- Page 1 Owner ’s Manual REFRIGERATOR- FREEZER Please read carefully the manual instruction and safety caution before operating your refrigerator and retain it for future reference G*-S502G*** www.lg.com P/NO : MFL67856604...
-
Page 2: Table Of Contents
CONTENTS IMPORTANT SAFETY INFORMATION ....3 INSTALLATION ............11 INNER PARTS ............12 OPERATIONS ............13 Starting Before Setting The Temperature Door Alarm Self Test Lamp Auto Off Feature Controls For Refrigerator Compartment Fast Freezing Child Lock Controls For Freezer Compartment Home Bar Ice Making Fast Freezing Zone... -
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION WARNING Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer. Do not damage the refrigerant circuit. Do not use electrical appliances inside the food storage compartment of the appliance, unless they are of the type recommended by the manufacturer. - Page 4 IMPORTANT SAFETY INFORMATION BASIC SAFETY PRECAUTIONS This guide contains many important safety messages. Always read and obey all safety messages. This is the safety alert symbol. It alerts you to safety messages that inform you of hazard that can hurt you or others or cause damage to the product. All safety messages will be preceded by the safety alert symbol and the hazard signal word WARNING, or CAUTION.
- Page 5 IMPORTANT SAFETY INFORMATION 1. When connecting the power Unplug the power plug when cleaning, Do not extend or modify the length of the handling or replacing the interior lamp of the power plug. refrigerator. It causes electric shock or fire •...
- Page 6 IMPORTANT SAFETY INFORMATION 2. When using the refrigerator Do not cling to the door or the shelves of the Do not place the heavy object or the door or the Family Homebar or the cool dangerous object chamber. (container with liquid) on It may make the refrigerator the refrigerator.
- Page 7 IMPORTANT SAFETY INFORMATION 2. When using the refrigerator Install in places away from the fire such as Do not use drier to dry the inside, nor light a the place where candle to remove odor. flammable gas is It may cause explosion or fire.
- Page 8 IMPORTANT SAFETY INFORMATION 2. When using the refrigerator Do not allow any person except the qualified When any strange smell or smoke is engineer to disassemble, repair or alter the detected from the refrigerator, disconnect refrigerator. the power plug Service Down-block center immediately and It may cause injury,...
- Page 9 IMPORTANT SAFETY INFORMATION 2. When using the refrigerator Place all the components in the right places Do not remove the cover before connecting the power. on the back. Do not use an Adapter Never leave lit candles or incense on the on the back.
- Page 10 IMPORTANT SAFETY INFORMATION Do not use products such as grinding Do not put any living animal in the sponge, brush, iron, or even special refrigerator. products to clean stainless steel, soap It may cause the animal products such as alcohol, kerosene, died.
-
Page 11: Installation
THIS REFRIGERATOR IS MANUFACTURED WITH GREAT CARE, AND UTILIZES THE LATEST IN TECHNOLOGY. WE ARE CONFIDENT THAT YOU WILL BE FULLY SATISFIED WITH IT'S PERFORMANCE AND RELIABILITY. BEFORE YOU START YOUR REFRIGERATOR, PLEASE READ THIS BOOKLET CAREFULLY . IT PROVIDES EXACT INSTRUCTIONS FOR INSTALLATION, OPERATION AND MAINTENANCE, AND ALSO SUPPLIES SOOME USEFUL HINTS. -
Page 12: Inner Parts
INNER PARTS FREEZER COMPARTMENT Lamp Shelf Freezer Temperature Control Dial Twisting Ice Serve Freezer Door Rack Type Ice Making REFRIGERATOR COMPARTMENT Home Bar Fresh Room Drawer Lamp Can Server Refreshment Center Side Cooling Shelves Home Bar Rack Vegetable Drawer Refrigerator Door Rack Vegetable Partitioner Levelling Screw... -
Page 13: Operations
