ENERGY STAR 115 Volt Built-in Room Air Conditioner ® ® Wall Case Dimensions and Installation Information (in inches) Note: When installing slide-out chassis units in through-the-wall applications, keep louvers free. Do not restrict air flow areas. 15-5/8 16-7/8 Parallel Parallel 115V...
Page 2
Opening for RAB36/37/38 Case all Opening for RAB36/37/38 Case 4" from side walls. Brick veneer or frame walls should have Trim Molding hed opening of 26-1/8" x 15-3/4", clear of wood studding surrounding case to provide firm anchoring...
Page 3
Features and Benefits • R-410A Refrigerant • 11,600 Cooling BTU • 9.4 E.E.R. • 115 Volts • ENERGY STAR Qualified ® • Electronic controls with remote • Electronic digital thermostat • Four-Way air direction • Up-front, washable air filter • 3 Cool / 3 Fan Speeds • Unit dimensions: 14-7/8"W x 24-3/4"H x 19-7/8"D • Model AJCQ12ACD – Soft Gray AJCQ12DCD Specification Created 9/09 390254...
