Sony HT-ST5000 Service Manual

Active speaker system
Hide thumbs Also See for HT-ST5000:
Table of Contents

Advertisement

Quick Links

SERVICE MANUAL
Ver. 1.0 2017.04
• All of the units included in the HT-ST5000
(SA-ST5000/SA-WST5000/Remote control)
are required to confi rming operation of SA-
ST5000. Check in advance that you have all
of the units.
Note:
Be sure to keep your PC used for service and
checking of this unit always updated with the
latest version of your anti-virus software.
In case a virus affected unit was found during
service, contact your Service Headquarters.
COMPONENT MODEL NAME
Bar Speaker (Active Speaker System)
Subwoofer (Active Subwoofer)
• Please refer to service manual separately issued for Subwoofer.
Amplifier section
Inputs
HDMI IN 1/2/3*
U.S. models:
ANALOG IN
POWER OUTPUT AND TOTAL HARMONIC
TV IN (OPT)
DISTORTION:
Outputs
(FTC)
HDMI OUT (TV (ARC))*
Front L + Front R:
With 6ohms loads, both channels
*HDMI IN 1/2/3 and HDMI OUT (TV (ARC))
driven, from 200 - 6,000Hz; rated
jacks support HDCP 2.2 protocol. HDCP
20W per channel minimum RMS
2.2 is newly enhanced copyright
power, with no more than 1% total
protection technology that is used to
harmonic distortion from 250mW to
protect content such as 4K movies.
rated output.
Front tweeter L + Front tweeter R:
HDMI Section
With 6ohms loads, both channels
Connector
driven, from 6,000 - 20,000Hz; rated
Type A (19pin)
20W per channel minimum RMS
USB section
power, with no more than 1% total
(USB) port:
harmonic distortion from 250mW to
Type A (For connecting USB memory)
rated output.
POWER OUTPUT (reference)
LAN section
Front L/Front R speaker blocks: 50W
LAN(100) terminal
(per channel at 6ohms, 1kHz)
100BASE-TX Terminal
Front tweeter L/Front tweeter R
Wireless LAN section
speaker blocks: 50 W (per channel at
6ohms, 10kHz)
Communication system
Center speaker block: 50 W (per
IEEE 802.11 a/b/g/n
channel at 6ohms, 1kHz)
Frequency band
Center tweeter speaker block: 50 W
2.4GHz, 5GHz
(per channel at 6ohms, 10kHz)
BLUETOOTH section
Top speaker block: 50 W (per channel
Communication system
at 6ohms, 1kHz)
BLUETOOTH Specification version 4.1
CND, AEP, UK models:
Output
POWER OUTPUT (rated)
BLUETOOTH Specification Power
Front L + Front R: 30W + 30W
Class1
(at 6ohms, 1kHz, 1% THD)
Maximum communication range
POWER OUTPUT (reference)
Line of sight approx. 30m
Front L/Front R speaker blocks: 50W
Maximum number of devices to be
(per channel at 6ohms, 1kHz)
registered
Front tweeter L/Front tweeter R
9 devices
speaker blocks: 50 W (per channel at
Frequency band
6ohms, 10kHz)
2.4 GHz band (2.4GHz - 2.4835GHz)
Center speaker block: 50 W (per
Modulation method
channel at 6ohms, 1kHz)
FHSS (Freq Hopping Spread Spectrum)
Center tweeter speaker block: 50 W
Compatible BLUETOOTH profiles
(per channel at 6ohms, 10kHz)
A2DP 1.2 (Advanced Audio Distribution
Top speaker block: 50 W (per channel
Profile)
at 6ohms, 1kHz)
AVRCP 1.5 (Audio Video Remote
Control Profile)
Supported Codecs
SBC
9-896-393-01
2017D33-1
Sony Video & Sound Products Inc.
©
2017.04
HT-ST5000
SA-ST5000
SA-WST5000
SPECIFICATIONS
Transmission range (A2DP)
20 Hz - 40,000 Hz (LDAC sampling
frequency 96kHz with 990 kbps
transmission)
20 Hz - 20,000 Hz (Sampling frequency
44.1kHz)
1)
The actual range will vary depending on
factors such as obstacles between
devices, magnetic fields around a
microwave oven, static electricity,
cordless phone use, reception
sensitivity, the operating system,
software applications, etc.
2)
BLUETOOTH standard profiles indicate
the purpose of BLUETOOTH
communication between devices.
3)
Codec: Audio signal compression and
conversion format
4)
Abbreviation for Subband Codec
5)
Abbreviation for Advanced Audio
Coding
Front L/Front R speaker block section
Speaker system
2-way coaxial speaker system,
Acoustic suspension
Speaker
Woofer: 65mm (2 5/8 in.) cone type,
Magnetic fluid speaker
Tweeter: 14mm (9/16 in.) soft dome
type
Center speaker block section
Speaker system
Center: 2-way coaxial speaker system,
Acoustic suspension
Satellite: Full range speaker system,
1)
Acoustic suspension
Speaker (5 speakers)
Center woofer: 65mm (2 5/8 in.) cone
type, Magnetic fluid speaker
Tweeter: 14mm (9/16 in.) soft dome
type
Satellite: 65mm (2 5/8 in.) cone type,
Magnetic fluid speaker
2)
Top speaker block section
Speaker system
Full range speaker system, Acoustic
suspension
3)
Speaker
4)
5)
, AAC
, LDAC
65mm (2 5/8 in.) cone type, Magnetic
fluid speaker
HT-ST5000
Canadian Model
General
Wireless transmitter section
Power requirements
120 V AC, 60 Hz (US, CND)
Communication system
220 V - 240 V AC, 50 Hz/60 Hz (AEP, UK)
Power consumption
Frequency band
On: 90W
For details about the power
consumption during standby mode,
Modulation method
see "Power Consumption by the
Setting Value for Each Standby
Mode"
What's in the Box
Dimensions* (approx.) (w/h/d)
• Bar Speaker (1)
1,180mm × 80mm × 142mm (46 1/2 in
• Grille frame (1)
× 3 1/4 in × 5 5/8 in) (without grille
• Subwoofer (1)
frame)
• Remote control (1)
1,180mm × 80mm × 145mm (46 1/2 in
• R03 (size AAA) battery (2)
× 3 1/4 in × 5 3/4 in) (with grille frame)
• HDMI cable (supports the specification
equal to Premium High Speed HDMI
*Not including projection portion
cable with Ethernet) (1) (US, CND)
Mass (approx.)
8.3kg (18 lb 4 4/5 oz) (without grille
• Optical digital cable (1) (AEP, UK)
• WALL MOUNT TEMPLATE (1)
frame)
8.8kg (19 lb 6 2/5 oz) (with grille
• Startup Guide
frame)
• Operating Instructions
Compatible iPod/iPhone models
Design and specifications are subject to
The compatible iPod/iPhone models are as
change without notice.
follows. Update your iPod/iPhone with the
latest software before using with the
system.
BLUETOOTH technology works with:
iPhone 7 Plus/iPhone 7/iPhone SE/iPhone
6s Plus/iPhone 6s/iPhone 6 Plus/
iPhone6/iPhone 5s/iPhone 5c/iPhone 5/
iPhone 4s
iPod touch (6th generation)/iPod touch
(5th generation)
SOUND BAR
ACTIVE SPEAKER SYSTEM
SA-ST5000
US Model
AEP Model
UK Model
Wireless Sound Specification version
3.0
5.2GHz (5.180GHz - 5.240GHz)
5.8GHz (5.736GHz - 5.814GHz)
DSSS
HT-ST5000
SA-ST5000
