Related Manuals for Philips CT1208-SBUA10A7
Summary of Contents for Philips CT1208-SBUA10A7
- Page 2 Philips continuously strives to improve its products, and the information and specifications described in this user guide are subject to change without notice. Philips tries to ensure that all information in this user guide is correct, but does not accept liability for any error, omission or discrepancy between this user guide and the product described.
-
Page 3: Table Of Contents
Calculator... 18 Alarm clock... 18 Call counters... 18 Operator services ... 19 Touchtones (DTMF)... 19 Make a second call ... 19 Answer a second call... 19 Autoredial... 19 Precautions ... 20 Troubleshooting ... 24 Glossary... 26 Philips authentic accessories... 27... -
Page 4: Memory Card
Memory card Switch on/off Enter PIN Make a call Answer a call End a call Quickly access the Names list Quickly access the Call list Quickly access the Ringer Volume Return to previous menu Press Return to idle screen Lock/Unlock the keypad Change the language used Access the menus... -
Page 5: Getting Started
Getting started Read the safety instructions in the "Precautions" section before use. Inserting the SIM card Remove the SIM card from its holder and insert in its slot, under the metal clip holder, push until it stops. Be careful that the clipped corner of the card is in the correct position as shown opposite. -
Page 6: Customising Your Phone
Then plug the transformer unit into an easily accessible AC power socket. Bars moving Bars steady Depending on the network and condition of use, talk time goes from 1.40 to 4 hours and standby time from 8 to 15 days. The only way to turn off the charger is to unplug it, so use an easily accessible AC power socket. - Page 7 Take off the cover by lifting it from the side of the phone, as shown opposite. Then twist it to remove it. Make sure you handle the product with care when the front is removed, in order not to damage the keys which are then unprotected.
-
Page 8: Switch On/Off And Pin Code
Switch on/off and PIN code To swith on the phone, press and hold the Depending on your subscription, you might then be prompted to enter the PIN code, which is the 4 to 8-digit secret code of your SIM card to protect it from abusive use. -
Page 9: Symbols
Symbols Alarm clock activated. Silent - Your phone will not ring when receiving a call. Vibra - Your phone will vibrate when receiving a call. SMS message - You have received a new message. SMS full - Memory for messages is full. -
Page 10: Emergency Call
To answer the call, press To reject a call, press you have activated “Call forward” (see page 11), or if you haven’t activated this option, the caller hears a busy tone. The phone will not ring if the ringer is deactivated (page 9) or set to Silence via a hotkey (page 9). -
Page 11: Hotkeys
Hotkeys Instead of entering the various menus and browsing the lists, you can directly access a specific function thanks to a Hotkey. Making a long press on this key will automatically activate this function. The following hotkeys are pre-defined: Depending on your subscription and in addition to the keys listed above, keys Settings Introduction Settings... -
Page 12: Display
personal computer, check on your operator’s Internet site the availability, terms and condition of this service and follow its instructions to download the selected ringer tone via SMS. You can then store it as Own melody. Key tones To activate/deactivate the key tones. Even if Key Tones are set Off, DTMF are Key tones played during calls (see page 19). -
Page 13: Time And Date
Time and date Set date Set the date by pressing the alphanumeric keys (you can also set the date by Set date < moving Set time Set the time by pressing the appropriate numeric keys (moving Set time or decreases the time minute by minute). Register again When travelling abroad, your phone will register to the network with the strongest reception... -
Page 14: Names, Calls And Messages
Names, calls and messages Introduction The SIM card of your mobile GSM phone features a phonebook called Names names and numbers of your correspondents. The number of names your phonebook can store depends on the card capacity. The SIM card capacity depends on the type of card you have. - Page 15 Press the key to switch to basic mode, to numeric mode, or to punctuation mode ENTER TEXT: Eng While in any text mode, press the ENTER TEXT: Eng ® Text Input ® Text Input is an intelligent editing mode for SMS, including a comprehensive word database.
