Electric Range
installation manual
This manual is made with 100% recycled paper.
imagine
the possibilities
ENGLISH
Thank you for purchasing this Samsung product.
To receive more complete service, please register
your product at
www.samsung.com/register
1-800-SAMSUNG(726-7864)
Installation-USA DG68-00108G-01_EN.indd 1
2012-02-16
11:14:21
Advertisement
Table of Contents
Related Manuals for Samsung NE595R0ABBW
Summary of Contents for Samsung NE595R0ABBW
- Page 1 Electric Range installation manual This manual is made with 100% recycled paper. imagine the possibilities ENGLISH Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.com/register 1-800-SAMSUNG(726-7864) Installation-USA DG68-00108G-01_EN.indd 1 2012-02-16 11:14:21...
-
Page 2: Before You Begin
before you begin ANTI-TIP DEVICE WARNING: To reduce the risk of tipping the appliance, the appliance must be secured by properly installed anti-tip devices packed with the appliance. WARNING a) A child or adult can tip the range and be killed. b) Install the anti-tip device to the structure and/or the range at rear right (or rear left) of the range bottom. -
Page 3: Remove Packaging
preparing to install the range REmoVE PACKAGING Remove packaging materials. Failure to remove packaging materials could result in damage to the appliance. PREPARE Tools & PARTs What tools you will need Drill Adjustable Wrench Pliers ˝ Nut Driver Phillips Screwdriver Flat Screwdriver Pencil Level... -
Page 4: Checking The Installation Site
ChECKING ThE INsTAllATIoN sITE Clearances and dimensions To install the range, refer to the following fi gure. For installation in CANADA, a Free-standing range is not to be installed closer than 12mm from any adjacent surface. CAUTION This range has been designed to comply with the maximum allowable wood CAUTION cabinet temperatures of 194°F. -
Page 5: Connecting The Power
connecting the power sTEP 1. mEETING ElECTRICAl CoNNECTIoN REQuIREmENTs CAUTION For personal safety, do not use an extension cord with this appliance. CAUTION Remove house fuse or open circuit breaker before beginning installation. This appliance must be supplied with the proper voltage and frequency, and connected to an individual properly grounded branch circuit, protected by a circuit breaker or fuse having amperage as specifi ed on the rating plate. -
Page 6: Step 2. Accessing The Power Cord Connection
sTEP 2. ACCEssING ThE PoWER CoRD CoNNECTIoN Remove the rear access cover and loosen the screw with a screwdriver. The terminal block will then be accessible. Terminal block Access cover Specifi ed power-supply-cord kit rating Diameter (inches) of range Range rating, watts Specifi ed rating of connection opening power-supply-cord kit,... -
Page 7: Step 3. Installing The Power Cord
sTEP 3. INsTAllING ThE PoWER CoRD For power cord installations, hook the strain relief over the power cord hole (1 ”) located below the rear of the drawer body. Insert the power cord through the strain relief and tighten the device. Conduit connection plate Power cord Strain relief... - Page 8 Installing a 4-wire power cord WARNING The neutral wire of the supply circuit must be connected to the neutral terminal WARNING located in the lower center of the terminal block. The power leads must be connected to the lower left and the lower right terminals of the terminal block.
-
Page 9: Step 4. Installing The Conduit
sTEP 4. INsTAllING ThE CoNDuIT Remove the conduit connection plate from the rear of the drawer body and rotate it as shown below. The conduit hole (1 ”) must be used. ” ” ” ” 1. Prepare the conduit cord shown in Figure 1. 2. -
Page 10: Step 5. Replacing The Access Cover
Installing a 4-wire conduit • Aluminum building wire may be used but it must be rated for the correct amperage and voltage to make the connection. Connect wires according to this Step 4 depending on the number of wires. • Wire used, location and enclosure of splices, etc., must conform to good wiring practices and local codes. -
Page 11: Installing The Range
installing the range INsTAllING ThE ANTI-TIP DEVICE WARNING To reduce the risk of tipping, the appliance must be secured by properly WARNING installing the Anti-Tip device packed with the appliance. • Refer to the installation instructions supplied with the bracket. •... -
Page 12: Finalizing The Installation
3. Check your adjustments Use a spirit level to check your adjustments. Place the level diagonally on the oven rack or surface cooktop, and check each direction for level. 1. Check direction 1. 2. Check direction 2. If the spirit level doesn’t show level on the oven rack or surface cooktop, adjust the leveling legs with a wrench.