OPERATIONS STARTING When your refrigerator is first installed, allow it 2-3 hours to stabilize at normal operating temperatures prior to filling it with fresh or frozen foods. If operation is interrupted, wait 5 minutes before restarting. BEFORE SETTING THE TEMPERATURE The temperature of the refrigerator is kept constant regardless of changes in room temperature. -
Page 14: Fast Freezing
OPERATIONS FAST FREEZING The FAST FREEZING feature operates when the refrigerator first turn on. The compressor and circulating fan operate at maximum cooling capacity to quickly lower the refrigerator temperature. It shuts off automatically. If warm food is placed into the refrigerator, FAST FREEZING can be started with the button on the control panel. -
Page 15: Home Bar
OPERATIONS HOME BAR How to Use Home Bar Press the button on the left in the center of Home Bar until “Click” sounds. Home Bar became larger to store more contents. Press until Food can be stored systematically with many “Click”... -
Page 16: Ice Making
OPERATIONS ICE MAKING Twisting Ice Serve Typ To make ice cubes, fill the ice tray with water and insert in its position. To remove ice cubes, hold the lever of the tray and pull turn gently. Then, ice cubes drop in to the ice cube box. -
Page 17: Vegetable Drawer
OPERATIONS VEGETABLE DRAWER Inserted Vegetable Drawer must be placed at its position. If door is opened, it can’t fill the role of it. Vegetable Partitioner Fix the partitioner by inserting it at the rear side of vegetable box as shown in the figure. How to use Vegetable drawer can be used through the control of knob. -
Page 18: Suggestions On Food Storage
SUGGESTIONS ON FOOD STORAGE STORING FOOD Store fresh food in the refrigerator compartment. How food is frozen and thawed is an important factor in maintaining its freshness and flavor. Do not store food which goes bad easily at low temperatures, such as bananas, pineapples, and melons. -
Page 19: Cleaning
CLEANING It is important that your refrigerator be kept clean INiR PARTS - Wash compartment shelves, to prevent undesirable odors. Spilled food should door racks, storage trays and magnetic door be wipe up immediately, since it may acidify and seals etc. Use a lukewarm solution of mild stain plastic surfaces if allowed to settle. -
Page 20: General Information
GENERAL INFORMATION VACATION TIME IF YOU MOVE During average length vacations, you will probably Remove or securely fasten down all loose items find it best to leave the refrigerator in operation. inside the refrigerator. Place freezable items in freezer for longer life. To avoid damaging the leveling screw(s), turn them When you plan to be away for an extended period, all the way into the base. -
Page 21: Important Warnings
IMPORTANT WARNINGS DO NOT USE AN EXTENSION CORD ABOUT GROUNDING (EARTHING) If possible, connect the refrigerator to its own In the event of an electric short circuit, grounding individual electrical outlet to prevent it and other (earthing) reduces the risk of electric shock by appliances or household lights from causing an providing an escape wire for the electric current. -
Page 22: Before Calling For Service
BEFORE CALLING FOR SERVICE SERVICE CALLS CAN OFTEN BE AVOIDED! IF YOU FEEL YOUR REFRIGERATOR IS NOT OPERATING PROPERLY, CHECK THESE POSSIBLE CAUSES FIRST : PROBLEM POSSIBLE CAUSES REFRIGERATOR DOES Has a house fuse blown or circuit breaker tripped? NOT OPERATE Has the power cord plug been removed or loosened from the electrical wall outlet? Temperature control not set on proper position. -
Page 23: Earth/ Grounding Construction (Optional)
It is recommended to install the earth to prevent electric shock in case of electricity leakage. How to connect the earth wire: • Connect the earth wire's metal ring end to the earth screw on the back of the refrigerator. •... - Page 24 Percentage running time Quantity of ice produced per 24 hours run Refrigerant R600a, 66g Net weight 83 kg Rated gross volume 475 liters Rated shelf area 1.92 m Manufacturer (and/or trade mark) LG Electronics Inc. Country of origin Made in Indonesia...
