Page 2
Hitachi Instruments (Dalian) Co., Ltd. 3. Hitachi Instruments (Dalian) Co., Ltd. assumes no liability for any direct, indirect, or consequential damages arising from use not described in this manual.
Be sure to read "IMPORTANT" and "SAFETY SUMMARY" at the beginning of this manual for ensuring safety in operation of the Primaide Analog Input Device Unit, and instruction manual of the Primaide Analog Input Device. If installation of this product is not yet completed, refer to Section 2.
Page 5
IMPORTANT PRECAUTION ON CE CONFORMITY MARKING In consideration of use in the European countries, this instrument bears the CE mark indicating the conformity to the requirements mentioned below. 1. ELECTROMAGNETIC COMPATIBILITY REQUIREMENT This instrument is designed to satisfy the European Norm EN61326-1 (2013) for the CE conformity marking through conformity to the EMC Directive 2014/30/EU.
WARRANTY ON PRODUCT The Primaide Analog Input Device Unit is warranted to be free from defects in material or workmanship under normal use within the product specifications indicated in this manual and under conditions given below. This warranty is void if the instrument is not used according to the instruction manual.
Page 7
Exclusions from Warranty Note that the following cases are excluded from the scope of this warranty. i.e., these cases are beyond the coverage of free- of-charge repair even during the warranty period indicated above (a) Failure due to operation at a place not meeting the installation requirements specified by the manufacturer.
parts, and failure of any part that have reached the end of its service life. (m) Failure due to a life-limited part that has exceeded the end of its useful lifetime. (n) Failure of the hardware, or damage to the system software, application software, data or hard disk due to computer virus infection.
For the customers to acquire in-depth understanding of the analytical instruments, technical seminars and customer training courses are available at the manufacturer or your site. For further information, contact your local Hitachi High-Tech Science Corporation sales representative. (The technical seminars and customer training courses are available on a chargeable basis.)
Page 10
Reagents, standard solutions and accuracy-control samples shall be handled, stored and discarded as instructed by the respective suppliers. Physiologically or biologically active samples are not applicable to this syringe because of possible infection with bacteria or viruses. IMPORTANT- 6...
• Operate the instrument according to the instructions given in this manual. • Installation at delivery should be referred to service personnel qualified by Hitachi High-Tech Science Corporation. The customer should not perform installation. • Be sure to observe the warnings indicated on the product and in the instruction manual.
Page 12
SAFETY SUMMARY General Safety Guidelines (Continued) In addition, the following signal word is used for ensuring proper use of the product. NOTE: Used to indicate an instruction for ensuring correct trouble-free use of the instrument and accurate measurement therewith. Precautions on Use •...
Page 13
• Do not perform any operation or action other than described in this manual. When in doubt, please contact your local Hitachi High-Tech Science Corporation sales representative or service office of Hitachi High-Tech Science Corporation sales representative •...
Page 14
Precautions on Installation, Maintenance and Relocation (Continued) • Do not perform any operation or action other than described in this manual. When in doubt, contact your local Hitachi High-Tech Science Corporation sales representative or service office of Hitachi High-Tech Science Corporation sales representative.
SAFETY SUMMARY Safety Instructions in This Manual Shown below are the safety instructions contained in this manual and their relevant sections in it. DANGER Indications The indication DANGER does not apply to this instrument. WARNING Indications The indication WARNING does not apply to this instrument. CAUTION Indications Fatigue due to Long Hours of Operation If you keep working with the display monitor and keyboard for...
Page 16
SAFETY SUMMARY NOTICE Accuracy/Precision of Measured Values Carry out control sample measurements to ensure that the performance of the instrument is normal. SAFETY - 6...
1. OUTLINE ......................... 1-1 Outline of Primaide AID .......... 1-1 2. INSTALLATION ....................... 2-1 Installation to Primaide 1000 Series Unit ....2-1 Combination with Primaide 1000 Series ....2-3 3. FUNCTIONS ......................3-1 Name and Function of Each Part ......3-1 Specifications ............
AIDs (2 ch). Upon combining AID with the Primaide 1000 series units, a detector of Primaide 1000 series can be used for Ch1 and a detector of other make for Ch2. Installable into an Primaide 1000 series unit.
1.1 Outline of Primaide AID Time: 0.011578 min - Signal intensity 0.0265 mV Fraction marker signal Fig. 1 Acquisition of Marker Signal from L-5200 PRIMAIDE SYSTEM MANAGER 1 - 2...
