- Page 1 Preface Introduction Installing the Subscriber Station RUGGEDCOM WIN5158 Technical Specifications Dimension Drawings Certification Installation Guide 01/2018 RC1143-EN-05...
- Page 2 Warranty Siemens warrants this product for a period of five (5) years from the date of purchase, conditional upon the return to factory for maintenance during the warranty term. This product contains no user-serviceable parts. Attempted service by unauthorized personnel shall render all warranties null and void.
-
Page 3: Table Of Contents
RUGGEDCOM WIN5158 Installation Guide Table of Contents Table of Contents Preface ......................Alerts ..............................v Related Documents ..........................vi Training .............................. vi Customer Support ..........................vi Chapter 1 Introduction ..................... 1.1 Feature Highlights ........................2 1.2 Description ........................... 2 Chapter 2 Installing the Subscriber Station ............... - Page 4 RUGGEDCOM WIN5158 Table of Contents Installation Guide Chapter 3 Technical Specifications .................. 3.1 Power Supply Requirements ......................27 3.2 Power Consumption ........................28 3.3 Radio and Modem Specifications ....................28 3.4 Operating Environment ....................... 28 3.5 Mechanical Specifications ......................29 3.6 IDU to ODU Cable Specifications ....................29 Chapter 4 Dimension Drawings ..................
-
Page 5: Preface
Preface Preface This guide describes the RUGGEDCOM WIN5158. It describes the major features of the subscriber station, installation, commissioning and important technical specifications. It is intended for use by subscriber station installers and operators, and assumes readers have a working knowledge of WiMAX technologies and procedures. -
Page 6: Related Documents
Siemens Sales representative. Customer Support Customer support is available 24 hours, 7 days a week for all Siemens customers. For technical support or general information, contact Siemens Customer Support through any of the following methods: Online Visit http://www.siemens.com/automation/support-request... -
Page 7: Introduction
Installation Guide Introduction Introduction The RUGGEDCOM WIN5158 subscriber station (also referred to as Customer Premises Equipment) is part of the RUGGEDCOM WIN family, a line of mobile WiMAX broadband wireless access systems based on the IEEE 802.16e mobile WiMAX standard. -
Page 8: Feature Highlights
The subscriber station supports both IP convergence sublayer for wireless Internet service providers or Ethernet Convergence Sublayer, ideal for mission critical private networks. Section 1.2 Description The RUGGEDCOM WIN5158 is available in one of two models: • AC Model The AC model receives power from a Siemens-approved PoE injector. • DC Model The DC model receives power directly from a Class 2 power supply. - Page 9 Introduction ANT 1 ANT 2 ETH/PWR RSSI RSSI W.LINK W.LINK Figure 1: RUGGEDCOM WIN5158 (AC Model) 1. ANT 1 Port 2. ETH/PWR Port 3. RSSI LEDs 4. W.LINK LED 5. PWR LED 6. ANT 2 Port 7. Chassis Ground 12VDC ANT 1 ANT 2 RSSI ETH/PWR RSSI W.LINK PWR W.LINK PWR...
- Page 10 Chapter 1 RUGGEDCOM WIN5158 Introduction Installation Guide State Description Green (Solid) Subscriber station is connected to the base station and receiving services. Green (Blinking) Link between the subscriber station and the base station is down. PWR LED Indicates when power is supplied to the subscriber station.
