d) Do a check of all nuts and screws.
e) Make sure that the electrical wires are not damaged.
f) Apply oil to the air filter.
g) Fill the air filter holder with 100ml oil.
To fill fuel
CAUTION:
octane number less than 90 RON (87 AKI).
This can cause damage to the product.
1. Stop the engine and let the product become cool.
2. Put the product in an area with good airflow.
3. Fill the fuel tank.
CAUTION:
much fuel in the fuel tank. The fuel expands
when it becomes hot.
4. Tighten the fuel tank cap carefully to prevent the risk
of fire.
5. Clean the product and the area around the product
from fuel spillage.
To start the product
WARNING
animal is in the safety zone of 20 m when the
product starts.
1. Open the fuel tap. (Fig. 48)
2. Move the choke control to the choke position. (Fig.
49)
3. Put the gear lever in the neutral gear position. (Fig.
50)
4. Apply full throttle with the throttle control. (Fig. 51)
5. Set the ON/OFF switch to ON. (Fig. 52)
6. Hold the bumper of the product, pull out the rope
slowly with your right hand until you feel some
resistance. pull the rope quickly and with force.
keep doing it until you hear the engine start.
Note that do not twist the starter rope around your
handle.
7. When the product starts, set the choke control to th
run position. (Fig. 53)
To operate the product forward
1. Set the speed lever to high speed. (Fig. 54)
2. Use the gear lever to select drive speed. Position 1 i
slow speed and position 2 is fast speed. (Fig. 55)
3. Push down the throttle lock on the handle.
4. Push the clutch handle (B) in the direction of the
handle to make the tine blades rotate. (Fig. 56)
Do not use gasoline with an
Make sure that there is not too
:
Make sure that no person or
5. Release the clutch handle (A) to make the tine
blades stop. (Fig.57)
To operate the product rearward
WARNING:
rearward, you must release the clutch lever to
prevent injury.
1. Make sure that no obstacles are behind the product.
2. Release the clutch lever.
3. Decrease the engine speed.
4. Set the speed lever to low speed.(Fig. 58)
5. Put the gear lever in the "N" gear position. (Fig. 59)
6. Push the reverse control against the handle. (Fig. 60)
7. Push down the the clutch handle(B) in the direction of
the handle to make the tine blades rotate. (Fig. 61)
8. Release the clutch handle (A) (Fig. 61) and reverse
handle to make the tine blades stop.
To stop the product
1. Set the throttle control to the MIN. position. (Fig. 62)
2. Set the ON/OFF switch to OFF. (Fig. 63)
3. Close the fuel tap. (Fig. 64)
To move the product with the wheel kit
1. Stop the engine. Refer to To stop the product on
page 12.
2. Replace the tine blades for the wheels. (Fig. 65)
3. Lift the drag bar from the ground with the handlebar.
(Fig. 66)
To use the PTO of the product
CAUTION: Please put the speed lever to
High speed when tilling and using water
pumps. Put the speed lever to low speed
when using the sprayer, ditcher and rear
cultivator.
1. Set the speed lever to "L" speed(Fig. 58) for ditcher,
rear cultivator and sprayer. Pull to "H" speed(Fig. 54)
e
for water pumps.
2. Put the PTO switch to ON and OFF to connect or
disconnect the accessories.(Fig. 69)
3. Operate the accessories following Fig. 56 steps.
Pull the clutch handle down(B) to operate the
s
accessories working, release the clutch handle(A)
to stop working.
WARNING:
is needed when using accessories with PTO.
It is designed as always-open clutch for safety
concern.
Before you move the product
Constant clutch engagement
