English Contents IMPORTANT SAFETY INSTRUCTIONS______________________ General description (Fig. 1)__________________________________ Introduction_________________________________________________ The display__________________________________________________ Charging_____________________________________________________ Using the product___________________________________________ Shaving______________________________________________________ Using the click-on attachments____________________________ Cleaning and maintenance_________________________________ Storage______________________________________________________ Replacement________________________________________________ Accessories__________________________________________________ Assistance___________________________________________________ Disposal_____________________________________________________ Full Two-Year Warranty_____________________________________ 45-DAY MONEY-BACK GUARANTEE_______________________ IMPORTANT SAFETY INSTRUCTIONS When using an electric product, basic precautions should always be followed, including the following: Read all instructions before using this product.
Page 7
- Use this product for its intended household use as described in this manual. Do not use attachments or cleaning cartridges not recommended by Philips North America LLC. - Never operate this product if it has a damaged power cord, if...
English - Always attach power cord to product first, then to power outlet. To disconnect, set all controls to 'off' position. Then remove power cord from power outlet. - Plug power cord directly into power outlet. Do not use an extension cord.
11 Power cord 12 Small plug Introduction Congratulations on your purchase and welcome to Philips Norelco! To fully benefit from the support that Philips Norelco offers, register your product at www.philips.com/register. The display Battery charge indicator Quick charge: When the shaver does not contain enough energy for one shave, the battery charge indicator flashes quickly.
Page 10
English Cleaning reminder Clean the shaver after every use for optimal performance (see 'Cleaning and maintenance'). When you turn off the shaver, the cleaning reminder flashes to remind you to clean the shaver. Travel lock When you are going to travel, you can lock the shaver to prevent it from accidentally turning Activating the travel lock 1 Press the on/off button for 3 seconds to...
English Replacement reminder For maximum shaving performance, replace the shaving heads every year. The shaver is equipped with a replacement reminder which reminds you to replace the shaving heads. The replacement reminder lights up continuously. Note: After replacing the shaving heads, you need to reset the replacement reminder by pressing the on/off button for 7 seconds.
- 21 Day Trial and Conversion Process. It is a fact that your skin and beard need time to adjust to a new grooming system. - Use your new shaver exclusively for 3 weeks to fully enjoy the closeness of a Philips Norelco shave.
Philips Norelco shaving system. - If you are still not convinced after 21 days, Philips Norelco will refund you the full purchase price as long as the request is received within 45 days of purchase.
Page 14
English - For the best results on skin comfort, pre- trim your beard if you have not shaved for 3 days or longer. Dry shaving 1 Turn on the shaver. 2 Move the shaving heads over your skin in circular movements to catch all hairs growing in different directions.
English 3 Rinse the shaving unit with warm water to ensure that the shaving unit glides smoothly over your skin. 4 Switch on the shaver. 5 Move the shaving heads over your skin in circular movements to catch all hairs growing in different directions.
English 3 Insert the lug of the attachment into the slot in the top of the shaver. Then press down the attachment to attach it to the shaver (‘click’). Using the trimmer attachment You can use the precision trimmer to groom your beard, sideburns and mustache.
Page 17
English Do not touch shaving heads with hard objects as this may dent or damage the precision-made slotted shaving head. Do not use abrasives, scourers or aggressive liquids such as gasoline or acetone to clean the shaver. Cleaning the shaver Clean the shaver after every use for optimal performance (see 'Cleaning and maintenance').
Page 18
English 4 Rinse the hair chamber with warm water. 5 Rinse the shaving head holder with warm water. 6 Carefully shake off excess water and let the shaving head holder air-dry completely. Note: Never dry the shaving unit with a towel or tissue, as this may damage the shaving heads.
Page 19
English 3 Pull the shaving head holder off the bottom part of the shaving unit. 4 Turn the retaining rings counterclockwise and remove them. 5 Remove the shaving heads from the shaving head holder. Each shaving head consists of a cutter and guard. Note: Do not clean more than one cutter and guard at a time, since they are all matching sets.
Page 20
English 8 Place the shaving heads in the shaving head holder. Note: Make sure that the projections of the shaving heads fit exactly into the recesses of the shaving head holder. 9 Place the retaining rings back onto the shaving head holder and turn them clockwise ('click').
