  • Page 1 EN User Manual | Cooker LKR54000NW LKR54000NX...

  • Page 2: Table Of Contents

    Welcome to Electrolux! Thank you for choosing our appliance. Get usage advice, brochures, trouble shooter, service and repair information: www.electrolux.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................5 3. INSTALLATION....................7 4. PRODUCT DESCRIPTION................10 5.
  • Page 3 be kept away from the appliance unless continuously supervised. • Children should be supervised to ensure that they do not play with the appliance. • Keep all packaging away from children and dispose of it appropriately. • WARNING: The appliance and its accessible parts become hot during use.
  • Page 4 • Never use water to extinguish the cooking fire. Switch off the appliance and cover flames with e.g. a fire blanket or lid. • CAUTION: The cooking process has to be supervised. A short term cooking process has to be supervised continuously.

  • Page 5: Safety Instructions

    • To remove the shelf supports first pull the front of the shelf support and then the rear end away from the side walls. Install the shelf supports in the opposite sequence. • WARNING: Use only hob guards designed by the manufacturer of the cooking appliance or indicated by the manufacturer of the appliance in the instructions for use as suitable or hob guards incorporated in the appliance.
  • Page 6 the appliance from the mains at all poles. • Open the appliance door carefully. The The isolation device must have a contact use of ingredients with alcohol can cause opening width of minimum 3 mm. a mixture of alcohol and air. •...

  • Page 7: Installation

    • Replace immediately the door glass intended to be used in other applications panels when they are damaged. Contact and are not suitable for household room the Authorised Service Centre. illumination. • Fat and food remaining in the appliance • This product contains a light source of can cause fire.
  • Page 8 3.2 Technical data Voltage 230 V Frequency 50 - 60 Hz Appliance class Dimension Height 858 - 923 6. Push the plinth in to the required height Width setting: 923, 898 or 858 mm. 7. Screw in screws C and D. Depth 3.4 Levelling of the appliance 3.3 Changing the height and the...
  • Page 9 2. You can find the hole on the left side at the back of the appliance. Lift the front of the appliance and put it in the middle of the space between the cupboards. If the space between the bench cupboards is larger than the width of the appliance, you must adjust the side measurement to centre the appliance.

  • Page 10: Product Description

    4. PRODUCT DESCRIPTION 4.1 General overview Knobs for the hob Temperature indicator / symbol Knob for the temperature Knob for the oven functions Hob lamp / symbol / indicator Heating element Lamp Shelf support, removable Shelf positions 4.2 Cooking surface layout Cooking zone 1200 W Steam outlet - number and position depend on the model...

  • Page 11: Before First Use

    5. BEFORE FIRST USE 1. Pull and hold the door lock. WARNING! Refer to Safety chapters. 5.1 Initial Cleaning Remove all accessories and removable shelf supports from the oven. Refer to "Care and cleaning" chapter. Clean the oven and the accessories before the first use.

  • Page 12: Hob - Hints And Tips

    6.2 Heat setting The zone operates at its maximum power Symbols Function level once you set the heat level to 8 or Off position 6.4 Residual heat indicator Keep warm WARNING! 1 - 9 Heat settings As long as the indicator is on, there is a risk of burns from residual heat.

  • Page 13: Hob - Care And Cleaning

    7.2 Examples of cooking To save energy and ensure that the hob applications operates properly the cookware bottom must have a suitable minimum diameter (at least the same as the zone diameter). The data in the table is for guidance only. Heat setting Use to: Time...

  • Page 14: Oven - Daily Use

    8.2 Cleaning the hob stains, shiny metallic discoloration. Clean the hob with a moist cloth and a non- • Remove immediately: melted plastic, abrasive detergent. After cleaning, wipe plastic foil, sugar and food with sugar, the hob dry with a soft cloth. otherwise, the dirt can cause damage to •...

  • Page 15: Oven - Using The Accessories

    Symbol Oven functions Application Moist Baking This function was used to comply with the Energy Efficiency Class and Ecodesign Regulations (according to EU 65/2014 and EU 66/2014). Tests according to: IEC/EN 60350-1. The oven door should be closed during cooking so that the func‐ tion is not interrupted and to ensure that the oven operates with the highest energy efficiency possible.

  • Page 16: Oven - Hints And Tips

    11. OVEN - HINTS AND TIPS You can extend the baking time by 10 – 15 WARNING! minutes if you bake cakes on more than one shelf position. Refer to Safety chapters. Cakes and pastries at different heights do not always brown equally.
  • Page 17 Food Quantity (g) Temperature Time (min) Shelf po‐ Accessories (°C) sition Yeast cake with ap‐ 2000 170 - 190 40 - 50 baking tray ples Drip pan cake 1500 160 - 170 baking tray 45 - 55 Chicken, whole 1350 200 - 220 60 - 70 wire shelf...
  • Page 18 11.7 Moist Baking Food Temper‐ Time (min) Shelf Accessories ature position (°C) Bread and pizza Buns 25 - 30 baking tray or grill- / roasting pan Bread rolls 40 - 45 baking tray or grill- / roasting pan Frozen pizza 350 g 25 - 35 wire shelf Cakes in baking tray...

  • Page 19: Oven - Care And Cleaning

    11.8 Fast Grilling Food Quantity (g) Temperature Time (min) Shelf po‐ Accessories (°C) sition 1000 15 + 15 wire shelf Beef steaks baking tray Half chicken 1200 30 + 30 wire shelf baking tray Pork roast cutlet 25 + 25 wire shelf baking tray Preheat the oven for 10 minutes.
  • Page 20 12.3 Removing the shelf supports To clean the oven, remove the shelf supports. CAUTION! Be careful when you remove the shelf supports. 1. Pull the front of the shelf support away from the side wall. 2. Carefully pull the heating element down. 2.
  • Page 21 12.6 Removing the drawer 1. Open the door until it is at an angle of approximately 30°. The door stands alone when slightly open. WARNING! Do not keep flammable items (such as cleaning materials, plastic bags, oven gloves, paper or cleaning sprays) in the drawer.

  • Page 22: Troubleshooting

    13. TROUBLESHOOTING WARNING! Refer to Safety chapters. 13.1 What to do if... Problem Possible cause Remedy You cannot activate the appliance. The appliance is not connected to Check if the appliance is correctly an electrical supply or it is connec‐ connected to the electrical supply.

  • Page 23: Energy Efficiency

    14. ENERGY EFFICIENCY 14.1 Product Information according to EU Ecodesign Regulations for hob Model identification LKR54000NW LKR54000NX Type of hob Hob inside Freestanding Cooker Number of cooking zones Heating technology Radiant Heater Diameter of circular Left rear 14.0 cm cooking zones (Ø) Right rear 18.0 cm...

  • Page 24: Environmental Concerns

    Heat source Electricity Volume 57 l Type of oven Oven inside Freestanding Cooker LKR54000NW 49.0 kg Mass LKR54000NX 50.0 kg IEC/EN 60350-1 - Household electric cooking appliances - Part 1: Ranges, ovens, steam ovens and grills - Meth‐ ods for measuring performance.
  • Page 28 867375005-B-352023...