-
Page 11: Installing The Subscriber Station
WARNING! Safety hazard – risk of serious personal injury and/or damage to equipment. Installing the RUGGEDCOM WIN5158 can pose a serious safety hazard. Be sure to take precautions to avoid the following: • Exposure to high voltage lines during installation •... -
Page 12: General Procedure
Chapter 2 RUGGEDCOM WIN5158 Installing the Subscriber Station Installation Guide IMPORTANT! This product should be installed in a restricted access location where access can only be gained by authorized personnel who have been informed of the restrictions and any precautions that must be taken. -
Page 13: Unpacking The Subscriber Station
If any item is missing or damaged, contact Siemens for assistance. Section 2.3 Required Tools and Materials The following tools and materials are required to install the RUGGEDCOM WIN5158: Kits Greases • Class I, Division 2 Kit (P/N MKIT0090) – For hazardous •... -
Page 14: Site Preparation And Precautions
Chapter 2 RUGGEDCOM WIN5158 Installing the Subscriber Station Installation Guide Tools Tapes • Wrench or socket set • POE cold shrink (maximum 49.2 mm or 1.9 in inner diameter before shrinking) or self-amalgamating tape • Phillips screwdriver • UV-resistant vinyl tape •... -
Page 15: Installing The Subscriber Station In Hazardous Locations
Installing the Subscriber Station in Hazardous Locations The RUGGEDCOM WIN5158 is designed to comply with the safety standards for Class I, Division 2, Zone 2 hazardous locations where concentrations of flammable gases, vapors or liquids may be present, as opposed to normal operating environments. -
Page 16: Mounting The Subscriber Station
Figure 3: Compliance Label (Example) Section 2.6 Mounting the Subscriber Station The RUGGEDCOM WIN5158 is designed for maximum mounting and display flexibility. It can be secured to a bracket and then mounted to a pole, wall or tower. NOTE For detailed dimensions of the subscriber station, refer to Chapter 4, Dimension... -
Page 17: Mounting The Subscriber Station To A Wall Or Tower
RUGGEDCOM WIN5158 Chapter 2 Installation Guide Installing the Subscriber Station Section 2.6.1 Mounting the Subscriber Station to a Wall or Tower Mount the subscriber station to any wall or tower capable of supporting its weight. An outer wall on a roof or other high location to avoid interference from other buildings or trees is preferred. -
Page 18: Mounting The Subscriber Station To A Pole
Chapter 2 RUGGEDCOM WIN5158 Installing the Subscriber Station Installation Guide 10. Tighten the screws connecting the arm bracket to the subscriber station and mounting bracket. Make sure the screws are torqued to 24 N·m (17.7 ft. lb.). Section 2.6.2 Mounting the Subscriber Station to a Pole The subscriber station can be attached to any pipe or pole with a diameter of 44.5 to 254 mm (1.75 to 10 in). -
Page 19: Installing The Antennas
14 N·m (10 lbf-ft). Section 2.7 Installing the Antennas The RUGGEDCOM WIN5158 supports N-Connect female antennas. To install an antenna, do the following: WARNING! Radiation hazard – risk of Radio Frequency (RF) exposure. This subscriber station is compliant with the requirements set forth in FCC CFR 47, section 1.1307, addressing Radio Frequency (RF) exposure... - Page 20 Chapter 2 RUGGEDCOM WIN5158 Installing the Subscriber Station Installation Guide from radio frequency base stations, as defined in FCC OET Bulletin 65 [http://transition.fcc.gov/Bureaus/ Engineering_Technology/Documents/bulletins/oet65/oet65.pdf]. The emitted radiation should be as little as possible. To achieve minimum RF exposure, install the subscriber station when it is configured not to transmit and set it to operational mode remotely, rather than having a technician enable transmission on-site.
