30" (76.2 CM) AND 36" (91.4 CM)
COMMERCIAL STYLE
WALL-MOUNT CANOPY RANGE HOOD
Installation Instructions and Use & Care Guide
For questions about features, operation/performance, parts, accessories or service, call: 1-800-422-1230
or visit our website at www.kitchenaid.com
In Canada, for assistance, installation and service, call: 1-800-807-6777
or visit our website at www.kitchenaid.ca
HOTTE D'EXTRACTION À MONTAGE MURAL
DE STYLE COMMERCIAL DE
30" (76,2 CM) ET 36" (91,4 CM)
Instructions d'installation et Guide d'utilisation et d'entretien
Au Canada, pour assistance, installation ou service composez le 1-800-807-6777
ou visitez notre site web à www.kitchenaid.ca
Table of Contents/Table des matières............................................................................. 2
IMPORTANT: READ AND SAVE THESE INSTRUCTIONS.
FOR RESIDENTIAL USE ONLY.
IMPORTANT : LIRE ET CONSERVER CES INSTRUCTIONS.
POUR UTILISATION RÉSIDENTIELLE UNIQUEMENT.
LI3Y4B/W11374534A
Advertisement
Table of Contents
Related Manuals for KitchenAid KVUC606JSS0
Summary of Contents for KitchenAid KVUC606JSS0
- Page 1 30" (76,2 CM) ET 36" (91,4 CM) Instructions d’installation et Guide d’utilisation et d’entretien Au Canada, pour assistance, installation ou service composez le 1-800-807-6777 ou visitez notre site web à www.kitchenaid.ca Table of Contents/Table des matières................2 IMPORTANT: READ AND SAVE THESE INSTRUCTIONS.
-
Page 2: Table Of Contents
TABLE OF CONTENTS TABLE DES MATIÈRES RANGE HOOD SAFETY ..............2 SÉCURITÉ DE LA HOTTE DE CUISINIÈRE .......15 INSTALLATION REQUIREMENTS ..........4 EXIGENCES D'INSTALLATION ...........17 Tools and Parts ................4 Outils et pièces................17 Location Requirements..............4 Exigences d’emplacement............17 Exigences concernant l’évacuation ...........18 Venting Requirements..............5 Spécifications électriques ............20 Electrical Requirements ...............6 INSTRUCTIONS D'INSTALLATION..........20... - Page 3 IMPORTANT SAFETY INSTRUCTIONS WARNING: TO REDUCE THE RISK OF A RANGE TOP WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC GREASE FIRE: SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: Never leave surface units unattended at high settings. Boilovers cause smoking and greasy spillovers that may Use this unit only in the manner intended by the ignite.
-
Page 4: Installation Requirements
INSTALLATION REQUIREMENTS Tools and Parts Location Requirements Gather the required tools and parts before starting installation. IMPORTANT: Observe all governing codes and ordinances. Read and follow the instructions provided with any tools listed Have a qualified technician install the range hood. It is the here. -
Page 5: Venting Requirements
Back View Venting Requirements 30" (76.2 cm) models: 12¼" (31.1 cm) Vent system must terminate to the outdoors. 36" (91.4 cm) models: 15" (38.1 cm) Do not terminate the vent system in an attic or other enclosed area. 7" (17.8 cm): 30" (76.2 cm) models Do not use a 4"... -
Page 6: Electrical Requirements
Rear discharge Example vent system This range hood can be vented directly out the back using the 3¼" x 10" (8.3 cm x 25.4 cm) rectangular damper (supplied) along ¹⁄₄ " x 10" (8.3 x 25.4 cm) with a 3¼" x 10" (8.3 cm x 25.4 cm) rectangular vent system (not elbow supplied). -
Page 7: Installation Instructions
INSTALLATION INSTRUCTIONS Prepare Location It is recommended that the vent system be installed before Determine Wiring Hole Location hood is installed. If you are installing a full width duct cover, follow the Cut only one 1¹⁄₄" (3.2 cm) diameter wiring access hole. See instructions included with that product. - Page 8 4. Repeat steps 1-3 for the underside of the top of the cabinet. For Wall Installations: 1. Determine and mark the centerline on the wall where the canopy hood will be installed. 2. Select a mounting height between a minimum of 24"...
-
Page 9: Install Range Hood
NOTE: If the wall cap is directly behind the 3¼" x 10" Complete Preparation (8.3 x 25.4 cm) rectangular vent connector, check that the damper and the wall cap do not interfere with each other. 1. Determine the required height for the home power supply Remove the damper from the 3¼"... -
Page 10: Install Vent Covers (Optional)
3. Use UL listed wire connectors and connect black wires (B) 5. Install terminal box cover. together. 6. Check that all light bulbs are secure in their sockets. 7. Reconnect power. WARNING Install Vent Covers (Optional) If you are installing an optional full width duct cover, follow the instructions included with that product. -
Page 11: Range Hood Care
RANGE HOOD CARE Cleaning IMPORTANT: Clean the hood and grease filters frequently Replacing a LED Lamp according to the following instructions. Replace grease filters before operating hood. Turn off the range hood and allow the LED lamp to cool. To Exterior Surfaces: avoid damage or decreasing the life of the new bulb, do not touch bulb with bare fingers. -
Page 12: Wiring Diagram
WIRING DIAGRAM Junction Box GND L N SE11RB Motor Resistance (Ohms) Blue - Red Blue - Gray 14.3 Blue - Black 9.8 (max) 21.6 (min) Blue - White Fan Speed Light Room Temp. 41˚F (23˚C) Motor Characteristics Power Supply 120 VAC Speed 3 Frequency 60 HZ... -
Page 13: Assistance Or Service
To locate the KitchenAid designated service company in your area, you can also look in your telephone directory Yellow Pages. For further assistance If you need further assistance, you can write to KitchenAid with any questions or concerns at: KitchenAid Brand Home Appliances Customer eXperience Center... - Page 15 06/19 Printed in Mexico /™ ©2019 KitchenAid. Used under license in Canada. All rights reserved. ® LI3Y4B/W11374534 Imprimé au Mexique Utilisé sous licence au Canada. Tous droits réservés.
