IEEE 802.3 10BASE-T Ethernet IEEE 802.3u 100-TX, 100BASE-FX Fast Ethernet and 1000BASE-SX for Gigabit Ethernet ANSI/IEEE Std 802.3 NWAY™ Auto Negotiation IEEE 802.3 Frames types: Transparent IEEE 802.3 MAC layer frame size: 64-1518 Protocol: CSMA/CD, Full Duplex Data Transfer Rate:...
  • Page 93 Fast Ethernet Switching System User’s Guide Physical and Environmental 100 – 240 VAC, 50/60 Hz (internal universal power AC inputs: supply) Power 105 watts maximum Consumption: DC fans: 2 built in 80 x 80 mm fans and 1 60 x 60 mm fan Operating 0 ~ 50 degrees Celsius Temperature:...
  • Page 94 Fast Ethernet Switching System User’s Guide Performance Transmission Cut-Through and Store-and-Forward Method: RAM Buffer: 1 M bytes per device Filtering Address 8 K entries per device Table: Packet Filtering/ 148810 pps per port (for 100 Mbps) Forwarding Rate: MAC Address Automatic update Learning: Max age: five minutes...