-
Page 21: Grounding The Subscriber Station
Installing the Subscriber Station Figure 7: Antenna and Lightning Protector Assembly 1. Drain Wire 2. RUGGEDCOM WIN5158 3. Shielded Coaxial Cable 4. Lightning Protector 5. Ground Wire 6. Antenna Make sure the PWR LED on the subscriber station is on. Adjust the position of the antenna until the maximum RSSI link quality reading is achieved. A single RSSI LED indicates the subscriber station is at minimum synchronized with the base station. -
Page 22: Connecting Power Directly (Dc Only)
Section 2.9.1 Connecting Power Directly (DC Only) The DC version of the RUGGEDCOM WIN5158 requires a 10 to 30 VDC Class 2 power supply. IMPORTANT! When connecting a DC battery power supply, make sure to use a 36 VDC, 3 A, double-pole circuit breaker as the main disconnecting device. -
Page 23: Connecting The Ruggedcom Win1010 (Ac Only)
Electrical hazard – risk of damage to equipment. The power cord provided with the data adapter is safety certified according to national rules. Do not use a power cord that has not been approved by Siemens for use with the data adapter. To connect power and data to the subscriber station, do the following: CAUTION! Crushing hazard –... -
Page 24: Connecting To A Ruggedcom Rp100 Or Rp110 (Ac Only)
Connecting to a RUGGEDCOM RP100 or RP110 (AC Only) The RUGGEDCOM RP100 and RP110 are optional power injectors for powering and providing data to the RUGGEDCOM WIN5158 (AC Only). The RUGGEDCOM RP100 and RP110 meet a wider temperature and voltage range than the standardRUGGEDCOM WIN1010. -
Page 25: Assembling The Poe Connector
Installation Guide Installing the Subscriber Station Figure 10: Typical Outdoor Installation 1. RUGGEDCOM WIN5158 2. Shielded Cable 3. Ground Connection 4. Lightning Protector 5. RUGGEDCOM RP100/RP110 6. Drain Wire (Shielded) For more information about the RUGGEDCOM RP100 or RP110, refer to the RUGGEDCOM RP100 Installation Guide or the RUGGEDCOM RP110 Installation Guide. - Page 26 Chapter 2 RUGGEDCOM WIN5158 Installing the Subscriber Station Installation Guide 38 mm (1.5 in) Figure 12: Cutting the Jacket 1. Wire Jacket 2. Foil Fold the foil back over the wire jacket. Figure 13: Folding Back the Foil 1. Foil 2. Twisted-Pair Wires 3. Drain Wire Bend the drain wire back over the jacket.
- Page 27 RUGGEDCOM WIN5158 Chapter 2 Installation Guide Installing the Subscriber Station Figure 15: Untwisting the Wire Pairs Arrange the wires according to the following pin-out description: Color Description Number White/Orange ETH Data TP0+ Orange ETH Data TP0- White/Green ETH Data TP1+ Figure 16: CAT-5e PoE Cable Pin-Out...
-
Page 28: Installing The Hazardous Location Kit
An approved Power-over-Ethernet (PoE) injector is required when the subscriber station is installed in a hazardous location. The RUGGEDCOM WIN5158 is certified for installation in Class I, Division 2 Groups A, B, C and D hazardous locations when installed using the Class I, Division 2 kit (P/N MKIT0090). The Class I, Division 2 kit contains the following items: •... -
Page 29: Weatherproofing The Subscriber Station
Most outdoor subscriber station, antenna and cable problems are caused by coaxial cable connections loosened by vibration, allowing moisture to penetrate the connector interface. Siemens strongly recommends weatherproofing all outdoor cable connections to prevent the ingress of water and help secure connections. -
Page 30: Weatherproofing A Cable
Chapter 2 RUGGEDCOM WIN5158 Installing the Subscriber Station Installation Guide IMPORTANT! The method of weatherproofing described in this section must be completed on all external connections. If surge arrestors are used, all associated connections and arrestors must be completely wrapped with splicing tape or self-amalgamating tape. -
Page 31: Applying Self-Amalgamating Tape
RUGGEDCOM WIN5158 Chapter 2 Installation Guide Installing the Subscriber Station Reconnect the cable and slide the tube up to meet the subscriber station chassis. Hold the tube against the subscriber station chassis and start rotating it clockwise while gently pulling out the core. - Page 32 Chapter 2 RUGGEDCOM WIN5158 Installing the Subscriber Station Installation Guide Configuring the Subscriber Station...