2. INSTALLATION 2.1 Installation to Primaide 1000 Series Unit AID is installable into the back of each unit of Primaide 1000 series (except for an organizer, autosampler and FL Detector). After attaching AID to the back of a unit, connect the e-Line connector (upper) that supplies 5 V for the unit and the e-Line connector of AID by using the attached e-Line cable.
Page 22
NOTE: 5 V power can not be supplied to a USB interface board from AID. Avoid connecting a USB interface board directly with AID via e-Line. (Connect so that 5 V power will be supplied to AID and USB interface board from the unit in which they are installed.) NOTE: The electronic components on the AID circuit board...
2.2 Combination with Primaide 1000 Series In order to perform data acquisition using AID for Primaide, at least two Primaide 1000 series units for mounting AID and a USB interface board are required. An example of connection of AID and an HPLC system is shown below.
Page 24
Since pump A cannot be used as a power supply unit of 5 V in a Low-pressure gradient system, three or more Primaide series units are required (so that the e-Line connector on 5 V supply side of pump A can be used for synchronization with pump B).
Page 25
(available at option) for fraction marker signal. : e-Line e-Line connector e - Line PM1410 コネクタ (ChromAssist Data Station/ Primaide System Manager) PM1210 e-Line connector SIGNAL e-Line connector MARKER(1) OUT L-5200 fraction START IN...
3. FUNCTIONS 3.1 Name and Function of Each Part Terminal block (AUX OUT) Terminal block (START IN) Terminal block (START OUT) Analog input connector Terminal block (BUSY OUT) HLG HLG ANALOG CH selector switch Fig. 3-1 Front View • Analog input connector : For acquisition of analog signals from the exterior.
3.2 Specifications 3.2 Specifications Power supply: 5 V (supplied from e-Line) Communication function: e-Line (equipped with two e-Line connectors) Analog signal input: One channel Input voltage: -0.1 to 1.1 V Input impedance: 10 M or higher Accuracy: 0.1% (from -10 mV to 1.0 V, after zero offset) Noise level: 1 ...
Page 29
(14) Input/output (e-Line common contacts): BUSY OUT (level), ERROR IN (level), ERROR OUT (level), START IN (level) (15) Terminal blocks: START IN (connected with e-Line contact) START OUT (connected with e-Line contact) BUSY OUT (connected with e-Line contact) AUX OUT (fraction marker signal) 3 - 3...
DATA BUFFER OVERFLOW Error in communication Check the connection with chromato-data station (CDS), and try reconnection with CDS. Primaide System Manager cannot 1. Failure in CH setting 1. Turn power off and correct the connect with AID. (other detector CH setting.
5. INDEX Analog signal ........................... 3-2 BUSY OUT ........................3-1, 3-3 CE conformity marking ..................IMPORTANT-1 Contact signal ......................APPENDIX-1 e-Line ....................... 2-1, APPENDIX-1 Fraction marker signal ...................... 1-1, 2-5 High-pressure gradient system ....................2-4 L-5200 ..........................1-2, 2-5 LED ............................3-1 Outline .............................
Page 34
Specifications .......................... 3-2 START IN ......................... 3-1, 3-3 START OUT ........................3-1, 3-3 Troubleshooting ........................4-1 USB interface board ........................ 2-3 INDEX - 2...
Their names and functions vary with the unit. A name that indicates the function is given at each connector. • Example of output contact signal EVENT of pump and column oven (Primaide 1310) • Example of input contact signal LAMP OFF IN of detector...
Page 36
Connector the main unit, and since the signals of each unit are connected in series via the e-Line cable, synchronism of the Primaide 1000 series system can be easily achieved. For obtaining synchronism with the D-2500 by way of contact signals, use the cables listed below for the connection.
Page 37
Fig. A-4. The rating of contacts used is 12 V, 0.1 A. Make sure the load connected does not exceed this rating. Other unit e-Line cable Primaide 1000 series unit A Primaide 1000 series unit B Fig. A-1 e-Line Cable Connection +5 V 320 ...
Page 38
+5 V 320 1 (H) Max. 10 mA 2 (L) 3 (G) Primaide 1000 series unit External unit Activated upon shorting contacts of external unit. Fig. A-3 Contact Signal Input Circuit 0.1 A max. 1 (H) 30 V max.