-
Page 16: Names
Example: to enter the word "home": 4 6 6 3 Press displays the first word of a list: Good. Press Press Basic Text Entry Each key allows you to obtain several characters. Quickly press the same key several times to reach the desired character. Example: to enter "my hat!" To obtain Press once... -
Page 17: Messages
"emotion icon". The receiver must have a Philips mobile phone that supports this feature to see the icon, or it will be replaced by its equivalent translation code at the end of the message received. - Page 18 Once you read a message, press message. Clear SMS The whole SMS list can be cleared at once: press Reset Reset and press Deleting your SMS list is useful to free memory space in order to store new messages. SMS settings This menu allows you to customise your SMS via the options described below.
-
Page 19: Call List
District code recognised in the Topics list with a Call list Call list missed and dialled (your Call list Call list Press then select Call list number, call status of any selected call and to know if it was sent or received. Press for access to a carousel which allows you to number or... -
Page 20: Calculator
Calculator This menu provides the following functions: Addition Calculator Subtraction Multiplication Division Equals The figures are entered using the keypad. Calculator accuracy is to 2 decimal places and is rounded up to the higher decimal figure. Press numbers. Make a long press on Alarm clock This menu allows you to set the alarm clock: Alarm clock... -
Page 21: Operator Services
To set or change the rate per unit. Enter the currency used (three characters max.) then enter the cost per unit. Charge rate Last call information To display the duration and/or cost of your last call (subscription dependent). Last call info Operator services Touchtones (DTMF) Your phone keys always transmit DTMF tones (Dual Tone Multiple Frequency) -
Page 22: Precautions
Precautions Your cellular mobile phone is your responsibility. To avoid damage to yourself, to others or to the phone itself, read and follow all the safety instructions and make them known to anyone borrowing your phone. Furthermore to prevent unauthorised use of your phone: •... - Page 23 • If you are a user of a pacemaker or hearing aid, or expect to use your cellular phone in the immediate vicinity of someone who does, then take the precautionary steps described below. - Consult your physician and pacemaker or hearing aid manufacturer to learn whether your particular device is susceptible to cellular phone interference.
- Page 24 Do not use your phone with a damaged antenna. If you touch a damaged antenna, you may suffer a minor skin burn. Have a damaged antenna replaced immediately by a qualified technician. Make sure it is replaced with a genuine Philips replacement part.
- Page 25 Remember to observe the local regulations regarding the disposal of your packaging materials, exhausted batteries and old phone and please promote their recycling. Philips has marked the battery and packaging with standard symbols designed to promote the recycling and appropriate disposal of your eventual waste.
-
Page 26: Troubleshooting
Troubleshooting PROBLEM The phone does Remove and reinstall the battery (see page 3). Then charge the not switch on phone until the battery icon has stopped flashing. Finally, unplug from the charger and try to switch the mobile on. The display shows Somebody tried to use your phone but didn’t know the PIN code BLOCKED when... - Page 27 You are not sure To receive all calls, make sure that none of the features that you are "Conditional call forward" or "unconditional call forward" is receiving calls activated (see page 11). This network and subscription dependent properly feature may display one of the following icons: Also note that backlight and vibra alerts will automatically be deactivated when the phone temperature reaches 60°C.
-
Page 28: Glossary
Glossary DTMF Dual Tone Multi Frequency. The tones are transmitted by the phone to the network. Used to interrogate answering machines, transmit codes, etc. Global System for Mobile communications. Type of network used by your Network phone. Home The network to which you subscribe to. network Home A particular area within your home network. -
Page 29: Philips Authentic Accessories
• Expandable to accommodate any battery size. To maximise the performance of your Philips phone and to not void the warranty, always purchase Philips Authentic Accessories that are specially designed for use with your phone. Philips Consumer Communications cannot be held liable for any damage due to use with non authorised accessories. - Page 30 BABT, Claremont House, 34 Molesey Road, Walton-on-Thames, KT12 4RQ, UK Identification mark: 0168 The technical documentation relevant to the above equipment will be held at: Philips France, Mobile Telephony Business Creation Team Route d’Angers 72081 Le Mans cedex 9 FRANCE...