Page 21
English Note: Hold the shaving head holder in your hand when you reinsert the shaving heads and reattach the retaining rings. Do not place the shaving head holder on a surface, as this may cause damage to the shaving heads. 10 Reinsert the hinge of the shaving head holder into the slot of the shaving unit.
English For optimal performance, lubricate the teeth of the attachment with a drop of sewing machine oil (not included) every six months. Storage Storage Put the protective cap on the shaver to protect the heads. Note: Always let the shaver air dry before you put the protective cap on it.
See chapter "Thorough Cleaning" for instructions on how to remove the retaining rings and shaving heads. Always replace the shaving heads with original Philips Norelco shaving heads only (see 'Accessories'). Replacement reminder The replacement reminder indicates that the shaving heads need to be replaced.The shaving unit symbol lights up when you switch the shaver off.
Full Two-Year Warranty Philips North America LLC warrants this new product (except shaving heads) against defects in materials or workmanship for a period of two years from the date of purchase,...
Page 25
Damage occurring during shipment is not covered by this warranty. NOTE: No other warranty, written or oral, is authorized by Philips Personal Health, a division of Philips North America LLC. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
We cannot be responsible for lost mail. The product must be postmarked no later than 45 days after the date of purchase. Philips reserves the right to verify the purchase price of the product and limit refunds not to exceed suggested retail price.
Español Contenido INSTRUCCIONES IMPORTANTES DE SEGURIDAD_________ Descripción general (Fig. 1)__________________________________ Introducción_________________________________________________ La pantalla___________________________________________________ Carga________________________________________________________ Uso del producto____________________________________________ Afeitado_____________________________________________________ Uso de los accesorios de ajuste de clic.____________________ Limpieza y mantenimiento_________________________________ Almacenamiento____________________________________________ Sustitución___________________________________________________ Accesorios___________________________________________________ Asistencia____________________________________________________ Desecho_____________________________________________________ Garantía Total de Dos Años________________________________ GARANTÍA DE DEVOLUCIÓN DE SU DINERO POR 45 DÍAS INSTRUCCIONES IMPORTANTES DE...
Page 28
- Use este producto para su uso previsto en el hogar, según se describe en este manual. No use accesorios o los cartuchos de limpieza que no estén recomendados por Philips North America LLC.
Page 29
Español - Nunca utilice este producto si el cable o el enchufe de carga están dañados, si no funciona correctamente, si se cayó, si está dañado o si se sumergió en agua mientras estaba conectado a la alimentación eléctrica. Para solicitar asistencia, comuníquese al 1-800-243-3050.
8 Recordatorio de reemplazo 9 Recordatorio de limpieza 10 Cortadora de precisión 11 Cable de alimentación 12 Conector pequeño Introducción ¡Felicitaciones por su compra y bienvenido a Philips Norelco! Para obtener el máximo beneficio del soporte que ofrece Philips Norelco, registre el producto en www.philips.com/register.
Español La pantalla Carga Carga rápida: Cuando la afeitadora no tiene suficiente energía para un afeitado, el indicador de carga de la batería destella rápidamente. Cuando el indicador de carga de la batería comienza a destellar lentamente, la afeitadora tiene suficiente energía para un afeitado.
Page 32
Español Activación del sistema de bloqueo 1 Pulse el botón de encendido/apagado durante 3 segundos para usar el modo de bloqueo de viaje. 3 sec. - Cuando activa el bloqueo de viaje el símbolo de bloqueo de viaje se ilumina continuamente.
Español de reemplazo presionando el botón encendido/apagado durante 7 segundos. Carga Cargue la afeitadora antes de usarla por primera vez y cuando la pantalla indique que la batería está casi agotada. La carga toma, aproximadamente, 1 hora. Nota: No puede usar la afeitadora mientras se carga.
- Prueba de 21 días y proceso de adaptación. Es un hecho que la piel y la barba tardan algún tiempo en acostumbrarse al nuevo sistema de arreglo personal. - Utilice su nueva afeitadora únicamente 3 semanas para disfrutar completamente de un afeitado Philips Norelco al ras.
- Sea perseverante. Si alterna entre métodos de afeitado durante el período de adaptación, será más difícil acostumbrarse al sistema de afeitado de Philips Norelco. - Si después de 21 días todavía no está satisfecho con los resultados, Philips Norelco le reembolsará el precio total de la compra, siempre que la solicitud de reembolso se reciba dentro de los 45 días...