-
Page 33: Technical Specifications
• Section 3.5, “Mechanical Specifications” • Section 3.6, “IDU to ODU Cable Specifications” Section 3.1 Power Supply Requirements The RUGGEDCOM WIN5158 requires an external power supply that meets the following requirements: AC Model Power Supply Rated Input Power Rated Output Power RUGGEDCOM WIN1010 100 to 240 VAC, 50 to 60 Hz, 1.5 A... -
Page 34: Power Consumption
Chapter 3 RUGGEDCOM WIN5158 Technical Specifications Installation Guide Section 3.2 Power Consumption Typical Power Consumption 12 W Section 3.3 Radio and Modem Specifications Operating Frequency 5725 to 5850 MHz Wireless Communication IEEE 802.16e-2009 Standard Operating Mode Time-Division Duplexing (TDD) Channel Bandwidths 3.5 MHz... -
Page 35: Mechanical Specifications
RUGGEDCOM WIN5158 Chapter 3 Installation Guide Technical Specifications Section 3.5 Mechanical Specifications Dimensions Refer to Chapter 4, Dimension Drawings Weight 1.5 kg (3.3 lb) Enclosure Aluminum Ingress Protection IP67 Section 3.6 IDU to ODU Cable Specifications IDU to ODU Cable Applications Outdoor installations, fixed or portable installations, digital distribution frames in transmission stations, outdoor installations in harsh environments. - Page 36 Chapter 3 RUGGEDCOM WIN5158 Technical Specifications Installation Guide Inner Jacket Material UV resistant FR-PVC Inner Jacket Diameter 6.1 mm (0.24 in) Total Number of Wires IDU to ODU Cable Standards Flammability Rating IEC 60332, UL1581 VW-1 Standards IEC 61156, TIA/EIA-568...
-
Page 37: Dimension Drawings
RUGGEDCOM WIN5158 Chapter 4 Installation Guide Dimension Drawings Dimension Drawings NOTE All dimensions are in millimeters, unless otherwise stated. 71.2 80.1 92.2 Figure 20: Overall Dimensions (AC Model) - Page 38 Chapter 4 RUGGEDCOM WIN5158 Dimension Drawings Installation Guide 71.2 44.2 92.2 Figure 21: Overall Dimensions (DC Model)
-
Page 39: Certification
RUGGEDCOM WIN5158 Chapter 5 Installation Guide Certification Certification The RUGGEDCOM WIN5158 ODU CPE has been thoroughly tested to guarantee its conformance with recognized standards and has received approval from recognized regulatory agencies. CONTENTS • Section 5.1, “Approvals” • Section 5.2, “Environmental Type Tests”... -
Page 40: Csa
Chapter 5 RUGGEDCOM WIN5158 Certification Installation Guide • UL 1604 Electrical Equipment for Use in Class I and II, Division 2, and Class III Hazardous (Classified) Locations • CAN/CSA-C22.2 No. 213-M1987 Non-Incendive Electrical Equipment for Use in Class I, Division 2 Hazardous Locations The subscriber station is marked with an MET classified mark that indicates compliance with both Canadian and U.S. -
Page 41: European Union (Eu)
Information Technology Equipment – Safety – Part 22: Equipment to be Installed Outdoors The subscriber station is marked with a TÜV Rheinland marking and can be used throughout the European community. A copy of the TÜV Rheinland Declaration of Conformity is available from Siemens Canada Ltd. For contact information, refer to “Contacting Siemens”. -
Page 42: Fcc
Wireless Access Systems – Amendment for Physical and Medium Access Control Layers for Combined Fixed and Mobile Operation in Licensed Bands Section 5.2 Environmental Type Tests The RUGGEDCOM WIN5158 has passed the following environmental tests. Test Description Test Levels IEC 60068-2-1 Low Temperature -25 °C for 72 hours... - Page 43 RUGGEDCOM WIN5158 Chapter 5 Installation Guide Certification Test Description Test Levels IEC 60068-2-14 Temperature Change -10 to 45 °C (14 to 113 °F) @ 0.5 °C/min (0.9 °F/min) for 2 cycles -40 to -30 °C (-40 to -22 °F) @ 1 °C/min (1.8 °F/min) for 5 cycles...
- Page 44 Chapter 5 RUGGEDCOM WIN5158 Certification Installation Guide Environmental Type Tests...