Page 36
Español de seguridad, no es posible usar la afeitadora mientras está conectada al enchufe de pared para cargarse. Para obtener los mejores resultados de confort sobre la piel, recorte su barba si no se ha afeitado durante 3 días o más. Afeitado seco 1 Encienda la afeitadora.
Page 37
Español 2 Aplique espuma o gel de afeitar sobre la piel. 3 Enjuague la unidad de afeitado con agua tibia para asegurar que se deslice suavemente sobre su piel. 4 Encienda la afeitadora. 5 Mueva los cabezales de afeitado sobre la piel con movimientos circulares para llegar a todos los vellos en las diferentes direcciones de crecimiento.
Español Uso de los accesorios de ajuste de clic. Quitar y poner los accesorios de ajuste de clic 1 Asegúrese de que la afeitadora esté apagada. 2 Extraiga el accesorio directo de la afeitadora. Nota: No gire el accesorio mientras lo extrae de la afeitadora.
Español 3 Sostenga la cortadora perpendicular a la piel y muévala hacia abajo ejerciendo una presión suave. 4 Apague y limpie la cortadora después de cada uso. Limpieza y mantenimiento Una limpieza frecuente garantiza los mejores resultados de afeitado. Nunca limpie, retire ni reemplace la unidad de afeitado cuando la afeitadora esté...
Page 40
Español afeitadora quede protegida contra el daño del agua. Precaución: Revise siempre si el agua no está muy caliente, para evitar quemarse las manos. 1 Encienda la afeitadora. 2 Enjuague la unidad de afeitado con agua caliente. 3 Apague la afeitadora. Presione el botón de liberación para abrir la unidad de afeitado.
Page 41
Español desechable, ya que esto puede dañar los cabezales de afeitado. 1 Cierre el sostenedor del cabezal ("clic") Método de limpieza a fondo Nota: Le aconsejamos que limpie los cabezales de afeitado a fondo una vez al mes o cuando la afeitadora ya no afeite tan bien como antes.
Page 42
Español 5 Quite los cabezales de afeitado del soporte del cabezal de afeitado. Cada cabezal de afeitado consiste de un cortador y un protector. Nota: No limpie más de un cortador y protector a la vez, ya que todos son pares. Si accidentalmente coloca una cuchilla en el protector de afeitado equivocado, tardará...
Page 43
Español 9 Coloque los anillos de retención de nuevo en el cabezal de afeitado y gírelos hacia la derecha ("clic"). - Cada anillo de retención tiene dos ranuras y dos salientes que ajustan perfecto en los salientes y ranuras del soporte del cabezal de afeitado.
Español Limpieza de la cuchilla de precisión Precaución: Nunca seque el accesorio de la cortadora con una toalla o paño, ya que esto puede dañar el dentado. Limpieza del accesorio de la cortadora Limpie el accesorio de la cortadora después de cada uso.
Consulte el capítulo "Limpieza a fondo" para ver las instrucciones sobre cómo remover los anillos de retención y los cabezales de afeitado. Siempre reemplace los cabezales de afeitado con cabezales originales de Philips Norelco solamente (ver 'Accesorios'). Recordatorio de reemplazo...
Están disponibles los siguientes accesorios y piezas sueltas: - Cabezales de afeitado Philips Norelco SH50. Asistencia Para asistencia, visite nuestro sitio web: www.philips.com/support o llame al número gratuito 1-800-243-3050.
Garantía Total de Dos Años Philips North America LLC garantiza este producto nuevo (excepto los cabezales de afeitado) contra defectos en los materiales o en la mano de obra por un período de dos años desde la fecha de compra y acepta...
Page 48
Cualquier daño que ocurra durante el envío no será cubierto por esta garantía. NOTA: Philips Personal Health, una división de Philips North America LLC no extienden ninguna otra garantía, escrita ni oral. Esta garantía le proporciona derechos legales específicos;...
El paquete del producto debe contar con matasellos que no supere los 45 días a partir de la fecha de compra. Philips se reserva el derecho a verificar el precio de compra del producto y limita los reembolsos al precio de venta minorista sugerido.
Page 54
P.O. Box 10313, Stamford, CT 06904 This symbol on the product’s nameplate means it is listed by Underwriters’ Laboratories, Inc. Norelco and Tripleheader are registered trademarks of Philips North America LLC. PHILIPS and Philips shield are registered trademarks of Koninklijke Philips N.V.
